1 |
04.164 HUB ASM; CLU,INPUT SHAFT,A/T
|
8-98189-510-0 |
01 |
1 |
1205-1205 |
| |
1 |
04.164 HUB ASM; CLU,INPUT SHAFT,A/T
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
|
8-98189-510-0 |
01 |
1 |
1206- |
| |
1 |
04.164 HUB ASM; CLU,INPUT SHAFT,A/T
4JJ1-TCS ENG(LFB)
|
8-98189-762-0 |
01 |
1 |
1206-1210 |
| |
1 |
04.164 HUB ASM; CLU,INPUT SHAFT,A/T
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
|
8-98189-762-0 |
01 |
1 |
1211- |
| |
2 |
04.164 RACE; THRUST BRG,A/T
|
8-98189-534-0 |
01 |
1 |
1205- |
| |
11 |
04.166 PISTON ASM; CLU,A/T
|
8-98189-512-0 |
01 |
1 |
1205-1205 |
| |
11 |
04.166 PISTON ASM; CLU,A/T
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
|
8-98189-512-0 |
01 |
1 |
1206- |
| |
11 |
04.166 PISTON ASM; CLU,A/T
4JJ1-TCS ENG(LFB)
|
8-98189-764-0 |
01 |
1 |
1206-1210 |
| |
11 |
04.166 PISTON ASM; CLU,A/T
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
|
8-98189-764-0 |
01 |
1 |
1211- |
| |
12 |
04.164 SPRING; CLU RETURN,A/T
|
8-98189-515-0 |
01 |
1 |
1205- |
| |
13 |
04.166 GASKET; INNER,CLU,A/T
ID=40
|
8-98189-513-0 |
01 |
1 |
1205- |
| |
16 |
04.166 RING; SNAP,CLU,A/T
(A)
ID=35
|
8-98189-518-0 |
01 |
1 |
1205- |
| |
16 |
04.166 RING; SNAP,CLU,A/T
(B)
ID=29
|
8-98189-533-0 |
03 |
1 |
1205- |
| |
18 |
04.164 BEARING; THRUST,CLU,A/T
|
8-98189-535-0 |
01 |
1 |
1205- |
| |
20 |
04.163 DISC; CLU,A/T
OD=162
|
8-98189-559-0 |
06 |
1 |
1205-1205 |
| |
20 |
04.163 DISC; CLU,A/T
4JJ1-TCS ENG(LFB)
OD=162
|
8-98189-559-0 |
05 |
1 |
1206-1210 |
| |
20 |
04.163 DISC; CLU,A/T
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
OD=162
|
8-98189-559-0 |
05 |
1 |
1211- |
| |
20 |
04.163 DISC; CLU,A/T
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
OD=162
|
8-98189-559-0 |
06 |
1 |
1206- |
| |
21 |
04.163 DISC ASM; CLU & FACING,A/T
ID=149
|
8-98189-558-0 |
06 |
1 |
1205-1205 |
| |
21 |
04.163 DISC ASM; CLU & FACING,A/T
4JJ1-TCS ENG(LFB)
ID=149
|
8-98189-558-0 |
05 |
1 |
1206-1210 |
| |
21 |
04.163 DISC ASM; CLU & FACING,A/T
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
ID=149
|
8-98189-558-0 |
05 |
1 |
1211- |
| |
21 |
04.163 DISC ASM; CLU & FACING,A/T
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
ID=149
|
8-98189-558-0 |
06 |
1 |
1206- |
| |
23 |
04.164 RING; RET,CLU,A/T
ID=160
|
8-98189-576-0 |
02 |
1 |
1205- |
| |
25 |
04.164 RING; RET,BACKING PLATE,A/T
ID=115
|
8-98189-532-0 |
01 |
1 |
1205- |
| |
27 |
04.163 DISC ASM; CLU & FACING,A/T
T=1.8
|
8-98189-520-0 |
06 |
1 |
1205-1205 |
| |
27 |
04.163 DISC ASM; CLU & FACING,A/T
4JJ1-TCS ENG(LFB)
T=1.8
|
8-98189-520-0 |
05 |
1 |
1206-1210 |
| |
27 |
04.163 DISC ASM; CLU & FACING,A/T
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
T=1.8
|
8-98189-520-0 |
05 |
1 |
1211- |
| |
27 |
