Sayfa 5-01 - Isuzu EPC

5-01 — FRAME AND OTHER PARTS (#81731) — 367 parça

497 497 497 497 485

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D	E
485	NUT; TRANS MTG MBR,FRAME M10 FLANGE THA	0-91180-210-0	04	1	1109-1109	●	●
485	NUT; TRANS MTG MBR,FRAME M10 FLANGE THA	0-91180-210-0	04	1	1110-	●	●	●	●	●
497	BOLT; C/MBR (C) M10X120 FLANGE THA	0-28066-012-0	04	1	1109-1109	●	●
497	BOLT; C/MBR (C) M10X120 FLANGE THA	0-28066-012-0	04	1	1110-	●	●	●	●	●
497	BOLT; C/MBR HIGH RIDE SUSPENSION<7YC> (B) M10X35 FLANGE THA	0-28661-035-0	06	1	1109-1109	●
497	BOLT; C/MBR (B) M10X35 FLANGE THA	0-28661-035-0	06	1	1109-1109		●
497	BOLT; C/MBR HIGH RIDE SUSPENSION<7YC> (B) M10X35 FLANGE THA	0-28661-035-0	06	1	1110-	●			●
497	BOLT; C/MBR (B) M10X35 FLANGE THA	0-28661-035-0	06	1	1110-		●			●
497	BOLT; C/MBR (A) M10X28 W/LK&PL WASHER THA	8-97945-706-0	02	1	1109-1109	●
497	BOLT; C/MBR (A) M10X28 W/LK&PL WASHER THA	8-97945-706-0	02	1	1110-	●		●	●
497	BOLT; C/MBR (D) M12X30 FLANGE THA	0-28651-230-0	08	1	1109-1109	●	●
497	BOLT; C/MBR (D) M12X30 FLANGE THA	0-28651-230-0	08	1	1110-	●	●	●	●	●
497	BOLT; C/MBR EXC. HIGH RIDE SUSPENSION<7YC> (B) M10X35 FLANGE THA	0-28661-035-0	04	1	1109-1109	●
497	BOLT; C/MBR EXC. HIGH RIDE SUSPENSION<7YC> (B) M10X35 FLANGE THA	0-28661-035-0	04	1	1110-	●			●
497	BOLT; C/MBR (B) M10X35 FLANGE THA	0-28661-035-0	04	1	1110-			●

1 1 156 29 156 29 101 29 156 352 156 29 156 256 547 547 547 547 164 164 29 352 39 2 29 11 24 29 101 204 29 256 29 29 156 29 156 156 156 352 156 514 29 156 105 156 105 514 440 5 11

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D	E
1	FRAME ASM A/T 5 SPEED-AISIN<MA1> HIGH RIDE SUSPENSION<7YC> THA	8-98102-285-4	01	1	1109-	●
1	FRAME ASM M/T MUA 5 SPEED 5H<MWQ> HIGH RIDE SUSPENSION<7YC> THA	8-98159-167-3	01	1	1109-	●
1	FRAME ASM M/T MUA 5 SPEED 5H<MWQ> EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98102-253-3	01	1	1109-1211	●
1	FRAME ASM EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98102-253-6	01	1	1212-	●
1	FRAME ASM M/T MUX 5 SPEED 5S<MZJ> HIGH RIDE SUSPENSION<7YC> THA	8-98159-165-3	01	1	1109-	●
1	FRAME ASM M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA	8-98159-172-1	01	1	1109-1211		●
1	FRAME ASM THA	8-98159-172-2	01	1	1212-		●
1	FRAME ASM 4JK1-TCS ENG<LKZ>,4JK1-TCX ENG<LR0> M/T MUA 5 SPEED 5H<MWQ> THA	8-98102-252-2	01	1	1110-1211			●
1	FRAME ASM THA	8-98102-252-5	01	1	1212-			●
1	FRAME ASM A/T 5 SPEED-AISIN<MA1> HIGH RIDE SUSPENSION<7YC> THA	8-98159-168-2	01	1	1110-				●
1	FRAME ASM A/T 5 SPEED-AISIN<MA1> EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98102-251-4	01	1	1110-				●
1	FRAME ASM M/T MUA 5 SPEED 5H<MWQ> HIGH RIDE SUSPENSION<7YC> THA	8-98159-169-3	01	1	1110-				●
1	FRAME ASM M/T MUA 5 SPEED 5H<MWQ> EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98159-178-4	01	1	1110-				●
1	FRAME ASM M/T MUX 5 SPEED 5S<MZJ> HIGH RIDE SUSPENSION<7YC> THA	8-98159-166-3	01	1	1110-				●
1	FRAME ASM 4JK1-TCX ENG<LR0>,4JJ1-TCX ENG<LS0> A/T 5 SPEED-AISIN<MA1> THA	8-98159-173-2	01	1	1110-					●
1	FRAME ASM 4JK1-TCX ENG<LR0>,4JJ1-TCX ENG<LS0> M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA	8-98159-174-2	01	1	1110-					●
2	MEMBER; CROSS,1ST THA	8-98106-701-1	01	1	1109-1109	●	●
2	MEMBER; CROSS,1ST THA	8-98106-701-1	01	1	1110-	●	●	●	●	●
5	MEMBER; CROSS,SUSPENSION EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-736-2	01	1	1109-1109	●
5	MEMBER; CROSS,SUSPENSION EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-736-2	01	1	1110-	●			●
5	MEMBER; CROSS,SUSPENSION THA	8-98106-736-2	01	1	1110-			●
