1 |
PAN ASM; OIL
|
8-97131-905-0 |
01 |
1 |
0008- |
| |
2 |
GAUGE; OIL LEVEL
|
8-97085-167-0 |
01 |
1 |
0008- |
| |
3 |
GASKET; DRAIN PLUG
ID=14.2 OD=24
|
8-94158-328-0 |
01 |
1 |
0008- |
| |
4 |
PLUG; DRAIN,OIL
M14X14
IDN
|
8-94152-613-0 |
01 |
1 |
0008- |
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
|
8-97109-027-0 |
01 |
1 |
0008- |
| |
9 |
GASKET; GUIDE TUBE,OIL LEVEL GAUGE
ID=11
|
5-09623-002-0 |
02 |
1 |
0008- |
| |
10 |
BOLT; GUIDE TUBE
M8X16 FLANGE
|
0-28080-816-0 |
02 |
1 |
0008-0512 |
| |
10 |
BOLT; GUIDE TUBE
M8X16 FLANGE
|
0-28050-816-0 |
02 |
1 |
0601- |
| |
23 |
BOLT; OIL PAN
M6X13 W/PL WASHER
|
8-97135-141-0 |
17 |
1 |
0008- |
| |
27 |
CRANKCASE
TURBOCHARGER<K51>
|
8-97191-841-0 |
01 |
1 |
0008-0210 |
| |
27 |
CRANKCASE
TURBOCHARGER<K51>
|
8-97358-796-0 |
01 |
1 |
0211- |
| |
27 |
CRANKCASE
EXC. TURBOCHARGER<K51>
|
8-97191-839-0 |
01 |
1 |
0008-0210 |
| |
27 |
CRANKCASE
EXC. TURBOCHARGER<K51>
|
8-97358-794-0 |
01 |
1 |
0211- |
| |
28 |
BOLT; CRANKCASE TO C/BL
M8X120 FLANGE
|
0-28085-812-0 |
01 |
1 |
0008-0512 |
| |
28 |
BOLT; CRANKCASE TO C/BL
M8X120 FLANGE
|
0-28055-812-0 |
01 |
1 |
0601- |
| |
28 |
BOLT; CRANKCASE TO C/BL
M8X32 W/LK WASHER
|
0-50040-832-0 |
19 |
1 |
0008-0909 |
| |
28 |
BOLT; CRANKCASE TO C/BL
M8X32 W/LK WASHER
|
0-50540-832-0 |
19 |
1 |
0910- |
| |
29 |
NUT; CRANKCASE
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
0008-0602 |
| |
29 |
NUT; CRANKCASE
M8 FLANGE
|
0-91180-108-0 |
02 |
1 |
0603- |
| |
30 |
STUD; CRANKCASE
M8X35 L=47
|
9-04110-835-0 |
02 |
1 |
0008-0604 |
| |
30 |
STUD; CRANKCASE
M8X35 L=47
|
0-41010-835-0 |
02 |
1 |
0605- |
| |
40 |
NIPPLE; OIL RETURN HOSE VAC PUMP
|
5-11369-038-0 |
01 |
1 |
0008- |
| |
41 |
RUBBER; SPACE
(A)
|
8-97123-362-0 |
01 |
1 |
0008- |
| |
41 |
RUBBER; SPACE
(B)
|
8-97123-363-0 |
01 |
1 |
0008- |
| |
42 |
GASKET; CRANKCASE TO C/BL
FRONT
|
8-97120-933-0 |
01 |
1 |
0008- |
| |
42 |
GASKET; CRANKCASE TO C/BL
REAR
|
8-97123-342-0 |
01 |
1 |
0008- |
| |
71 |
STUD; OIL DRAIN PIPE
TURBOCHARGER<K51>
M8X18 L=30
|
9-04110-818-0 |
02 |
1 |
0008-0604 |
| |
71 |
STUD; OIL DRAIN PIPE
TURBOCHARGER<K51>
M8X18 L=30
|
0-41010-818-0 |
02 |
1 |
0605- |
| |
113 |
PIN; STRAIGHT
|
9-09878-597-0 |
02 |
1 |
0008- |
| |
276 |
COVER; CRANKCASE
|
8-97229-929-6 |
01 |
1 |
0008- |
| |
280 |
BOLT; COVER
M8X22 W/LK&PL WASHER
IDN
|
8-94329-953-1 |
05 |
1 |
0008- |
| |
329 |
GUIDE; COVER,CRANKCASE
OD=13 T=9.5
IDN
|
8-94140-427-1 |
05 |
1 |
0008-1101 |
| |
329 |
GUIDE; COVER,CRANKCASE
OD=13 T=9.5
|
8-98164-239-0 |
05 |
1 |
1102- |
| |
330 |
RUBBER; MTG,CRANKCASE COVER
OD=22
IDN
|
8-94140-428-1 |
05 |
1 |
0008-0201 |
| |
330 |
RUBBER; MTG,CRANKCASE COVER
OD=21.8
|
8-97325-051-0 |
05 |
1 |
0202- |
