◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ FSR ▶ 10624 - FSR-RHD ▶ 7 - Interior Trim, Emblems / Labels, Seats, Mirrors ▶ 7-10 - CAUTION PLATE AND LABEL ▶
7-10 — CAUTION PLATE AND LABEL (#96) — 28 parça
çizim 27618
119 4 4 4 4
BalonParca AdiParca NoAdetTipApplied Date A B
4 LABEL; ENG MAINTENANCE
HONG KONG EQUIPMENT(PQ1) (A) 		8-94390-020-0 01 1 9501- ●
4 LABEL; ENG MAINTENANCE
THAILAND EQUIPMENT(PM9) (B) ENG MAINTENANCE CAUTION 		1-85886-718-1 01 1 9211- ●
4 LABEL; ENG MAINTENANCE
THAILAND EQUIPMENT(PM9) (C) FILTER MAINTENANCE CAUTION 		1-85886-719-1 01 1 9211-9405 ●
4 LABEL; ENG MAINTENANCE
EXC. THAILAND EQUIPMENT(PM9) (D) 		8-94393-471-0 01 1 9202-9412 ● ●
4 LABEL; ENG MAINTENANCE
EXC. THAILAND EQUIPMENT(PM9),HONG KONG EQUIPMENT(PQ1) (D) 		8-94393-471-0 01 1 9501- ● ●
119 PLATE; CAUTION,HAND BRK LEVER
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A) 		1-85881-373-0 01 1 9202- ● ●
çizim 27767
2 6 63
BalonParca AdiParca NoAdetTipApplied Date A B
2 LABEL; FUEL CAUTION
FUEL TANK 160L<NG6>,FUEL TANK 200L FMCSR<PK6> 		8-94414-353-0 01 1 9202- ● ●
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE TIRE CARRIER LIFTING TYPE VAR1<SY8> CAUTIONS ARABIAN<WJ7> 		1-85883-114-0 01 1 9202- ● ●
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE TIRE CARRIER LIFTING TYPE VAR1<SY8> EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> 		1-53639-004-0 01 1 9202- ● ●
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE TIRE CARRIER LIFTING TYPE VAR1<SY8> CAUTIONS FRENCH<WJ8> 		1-85883-108-0 01 1 9202- ● ●
63 PLATE; CAUTION,SEAT AIR
CAUTIONS ARABIAN<WJ7> SUSP SEAT W/SEAT BELT ANCHORAGE<WN5> 		1-75537-202-0 01 1 9202- ● ●
63 PLATE; CAUTION,SEAT AIR
CAUTIONS FRENCH<WJ8> SUSP SEAT W/SEAT BELT ANCHORAGE<WN5> 		1-75537-201-0 01 1 9202- ● ●
63 PLATE; CAUTION,SEAT AIR
SUSP SEAT W/SEAT BELT ANCHORAGE<WN5> EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> 		1-75537-199-0 01 1 9202- ● ●
çizim 27771
60 69
BalonParca AdiParca NoAdetTipApplied Date A B
60 PLATE; CAUTION,CAB TILT 1-85883-126-0 01 1 9202- ●
69 PLATE; CAUTION,STARTER SW
CAUTIONS ARABIAN<WJ7> 		1-85887-537-0 01 1 9202- ● ●
69 PLATE; CAUTION,STARTER SW
EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> 		1-85887-389-0 01 1 9202- ● ●
69 PLATE; CAUTION,STARTER SW
CAUTIONS FRENCH<WJ8> 		1-85887-535-0 01 1 9202- ● ●
çizim 92696
51 51 49
BalonParca AdiParca NoAdetTipApplied Date A B
49 PLATE; CAUTION,FUSE BOX
AUTO DOOR LOCK<AU4> POWER WINDOW<A30> 		1-85888-297-0 01 1 9302-9307 ●
49 PLATE; CAUTION,FUSE BOX
AUTO DOOR LOCK<AU4> POWER WINDOW<A30> EXC. HEAD LAMP RECTANGULAR W/FOG LAMP<TAN> 		1-85888-297-0 01 1 9308- ●
49 PLATE; CAUTION,FUSE BOX
AUTO DOOR LOCK<AU4> POWER WINDOW<A30> HEAD LAMP RECTANGULAR W/FOG LAMP<TAN> 		1-85888-310-0 01 1 9308- ●
49 PLATE; CAUTION,FUSE BOX 1-85887-685-1 01 1 9202-9301 ● ●
49 PLATE; CAUTION,FUSE BOX
EXC. AUTO DOOR LOCK<AU4>,POWER WINDOW<A30>,HEAD LAMP RECTANGULAR W/FOG LAMP<TAN> 		1-85887-685-2 01 1 9302- ●
49 PLATE; CAUTION,FUSE BOX 1-85887-685-2 01 1 9302- ●
51 PLATE; CAUTION,WARNING
CAUTIONS ARABIAN<WJ7> (A) 		1-85880-581-0 01 1 9202- ● ●
51 PLATE; CAUTION,WARNING
CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> (B) 		1-85888-229-1 01 1 9202- ● ●
51 PLATE; CAUTION,WARNING
EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> (A) 		1-85880-576-1 01 1 9202- ● ●
51 PLATE; CAUTION,WARNING
EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8> (B) 		1-85888-217-1 01 1 9202- ● ●
51 PLATE; CAUTION,WARNING
CAUTIONS FRENCH<WJ8> (A) 		1-85880-580-0 01 1 9202- ● ●
İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
