1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
TRANSMISSION SIDE PTO WO/LEVER(SH5)
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
|
1-33043-879-0 |
01 |
1 |
0612- |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
15" CLUTCH(RE9)
ASSISTOR SHIFT CONTROL<WX8>
|
1-33043-876-0 |
01 |
1 |
0406-0611 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
15" CLUTCH(RE9)
ASSISTOR SHIFT CONTROL<WX8>
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5)
|
1-33043-876-0 |
01 |
1 |
0612- |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
|
1-33043-879-0 |
01 |
1 |
0406-0611 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5)
|
1-33043-879-0 |
01 |
1 |
0612- |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
15" CLUTCH(RE9)
ASSISTOR SHIFT CONTROL<WX8>
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
|
1-33043-875-0 |
01 |
1 |
0406-0611 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
15" CLUTCH(RE9)
ASSISTOR SHIFT CONTROL<WX8>
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A),
TRANSMISSION SIDE PTO WO/LEVER(SH5)
|
1-33043-875-0 |
01 |
1 |
0612- |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
|
1-33043-878-0 |
01 |
1 |
0406-0611 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A),
TRANSMISSION SIDE PTO WO/LEVER(SH5)
|
1-33043-878-0 |
01 |
1 |
0612- |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
15" CLUTCH(RE9)
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
|
1-33043-748-0 |
01 |
1 |
0303-0405 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
15" CLUTCH(RE9)
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A),
ASSISTOR SHIFT CONTROL<WX8>
|
1-33043-748-0 |
01 |
1 |
0406-0611 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
15" CLUTCH(RE9)
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5),ASSISTOR
SHIFT CONTROL<WX8>
|
1-33043-748-0 |
01 |
1 |
0612- |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
|
1-33041-568-0 |
01 |
1 |
0005-0210 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
15" CLUTCH(RE9)
|
1-33043-617-0 |
01 |
1 |
0211-0405 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
15" CLUTCH(RE9)
EXC. ASSISTOR SHIFT CONTROL<WX8>
|
1-33043-617-0 |
01 |
1 |
0406-0611 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
15" CLUTCH(RE9)
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5),ASSISTOR
SHIFT CONTROL<WX8>
|
1-33043-617-0 |
01 |
1 |
0612- |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
PARKING BRAKE DRUM 8.5"(B1S)
|
1-33041-538-0 |
01 |
1 |
0005-0210 |
|
● |
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
14" CLUTCH(WF6)
|
1-33043-611-0 |
01 |
1 |
0211-0405 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
14" CLUTCH(WF6)
EXC. ASSISTOR SHIFT CONTROL<WX8>
|
1-33043-611-0 |
01 |
1 |
0406-0611 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
14" CLUTCH(WF6)
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5),ASSISTOR
SHIFT CONTROL<WX8>
|
1-33043-611-0 |
01 |
1 |
0612- |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
FRR STD CAB(FRR*M*)
EXC. PARKING BRAKE DRUM 8.5"(B1S)
|
1-33041-540-0 |
01 |
1 |
0005-0210 |
|
● |
| |
1 |
TRANSMISSION ASM; MANUAL
FRR DOUBLE CAB(FR**W*)
|
1-33041-540-0 |
01 |
1 |
0005-0210 |
|
● |
| |
1 |
TRANSMISSION ASM; MANUAL
14" CLUTCH(WF6)
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
|
1-33043-610-0 |
01 |
1 |
0211-0405 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
14" CLUTCH(WF6)
