1 |
SHOE; BRK,FRT
|
1-47120-545-0 |
04 |
1 |
9912-0007 |
| |
1 |
SHOE; BRK,FRT
|
1-47120-624-0 |
04 |
1 |
0008- |
| |
2 |
LINING; FRT BRK SHOE,STANDARD
|
1-47125-632-0 |
04 |
1 |
9912-0007 |
| |
2 |
LINING; FRT BRK SHOE,STANDARD
|
1-47125-801-0 |
04 |
1 |
0008- |
| |
3 |
LINING; FRT BRK SHOE,OVER SIZE
|
1-47125-634-0 |
04 |
1 |
9912-0007 |
| |
3 |
LINING; FRT BRK SHOE,OVER SIZE
|
1-47125-802-0 |
04 |
1 |
0008- |
| |
4 |
LINING SET; FRT BRK,STANDARD
|
1-88310-453-0 |
01 |
1 |
9912-0007 |
| |
4 |
LINING SET; FRT BRK,STANDARD
|
1-88310-501-1 |
01 |
1 |
0008- |
| |
4 |
LINING SET; FRT BRK,STANDARD
BEST VALUE PARTS
|
1-87610-126-0 |
01 |
1 |
0008-0409 |
| |
5 |
LINING SET; FRT BRK,OVER SIZE
|
1-88310-454-0 |
01 |
1 |
9912-0007 |
| |
5 |
LINING SET; FRT BRK,OVER SIZE
|
1-88310-502-1 |
01 |
1 |
0008- |
| |
7 |
RIVET; LINING,FRT BRK
L=11.5
|
1-09732-015-0 |
56 |
1 |
9912-0007 |
| |
7 |
RIVET; LINING,FRT BRK
|
1-09732-029-0 |
56 |
1 |
0008- |
| |
15 |
CYLINDER; WHEEL,FRT BRK
|
1-47600-939-0 |
02 |
1 |
9912- |
| |
15 |
CYLINDER; WHEEL,FRT BRK
|
1-47600-938-0 |
02 |
1 |
9912- |
| |
16 |
SCREW; BLEEDER,FRT BRK
|
9-47615-027-0 |
04 |
1 |
9912-0703 |
| |
16 |
SCREW; BLEEDER,FRT BRK
|
8-98050-476-0 |
04 |
1 |
0704- |
| |
17 |
CAP; BLEEDER,FRT WHEEL CYL
|
1-47619-009-0 |
04 |
1 |
9912-0703 |
| |
17 |
CAP; BLEEDER,FRT WHEEL CYL
|
8-98050-479-0 |
04 |
1 |
0704- |
| |
24 |
PISTON; FRT WHEEL CYL
|
1-47624-319-0 |
02 |
1 |
9912- |
| |
24 |
PISTON; FRT WHEEL CYL
|
1-47624-318-0 |
02 |
1 |
9912- |
| |
25 |
SCREW; ADJ,FRT WHEEL CYL
RH THREAD
|
1-47622-021-0 |
02 |
1 |
9912- |
| |
25 |
SCREW; ADJ,FRT WHEEL CYL
LH THREAD
|
1-47622-020-0 |
02 |
1 |
9912- |
| |
26 |
CUP SET; FRT WHEEL CYL
|
1-87830-679-0 |
04 |
1 |
9912- |
| |
29 |
SPRING; RETURN,FRT BRK SHOE
|
1-09583-216-0 |
04 |
1 |
9912-0409 |
| |
29 |
SPRING; RETURN,FRT BRK SHOE
|
1-09583-288-0 |
04 |
1 |
0410- |
| |
35 |
BOLT; FRT WHEEL CYL
M14X30
|
1-09000-365-0 |
04 |
1 |
9912- |
| |
35 |
BOLT; FRT WHEEL CYL
M8X22
|
9-09802-475-0 |
04 |
1 |
9912-0007 |
| |
35 |
BOLT; FRT WHEEL CYL
M8X22
|
9-09802-475-0 |
08 |
1 |
0008- |
| |
35 |
BOLT; FRT WHEEL CYL
M8X22
|
9-69802-475-0 |
04 |
1 |
9912-0007 |
| |
67 |
PLATE; BACK,FRT BRK
|
1-47150-376-0 |
01 |
1 |
9912- |
| |
67 |
PLATE; BACK,FRT BRK
|
1-47150-375-0 |
01 |
1 |
9912- |
| |
71 |
GROMMET; CHECK HOLE
|
1-09333-033-0 |
04 |
1 |
9912- |
| |
74 |
CONNECTOR; FRT BRK
|
1-47630-007-1 |
01 |
1 |
9912-0007 |
| |
74 |
CONNECTOR; FRT BRK
|
1-47630-014-1 |
01 |
1 |
0008- |
| |
74 |
CONNECTOR; FRT BRK
|
1-47630-006-1 |
01 |
1 |
9912-0007 |
| |
74 |
CONNECTOR; FRT BRK
|
1-47630-013-1 |
01 |
1 |
0008- |
| |
75 |
PIPE; OIL,FWD,FRT BRK
|
1-47414-238-0 |
01 |
1 |
9912- |
| |
75 |
PIPE; OIL,FWD,FRT BRK
|
1-47414-237-0 |
01 |
1 |
9912- |
| |
76 |
PIPE; OIL,BACKWARD,FRT BRK
|
1-47414-242-0 |
01 |
1 |
9912- |
| |
76 |
PIPE; OIL,BACKWARD,FRT BRK
|
1-47414-241-0 |
01 |
1 |
9912- |
| |
86 |
WASHER; LK,FRT WHEEL CYL
ID=14.2
|
9-09150-614-0 |
04 |
1 |
9912-0603 |
| |
86 |
WASHER; LK,FRT WHEEL CYL
ID=14.2
|
0-91510-614-0 |
04 |
1 |
0604- |
| |
90 |
BOLT; CONNECTOR
M8X16
|
9-09602-119-1 |
02 |
1 |
9912-0703 |
| |
90 |
BOLT; CONNECTOR
|
5-09030-036-1 |
02 |
1 |
0704- |
| |
92 |
GROMMET; ADJ HOLE
|
9-09956-640-0 |
04 |
1 |
9912- |
| |
101 |
PROTECTOR; OIL PIPE,FRT BRK
|
9-47461-158-0 |
02 |
1 |
9912- |
| |
111 |
NUT; FLANGE,SHOE HOLD
|
1-09440-002-0 |
04 |
1 |
9912- |
| |
114 |
PIN; SPLIT,SHOE HOLD
|
9-09874-040-0 |
04 |
1 |
9912- |
| |
120 |
SPRING; LK,ADJ,FRT WHEEL CYL
|
1-47629-056-1 |
02 |
1 |
9912-0007 |
| |
120 |
SPRING; LK,ADJ,FRT WHEEL CYL
|
1-47629-055-1 |
02 |
1 |
9912-0007 |
| |
120 |
SPRING; LK,ADJ,FRT WHEEL CYL
|
1-47629-072-0 |
04 |
1 |
0008- |
| |
121 |
SCREW; LK SPR FRT WHEEL CYL
|
1-09164-004-0 |
08 |
1 |
9912-0007 |
| |
121 |
SCREW; LK SPR FRT WHEEL CYL
|
8-94128-727-0 |
04 |
1 |
0008- |
| |
123 |
WASHER; LK,SPR,FRT WHEEL CYL
|
1-09509-029-0 |
08 |
1 |
9912-0007 |
