Sayfa 0-50 - Isuzu EPC

◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ NLR ▶ 51282 - NLR/NMR 55,85(LHD) ▶ 0 - Engine, Emission, Engine Electrical ▶ 0-50 - OIL COOLER AND OIL FILTER ▶

0-50 — OIL COOLER AND OIL FILTER (#79052) — 148 parça

272 1 329 1 329 11 9 62 63 64 2 70 67 65

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D	E	F
1	01.540 FILTER & COOLER ASM; OIL	8-98003-929-9	01	1	1012-1208	●	●
1	01.540 FILTER & COOLER ASM; OIL	8-98196-739-0	01	1	1209-1504	●	●
1	01.540 FILTER & COOLER ASM; OIL	8-98270-496-0	01	1	1505-	●	●
1	01.540 FILTER & COOLER ASM; OIL	8-97224-298-2	01	1	1012-			●
1	01.540 FILTER & COOLER ASM; OIL	8-94327-272-1	01	1	1012-				●
2	01.836 ELEMENT; OIL FILTER	8-97148-270-1	01	1	1012-1509					●	●
2	01.836 ELEMENT; OIL FILTER	8-98328-207-0	01	1	1510-					●	●
2	01.836 ELEMENT; OIL FILTER	8-98018-858-0	01	1	1012-	●	●
2	01.836 ELEMENT; OIL FILTER	8-97329-911-0	01	1	1012-			●
2	01.836 ELEMENT; OIL FILTER	8-97049-708-0	01	1	1012-				●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-021-0	01	1	1012-			●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-118-0	01	1	1012-	●	●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-117-0	02	1	1012-1509					●	●
9	01.840 GASKET; CENTER BOLT ALSO INCLUDED IN GASKET SET(ENGINE). (A)	1-09623-500-0	01	1	1012-	●	●
9	01.840 GASKET; CENTER BOLT ALSO INCLUDED IN GASKET SET(ENGINE). 01.550 (B) ID=26.2	9-09566-226-0	02	1	1012-	●	●
9	01.840 GASKET; CENTER BOLT ALSO INCLUDED IN GASKET SET(ENGINE). (C)	8-97047-000-0	01	1	1012-			●
11	01.840 BOLT; CENTER	8-98018-847-0	01	1	1012-	●	●
11	01.840 BOLT; CENTER	8-97144-713-0	01	1	1012-			●
62	01.540 COOLER ASM; OIL	8-97226-391-0	01	1	1012-			●
62	01.540 COOLER ASM; OIL	8-94401-680-0	01	1	1012-				●
63	01.550 GASKET; COOLER TO BRKT	8-94383-720-0	01	1	1012-			●	●
64	01.540 BODY; OIL FILTER & OIL COOLER	8-97166-497-2	01	1	1012-			●
64	01.540 BODY; OIL FILTER & OIL COOLER	8-97081-756-0	01	1	1012-				●
65	01.540 VALVE; OIL COOLER	8-94450-772-0	01	1	1012-			●
65	01.540 VALVE; OIL COOLER 01.837	8-94167-882-0	01	1	1012-				●
67	01.550 GASKET; VLV	9-09562-215-0	01	1	1012-	●	●
67	01.550 GASKET; VLV 01.837	9-09920-975-0	01	1	1012-			●
70	01.844 GASKET; PLUG,OIL FILTER (D)	9-09921-193-0	01	1	1012-			●
70	01.844 GASKET; PLUG,OIL FILTER (A) ID=13.6	8-94167-884-0	01	1	1012-				●
70	01.844 GASKET; PLUG,OIL FILTER (B) ID=8.8	8-94167-885-0	01	1	1012-				●
70	01.844 GASKET; PLUG,OIL FILTER (C) ID=6.8	8-94167-886-0	01	1	1012-				●
272	01.844 GASKET; OIL FILTER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). ID=22.1	8-94399-399-0	02	1	1012-					●	●
272	01.844 GASKET; OIL FILTER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). 01.550	8-98087-965-0	01	1	1012-			●	●
329	01.840 BOLT; OIL FILTER 04.686 (B) M8X60 FLANGE	0-28050-860-0	02	1	1012-			●
329	01.840 BOLT; OIL FILTER 00.004 (A) M8X32 FLANGE	0-28080-832-0	02	1	1012-			●
329	01.840 BOLT; OIL FILTER 03.275 (C) M8X25 FLANGE	0-28050-825-0	04	1	1012-				●