5	MEMBER; CROSS,SUSPENSION HIGH RIDE SUSPENSION<7YC> THA	8-98173-915-0	01	1	1109-1109	●
5	MEMBER; CROSS,SUSPENSION HIGH RIDE SUSPENSION<7YC> THA	8-98173-915-1	01	1	1110-	●			●
5	MEMBER; CROSS,SUSPENSION THA	8-98173-916-0	01	1	1109-1109		●
5	MEMBER; CROSS,SUSPENSION THA	8-98173-916-0	01	1	1110-1307		●			●
5	MEMBER; CROSS,SUSPENSION THA	8-98229-450-0	01	1	1308-		●			●
11	BRACKET; ENG MTG EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-793-1	01	1	1109-1109	●
11	BRACKET; ENG MTG EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-793-2	01	1	1110-	●			●
11	BRACKET; ENG MTG THA	8-98106-793-2	01	1	1110-			●
11	BRACKET; ENG MTG EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-795-1	01	1	1109-1109	●
11	BRACKET; ENG MTG EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-795-1	01	1	1110-	●			●
11	BRACKET; ENG MTG THA	8-98106-795-1	01	1	1110-			●
11	BRACKET; ENG MTG HIGH RIDE SUSPENSION<7YC> THA	8-98106-794-2	01	1	1109-1109	●
11	BRACKET; ENG MTG THA	8-98106-794-2	01	1	1109-1109		●
11	BRACKET; ENG MTG HIGH RIDE SUSPENSION<7YC> THA	8-98106-794-2	01	1	1110-	●			●
11	BRACKET; ENG MTG THA	8-98106-794-2	01	1	1110-		●			●
11	BRACKET; ENG MTG HIGH RIDE SUSPENSION<7YC> THA	8-98106-796-2	01	1	1109-1109	●
11	BRACKET; ENG MTG THA	8-98106-796-2	01	1	1109-1109		●
11	BRACKET; ENG MTG HIGH RIDE SUSPENSION<7YC> THA	8-98106-796-2	01	1	1110-	●			●
11	BRACKET; ENG MTG THA	8-98106-796-2	01	1	1110-		●			●
24	BRACKET; FRT SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-806-3	01	1	1109-1109	●
24	BRACKET; FRT SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-806-3	01	1	1110-	●			●
24	BRACKET; FRT SPR,FRT THA	8-98106-806-3	01	1	1110-			●
24	BRACKET; FRT SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-807-1	01	1	1109-1109	●
24	BRACKET; FRT SPR,FRT THA	8-98106-807-1	01	1	1109-1109		●
24	BRACKET; FRT SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-807-1	01	1	1110-	●			●
24	BRACKET; FRT SPR,FRT THA	8-98106-807-1	01	1	1110-		●			●
29	BRACKET; CAB MTG (G) THA	8-98106-842-2	01	1	1109-	●	●
29	BRACKET; CAB MTG (G) THA	8-98106-843-2	01	1	1109-	●	●
29	BRACKET; CAB MTG (A) THA	8-97942-341-3	02	1	1109-1109	●	●
29	BRACKET; CAB MTG (A) THA	8-97942-341-3	02	1	1110-	●	●	●	●	●
29	BRACKET; CAB MTG (B) THA	8-98106-784-3	01	1	1109-1109	●	●
29	BRACKET; CAB MTG (B) THA	8-98106-784-3	01	1	1110-	●	●	●	●	●
29	BRACKET; CAB MTG (C) THA	8-98106-791-3	01	1	1109-1109	●	●
29	BRACKET; CAB MTG (C) THA	8-98106-791-3	01	1	1110-	●	●	●	●	●
29	BRACKET; CAB MTG (D) THA	8-98107-534-0	02	1	1109-1109	●	●
29	BRACKET; CAB MTG (D) THA	8-98107-534-0	02	1	1110-	●	●	●	●	●
29	BRACKET; CAB MTG (F) THA	8-98173-497-0	02	1	1110-			●	●	●
29	BRACKET; CAB MTG (E) THA	8-98106-844-2	01	1	1110-				●	●
29	BRACKET; CAB MTG (E) THA	8-98106-845-2	01	1	1110-				●	●
39	BRACKET; FRT SPR,RR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-808-3	01	1	1109-1109	●
39	BRACKET; FRT SPR,RR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-808-3	01	1	1110-	●			●
39	BRACKET; FRT SPR,RR THA	8-98106-808-3	01	1	1110-			●
39	BRACKET; FRT SPR,RR HIGH RIDE SUSPENSION<7YC> THA	8-98106-809-1	01	1	1109-1109	●
39	BRACKET; FRT SPR,RR THA	8-98106-809-1	01	1	1109-1109		●
39	BRACKET; FRT SPR,RR HIGH RIDE SUSPENSION<7YC> THA	8-98106-809-1	01	1	1110-	●			●
39	BRACKET; FRT SPR,RR THA	8-98106-809-1	01	1	1110-		●			●
101	BRACKET; RR SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-866-0	01	1	1109-1109	●
101	BRACKET; RR SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-866-0	01	1	1110-	●			●
101	BRACKET; RR SPR,FRT THA	8-98106-866-0	01	1	1110-			●
101	BRACKET; RR SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-867-0	01	1	1109-1109	●