04.163 DISC ASM; CLU & FACING,A/T
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
T=1.8
|
8-98189-520-0 |
06 |
1 |
1206- |
| |
28 |
04.163 DISC; CLU,A/T
OD=120
|
8-98189-519-0 |
07 |
1 |
1205-1205 |
| |
28 |
04.163 DISC; CLU,A/T
4JJ1-TCS ENG(LFB)
OD=120
|
8-98189-519-0 |
06 |
1 |
1206-1210 |
| |
28 |
04.163 DISC; CLU,A/T
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
OD=120
|
8-98189-519-0 |
06 |
1 |
1211- |
| |
28 |
04.163 DISC; CLU,A/T
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
OD=120
|
8-98189-519-0 |
07 |
1 |
1206- |
| |
29 |
04.164 RING; SNAP,CLU,A/T
ID=171
|
8-98189-597-0 |
01 |
1 |
1205- |
| |
31 |
04.166 GASKET; CLU,INNER,A/T
ID=101
|
8-98189-586-0 |
01 |
1 |
1205- |
| |
32 |
04.166 GASKET; CLU,OUTER,A/T
(A)
ID=142
|
8-98189-582-0 |
01 |
1 |
1205- |
| |
32 |
04.166 GASKET; CLU,OUTER,A/T
(B)
ID=140
|
8-98189-585-0 |
01 |
1 |
1205- |
| |
39 |
04.164 SPRING; DIRECT CLU RETURN
|
8-98189-543-0 |
01 |
1 |
1205- |
| |
41 |
04.164 FLANGE; DIRECT CLU
T=3.0
|
8-98189-521-0 |
01 |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=3.0
|
8-98189-521-0 |
AR |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=3.1
|
8-98189-522-0 |
AR |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=3.2
|
8-98189-523-0 |
AR |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=3.3
|
8-98189-524-0 |
AR |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=3.4
|
8-98189-525-0 |
AR |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=3.5
|
8-98189-526-0 |
AR |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=3.6
|
8-98189-527-0 |
AR |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=3.7
|
8-98189-528-0 |
AR |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=3.8
|
8-98189-529-0 |
AR |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=3.9
|
8-98189-530-0 |
AR |
1 |
1205- |
| |
43 |
04.164 FLANGE; FWD CLU
T=4.0
|
8-98189-531-0 |
AR |
1 |
1205- |
| |
46 |
04.166 PISTON; DIRECT CLU,A/T
|
8-98189-540-0 |
01 |
1 |
1205-1205 |
| |
46 |
04.166 PISTON; DIRECT CLU,A/T
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
|
8-98189-540-0 |
01 |
1 |
1206- |
| |
46 |
04.166 PISTON; DIRECT CLU,A/T
4JJ1-TCS ENG(LFB)
|
8-98189-766-0 |
01 |
1 |
1206-1210 |
| |
46 |
04.166 PISTON; DIRECT CLU,A/T
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
|
8-98189-766-0 |
01 |
1 |
1211- |
| |
52 |
04.167 GASKET; PISTON INNER,DIRECT CLU,
ID=75
|
8-98189-542-0 |
01 |
1 |
1205- |
| |
53 |
04.167 GASKET; PISTON OUTER,DIRECT CLU,
ID=126.7
|
8-98189-541-0 |
01 |
1 |
1205- |
| |
76 |
04.262 PLATE; 3RD CLU
T=2.4
|
8-98189-591-0 |
04 |
1 |
1205- |
| |
95 |
04.166 GASKET; CLU HUB
(A)
ID=108
|
8-98189-514-0 |
01 |
1 |
1205- |
| |
95 |
04.166 GASKET; CLU HUB
(B)
ID=107
|
8-98189-517-0 |
