1 |
PAN ASM; OIL
|
8-94394-711-1 |
01 |
1 |
0005-0210 |
● |
|
|
| |
1 |
PAN ASM; OIL
|
1-11360-708-3 |
01 |
1 |
0005- |
|
● |
|
| |
1 |
PAN ASM; OIL
|
8-94394-711-2 |
01 |
1 |
0303- |
|
|
● |
| |
2 |
GAUGE; OIL LEVEL
|
1-11760-396-0 |
01 |
1 |
0005-0210 |
● |
|
|
| |
2 |
GAUGE; OIL LEVEL
|
1-11760-395-0 |
01 |
1 |
0005- |
|
● |
|
| |
2 |
GAUGE; OIL LEVEL
|
1-11760-396-1 |
01 |
1 |
0303- |
|
|
● |
| |
5 |
GASKET; PLUG,OIL DRAIN
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=24.4
|
1-09623-057-0 |
01 |
1 |
0005-0210 |
● |
|
|
| |
5 |
GASKET; PLUG,OIL DRAIN
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=26.8
|
1-09623-058-0 |
01 |
1 |
0005- |
|
● |
|
| |
5 |
GASKET; PLUG,OIL DRAIN
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=24.4
|
1-09623-057-0 |
01 |
1 |
0303- |
|
|
● |
| |
6 |
PLUG; OIL DRAIN
|
9-09662-012-0 |
01 |
1 |
0005-0210 |
● |
|
|
| |
6 |
PLUG; OIL DRAIN
M24X17 FLANGE
|
1-09604-064-1 |
01 |
1 |
0005-0111 |
|
● |
|
| |
6 |
PLUG; OIL DRAIN
M24X17 FLANGE
|
1-09604-022-0 |
01 |
1 |
0112- |
|
● |
|
| |
6 |
PLUG; OIL DRAIN
|
9-09662-012-0 |
01 |
1 |
0303- |
|
|
● |
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
(B)
|
1-11766-453-0 |
01 |
1 |
0005-0210 |
● |
|
|
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
(A)
|
8-94395-114-3 |
01 |
1 |
0005-0210 |
● |
|
|
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
(C)
|
1-11766-483-0 |
01 |
1 |
0005- |
|
● |
|
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
(B)
|
1-11766-453-0 |
01 |
1 |
0303- |
|
|
● |
| |
8 |
TUBE; GUIDE,OIL LEVEL GAUGE
(A)
|
8-94395-114-3 |
01 |
1 |
0303- |
|
|
● |
| |
9 |
GASKET; GUIDE TUBE,OIL LEVEL GAUGE
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=11
|
5-09623-002-0 |
02 |
1 |
0005-0112 |
● |
|
|
| |
9 |
GASKET; GUIDE TUBE,OIL LEVEL GAUGE
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=11
|
1-09623-469-0 |
02 |
1 |
0201-0210 |
● |
|
|
| |
9 |
GASKET; GUIDE TUBE,OIL LEVEL GAUGE
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=11
|
1-09623-469-0 |
01 |
1 |
0005- |
|
● |
|
| |
9 |
GASKET; GUIDE TUBE,OIL LEVEL GAUGE
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=11
|
1-09623-469-0 |
02 |
1 |
0303- |
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
(C)
M8X16 FLANGE
|
0-28080-816-0 |
01 |
1 |
0005-0210 |
● |
|
|
| |
10 |
BOLT; GUIDE TUBE
(A)
M8X20 FLANGE
|
0-28080-820-0 |
02 |
1 |
0005-0210 |
● |
|
|
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X20 FLANGE
|
0-28680-820-0 |
02 |
1 |
0005-0210 |
● |
|
|
| |
10 |
BOLT; GUIDE TUBE
(A)
M6X40 FLANGE
|
0-28080-640-0 |
01 |
1 |
0005-0512 |
|
● |
|
| |
10 |
BOLT; GUIDE TUBE
(A)
M6X40 FLANGE
|
0-28050-640-0 |
01 |
1 |
0601- |
|
● |
|
| |
10 |
BOLT; GUIDE TUBE
(C)
M8X12 FLANGE
|
0-28080-812-0 |
02 |
1 |
0005-0210 |
|
● |
|
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X20 FLANGE
|
0-28080-820-0 |
01 |
1 |
0005-0512 |
|
● |
|
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X20 FLANGE
|
0-28050-820-0 |
01 |
1 |
0601- |
|
● |
|
| |
10 |
BOLT; GUIDE TUBE
(C)
M8X16 FLANGE
|
0-28080-816-0 |
01 |
1 |
0303-0512 |