101	BRACKET; RR SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-867-0	01	1	1110-	●			●
101	BRACKET; RR SPR,FRT THA	8-98106-867-0	01	1	1110-			●
101	BRACKET; RR SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-868-0	01	1	1109-1109	●
101	BRACKET; RR SPR,FRT THA	8-98106-868-0	01	1	1109-1109		●
101	BRACKET; RR SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-868-0	01	1	1110-	●			●
101	BRACKET; RR SPR,FRT THA	8-98106-868-0	01	1	1110-		●			●
101	BRACKET; RR SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-869-0	01	1	1109-1109	●
101	BRACKET; RR SPR,FRT THA	8-98106-869-0	01	1	1109-1109		●
101	BRACKET; RR SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-869-0	01	1	1110-	●			●
101	BRACKET; RR SPR,FRT THA	8-98106-869-0	01	1	1110-		●			●
105	BRACKET; RR SPR,RR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-97942-294-0	02	1	1109-1109	●
105	BRACKET; RR SPR,RR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-97942-294-0	02	1	1110-	●			●
105	BRACKET; RR SPR,RR THA	8-97942-294-0	02	1	1110-			●
105	BRACKET; RR SPR,RR HIGH RIDE SUSPENSION<7YC> THA	8-98106-870-0	02	1	1109-1109	●
105	BRACKET; RR SPR,RR THA	8-98106-870-0	02	1	1109-1109		●
105	BRACKET; RR SPR,RR HIGH RIDE SUSPENSION<7YC> THA	8-98106-870-0	02	1	1110-	●			●
105	BRACKET; RR SPR,RR THA	8-98106-870-0	02	1	1110-		●			●
156	BRACKET; RR BODY MTG (C) THA	8-98106-863-2	02	1	1110-1203				●	●
156	BRACKET; RR BODY MTG (C) THA	8-98214-084-0	02	1	1204-				●	●
156	BRACKET; RR BODY MTG (D) THA	8-98106-847-1	01	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (D) THA	8-98106-847-1	01	1	1110-1203	●	●	●
156	BRACKET; RR BODY MTG (D) THA	8-98213-872-0	01	1	1204-	●	●	●
156	BRACKET; RR BODY MTG (D) THA	8-98106-848-1	01	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (D) THA	8-98106-848-1	01	1	1110-1203	●	●	●
156	BRACKET; RR BODY MTG (D) THA	8-98213-873-0	01	1	1204-	●	●	●
156	BRACKET; RR BODY MTG (A) THA	8-98106-849-0	03	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (A) THA	8-98106-849-0	03	1	1110-1203	●	●	●	●	●
156	BRACKET; RR BODY MTG (A) THA	8-98213-874-0	03	1	1204-	●	●	●	●	●
156	BRACKET; RR BODY MTG (B) THA	8-98106-850-0	01	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (B) THA	8-98106-850-0	01	1	1110-1203	●	●	●	●	●
156	BRACKET; RR BODY MTG (B) THA	8-98213-875-0	01	1	1204-	●	●	●	●	●
156	BRACKET; RR BODY MTG (E) THA	8-98106-864-0	01	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (E) THA	8-98106-864-0	01	1	1110-	●	●	●
156	BRACKET; RR BODY MTG (E) THA	8-98106-865-0	01	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (E) THA	8-98106-865-0	01	1	1110-	●	●	●
156	BRACKET; RR BODY MTG (F) THA	8-98106-837-2	01	1	1110-1203			●
156	BRACKET; RR BODY MTG (F) THA	8-98213-870-0	01	1	1204-			●
156	BRACKET; RR BODY MTG (F) THA	8-98106-838-2	01	1	1110-1203			●
156	BRACKET; RR BODY MTG (F) THA	8-98213-871-0	01	1	1204-			●
164	PLATE; FRT THA	8-98106-814-0	01	1	1109-1109	●	●
164	PLATE; FRT THA	8-98106-814-0	01	1	1110-	●	●	●	●	●
164	PLATE; FRT THA	8-98106-815-0	01	1	1109-1109	●	●
164	PLATE; FRT THA	8-98106-815-0	01	1	1110-	●	●	●	●	●
204	MEMBER; CROSS,TRANS MTG A/T 5 SPEED-AISIN<MA1> HIGH RIDE SUSPENSION<7YC> THA	8-98106-760-4	01	1	1109-1109	●
204	MEMBER; CROSS,TRANS MTG A/T 5 SPEED-AISIN<MA1> HIGH RIDE SUSPENSION<7YC> THA	8-98106-760-5	01	1	1110-	●
204	MEMBER; CROSS,TRANS MTG A/T 5 SPEED-AISIN<MA1> THA	8-98106-760-5	01	1	1110-				●
204	MEMBER; CROSS,TRANS MTG M/T MUA 5 SPEED 5H<MWQ> THA	8-98106-759-3	01	1	1109-1109	●
204	MEMBER; CROSS,TRANS MTG M/T MUA 5 SPEED 5H<MWQ> THA	8-98106-759-4	01	1	1110-	●			●
