Isuzu WW
▶
TRUCKS
▶
QKR
▶
51423 - QKR RHD
▶
4 - Propeller Shaft, Axles, Steering, Suspension
▶
4-11 - FRONT HUB AND DRUM OR ROTOR
▶
4-11 — FRONT HUB AND DRUM OR ROTOR
(#96085) — 23 parça
Tümü
A - NKR5SE
B - NKR5SN
29
17
19
28
18
15
13
2
12
1
10
23
7
23
29
28
19
17
15
13
12
2
1
10
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
06.330 CAP; HUB,FRT AXLE
8-97360-101-0
02
1
1206-1407
●
●
1
06.330 CAP; HUB,FRT AXLE
8-98276-604-0
02
1
1408-
●
●
2
05.812 PIN; SPLIT,HUB TO AXLE SHAFT
OD=4.6 L=40
0-81125-040-0
02
1
1206-
●
●
7
05.812 NUT; FRT HUB
M20
0-91110-520-0
10
1
1206-
●
10
05.812 NUT; FRT HUB BRG
06.022
8-94247-357-1
02
1
1206-
●
●
12
06.321 WASHER; LK,FRT HUB BRG
8-94247-356-1
02
1
1206-1502
●
●
12
06.321 WASHER; LK,FRT HUB BRG
05.812
8-98282-435-0
02
1
1503-
●
●
13
06.313 BEARING; HUB OUTER,FRT AXLE
NSK
9-00093-172-0
02
1
1206-
●
●
13
06.313 BEARING; HUB OUTER,FRT AXLE
BEST VALUE PARTS
5-87610-134-0
02
1
1206-
●
●
15
05.812 PIN; WHEEL,FRT AXLE
(A) M14X50 RH THREAD
9-42331-605-5
06
1
1206-
●
15
05.812 PIN; WHEEL,FRT AXLE
(A) M14X50 LH THREAD
9-42332-605-5
06
1
1206-
●
15
05.812 PIN; WHEEL,FRT AXLE
(B) M18X29,M20X43.5 RH THREAD
8-94383-436-2
05
1
1206-
●
15
05.812 PIN; WHEEL,FRT AXLE
(B) M18X29 LH THREAD,M20X43.5 RH THREAD
8-94383-437-2
05
1
1206-
●
17
06.307 HUB; FRT AXLE
(A)
8-94420-597-1
02
1
1206-
●
17
06.307 HUB; FRT AXLE
(B)
8-94365-459-0
02
1
1206-
●
18
06.022 BOLT; DRUM TO HUB
04.012 M6X18
0-20800-618-0
02
1
1206-
●
19
06.311 BEARING; HUB INNER,FRT AXLE
JTEKT
8-98171-254-0
02
1
1206-
●
●
19
06.311 BEARING; HUB INNER,FRT AXLE
BEST VALUE PARTS
1-87610-134-0
02
1
1206-
●
●
23
05.809 DRUM; BRK,FRT
(A)
8-97085-071-2
02
1
1206-1306
●
23
05.809 DRUM; BRK,FRT
(A)
8-98242-348-0
02
1
1307-
●
23
05.809 DRUM; BRK,FRT
(B)
8-97094-434-2
02
1
1206-
●
28
06.326 SEAL; OIL,FRT HUB
8-94248-117-1
02
1
1206-
●
●
29
06.326 DISTANCE PIECE; HUB BRKT
NTN
8-97234-513-0
02
1
1206-
●
●