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A),
ASSISTOR SHIFT CONTROL<WX8>
|
1-33043-610-0 |
01 |
1 |
0406-0611 |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
14" CLUTCH(WF6)
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A),
TRANSMISSION SIDE PTO WO/LEVER(SH5),ASSISTOR SHIFT
CONTROL<WX8>
|
1-33043-610-0 |
01 |
1 |
0612- |
● |
|
| |
1 |
TRANSMISSION ASM; MANUAL
FSR(FS****)
|
1-33041-546-0 |
01 |
1 |
0005-0210 |
|
● |
| |
24 |
COVER; CHECK HOLE,DUST
|
1-31131-041-0 |
01 |
1 |
0005-0210 |
● |
● |
| |
24 |
COVER; CHECK HOLE,DUST
|
1-31131-041-0 |
01 |
1 |
0211-0306 |
● |
|
| |
24 |
COVER; CHECK HOLE,DUST
|
1-31131-041-0 |
01 |
1 |
0307- |
● |
|
| |
27 |
BOLT; COVER TO CLU HSG
M8X12 FLANGE
|
0-28080-812-0 |
02 |
1 |
0005-0104 |
● |
● |
| |
27 |
BOLT; COVER TO CLU HSG
M8X16 FLANGE
|
0-28080-816-0 |
02 |
1 |
0105-0210 |
● |
● |
| |
27 |
BOLT; COVER TO CLU HSG
M8X16 FLANGE
|
0-28080-816-0 |
02 |
1 |
0211-0306 |
● |
|
| |
27 |
BOLT; COVER TO CLU HSG
M8X16 FLANGE
|
0-28080-816-0 |
02 |
1 |
0307-0512 |
● |
|
| |
27 |
BOLT; COVER TO CLU HSG
M8X16 FLANGE
|
0-28050-816-0 |
02 |
1 |
0601- |
● |
|
| |
28 |
COVER; FRT,TRANS CASE
|
1-33121-105-0 |
01 |
1 |
0005-0210 |
● |
|
| |
28 |
COVER; FRT,TRANS CASE
14" CLUTCH(WF6)
|
1-33121-105-0 |
01 |
1 |
0211- |
● |
|
| |
28 |
COVER; FRT,TRANS CASE
|
1-33121-134-1 |
01 |
1 |
0005-0210 |
|
● |
| |
28 |
COVER; FRT,TRANS CASE
15" CLUTCH(RE9)
|
1-33121-108-1 |
01 |
1 |
0211- |
● |
|
| |
29 |
BOLT; FRT COVER
M10X28 FLANGE REAMER
|
1-09040-089-1 |
04 |
1 |
0005-0210 |
● |
● |
| |
29 |
BOLT; FRT COVER
M10X28 FLANGE REAMER
|
1-09040-089-1 |
04 |
1 |
0211-0805 |
● |
|
| |
29 |
BOLT; FRT COVER
M10X28 FLANGE REAMER
|
8-97365-375-0 |
04 |
1 |
0806- |
● |
|
| |
32 |
GASKET; BOLT,FRT COVER
ALSO INCLUDED IN GASKET SET(M/T).
ID=10
|
1-09623-369-0 |
04 |
1 |
0005-0210 |
● |
● |
| |
32 |
GASKET; BOLT,FRT COVER
ALSO INCLUDED IN GASKET SET(M/T).
ID=10
|
1-09623-369-0 |
04 |
1 |
0211- |
● |
|
| |
33 |
SEAL; OIL,FRT COVER,T/M
ALSO INCLUDED IN GASKET SET(M/T).
|
1-09625-498-0 |
01 |
1 |
0005-0210 |
● |
|
| |
33 |
SEAL; OIL,FRT COVER,T/M
ALSO INCLUDED IN GASKET SET(M/T).
14" CLUTCH(WF6)
|
1-09625-498-0 |
01 |
1 |
0211- |
● |
|
| |
33 |
SEAL; OIL,FRT COVER,T/M
ALSO INCLUDED IN GASKET SET(M/T).
|
1-09625-565-1 |
01 |
1 |
0005-0210 |
|
● |
| |
33 |
SEAL; OIL,FRT COVER,T/M
ALSO INCLUDED IN GASKET SET(M/T).
15" CLUTCH(RE9)
|
1-09625-497-0 |
01 |
1 |
0211- |
● |
|
| |
35 |
GROMMET; CLU HSG
(B)
OD=15 T=6.6
|
8-97037-246-0 |
01 |
1 |
0005- |
● |
|
| |
35 |
GROMMET; CLU HSG
(A)
|
9-09575-796-0 |
01 |
1 |
0005-0210 |
● |
● |
| |
35 |
GROMMET; CLU HSG
(A)
|
9-09575-796-0 |
01 |
1 |
0211- |
● |
|
| |
36 |
BEARING; NEEDLE,CLU HSG
NTN
|
1-09811-002-1 |
02 |
1 |
0005-0210 |
● |
● |
| |
36 |
BEARING; NEEDLE,CLU HSG
NTN
|
1-09811-002-1 |
02 |
1 |
0211-0306 |
● |
|
| |
36 |
BEARING; NEEDLE,CLU HSG
NTN
|
1-09811-002-1 |
02 |
1 |
0307- |
● |
|
| |
37 |
SEAL; DUST,CLU HSG
ALSO INCLUDED IN GASKET SET(M/T).
|
1-09625-002-0 |
02 |
1 |
0005-0210 |
● |
● |
| |
37 |
SEAL; DUST,CLU HSG
ALSO INCLUDED IN GASKET SET(M/T).
|
1-09625-002-0 |
02 |
1 |
0211-0306 |
● |
|
| |
37 |
SEAL; DUST,CLU HSG
ALSO INCLUDED IN GASKET SET(M/T).
|
1-09625-002-0 |
02 |
1 |
0307- |
● |
|
| |
45 |
GASKET; FILLER PLUG
ALSO INCLUDED IN GASKET SET(M/T).
ID=26.8
|
1-09623-058-0 |
01 |
1 |
0005-0210 |
● |
● |
| |
45 |
GASKET; FILLER PLUG
ALSO INCLUDED IN GASKET SET(M/T).