204	MEMBER; CROSS,TRANS MTG 4JK1-TCS ENG<LKZ>,4JK1-TCX ENG<LR0> M/T MUA 5 SPEED 5H<MWQ> THA	8-98106-759-4	01	1	1110-			●
204	MEMBER; CROSS,TRANS MTG M/T MUX 5 SPEED 5S<MZJ> HIGH RIDE SUSPENSION<7YC> THA	8-98106-758-3	01	1	1109-1109	●
204	MEMBER; CROSS,TRANS MTG M/T MUX 5 SPEED 5S<MZJ> HIGH RIDE SUSPENSION<7YC> THA	8-98106-758-5	01	1	1110-	●			●
204	MEMBER; CROSS,TRANS MTG THA	8-98106-761-3	01	1	1109-1109		●
204	MEMBER; CROSS,TRANS MTG M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA	8-98106-761-4	01	1	1110-		●
204	MEMBER; CROSS,TRANS MTG 4JK1-TCX ENG<LR0>,4JJ1-TCX ENG<LS0> M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA	8-98106-761-4	01	1	1110-					●
204	MEMBER; CROSS,TRANS MTG 4JK1-TCX ENG<LR0>,4JJ1-TCX ENG<LS0> A/T 5 SPEED-AISIN<MA1> THA	8-98106-762-4	01	1	1110-					●
256	BRACKET; S/ABS EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-800-2	01	1	1109-1109	●
256	BRACKET; S/ABS EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-800-2	01	1	1110-	●			●
256	BRACKET; S/ABS THA	8-98106-800-2	01	1	1110-			●
256	BRACKET; S/ABS EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-802-1	01	1	1109-1109	●
256	BRACKET; S/ABS EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-802-1	01	1	1110-	●			●
256	BRACKET; S/ABS THA	8-98106-802-1	01	1	1110-			●
256	BRACKET; S/ABS HIGH RIDE SUSPENSION<7YC> THA	8-98106-801-6	01	1	1109-1109	●
256	BRACKET; S/ABS THA	8-98106-801-6	01	1	1109-1109		●
256	BRACKET; S/ABS HIGH RIDE SUSPENSION<7YC> THA	8-98106-801-6	01	1	1110-	●			●
256	BRACKET; S/ABS THA	8-98106-801-6	01	1	1110-		●			●
256	BRACKET; S/ABS HIGH RIDE SUSPENSION<7YC> THA	8-98106-803-4	01	1	1109-1109	●
256	BRACKET; S/ABS THA	8-98106-803-4	01	1	1109-1109		●
256	BRACKET; S/ABS HIGH RIDE SUSPENSION<7YC> THA	8-98106-803-4	01	1	1110-	●			●
256	BRACKET; S/ABS THA	8-98106-803-4	01	1	1110-		●			●
352	BRACKET; BUMPER RUBBER HIGH RIDE SUSPENSION<7YC> (A) THA	8-98106-835-3	01	1	1109-1109	●
352	BRACKET; BUMPER RUBBER (A) THA	8-98106-835-3	01	1	1109-1109		●
352	BRACKET; BUMPER RUBBER HIGH RIDE SUSPENSION<7YC> (A) THA	8-98106-835-3	01	1	1110-	●			●
352	BRACKET; BUMPER RUBBER (A) THA	8-98106-835-3	01	1	1110-		●			●
352	BRACKET; BUMPER RUBBER HIGH RIDE SUSPENSION<7YC> (A) THA	8-98106-836-3	01	1	1109-1109	●
352	BRACKET; BUMPER RUBBER (A) THA	8-98106-836-3	01	1	1109-1109		●
352	BRACKET; BUMPER RUBBER HIGH RIDE SUSPENSION<7YC> (A) THA	8-98106-836-3	01	1	1110-	●			●
352	BRACKET; BUMPER RUBBER (A) THA	8-98106-836-3	01	1	1110-		●			●
352	BRACKET; BUMPER RUBBER HIGH RIDE SUSPENSION<7YC> (B) THA	8-98106-871-1	02	1	1109-1109	●
352	BRACKET; BUMPER RUBBER (B) THA	8-98106-871-1	02	1	1109-1109		●
352	BRACKET; BUMPER RUBBER HIGH RIDE SUSPENSION<7YC> (B) THA	8-98106-871-1	02	1	1110-	●			●
352	BRACKET; BUMPER RUBBER (B) THA	8-98106-871-1	02	1	1110-		●			●
440	BRACKET; HOSE EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-872-1	01	1	1109-1109	●
440	BRACKET; HOSE EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-872-1	01	1	1110-	●			●
440	BRACKET; HOSE THA	8-98106-872-1	01	1	1110-			●
440	BRACKET; HOSE HIGH RIDE SUSPENSION<7YC> THA	8-98106-873-1	01	1	1109-1109	●
440	BRACKET; HOSE THA	8-98106-873-1	01	1	1109-1109		●
440	BRACKET; HOSE HIGH RIDE SUSPENSION<7YC> THA	8-98106-873-1	01	1	1110-	●			●
440	BRACKET; HOSE THA	8-98106-873-1	01	1	1110-		●			●
514	PIN; S/ABS THA	8-97942-395-1	02	1	1109-1109	●	●
514	PIN; S/ABS THA	8-97942-395-1	02	1	1110-	●	●	●	●	●
547	BRACE; C/MBR (A) THA	8-98173-910-0	01	1	1109-1109	●
547	BRACE; C/MBR (A) THA	8-98173-910-1	01	1	1110-	●		●	●
547	BRACE; C/MBR (B) THA	8-98173-913-0	01	1	1109-1109	●
