7-41 — UNDER COVER; INSTRUMENT (#986) — 8 parça

19 19 19 19 23 21 5 1

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	PANEL; COMPARTMENT,A/C UNIT DARK GRAY	1-65680-815-1	01	1	9202-	●	●
5	FINISHER; COMPARTMENT PANEL,A/C UNIT L=2040	1-71997-513-1	04	1	9202-	●	●
5	FINISHER; COMPARTMENT PANEL,A/C UNIT L=190	1-71998-300-0	01	1	9202-	●	●
5	FINISHER; COMPARTMENT PANEL,A/C UNIT L=800	1-73948-003-0	01	1	9202-	●	●
5	FINISHER; COMPARTMENT PANEL,A/C UNIT L=140	1-76678-002-0	01	1	9202-9204	●	●
19	SCREW; FASTENER,SIDE CLUSTER BEZEL M5X14 TAPPING	1-72548-072-0	13	1	9202-	●	●
21	BOLT; BLIND PANEL,A/C M6X14 W/LK&PL WASHER	1-09980-549-0	06	1	9202-	●	●
23	BRACKET; COMPARTMENT PANEL,A/C UNIT	1-65680-369-1	01	1	9202-	●	●
