13 |
WASHER; LK,LWR LINK
ID=10.2
|
9-09150-610-0 |
02 |
1 |
0201-0603 |
| |
13 |
WASHER; LK,LWR LINK
ID=10.2
IDN
|
0-91510-610-0 |
02 |
1 |
0604- |
| |
14 |
NUT; S/ABS,UPR
M10
|
9-09110-410-0 |
02 |
1 |
0201- |
| |
17 |
BUSHING; RUBBER,S/ABS
IDN
|
8-97957-655-0 |
04 |
1 |
0201- |
| |
18 |
WASHER; CENTERING,S/ABS
IDN
|
8-97957-656-0 |
02 |
1 |
0201- |
| |
48 |
JOINT ASM; BALL,LWR CONT ARM
|
8-94459-464-3 |
02 |
1 |
0201- |
| |
53 |
NUT; LWR LINK
M10 FLANGE
|
8-94242-425-0 |
02 |
1 |
0201- |
| |
58 |
BUSHING; LWR LINK
ID=16
|
8-94316-903-0 |
02 |
1 |
0201- |
| |
60 |
BOLT; S/ABS TO LWR LINK
M12X50
|
9-91061-250-0 |
02 |
1 |
0201- |
| |
62 |
ABSORBER ASM; SHOCK,FRT
IDN
|
8-97959-201-0 |
02 |
1 |
0201- |
| |
65 |
WASHER; S/ABS
IDN
|
8-97957-654-0 |
04 |
1 |
0201- |
| |
80 |
NUT; LWR LINK END TO KNUCKLE
M18 SLOTTED
|
9-99116-418-0 |
02 |
1 |
0201-0605 |
| |
80 |
NUT; LWR LINK END TO KNUCKLE
M18 SLOTTED
|
0-91116-518-0 |
02 |
1 |
0606- |
| |
81 |
PIN; SPLIT,LWR LINK TO KNUCKLE
OD=3.7 L=30
|
9-08114-030-0 |
02 |
1 |
0201-0606 |
| |
81 |
PIN; SPLIT,LWR LINK TO KNUCKLE
OD=3.7 L=30
|
0-81124-030-0 |
02 |
1 |
0607- |
| |
84 |
ARM; LWR CONT
|
8-94459-461-2 |
01 |
1 |
0201- |
| |
84 |
ARM; LWR CONT
|
8-94459-460-2 |
01 |
1 |
0201- |
| |
96 |
BOLT; LWR LINK
(A)
M10X50
|
9-01066-050-0 |
02 |
1 |
0201-0512 |
| |
96 |
BOLT; LWR LINK
(A)
M10X50
|
0-10956-050-0 |
02 |
1 |
0601- |
| |
96 |
BOLT; LWR LINK
(B)
M10X20
|
9-02061-020-0 |
02 |
1 |
0201-0512 |
| |
96 |
BOLT; LWR LINK
(B)
M10X20
|
0-20951-020-0 |
02 |
1 |
0601- |
| |
103 |
NUT; S/ABS TO LWR LINK
M12 FLANGE
|
0-91150-212-0 |
02 |
1 |
0201-0602 |
| |
103 |
NUT; S/ABS TO LWR LINK
M12 FLANGE
|
0-91180-212-0 |
02 |
1 |
0603- |
| |
104 |
RUBBER; BUMPER,STRUT
IDN
|
8-94433-673-0 |
02 |
1 |
0201- |
| |
105 |
BOLT; STRUT BAR TO LWR LINK
(A)
M10X35
|
8-94237-412-0 |
02 |
1 |
0201- |
| |
105 |
BOLT; STRUT BAR TO LWR LINK
(B)
M10X65
|
9-01066-065-0 |
02 |
1 |
0201- |
| |
109 |
TUBE; DIST,STRUT BAR
|
8-94439-157-0 |
02 |
1 |
0201-0712 |
| |
109 |
TUBE; DIST,STRUT BAR
IDN
|
8-98098-018-0 |
02 |
1 |
0801- |
| |
112 |
BAR; STRUT
|
8-94473-192-4 |
01 |
1 |
0201-0712 |
| |
112 |
BAR; STRUT
IDN
|
8-98098-033-0 |
01 |
1 |
0801- |
| |
112 |
BAR; STRUT
|
8-94473-191-4 |
01 |
1 |
0201-0712 |
| |
112 |
BAR; STRUT
IDN
|
8-98098-032-0 |
01 |
1 |
0801- |
| |
127 |
WASHER; LK,STRUT BAR TO LWR LINK
ID=10.2
|
9-09150-610-0 |
02 |
1 |
0201-0603 |
| |
127 |
WASHER; LK,STRUT BAR TO LWR LINK
ID=10.2
IDN
|
0-91510-610-0 |
02 |
1 |
0604- |
| |
128 |
WASHER; PL,STRUT
ID=10.5 OD=26
|
9-09164-710-0 |
02 |
1 |
0201-0605 |
| |
128 |
WASHER; PL,STRUT
ID=10.5 OD=26
|
0-91614-710-0 |
02 |
1 |
0606- |
| |
129 |
WASHER; LK,STRUT BAR
ID=16.2
|
9-09150-616-0 |
02 |
1 |
0201-0603 |
| |
129 |
WASHER; LK,STRUT BAR
ID=16.2
|
0-91510-616-0 |
02 |
1 |
0604- |
| |
130 |
NUT; STRUT BAR TO LWR LINK
M10 FLANGE
|
8-94242-425-0 |
02 |
1 |
0201- |
| |
131 |
RUBBER; CUSHION,STRUT BAR
|
8-94433-672-0 |
04 |
1 |
0201- |
| |
133 |
NUT; STRUT BAR
M16
IDN
|
9-99110-516-0 |
04 |
1 |
0201-0512 |
| |
133 |
NUT; STRUT BAR
M16
|
0-91110-516-0 |
04 |
1 |
0601- |
| |
134 |
WASHER; STRUT BAR
|
8-94439-158-1 |
04 |
1 |
0201-0712 |
| |
134 |
WASHER; STRUT BAR
IDN
|
8-98098-034-0 |
04 |
1 |
0801- |
| |
137 |
BRACKET; STAB BAR TO FRAME
|
8-94143-209-0 |
02 |
1 |
0201- |
| |
152 |
NUT; LWR LINK TO FRT C/MBR
M14
IDN
|
9-99110-514-0 |
02 |
1 |
0201-0512 |
| |
152 |
NUT; LWR LINK TO FRT C/MBR
M14
|
0-91110-514-0 |
02 |
1 |
0601- |
| |
155 |
WASHER; LK,UPR LINK TO FRT C/MBR
ID=14.2
|
9-09150-514-0 |
02 |
1 |
0201-0603 |
| |
155 |
WASHER; LK,UPR LINK TO FRT C/MBR
ID=14.2
|
0-91510-514-0 |
02 |
1 |
0604- |
| |
167 |
BOLT; LWR LINK TO FRT C/MBR
M14X90
|
0-10806-490-0 |
02 |
1 |
0201-0512 |
| |
167 |
BOLT; LWR LINK TO FRT C/MBR
M14X90
|
0-10856-490-0 |
02 |
1 |
0601- |