547	BRACE; C/MBR (B) THA	8-98173-913-0	01	1	1110-	●		●	●
547	BRACE; C/MBR (C) THA	8-98173-914-0	01	1	1109-1109	●
547	BRACE; C/MBR (C) THA	8-98173-914-0	01	1	1110-	●		●	●
547	BRACE; C/MBR (D) THA	8-98177-568-2	01	1	1109-1109	●
547	BRACE; C/MBR (D) THA	8-98177-568-3	01	1	1110-	●		●	●
547	BRACE; C/MBR (B) THA	8-98173-911-0	01	1	1109-1109		●
547	BRACE; C/MBR (B) THA	8-98173-911-0	01	1	1110-		●			●
547	BRACE; C/MBR (C) THA	8-98173-912-0	01	1	1109-1109		●
547	BRACE; C/MBR (C) THA	8-98173-912-0	01	1	1110-		●			●
547	BRACE; C/MBR (D) THA	8-98173-907-1	01	1	1109-1109		●
547	BRACE; C/MBR (D) THA	8-98173-907-1	01	1	1110-1307		●			●
547	BRACE; C/MBR (D) THA	8-98229-465-0	01	1	1308-		●			●
547	BRACE; C/MBR (A) THA	8-98173-908-0	01	1	1109-1109		●
547	BRACE; C/MBR (A) THA	8-98173-908-0	01	1	1110-1307		●			●
547	BRACE; C/MBR (A) THA	8-98229-466-0	01	1	1308-		●			●

547 547 547 547 164 164 29 11 256 29 29 29 156 29 156 156 156 1 1 156 514 514 101 302 204 39 5 29 29 29 256 302 29 29 29 101 156 156 156 105 156 440 29 24 2 11 156

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D	E
1	FRAME ASM A/T 5 SPEED-AISIN<MA1> HIGH RIDE SUSPENSION<7YC> THA	8-98102-285-4	01	1	1109-	●
1	FRAME ASM M/T MUA 5 SPEED 5H<MWQ> HIGH RIDE SUSPENSION<7YC> THA	8-98159-167-3	01	1	1109-	●
1	FRAME ASM M/T MUA 5 SPEED 5H<MWQ> EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98102-253-3	01	1	1109-1211	●
1	FRAME ASM EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98102-253-6	01	1	1212-	●
1	FRAME ASM M/T MUX 5 SPEED 5S<MZJ> HIGH RIDE SUSPENSION<7YC> THA	8-98159-165-3	01	1	1109-	●
1	FRAME ASM M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA	8-98159-172-1	01	1	1109-1211		●
1	FRAME ASM THA	8-98159-172-2	01	1	1212-		●
1	FRAME ASM 4JK1-TCS ENG<LKZ>,4JK1-TCX ENG<LR0> M/T MUA 5 SPEED 5H<MWQ> THA	8-98102-252-2	01	1	1110-1211			●
1	FRAME ASM THA	8-98102-252-5	01	1	1212-			●
1	FRAME ASM A/T 5 SPEED-AISIN<MA1> HIGH RIDE SUSPENSION<7YC> THA	8-98159-168-2	01	1	1110-				●
1	FRAME ASM A/T 5 SPEED-AISIN<MA1> EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98102-251-4	01	1	1110-				●
1	FRAME ASM M/T MUA 5 SPEED 5H<MWQ> HIGH RIDE SUSPENSION<7YC> THA	8-98159-169-3	01	1	1110-				●
1	FRAME ASM M/T MUA 5 SPEED 5H<MWQ> EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98159-178-4	01	1	1110-				●
1	FRAME ASM M/T MUX 5 SPEED 5S<MZJ> HIGH RIDE SUSPENSION<7YC> THA	8-98159-166-3	01	1	1110-				●
1	FRAME ASM 4JK1-TCX ENG<LR0>,4JJ1-TCX ENG<LS0> A/T 5 SPEED-AISIN<MA1> THA	8-98159-173-2	01	1	1110-					●
1	FRAME ASM 4JK1-TCX ENG<LR0>,4JJ1-TCX ENG<LS0> M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA	8-98159-174-2	01	1	1110-					●
2	MEMBER; CROSS,1ST THA	8-98106-701-1	01	1	1109-1109	●	●
2	MEMBER; CROSS,1ST THA	8-98106-701-1	01	1	1110-	●	●	●	●	●
5	MEMBER; CROSS,SUSPENSION EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-736-2	01	1	1109-1109	●
5	MEMBER; CROSS,SUSPENSION EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-736-2	01	1	1110-	●			●
5	MEMBER; CROSS,SUSPENSION THA	8-98106-736-2	01	1	1110-			●
5	MEMBER; CROSS,SUSPENSION HIGH RIDE SUSPENSION<7YC> THA	8-98173-915-0	01	1	1109-1109	●
5	MEMBER; CROSS,SUSPENSION HIGH RIDE SUSPENSION<7YC> THA	8-98173-915-1	01	1	1110-	●			●
5	MEMBER; CROSS,SUSPENSION THA	8-98173-916-0	01	1	1109-1109		●
5	MEMBER; CROSS,SUSPENSION THA	8-98173-916-0	01	1	1110-1307		●			●
5	MEMBER; CROSS,SUSPENSION THA	8-98229-450-0	01	1	1308-		●			●
11	BRACKET; ENG MTG EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-793-1	01	1	1109-1109	●
11	BRACKET; ENG MTG EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-793-2	01	1	1110-	●			●
