1 |
06.008 AXLE; FRT
|
8-97262-000-4 |
01 |
1 |
0803- |
● |
● |
| |
2 |
06.020 KNUCKLE; FRT AXLE
BRAKE SYSTEM HEAVY DUTY VAR2<WG3>
|
8-97261-549-2 |
01 |
1 |
1302- |
● |
● |
| |
2 |
06.020 KNUCKLE; FRT AXLE
BRAKE SYSTEM HEAVY DUTY VAR2<WG3>
|
8-97261-550-2 |
01 |
1 |
1302- |
● |
● |
| |
2 |
06.020 KNUCKLE; FRT AXLE
|
8-97261-545-1 |
01 |
1 |
0803-1301 |
● |
● |
| |
2 |
06.020 KNUCKLE; FRT AXLE
EXC. BRAKE SYSTEM HEAVY DUTY VAR2<WG3>
|
8-97261-545-2 |
01 |
1 |
1302- |
● |
● |
| |
2 |
06.020 KNUCKLE; FRT AXLE
|
8-97261-546-1 |
01 |
1 |
0803-1301 |
● |
● |
| |
2 |
06.020 KNUCKLE; FRT AXLE
EXC. BRAKE SYSTEM HEAVY DUTY VAR2<WG3>
|
8-97261-546-2 |
01 |
1 |
1302- |
● |
● |
| |
4 |
06.203 KING PIN KIT
|
5-87832-220-2 |
01 |
1 |
0803- |
● |
● |
| |
10 |
06.009 PLUG; PLATE,KNUCKLE
|
8-97360-117-0 |
01 |
1 |
0803- |
● |
● |
| |
12 |
06.021 GASKET; KNUCKLE
|
8-98084-500-0 |
02 |
1 |
0803- |
● |
● |
| |
14 |
06.021 BUSHING; KING PIN
JBK
|
8-94127-925-2 |
04 |
1 |
0803-0809 |
● |
● |
| |
14 |
06.021 BUSHING; KING PIN
DAIDO WO/NOTCH
|
8-94107-672-3 |
04 |
1 |
0803- |
● |
● |
| |
17 |
06.009 BOLT; STOPPER KNUCKLE
FRT&RR 7R-16-10 16X5.5F-115 GULF
SPEC(BQN)
|
8-98016-968-0 |
03 |
1 |
0803- |
● |
|
| |
17 |
06.009 BOLT; STOPPER KNUCKLE
|
8-98016-968-0 |
03 |
1 |
0803- |
|
● |
| |
17 |
06.009 BOLT; STOPPER KNUCKLE
FRT&RR 195/85R16 RIB 16X5.5J-116.5 SILVER
(CUC)
M12X24 EYE-BOLT
|
8-97360-059-0 |
03 |
1 |
0803- |
● |
|
| |
18 |
06.216 NUT; STOPPER BOLT,KNUCKLE
04.439
M12
|
0-91111-512-0 |
03 |
1 |
0803- |
● |
● |
| |
21 |
06.166 NIPPLE; GREASE,KING PIN
05.601
M6 STRAIGHT
|
0-90301-406-0 |
04 |
1 |
0803- |
● |
● |
| |
25 |
06.210 BEARING; THRUST,KING PIN
06.021
|
8-94248-883-3 |
01 |
1 |
0803- |
● |
● |
| |
25 |
06.210 BEARING; THRUST,KING PIN
|
8-97141-943-1 |
01 |
1 |
0803- |
● |
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.50
|
8-94162-574-0 |
AR |
1 |
0803- |
● |
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.55
|
8-94162-575-0 |
AR |
1 |
0803- |
● |
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.60
|
8-94162-576-0 |
AR |
1 |
0803- |
● |
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.65
|
8-94162-577-0 |
AR |
1 |
0803- |
● |
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
05.460
(B)
T=1.95
|
8-94168-490-0 |
01 |
1 |
0803- |
● |
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.70
|
8-94174-352-0 |
AR |
1 |
0803- |
● |
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.80
|
8-94174-354-0 |
AR |
1 |
0803- |
● |
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.90
|
8-94174-356-0 |
AR |
1 |
0803- |
● |
● |
| |
31 |
07.347 PIN; S/ABS,LWR
|
8-97141-944-0 |
02 |
1 |
0803- |
● |
● |
| |
32 |
06.216 BOLT; KEY,KING PIN
|
8-97141-945-2 |
02 |
1 |
0803- |
● |
● |
| |
33 |
06.216 NUT; KEY BOLT
00.833
M10
|
0-91110-510-0 |
02 |
1 |
0803- |
● |
● |
| |
34 |
06.216 WASHER; LK,KEY BOLT
06.606
ID=10.2
|
0-91510-510-0 |
02 |
1 |
0803- |
● |
● |
| |
36 |
06.103 ARM; KNUCKLE
|
8-97168-291-4 |
01 |
1 |
0803- |
● |
● |
| |
44 |
06.225 COVER; KING PIN
OD=36
|
8-97360-023-0 |
02 |
1 |
0803- |
● |
● |
| |
48 |
06.225 BOLT; COVER
M10X12 FLANGE
|
0-28051-012-0 |
02 |
1 |
0803- |
● |
● |
| |
49 |
06.225 CAP; KNUCKLE
|
8-97360-024-0 |
02 |
1 |
0803- |
● |
● |
| |
58 |
06.103 ARM; TIE ROD
|
8-97168-292-0 |
01 |
1 |
0803- |
● |
● |
| |
59 |
06.104 NUT; TIE ROD ARM
|
8-97360-123-0 |
02 |
1 |
0803- |
● |
● |
| |
61 |
06.233 ROD END; TIE ROD
|
8-97142-100-1 |
01 |
1 |
0803-1309 |
● |
● |
| |
61 |
06.233 ROD END; TIE ROD
|
8-97107-348-2 |
01 |
1 |
1310- |
● |
● |
| |
61 |
06.233 ROD END; TIE ROD
|
8-97142-101-1 |
01 |
1 |
0803-1309 |
● |
● |
| |
61 |
06.233 ROD END; TIE ROD
|
8-97107-349-2 |
01 |
1 |
1310- |
● |
● |
| |
66 |
06.234 NUT; TIE ROD END
M16 SLOTTED
|
0-91116-516-0 |
02 |
1 |
0803-1204 |
● |
● |
| |
66 |
06.234 NUT; TIE ROD END
06.216
M16 SLOTTED
|
8-98049-689-0 |
02 |
1 |
1205- |
● |
● |
| |
69 |
06.255 PIN; SPLIT,TIE ROD END
OD=3.7 L=20
|
0-81124-020-0 |
02 |
1 |
0803- |
● |
● |
| |
70 |
06.234 NUT; TIE ROD END
M20 LH THREAD
|
8-94254-726-0 |
01 |
1 |
0803- |
● |
● |
| |
70 |
06.234 NUT; TIE ROD END
M20
|
8-98043-530-0 |
01 |
1 |
0803- |
● |
● |
| |
81 |
06.230 ROD; TIE
|
8-97142-024-0 |
01 |
1 |
0803- |
● |
● |