ID=26.8
|
1-09623-058-0 |
01 |
1 |
0211- |
● |
|
| |
50 |
GASKET; DRAIN PLUG
ALSO INCLUDED IN GASKET SET(M/T).
ID=26.8
|
1-09623-058-0 |
01 |
1 |
0005-0210 |
● |
● |
| |
50 |
GASKET; DRAIN PLUG
ALSO INCLUDED IN GASKET SET(M/T).
ID=26.8
|
1-09623-058-0 |
01 |
1 |
0211- |
● |
|
| |
51 |
COVER; SEAL,COUNTER,FRT
|
1-33319-107-1 |
01 |
1 |
0005- |
● |
|
| |
51 |
COVER; SEAL,COUNTER,FRT
|
1-33319-056-0 |
01 |
1 |
0005-0210 |
|
● |
| |
71 |
COVER; SIDE,TRANS CASE
|
1-33141-033-0 |
01 |
1 |
0005-0611 |
● |
|
| |
71 |
COVER; SIDE,TRANS CASE
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5)
|
1-33141-033-0 |
01 |
1 |
0612- |
● |
|
| |
71 |
COVER; SIDE,TRANS CASE
|
1-33141-028-0 |
01 |
1 |
0005-0210 |
|
● |
| |
72 |
BOLT; SIDE COVER
M10X16 FLANGE
|
0-28181-016-0 |
08 |
1 |
0005-0210 |
● |
● |
| |
72 |
BOLT; SIDE COVER
M10X16 FLANGE
|
0-28181-016-0 |
08 |
1 |
0211-0512 |
● |
|
| |
72 |
BOLT; SIDE COVER
M10X16 FLANGE
|
0-28151-016-0 |
08 |
1 |
0601-0611 |
● |
|
| |
72 |
BOLT; SIDE COVER
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5)
M10X16 FLANGE
|
0-28151-016-0 |
08 |
1 |
0612- |
● |
|
| |
73 |
GASKET; SIDE COVER TO TRANS CASE
ALSO INCLUDED IN GASKET SET(M/T).
|
1-33142-036-0 |
01 |
1 |
0005-0210 |
● |
● |
| |
73 |
GASKET; SIDE COVER TO TRANS CASE
ALSO INCLUDED IN GASKET SET(M/T).
|
1-33142-036-0 |
01 |
1 |
0211-0611 |
● |
|
| |
73 |
GASKET; SIDE COVER TO TRANS CASE
ALSO INCLUDED IN GASKET SET(M/T).
EXC. TRANSMISSION SIDE PTO WO/LEVER(SH5)
|
1-33142-036-0 |
01 |
1 |
0612- |
● |
|
| |
86 |
BOLT; RR COVER
(B)
M17X35
|
1-09044-076-0 |
08 |
1 |
0005- |
● |
|
| |
86 |
BOLT; RR COVER
(A)
M12X60
|
1-09044-084-0 |
01 |
1 |
0005- |
● |
|
| |
86 |
BOLT; RR COVER
(A)
M10X25
|
1-09044-080-0 |
08 |
1 |
0005-0210 |
|
● |
| |
86 |
BOLT; RR COVER
PARKING BRAKE DRUM 8.5"(B1S)
(B)
M10X55
|
1-09044-083-0 |
03 |
1 |
0005-0210 |
|
● |
| |
86 |
BOLT; RR COVER
EXC. PARKING BRAKE DRUM 8.5"(B1S)
(B)
M10X50 FLANGE
|
1-09044-081-0 |
03 |
1 |
0005-0210 |
|
● |
| |
90 |
SEAL; OIL,RR COVER
ALSO INCLUDED IN GASKET SET(M/T).
NOK
|
1-09625-513-0 |
01 |
1 |
0005- |
● |
|
| |
90 |
SEAL; OIL,RR COVER
ALSO INCLUDED IN GASKET SET(M/T).
NOK
|
1-09625-505-0 |
01 |
1 |
0005-0210 |
|
● |
| |
97 |
STUD; PARKING BRK
M14X27 L=49
|
1-09302-099-1 |
01 |
1 |
0005-0210 |
● |
|
| |
97 |
STUD; PARKING BRK
14" CLUTCH(WF6)
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
M14X27 L=49
|
1-09302-099-1 |
03 |
1 |
0211-0302 |
● |
|
| |
97 |
STUD; PARKING BRK
EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
M14X27 L=49
|
1-09302-099-1 |
03 |
1 |
0303- |
● |
|
| |
97 |
STUD; PARKING BRK
M14X22.5 L=42.5
|
1-09302-138-1 |
01 |
1 |
0005-0210 |
|
● |
| |
97 |
STUD; PARKING BRK
PARKING BRAKE DRUM 8.5"(B1S)
M14X22.5 L=42.5
|
1-09302-138-1 |
03 |
1 |
0005-0210 |
|
● |
| |
97 |
STUD; PARKING BRK
M14X27 L=49
|
1-09302-099-1 |
01 |
1 |
0211- |
● |
|
| |
100 |
PLUG; DRAIN RR COVER
M24X17 FLANGE
|
1-09604-023-0 |
01 |
1 |
0005-0210 |
|
● |
| |
101 |
GASKET; DRAIN RR COVER
ALSO INCLUDED IN GASKET SET(M/T).