11	BRACKET; ENG MTG THA	8-98106-793-2	01	1	1110-			●
11	BRACKET; ENG MTG EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-795-1	01	1	1109-1109	●
11	BRACKET; ENG MTG EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-795-1	01	1	1110-	●			●
11	BRACKET; ENG MTG THA	8-98106-795-1	01	1	1110-			●
11	BRACKET; ENG MTG HIGH RIDE SUSPENSION<7YC> THA	8-98106-794-2	01	1	1109-1109	●
11	BRACKET; ENG MTG THA	8-98106-794-2	01	1	1109-1109		●
11	BRACKET; ENG MTG HIGH RIDE SUSPENSION<7YC> THA	8-98106-794-2	01	1	1110-	●			●
11	BRACKET; ENG MTG THA	8-98106-794-2	01	1	1110-		●			●
11	BRACKET; ENG MTG HIGH RIDE SUSPENSION<7YC> THA	8-98106-796-2	01	1	1109-1109	●
11	BRACKET; ENG MTG THA	8-98106-796-2	01	1	1109-1109		●
11	BRACKET; ENG MTG HIGH RIDE SUSPENSION<7YC> THA	8-98106-796-2	01	1	1110-	●			●
11	BRACKET; ENG MTG THA	8-98106-796-2	01	1	1110-		●			●
24	BRACKET; FRT SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-806-3	01	1	1109-1109	●
24	BRACKET; FRT SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-806-3	01	1	1110-	●			●
24	BRACKET; FRT SPR,FRT THA	8-98106-806-3	01	1	1110-			●
24	BRACKET; FRT SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-807-1	01	1	1109-1109	●
24	BRACKET; FRT SPR,FRT THA	8-98106-807-1	01	1	1109-1109		●
24	BRACKET; FRT SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-807-1	01	1	1110-	●			●
24	BRACKET; FRT SPR,FRT THA	8-98106-807-1	01	1	1110-		●			●
29	BRACKET; CAB MTG (G) THA	8-98106-842-2	01	1	1109-	●	●
29	BRACKET; CAB MTG (G) THA	8-98106-843-2	01	1	1109-	●	●
29	BRACKET; CAB MTG (A) THA	8-97942-341-3	02	1	1109-1109	●	●
29	BRACKET; CAB MTG (A) THA	8-97942-341-3	02	1	1110-	●	●	●	●	●
29	BRACKET; CAB MTG (B) THA	8-98106-784-3	01	1	1109-1109	●	●
29	BRACKET; CAB MTG (B) THA	8-98106-784-3	01	1	1110-	●	●	●	●	●
29	BRACKET; CAB MTG (C) THA	8-98106-791-3	01	1	1109-1109	●	●
29	BRACKET; CAB MTG (C) THA	8-98106-791-3	01	1	1110-	●	●	●	●	●
29	BRACKET; CAB MTG (D) THA	8-98107-534-0	02	1	1109-1109	●	●
29	BRACKET; CAB MTG (D) THA	8-98107-534-0	02	1	1110-	●	●	●	●	●
29	BRACKET; CAB MTG (F) THA	8-98173-497-0	02	1	1110-			●	●	●
29	BRACKET; CAB MTG (E) THA	8-98106-844-2	01	1	1110-				●	●
29	BRACKET; CAB MTG (E) THA	8-98106-845-2	01	1	1110-				●	●
39	BRACKET; FRT SPR,RR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-808-3	01	1	1109-1109	●
39	BRACKET; FRT SPR,RR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-808-3	01	1	1110-	●			●
39	BRACKET; FRT SPR,RR THA	8-98106-808-3	01	1	1110-			●
39	BRACKET; FRT SPR,RR HIGH RIDE SUSPENSION<7YC> THA	8-98106-809-1	01	1	1109-1109	●
39	BRACKET; FRT SPR,RR THA	8-98106-809-1	01	1	1109-1109		●
39	BRACKET; FRT SPR,RR HIGH RIDE SUSPENSION<7YC> THA	8-98106-809-1	01	1	1110-	●			●
39	BRACKET; FRT SPR,RR THA	8-98106-809-1	01	1	1110-		●			●
101	BRACKET; RR SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-866-0	01	1	1109-1109	●
101	BRACKET; RR SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-866-0	01	1	1110-	●			●
101	BRACKET; RR SPR,FRT THA	8-98106-866-0	01	1	1110-			●
101	BRACKET; RR SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-867-0	01	1	1109-1109	●
101	BRACKET; RR SPR,FRT EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-867-0	01	1	1110-	●			●
101	BRACKET; RR SPR,FRT THA	8-98106-867-0	01	1	1110-			●
101	BRACKET; RR SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-868-0	01	1	1109-1109	●
101	BRACKET; RR SPR,FRT THA	8-98106-868-0	01	1	1109-1109		●
101	BRACKET; RR SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-868-0	01	1	1110-	●			●
101	BRACKET; RR SPR,FRT THA	8-98106-868-0	01	1	1110-		●			●
