Sayfa 2-81 - Isuzu EPC

◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ FSS ▶ 10831 - FSS/FTS(AUSTRALIA) ▶ 2 - Clutch, Transmission, Trans Axle ▶ 2-81 - POWER TAKE OFF; TRANSMISSION SIDE ▶

2-81 — POWER TAKE OFF; TRANSMISSION SIDE (#8139) — 102 parça

1 20 40 112 26 44 45 1 112 19 18 12 9 42 37 13 15 33 50 11 8 36 35 50 22 23 31 32 8 17 6 4 9 30 49 2 21 49

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	POWER TAKE OFF ASM; TRANS SIDE TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38000-356-2	01	1	0005-0210	●
1	POWER TAKE OFF ASM; TRANS SIDE TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38000-309-1	01	1	0005-0210		●	●
2	CASE; GEAR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38111-102-0	01	1	0005-0210	●
2	CASE; GEAR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38111-085-0	01	1	0005-0210		●	●
4	COVER; UPR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38131-016-0	01	1	0005-0210	●
4	COVER; UPR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38131-008-0	01	1	0005-0210		●	●
6	COVER; FRT,OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38151-023-0	01	1	0005-0210	●
6	COVER; FRT,OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	9-38151-604-0	01	1	0005-0210		●	●
8	BEARING; OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-09800-121-0	02	1	0005-0210	●	●	●
9	BOLT; OUTPUT SHAFT COVER,TRANS SIDE PT TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M8X16 FLANGE	0-28080-816-0	08	1	0005-0210	●
9	BOLT; OUTPUT SHAFT COVER,TRANS SIDE PT TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M8X12 FLANGE	0-28080-812-0	08	1	0005-0210		●	●
11	BEARING; IDLE GEAR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-09811-144-0	01	1	0005-0210	●	●	●
12	SHAFT; IDLE GEAR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38221-024-0	01	1	0005-0210	●	●	●
13	GEAR; IDLE,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) Z=36	1-38241-042-0	01	1	0005-0210	●
13	GEAR; IDLE,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) Z=32	1-38241-063-0	01	1	0005-0210		●	●
15	PIN; SPR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) L=16	9-09878-613-0	01	1	0005-0210	●	●	●
17	BOLT; UPR COVER,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M10X16 FLANGE	0-28181-016-0	04	1	0005-0210	●	●	●
18	ARM; GEAR SHIFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38361-028-0	01	1	0005-0110	●
18	ARM; GEAR SHIFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38361-042-0	01	1	0111-0210	●
18	ARM; GEAR SHIFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38361-029-0	01	1	0005-0210		●	●
19	PIN; SPR,SHIFT ARM,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	9-09878-614-0	01	1	0005-0210	●
19	PIN; SPR,SHIFT ARM,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-09748-019-0	01	1	0005-0210		●	●
20	ROD; GEAR SHIFTER,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38371-062-0	01	1	0005-0210	●
20	ROD; GEAR SHIFTER,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38371-033-0	01	1	0005-0210		●	●
21	COVER; SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-09600-085-0	01	1	0005-0210	●
21	COVER; SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	9-33545-001-0	01	1	0005-0210		●	●
22	COLLAR; DIST,OUTPUT SHAFT,TRANS SIDE P TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38226-046-0	01	1	0005-0210	●
22	COLLAR; DIST,OUTPUT SHAFT,TRANS SIDE P TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38226-044-0	01	1	0005-0210		●	●
23	GEAR; OUTPUT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) Z=19	1-38241-120-0	01	1	0005-0210	●
23	GEAR; OUTPUT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) Z=22	1-38241-064-0	01	1	0005-0210		●	●
26	SPRING; SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38121-004-0	01	1	0005-0210	●	●	●
30	SHAFT; OUTPUT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38221-041-0	01	1	0005-0210	●
30	SHAFT; OUTPUT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38211-009-0	01	1	0005-0210		●	●
31	KEY; OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) (A) L=25	1-09735-024-0	01	1	0005-0210	●	●	●
31	KEY; OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) (B) L=30	9-08011-030-0	01	1	0005-0210		●	●
32	COVER; RR,OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38152-023-0	01	1	0005-0210	●
32	COVER; RR,OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38152-024-0	01	1	0005-0210		●	●
33	SEAL; OIL,OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38159-007-0	01	1	0005-0210	●	●	●
35	WASHER; PL,FLANGE FIX,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) ID=15	9-09160-514-0	01	1	0005-0210	●	●	●
36	WASHER; LK,FLANGE FIX,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) ID=14.2	9-09150-514-0	01	1	0005-0210	●	●	●
37	NUT; FLANGE FIX,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M14	9-99111-414-0	01	1	0005-0210	●	●	●
40	GASKET; AIR SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	9-09561-324-0	01	1	0005-0210	●	●	●
42	CYLINDER; AIR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38377-007-0	01	1	0005-0210	●
42	CYLINDER; AIR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38377-003-0	01	1	0005-0210		●	●
44	BOLT; COVER,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M10X25 FLANGE	0-28181-025-0	02	1	0005-0210	●	●	●
45	NIPPLE; AIR CYL,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M12 & PT1/4 STRAIGHT	1-09650-074-1	01	1	0005-0210	●	●	●
49	PLUG; IDLE SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-09600-084-0	02	1	0005-0210	●
50	WASHER; THRUST,IDLE GEAR,TRANS SIDE PT TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38226-058-0	02	1	0005-0210	●
50	WASHER; THRUST,IDLE GEAR,TRANS SIDE PT TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38226-043-0	02	1	0005-0210		●	●
112	COLLAR; SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) (A)	1-38226-063-0	01	1	0005-0210	●
112	COLLAR; SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) (B)	1-38379-033-0	01	1	0005-0110	●

