◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ FV ▶ 10829 - FV/GV(AUSTRAL)A.SUS ▶ 0 - Engine, Emission, Engine Electrical ▶ 0-01 - PARTIAL ENGINE ▶
0-01 — PARTIAL ENGINE (#8251) — 14 parça
çizim 10637
1
BalonParca AdiParca NoAdetTipApplied Date A B C
1 ENGINE ASM; PARTIAL 1-87310-570-2 01 1 0211- ●
1 ENGINE ASM; PARTIAL 1-87310-497-0 01 1 0005-0210 ●
1 ENGINE ASM; PARTIAL 1-87310-521-0 01 1 0303-0504 ●
1 ENGINE ASM; PARTIAL 1-87310-522-1 01 1 0505-1012 ●
1 ENGINE ASM; PARTIAL 1-87310-715-0 01 1 1101-1208 ●
1 ENGINE ASM; PARTIAL 1-87310-789-0 01 1 1209- ●
1 ENGINE ASM; PARTIAL 1-87310-572-1 01 1 0005-0210 ●
çizim 10638
1
BalonParca AdiParca NoAdetTipApplied Date A B C
1 ENGINE ASM; PARTIAL 1-87310-570-2 01 1 0211- ●
1 ENGINE ASM; PARTIAL 1-87310-497-0 01 1 0005-0210 ●
1 ENGINE ASM; PARTIAL 1-87310-521-0 01 1 0303-0504 ●
1 ENGINE ASM; PARTIAL 1-87310-522-1 01 1 0505-1012 ●
1 ENGINE ASM; PARTIAL 1-87310-715-0 01 1 1101-1208 ●
1 ENGINE ASM; PARTIAL 1-87310-789-0 01 1 1209- ●
1 ENGINE ASM; PARTIAL 1-87310-572-1 01 1 0005-0210 ●
İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