101	BRACKET; RR SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-869-0	01	1	1109-1109	●
101	BRACKET; RR SPR,FRT THA	8-98106-869-0	01	1	1109-1109		●
101	BRACKET; RR SPR,FRT HIGH RIDE SUSPENSION<7YC> THA	8-98106-869-0	01	1	1110-	●			●
101	BRACKET; RR SPR,FRT THA	8-98106-869-0	01	1	1110-		●			●
105	BRACKET; RR SPR,RR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-97942-294-0	02	1	1109-1109	●
105	BRACKET; RR SPR,RR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-97942-294-0	02	1	1110-	●			●
105	BRACKET; RR SPR,RR THA	8-97942-294-0	02	1	1110-			●
105	BRACKET; RR SPR,RR HIGH RIDE SUSPENSION<7YC> THA	8-98106-870-0	02	1	1109-1109	●
105	BRACKET; RR SPR,RR THA	8-98106-870-0	02	1	1109-1109		●
105	BRACKET; RR SPR,RR HIGH RIDE SUSPENSION<7YC> THA	8-98106-870-0	02	1	1110-	●			●
105	BRACKET; RR SPR,RR THA	8-98106-870-0	02	1	1110-		●			●
156	BRACKET; RR BODY MTG (C) THA	8-98106-863-2	02	1	1110-1203				●	●
156	BRACKET; RR BODY MTG (C) THA	8-98214-084-0	02	1	1204-				●	●
156	BRACKET; RR BODY MTG (D) THA	8-98106-847-1	01	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (D) THA	8-98106-847-1	01	1	1110-1203	●	●	●
156	BRACKET; RR BODY MTG (D) THA	8-98213-872-0	01	1	1204-	●	●	●
156	BRACKET; RR BODY MTG (D) THA	8-98106-848-1	01	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (D) THA	8-98106-848-1	01	1	1110-1203	●	●	●
156	BRACKET; RR BODY MTG (D) THA	8-98213-873-0	01	1	1204-	●	●	●
156	BRACKET; RR BODY MTG (A) THA	8-98106-849-0	03	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (A) THA	8-98106-849-0	03	1	1110-1203	●	●	●	●	●
156	BRACKET; RR BODY MTG (A) THA	8-98213-874-0	03	1	1204-	●	●	●	●	●
156	BRACKET; RR BODY MTG (B) THA	8-98106-850-0	01	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (B) THA	8-98106-850-0	01	1	1110-1203	●	●	●	●	●
156	BRACKET; RR BODY MTG (B) THA	8-98213-875-0	01	1	1204-	●	●	●	●	●
156	BRACKET; RR BODY MTG (E) THA	8-98106-864-0	01	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (E) THA	8-98106-864-0	01	1	1110-	●	●	●
156	BRACKET; RR BODY MTG (E) THA	8-98106-865-0	01	1	1109-1109	●	●
156	BRACKET; RR BODY MTG (E) THA	8-98106-865-0	01	1	1110-	●	●	●
156	BRACKET; RR BODY MTG (F) THA	8-98106-837-2	01	1	1110-1203			●
156	BRACKET; RR BODY MTG (F) THA	8-98213-870-0	01	1	1204-			●
156	BRACKET; RR BODY MTG (F) THA	8-98106-838-2	01	1	1110-1203			●
156	BRACKET; RR BODY MTG (F) THA	8-98213-871-0	01	1	1204-			●
164	PLATE; FRT THA	8-98106-814-0	01	1	1109-1109	●	●
164	PLATE; FRT THA	8-98106-814-0	01	1	1110-	●	●	●	●	●
164	PLATE; FRT THA	8-98106-815-0	01	1	1109-1109	●	●
164	PLATE; FRT THA	8-98106-815-0	01	1	1110-	●	●	●	●	●
204	MEMBER; CROSS,TRANS MTG A/T 5 SPEED-AISIN<MA1> HIGH RIDE SUSPENSION<7YC> THA	8-98106-760-4	01	1	1109-1109	●
204	MEMBER; CROSS,TRANS MTG A/T 5 SPEED-AISIN<MA1> HIGH RIDE SUSPENSION<7YC> THA	8-98106-760-5	01	1	1110-	●
204	MEMBER; CROSS,TRANS MTG A/T 5 SPEED-AISIN<MA1> THA	8-98106-760-5	01	1	1110-				●
204	MEMBER; CROSS,TRANS MTG M/T MUA 5 SPEED 5H<MWQ> THA	8-98106-759-3	01	1	1109-1109	●
204	MEMBER; CROSS,TRANS MTG M/T MUA 5 SPEED 5H<MWQ> THA	8-98106-759-4	01	1	1110-	●			●
204	MEMBER; CROSS,TRANS MTG 4JK1-TCS ENG<LKZ>,4JK1-TCX ENG<LR0> M/T MUA 5 SPEED 5H<MWQ> THA	8-98106-759-4	01	1	1110-			●
204	MEMBER; CROSS,TRANS MTG M/T MUX 5 SPEED 5S<MZJ> HIGH RIDE SUSPENSION<7YC> THA	8-98106-758-3	01	1	1109-1109	●
204	MEMBER; CROSS,TRANS MTG M/T MUX 5 SPEED 5S<MZJ> HIGH RIDE SUSPENSION<7YC> THA	8-98106-758-5	01	1	1110-	●			●
204	MEMBER; CROSS,TRANS MTG THA	8-98106-761-3	01	1	1109-1109		●
204	MEMBER; CROSS,TRANS MTG M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA	8-98106-761-4	01	1	1110-		●
