0-42 — FUEL PUMP AND PIPE
(#9730) — 25 parça
112
209
207
108
115
110
119
123
115
110
107
207
119
107
123
111
216
111
216
111
217
147
145
253
222
148
123
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
107
PIPE; FUEL,FEED PUMP TO FUEL FILTER
8-94395-042-1
01
1
0011-
108
BOLT; JOINT,FUEL FILTER
M14X27 FLANGE
1-09675-086-0
01
1
0201-
110
GASKET; JOINT BOLT,FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=14.2 OD=19.2
1-09630-085-0
02
1
0201-1312
110
GASKET; JOINT BOLT,FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=14.2 OD=19.2
8-98251-345-0
02
1
1401-
111
CLIP; FUEL PIPE
L=48
5-09709-103-0
03
1
0011-
112
BOLT; JOINT,FUEL FILTER
M14X27 FLANGE
1-09675-086-0
01
1
0011-
115
GASKET; JOINT BOLT,FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=14.2 OD=19.2
1-09630-085-0
02
1
0011-1312
115
GASKET; JOINT BOLT,FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=14.2 OD=19.2
8-98251-345-0
02
1
1401-
119
PIPE; FUEL,FUEL FILTER TO INJ PUMP
8-94395-041-0
01
1
0011-
123
PIPE; FUEL,FUEL FILTER LEAK OFF
8-94390-831-2
01
1
0011-
145
CLIP; FUEL PIPE
L=48
5-09709-103-0
01
1
0011-
147
BOLT; CLIP,FUEL PIPE
M6X30 W/LK WASHER
0-50040-630-0
01
1
0011-0512
147
BOLT; CLIP,FUEL PIPE
M6X30 W/LK WASHER
0-50540-630-0
01
1
0601-
148
BOLT; BRKT
M8X16 FLANGE
0-28080-816-0
02
1
0011-0512
148
BOLT; BRKT
M8X16 FLANGE
0-28050-816-0
02
1
0601-
207
GASKET; EYE BOLT
ID=14.2 OD=19.2
1-09630-085-0
02
1
0011-0112
209
BOLT; EYE,FUEL FILTER
1-15619-310-0
01
1
0011-0112
216
BOLT; CLIP,FUEL PIPE
M6X22 FLANGE
0-28080-622-0
01
1
0011-0108
216
BOLT; CLIP,FUEL PIPE
M6X30 W/LK WASHER
0-50040-630-0
02
1
0011-0512
216
BOLT; CLIP,FUEL PIPE
M6X30 W/LK WASHER
0-50540-630-0
02
1
0601-
217
GASKET; OVERFLOW VLV
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=14.2 OD=19.2
1-09630-085-0
01
1
0011-1312
217
GASKET; OVERFLOW VLV
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=14.2 OD=19.2
8-98251-345-0
01
1
1401-
222
BRACKET; CLIP
8-94395-079-2
01
1
0011-
253
COVER; RUBBER
ID=6 OD=10 L=70
1-09376-512-0
01
1
0011-
253
COVER; RUBBER
ID=10 OD=14 L=30
9-09956-682-0
02
1
0011-