1 1 45 44 42 15 40 12 67 50 17 4 66 20 19 37 36 35 26 39 2 13 18 11 9 50 32 33 21 8 31 31 22 8 23 6 30 9

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	POWER TAKE OFF ASM; TRANS SIDE TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38000-356-2	01	1	0005-0210	●
1	POWER TAKE OFF ASM; TRANS SIDE TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38000-309-1	01	1	0005-0210		●	●
2	CASE; GEAR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38111-102-0	01	1	0005-0210	●
2	CASE; GEAR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38111-085-0	01	1	0005-0210		●	●
4	COVER; UPR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38131-016-0	01	1	0005-0210	●
4	COVER; UPR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38131-008-0	01	1	0005-0210		●	●
6	COVER; FRT,OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38151-023-0	01	1	0005-0210	●
6	COVER; FRT,OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	9-38151-604-0	01	1	0005-0210		●	●
8	BEARING; OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-09800-121-0	02	1	0005-0210	●	●	●
9	BOLT; OUTPUT SHAFT COVER,TRANS SIDE PT TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M8X16 FLANGE	0-28080-816-0	08	1	0005-0210	●
9	BOLT; OUTPUT SHAFT COVER,TRANS SIDE PT TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M8X12 FLANGE	0-28080-812-0	08	1	0005-0210		●	●
11	BEARING; IDLE GEAR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-09811-144-0	01	1	0005-0210	●	●	●
12	SHAFT; IDLE GEAR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38221-024-0	01	1	0005-0210	●	●	●
13	GEAR; IDLE,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) Z=36	1-38241-042-0	01	1	0005-0210	●
13	GEAR; IDLE,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) Z=32	1-38241-063-0	01	1	0005-0210		●	●
15	PIN; SPR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) L=16	9-09878-613-0	01	1	0005-0210	●	●	●
17	BOLT; UPR COVER,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M10X16 FLANGE	0-28181-016-0	04	1	0005-0210	●	●	●
18	ARM; GEAR SHIFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38361-028-0	01	1	0005-0110	●
18	ARM; GEAR SHIFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38361-042-0	01	1	0111-0210	●
18	ARM; GEAR SHIFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38361-029-0	01	1	0005-0210		●	●
19	PIN; SPR,SHIFT ARM,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	9-09878-614-0	01	1	0005-0210	●
19	PIN; SPR,SHIFT ARM,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-09748-019-0	01	1	0005-0210		●	●
20	ROD; GEAR SHIFTER,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38371-062-0	01	1	0005-0210	●
20	ROD; GEAR SHIFTER,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38371-033-0	01	1	0005-0210		●	●
21	COVER; SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-09600-085-0	01	1	0005-0210	●
21	COVER; SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	9-33545-001-0	01	1	0005-0210		●	●
22	COLLAR; DIST,OUTPUT SHAFT,TRANS SIDE P TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38226-046-0	01	1	0005-0210	●
22	COLLAR; DIST,OUTPUT SHAFT,TRANS SIDE P TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38226-044-0	01	1	0005-0210		●	●
23	GEAR; OUTPUT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) Z=19	1-38241-120-0	01	1	0005-0210	●
23	GEAR; OUTPUT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) Z=22	1-38241-064-0	01	1	0005-0210		●	●
26	SPRING; SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38121-004-0	01	1	0005-0210	●	●	●
30	SHAFT; OUTPUT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38221-041-0	01	1	0005-0210	●
30	SHAFT; OUTPUT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38211-009-0	01	1	0005-0210		●	●
31	KEY; OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) (A) L=25	1-09735-024-0	01	1	0005-0210	●	●	●
31	KEY; OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) (B) L=30	9-08011-030-0	01	1	0005-0210		●	●
32	COVER; RR,OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38152-023-0	01	1	0005-0210	●
32	COVER; RR,OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38152-024-0	01	1	0005-0210		●	●
33	SEAL; OIL,OUTPUT SHAFT,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38159-007-0	01	1	0005-0210	●	●	●
35	WASHER; PL,FLANGE FIX,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) ID=15	9-09160-514-0	01	1	0005-0210	●	●	●
36	WASHER; LK,FLANGE FIX,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) ID=14.2	9-09150-514-0	01	1	0005-0210	●	●	●
37	NUT; FLANGE FIX,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M14	9-99111-414-0	01	1	0005-0210	●	●	●
39	STOPPER; SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38379-006-0	01	1	0005-0210		●	●
40	GASKET; AIR SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	9-09561-324-0	01	1	0005-0210	●	●	●
42	CYLINDER; AIR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38377-007-0	01	1	0005-0210	●
42	CYLINDER; AIR,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38377-003-0	01	1	0005-0210		●	●
44	BOLT; COVER,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M10X25 FLANGE	0-28181-025-0	02	1	0005-0210	●	●	●
45	NIPPLE; AIR CYL,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) M12 & PT1/4 STRAIGHT	1-09650-074-1	01	1	0005-0210	●	●	●
50	WASHER; THRUST,IDLE GEAR,TRANS SIDE PT TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38226-058-0	02	1	0005-0210	●
50	WASHER; THRUST,IDLE GEAR,TRANS SIDE PT TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	1-38226-043-0	02	1	0005-0210		●	●
66	BALL; SHIFTER ROD,TRANS SIDE PTO TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5)	9-00097-009-0	01	1	0005-0210		●	●
67	PIN; STRAIGHT TRANSMISSION SIDE PTO(SD8),TRANSMISSION SIDE PTOWO/LEVER(SH5) OD=8 L=16	9-08160-816-0	01	1	0005-0210		●	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
