50919 - TBR (GM-INDONESIA)
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-01 - FRONT BUMPER
▶
6-01 — FRONT BUMPER
(#95499) — 29 parça
84
104
42
2
197
645
646
638
3
42
638
639
633
639
639
184
30
32
127
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
2
BUMPER; FRT,CENTER
IDN
8-97957-993-1
01
1
0201-
3
BUMPER; FRT,SIDE
IDN
8-97957-996-3
01
1
0201-
3
BUMPER; FRT,SIDE
IDN
8-97957-995-3
01
1
0201-
30
BRACKET; FRT BUMPER
IDN
8-97956-553-1
01
1
0201-
30
BRACKET; FRT BUMPER
IDN
8-97956-552-1
01
1
0201-
32
BOLT; BRKT,BUMPER
M12X30 FLANGE
0-28691-230-0
04
1
0201-0512
32
BOLT; BRKT,BUMPER
M12X30 FLANGE
0-28661-230-0
04
1
0601-
42
BOLT; BUMPER
(A) M8X20 FLANGE
0-28680-820-0
04
1
0201-0512
42
BOLT; BUMPER
(A) M8X20 FLANGE IDN
0-28650-820-0
04
1
0601-
42
BOLT; BUMPER
(B) M8X20 DACRO-COATING THA
8-94241-821-0
08
1
0201-
84
HOOK
IDN
8-97958-976-0
01
1
0201-
104
COVER; HOLE,FOG LAMP
IDN
8-97956-714-1
01
1
0201-
104
COVER; HOLE,FOG LAMP
IDN
8-97956-713-1
01
1
0201-
127
NUT; FRT BUMPER
M8 FLANGE
5-09440-005-0
08
1
0201-0805
127
NUT; FRT BUMPER
M8 FLANGE
8-97581-233-0
08
1
0806-
184
TAPE; FRONT BUMPER
IDN
8-97959-275-0
01
1
0201-
184
TAPE; FRONT BUMPER
IDN
8-97959-274-0
01
1
0201-
197
GRILLE; BUMPER
IDN
8-97957-167-0
01
1
0201-
633
CLIP; BUMPER
8-97806-845-2
02
1
0201-
638
BOLT; CTR TO SIDE,FRT BUMPER
M6X20 FLANGE
0-28680-620-0
04
1
0201-0512
638
BOLT; CTR TO SIDE,FRT BUMPER
M6X20 FLANGE IDN
0-28650-620-0
04
1
0601-
638
BOLT; CTR TO SIDE,FRT BUMPER
M6X12
8-97807-917-0
02
1
0201-0208
638
BOLT; CTR TO SIDE,FRT BUMPER
M6X12 FLANGE
8-97351-109-0
02
1
0209-
639
NUT; CTR TO SIDE,FRT BUMPER
(B) M6 FLANGE
0-91150-106-0
04
1
0201-0602
639
NUT; CTR TO SIDE,FRT BUMPER
(B) M6 FLANGE
0-91180-106-0
04
1
0603-
639
NUT; CTR TO SIDE,FRT BUMPER
(A) IDN
8-94471-330-2
04
1
0201-
645
BOLT; BUMPER GRILLE
M6X12
8-97807-917-0
05
1
0201-0208
645
BOLT; BUMPER GRILLE
M6X12 FLANGE
8-97351-109-0
05
1
0209-
646
FASTENER; BUMPER GRILLE
D=5.8 SCREW & GROMMET NYLON IDN
8-94242-150-0
06
1
0201-