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
(C)
M8X16 FLANGE
|
0-28050-816-0 |
01 |
1 |
0601- |
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
(A)
M8X20 FLANGE
|
0-28080-820-0 |
02 |
1 |
0303-0512 |
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
(A)
M8X20 FLANGE
|
0-28050-820-0 |
02 |
1 |
0601- |
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X20 FLANGE
|
0-28680-820-0 |
02 |
1 |
0303-0512 |
|
|
● |
| |
10 |
BOLT; GUIDE TUBE
(B)
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
0601- |
|
|
● |
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
(C)
|
8-94395-843-0 |
01 |
1 |
0005-0210 |
● |
|
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
(B)
|
1-11769-169-0 |
01 |
1 |
0005-0210 |
|
● |
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
(D)
|
1-11769-167-0 |
01 |
1 |
0211- |
|
● |
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
(A)
|
1-11769-193-0 |
01 |
1 |
0005-0210 |
|
● |
|
| |
12 |
BRACKET; TUBE,OIL LEVEL GAUGE
(C)
|
8-94395-843-0 |
01 |
1 |
0303- |
|
|
● |
| |
15 |
CLIP; GUIDE TUBE
(B)
|
1-09701-193-1 |
01 |
1 |
0005- |
|
● |
|
| |
15 |
CLIP; GUIDE TUBE
(A)
|
1-09701-194-1 |
01 |
1 |
0005- |
|
● |
|
| |
16 |
GASKET; OIL PAN TO C/BL
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-11367-113-0 |
01 |
1 |
0005-0205 |
|
● |
|
| |
16 |
GASKET; OIL PAN TO C/BL
ALSO INCLUDED IN GASKET SET(ENGINE).
|
1-11367-129-1 |
01 |
1 |
0206-1103 |
|
● |
|
| |
16 |
GASKET; OIL PAN TO C/BL
ALSO INCLUDED IN GASKET SET(ENGINE).
|
8-98187-258-0 |
01 |
1 |
1104- |
|
● |
|
| |
22 |
WASHER; LK,OIL PAN
ID=8.2
|
9-09150-508-0 |
06 |
1 |
0005-0603 |
|
● |
|
| |
22 |
WASHER; LK,OIL PAN
ID=8.2
|
0-91510-508-0 |
06 |
1 |
0604- |
|
● |
|
| |
23 |
BOLT; OIL PAN
(A)
M8X18 FLANGE
|
0-28080-818-0 |
30 |
1 |
0005-0210 |
● |
|
|
| |
23 |
BOLT; OIL PAN
(B)
M8X22 W/LK&PL WASHER
|
0-50140-822-0 |
30 |
1 |
0005-0906 |
|
● |
|
| |
23 |
BOLT; OIL PAN
(B)
M8X22 W/LK&PL WASHER
|
0-50640-822-0 |
30 |
1 |
0907- |
|
● |
|
| |
23 |
BOLT; OIL PAN
(A)
M8X18 FLANGE
|
0-28080-818-0 |
28 |
1 |
0303- |
|
|
● |
| |
23 |
BOLT; OIL PAN
(C)
M8X28 FLANGE
|
0-28080-828-0 |
02 |
1 |
0303- |
|
|
● |
| |
24 |
NUT; OIL PAN
M8 FLANGE
|
0-91150-108-0 |
04 |
1 |
0005-0210 |
● |
|
|
| |
24 |
NUT; OIL PAN
M8
|
9-09110-408-0 |
06 |
1 |
0005-0512 |
|
● |
|
| |
24 |
NUT; OIL PAN
M8
|
0-91110-508-0 |
06 |
1 |
0601- |
|
● |
|
| |
24 |
NUT; OIL PAN
M8 FLANGE
|
0-91150-108-0 |
04 |
1 |
0303-0602 |
|
|
● |
| |
24 |
NUT; OIL PAN
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
0603- |
|
|
● |
| |
47 |
CLIP; HOSE,AIR BREATHER
|
1-11369-115-0 |
01 |
1 |
0005-0210 |
● |
|
|
| |
47 |
CLIP; HOSE,AIR BREATHER
|
1-11229-014-0 |
01 |
1 |
0005- |
|
● |
|
| |
47 |
CLIP; HOSE,AIR BREATHER
|
1-11369-115-0 |
01 |
1 |
0303- |
|
|
● |
| |
150 |
CLIP; WATER,OIL DRAIN
|
9-11229-070-0 |
02 |
1 |
0005-0210 |
|
● |
|
| |
150 |
CLIP; WATER,OIL DRAIN
|
9-11229-070-0 |
03 |
1 |
0211- |
|
● |
|
| |
204 |
WASHER; PL,OIL PAN
ID=8.4
|
9-09160-508-0 |
06 |
1 |
0005-0605 |
|
● |
|
| |
204 |
WASHER; PL,OIL PAN
ID=8.4 OD=16
|
0-91610-508-0 |
06 |
1 |
0606- |
|
● |
|