ID=26.8
|
1-09623-058-0 |
01 |
1 |
0005-0210 |
|
● |
| |
102 |
RETAINER; BRG UPR,MAINSHAFT
|
1-33151-050-0 |
01 |
1 |
0005-0210 |
|
● |
| |
103 |
RETAINER; BRG
|
1-33151-051-0 |
01 |
1 |
0005-0210 |
|
● |
| |
104 |
BOLT; BRG RET
M10X25
|
1-09049-006-1 |
08 |
1 |
0005-0210 |
|
● |
| |
117 |
BOLT; PTO FIX
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
TRANSMISSION SIDE PTO WO/LEVER(SH5)
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
M10X28 FLANGE
|
0-28181-028-0 |
06 |
1 |
0612-0805 |
● |
|
| |
117 |
BOLT; PTO FIX
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
TRANSMISSION SIDE PTO WO/LEVER(SH5)
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
M10X28 FLANGE
|
8-98044-944-0 |
06 |
1 |
0806- |
● |
|
| |
119 |
STUD; PTO FIX
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
TRANSMISSION SIDE PTO WO/LEVER(SH5)
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
M10X30 L=45
|
0-44011-030-0 |
02 |
1 |
0612- |
● |
|
| |
121 |
NUT; PTO FIX
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
TRANSMISSION SIDE PTO WO/LEVER(SH5)
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
M10 FLANGE
|
0-91180-210-0 |
02 |
1 |
0612- |
● |
|
| |
301 |
PLATE; DIST,PTO TO TRANS
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
TRANSMISSION SIDE PTO WO/LEVER(SH5)
14" CLUTCH(WF6)
ASSISTOR SHIFT CONTROL<WX8>
|
1-38119-037-0 |
01 |
1 |
0612- |
● |
|
| |
417 |
PLUG; OIL FILLER,TRANS
M24X17 FLANGE
|
1-09604-064-1 |
01 |
1 |
0005-0201 |
● |
● |
| |
417 |
PLUG; OIL FILLER,TRANS
M24X17 FLANGE
|
1-09604-022-0 |
01 |
1 |
0202-0210 |
● |
● |
| |
417 |
PLUG; OIL FILLER,TRANS
M24X17 FLANGE
|
1-09604-022-0 |
01 |
1 |
0211- |
● |
|
| |
421 |
COVER; RR,TRANS
|
1-33131-177-1 |
01 |
1 |
0005- |
● |
|
| |
421 |
COVER; RR,TRANS
|
1-33131-173-2 |
01 |
1 |
0005-0210 |
|
● |
| |
429 |
PIN; STRAIGHT
OD=10 L=18
|
9-08151-018-0 |
02 |
1 |
0005-0210 |
● |
● |
| |
429 |
PIN; STRAIGHT
OD=10 L=18
|
9-08151-018-0 |
02 |
1 |
0211- |
● |
|
| |
430 |
PLUG; OIL DRAIN
M24X17 FLANGE
|
1-09604-023-0 |
01 |
1 |
0005-0210 |
● |
● |
| |
430 |
PLUG; OIL DRAIN
M24X17 FLANGE
|
1-09604-023-0 |
01 |
1 |
0211- |
● |
|
| |
434 |
HOUSING; CLU
|
1-31110-169-0 |
01 |
1 |
0005- |
● |
|
| |
434 |
HOUSING; CLU
|
1-31110-154-1 |
01 |
1 |
0005-0203 |
|
● |
| |
434 |
HOUSING; CLU
|
1-31110-207-0 |
01 |
1 |
0204-0210 |
|
● |
| |
435 |
CASE; TRANS
|
1-33111-355-0 |
01 |
1 |
0612- |
● |
|
| |
435 |
CASE; TRANS
|
1-33111-235-0 |
01 |
1 |
0005-0201 |
● |
|
| |
435 |
CASE; TRANS
|
1-33111-323-0 |
01 |
1 |
0202-0303 |
● |
|
| |
435 |
CASE; TRANS
|
1-33111-342-0 |
01 |
1 |
0304-0406 |
● |
|
| |
435 |
CASE; TRANS
|
8-97381-568-0 |
01 |
1 |
0407-0802 |
● |
|
| |
435 |
CASE; TRANS
|
1-33111-252-0 |
01 |
1 |
0005-0210 |
|
● |
