Isuzu WW
▶
TRUCKS
▶
FVR
▶
10854 - FVR-LHD(BUS CHASSIS)
▶
7 - Interior Trim, Emblems / Labels, Seats, Mirrors
▶
7-60 - SEAT BELT
▶
7-60 — SEAT BELT
(#9815) — 9 parça
171
3
2
177
136
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
2
BELT; SEAT,TONGUE SIDE
FRONT SEAT BELT WO/RETRACTOR 2 POINT<W25>
1-75618-780-5
01
1
0105-
2
BELT; SEAT,TONGUE SIDE
FRONT SEAT BELT 3 POINT<SHY>
1-75617-514-6
01
1
0011-0806
2
BELT; SEAT,TONGUE SIDE
FRONT SEAT BELT 3 POINT<SHY>
8-98120-801-0
01
1
0807-
3
BELT; SEAT,BUCKLE SIDE
1-75618-779-0
01
1
0011-
136
BOLT; SEAT BELT
FRONT SEAT BELT WO/RETRACTOR 2 POINT<W25> M10X30 FLANGE
0-28791-030-0
02
1
0105-0512
136
BOLT; SEAT BELT
FRONT SEAT BELT WO/RETRACTOR 2 POINT<W25> M10X30 FLANGE
0-28761-030-0
02
1
0601-
171
CLIP; SEAT BELT GUIDE
1-09987-239-0
02
1
0011-0108
177
NUT
FRONT SEAT BELT WO/RETRACTOR 2 POINT<W25> M10 FLANGE
0-91150-210-0
02
1
0105-0602
177
NUT
FRONT SEAT BELT WO/RETRACTOR 2 POINT<W25> M10 FLANGE
0-91180-210-0
02
1
0603-
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