01 |
1 |
1205- |
| |
139 |
04.164 RING; SNAP
(A)
ID=64
|
8-98189-557-0 |
01 |
1 |
1205- |
| |
139 |
04.164 RING; SNAP
(B)
ID=79
|
8-98189-589-0 |
01 |
1 |
1205- |
| |
142 |
04.167 SPRING; CLU
|
8-98189-587-0 |
01 |
1 |
1205- |
| |
157 |
04.166 CLUTCH ASM; A/T
|
8-98189-538-0 |
01 |
1 |
1205-1205 |
| |
157 |
04.166 CLUTCH ASM; A/T
4JJ1-TCX ENG(LS0),4JK1-TCY ENG(RDX)
|
8-98189-538-0 |
01 |
1 |
1206- |
| |
157 |
04.166 CLUTCH ASM; A/T
4JJ1-TCS ENG(LFB)
|
8-98189-765-0 |
01 |
1 |
1206-1210 |
| |
157 |
04.166 CLUTCH ASM; A/T
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
|
8-98189-765-0 |
01 |
1 |
1211- |
| |
161 |
04.166 PLATE; CLU
T=1.5
|
8-98189-595-0 |
01 |
1 |
1205- |
| |
184 |
04.166 BALANCER; CLUTCH NO 1
|
8-98189-516-0 |
01 |
1 |
1205- |
| |
185 |
04.166 BALANCER; CLUTCH NO 3
|
8-98189-588-0 |
01 |
1 |
1205- |
| |
186 |
04.166 PISTON; REVERSE CLUTCH
|
8-98189-579-0 |
01 |
1 |
1205- |
| |
187 |
04.166 BALANCER; CLUTCH NO 2
|
8-98189-556-0 |
01 |
1 |
1205- |
| |
188 |
04.164 FLANGE; REVERSE CLUTCH
T=3.0
|
8-98189-560-0 |
AR |
1 |
1205- |
| |
188 |
04.164 FLANGE; REVERSE CLUTCH
T=3.1
|
8-98189-561-0 |
AR |
1 |
1205- |
| |
188 |
04.164 FLANGE; REVERSE CLUTCH
T=3.2
|
8-98189-562-0 |
AR |
1 |
1205- |
| |
188 |
04.164 FLANGE; REVERSE CLUTCH
T=3.3
|
8-98189-563-0 |
AR |
1 |
1205- |
| |
188 |
04.164 FLANGE; REVERSE CLUTCH
T=3.4
|
8-98189-564-0 |
AR |
1 |
1205- |
| |
188 |
04.164 FLANGE; REVERSE CLUTCH
T=3.5
|
8-98189-565-0 |
AR |
1 |
1205- |
| |
188 |
04.164 FLANGE; REVERSE CLUTCH
T=3.6
|
8-98189-566-0 |
AR |
1 |
1205- |
| |
188 |
04.164 FLANGE; REVERSE CLUTCH
T=3.7
|
8-98189-568-0 |
AR |
1 |
1205- |
| |
188 |
04.164 FLANGE; REVERSE CLUTCH
T=3.8
|
8-98189-572-0 |
AR |
1 |
1205- |
| |
189 |
04.163 DISC; CLUTCH NO 3
OD=162
|
8-98189-590-0 |
05 |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=3.0
|
8-98189-560-0 |
AR |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=3.1
|
8-98189-561-0 |
AR |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=3.2
|
8-98189-562-0 |
AR |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=3.3
|
8-98189-563-0 |
AR |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=3.4
|
8-98189-564-0 |
AR |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=3.5
|
8-98189-565-0 |
AR |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=3.6
|
8-98189-566-0 |
AR |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=3.7
|
8-98189-568-0 |
AR |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=3.8
|
8-98189-572-0 |
AR |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=2.8
|
8-98189-592-0 |
AR |
1 |
1205- |
| |
190 |
04.164 FLANGE; CLUTCH
T=2.9
|
8-98189-594-0 |
AR |
1 |
1205- |
| |
191 |
04.166 SLEEVE; CLUTCH
|
8-98189-596-0 |
01 |
1 |
1205- |
