Isuzu WW
▶
PICKUP
▶
TFR
▶
51374 - TFR/TFS(EUROPE)-LHD
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-86 - TRUNK OPENER AND FUEL LID
▶
6-86 — TRUNK OPENER AND FUEL LID
(#79546) — 13 parça
Tümü
A - TFB6CF
B - TFB6SF
C - TFB6WF
D - TFS6CF
E - TFS6SF
F - TFS6WF
102
20
65
105
109
105
2
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
D
E
F
2
17.225 SCREW; LEVER TO BODY
08.083 M5X16 TAPPING
8-98167-449-0
02
1
1203-1305
●
●
●
●
●
●
2
17.225 SCREW; LEVER TO BODY
REAR BODY DBL WALL CTR PULL(E63) 08.083 M5X16 TAPPING
8-98167-449-0
02
1
1306-
●
●
●
●
●
●
20
17.505 CABLE; TRUNK LID & FUEL FILLER
REAR BODY DBL WALL CTR PULL(E63)
8-98072-707-2
01
1
1203-
●
●
20
17.505 CABLE; TRUNK LID & FUEL FILLER
REAR BODY DBL WALL CTR PULL(E63)
8-98073-728-2
01
1
1203-
●
●
20
17.505 CABLE; TRUNK LID & FUEL FILLER
REAR BODY DBL WALL CTR PULL(E63)
8-98073-726-2
01
1
1203-
●
●
65
17.505 KNOB; FUEL FILLER DOOR
REAR BODY DBL WALL CTR PULL(E63) BLACK
8-98103-120-0
01
1
1203-
●
●
●
●
●
●
102
17.505 GROMMET
REAR BODY DELETE(8HH)
8-97321-645-1
01
1
1203-
●
●
●
●
●
●
105
17.505 CLIP; CABLE,FUEL LID OPENER
REAR BODY DBL WALL CTR PULL(E63) (A)
8-98147-853-0
01
1
1203-
●
●
105
17.505 CLIP; CABLE,FUEL LID OPENER
REAR BODY DBL WALL CTR PULL(E63) (B) ID=7
8-98158-303-0
04
1
1203-
●
●
105
17.505 CLIP; CABLE,FUEL LID OPENER
REAR BODY DBL WALL CTR PULL(E63) 02.559 (A) D=5.8
5-09709-081-0
02
1
1203-
●
●
105
17.505 CLIP; CABLE,FUEL LID OPENER
REAR BODY DBL WALL CTR PULL(E63) (B) ID=7
8-98158-303-0
02
1
1203-
●
●
105
17.505 CLIP; CABLE,FUEL LID OPENER
REAR BODY DBL WALL CTR PULL(E63) (B) ID=7
8-98158-303-0
03
1
1203-
●
●
109
17.505 CLIP; CABLE
REAR BODY DBL WALL CTR PULL(E63) 03.008 L=330
5-09709-118-0
01
1
1203-
●
●
●
●
●
●