204	MEMBER; CROSS,TRANS MTG 4JK1-TCX ENG<LR0>,4JJ1-TCX ENG<LS0> M/T MUA 5 SPEED 5H<MWQ>,M/T MUX 5 SPEED 5S<MZJ> THA	8-98106-761-4	01	1	1110-					●
204	MEMBER; CROSS,TRANS MTG 4JK1-TCX ENG<LR0>,4JJ1-TCX ENG<LS0> A/T 5 SPEED-AISIN<MA1> THA	8-98106-762-4	01	1	1110-					●
256	BRACKET; S/ABS EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-800-2	01	1	1109-1109	●
256	BRACKET; S/ABS EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-800-2	01	1	1110-	●			●
256	BRACKET; S/ABS THA	8-98106-800-2	01	1	1110-			●
256	BRACKET; S/ABS EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-802-1	01	1	1109-1109	●
256	BRACKET; S/ABS EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-802-1	01	1	1110-	●			●
256	BRACKET; S/ABS THA	8-98106-802-1	01	1	1110-			●
256	BRACKET; S/ABS HIGH RIDE SUSPENSION<7YC> THA	8-98106-801-6	01	1	1109-1109	●
256	BRACKET; S/ABS THA	8-98106-801-6	01	1	1109-1109		●
256	BRACKET; S/ABS HIGH RIDE SUSPENSION<7YC> THA	8-98106-801-6	01	1	1110-	●			●
256	BRACKET; S/ABS THA	8-98106-801-6	01	1	1110-		●			●
256	BRACKET; S/ABS HIGH RIDE SUSPENSION<7YC> THA	8-98106-803-4	01	1	1109-1109	●
256	BRACKET; S/ABS THA	8-98106-803-4	01	1	1109-1109		●
256	BRACKET; S/ABS HIGH RIDE SUSPENSION<7YC> THA	8-98106-803-4	01	1	1110-	●			●
256	BRACKET; S/ABS THA	8-98106-803-4	01	1	1110-		●			●
302	REINFORCEMENT; S/MBR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98125-713-0	01	1	1109-1109	●
302	REINFORCEMENT; S/MBR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98125-713-0	01	1	1110-	●
302	REINFORCEMENT; S/MBR THA	8-98125-713-0	01	1	1110-			●
302	REINFORCEMENT; S/MBR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98125-714-0	01	1	1109-1109	●
302	REINFORCEMENT; S/MBR EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98125-714-0	01	1	1110-	●
302	REINFORCEMENT; S/MBR THA	8-98125-714-0	01	1	1110-			●
440	BRACKET; HOSE EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-872-1	01	1	1109-1109	●
440	BRACKET; HOSE EXC. HIGH RIDE SUSPENSION<7YC> THA	8-98106-872-1	01	1	1110-	●			●
440	BRACKET; HOSE THA	8-98106-872-1	01	1	1110-			●
440	BRACKET; HOSE HIGH RIDE SUSPENSION<7YC> THA	8-98106-873-1	01	1	1109-1109	●
440	BRACKET; HOSE THA	8-98106-873-1	01	1	1109-1109		●
440	BRACKET; HOSE HIGH RIDE SUSPENSION<7YC> THA	8-98106-873-1	01	1	1110-	●			●
440	BRACKET; HOSE THA	8-98106-873-1	01	1	1110-		●			●
514	PIN; S/ABS THA	8-97942-395-1	02	1	1109-1109	●	●
514	PIN; S/ABS THA	8-97942-395-1	02	1	1110-	●	●	●	●	●
547	BRACE; C/MBR (A) THA	8-98173-910-0	01	1	1109-1109	●
547	BRACE; C/MBR (A) THA	8-98173-910-1	01	1	1110-	●		●	●
547	BRACE; C/MBR (B) THA	8-98173-913-0	01	1	1109-1109	●
547	BRACE; C/MBR (B) THA	8-98173-913-0	01	1	1110-	●		●	●
547	BRACE; C/MBR (C) THA	8-98173-914-0	01	1	1109-1109	●
547	BRACE; C/MBR (C) THA	8-98173-914-0	01	1	1110-	●		●	●
547	BRACE; C/MBR (D) THA	8-98177-568-2	01	1	1109-1109	●
547	BRACE; C/MBR (D) THA	8-98177-568-3	01	1	1110-	●		●	●
547	BRACE; C/MBR (B) THA	8-98173-911-0	01	1	1109-1109		●
547	BRACE; C/MBR (B) THA	8-98173-911-0	01	1	1110-		●			●
547	BRACE; C/MBR (C) THA	8-98173-912-0	01	1	1109-1109		●
547	BRACE; C/MBR (C) THA	8-98173-912-0	01	1	1110-		●			●
547	BRACE; C/MBR (D) THA	8-98173-907-1	01	1	1109-1109		●
547	BRACE; C/MBR (D) THA	8-98173-907-1	01	1	1110-1307		●			●
547	BRACE; C/MBR (D) THA	8-98229-465-0	01	1	1308-		●			●
547	BRACE; C/MBR (A) THA	8-98173-908-0	01	1	1109-1109		●
547	BRACE; C/MBR (A) THA	8-98173-908-0	01	1	1110-1307		●			●
547	BRACE; C/MBR (A) THA	8-98229-466-0	01	1	1308-		●			●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