379 103 102 379 89 90 444 105 111 469 105 105 469 137 12 208 164 137 544 496 265 272 272 362 2 394 469 496 273

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D	E	F
2	01.836 ELEMENT; OIL FILTER	8-97148-270-1	01	1	1012-1509					●	●
2	01.836 ELEMENT; OIL FILTER	8-98328-207-0	01	1	1510-					●	●
2	01.836 ELEMENT; OIL FILTER	8-98018-858-0	01	1	1012-	●	●
2	01.836 ELEMENT; OIL FILTER	8-97329-911-0	01	1	1012-			●
2	01.836 ELEMENT; OIL FILTER	8-97049-708-0	01	1	1012-				●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-021-0	01	1	1012-			●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-118-0	01	1	1012-	●	●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-117-0	02	1	1012-1509					●	●
12	01.540 VALVE ASM; BYPASS	8-97013-566-2	01	1	1012-					●	●
89	01.540 BOLT; ELEMENT TO CASE 01.062 M8X16 FLANGE	0-28080-816-0	04	1	1012-1211					●	●
89	01.540 BOLT; ELEMENT TO CASE 02.343 M8X16 FLANGE	0-28050-816-0	04	1	1212-					●	●
90	01.540 GASKET; BOLT,OIL COOLER 01.550	1-21729-043-0	04	1	1012-					●	●
102	01.540 COOLER ASM; OIL	8-97385-200-6	01	1	1012-					●	●
103	01.540 BOLT; OIL COOLER 04.338 M8X20 FLANGE	0-28050-820-0	07	1	1012-					●	●
103	01.540 BOLT; OIL COOLER 03.162 M8X35 FLANGE	0-28050-835-0	07	1	1012-					●	●
105	01.540 STUD; OIL COOLER M8X52 L=63	8-97016-314-0	03	1	1012-					●	●
111	01.540 CORE; OIL COOLER	8-97334-101-1	01	1	1012-					●	●
137	01.840 BOLT 01.531 M8X20 FLANGE	0-28650-820-0	02	1	1012-					●	●
164	01.550 GASKET; HTR PIPE ALSO INCLUDED IN GASKET SET(ENGINE). ID=18.6	8-97146-684-0	01	1	1012-					●	●
208	01.540 PIPE; WATER,HTR HEATER & DEFROSTER(C41),AIR CONDITIONER MANUAL CONT(C60)	8-97146-519-0	01	1	1012-1405					●	●
208	01.540 PIPE; WATER,HTR NLR SGL CAB(NM**SE) HEATER & DEFROSTER(C41) FAST GLOW SYSTEM<KM6> EXC. HIGH ALTITUDE COMPENSATOR(EE2), MANUAL STEERING<N51>	8-97146-519-0	01	1	1406-					●
208	01.540 PIPE; WATER,HTR NMR SGL CAB(NM**SN) HEATER & DEFROSTER(C41) SAUDI ARABIA EQUIPMENT(GH3) FAST GLOW SYSTEM<KM6> ANTI EROSION SPEC(7XK) EXC. HIGH ALTITUDE COMPENSATOR(EE2), EXHAUST BRAKE<NF8>,MANUAL STEERING<N51>	8-97146-519-0	01	1	1406-						●
208	01.540 PIPE; WATER,HTR NMR SGL CAB(NM**SN) HEATER & DEFROSTER(C41),AIR CONDITIONER MANUAL CONT(C60) SAUDI ARABIA EQUIPMENT(GH3) FAST GLOW SYSTEM<KM6> EXHAUST BRAKE<NF8> ANTI EROSION SPEC(7XK) EXC. HIGH ALTITUDE COMPENSATOR(EE2), MANUAL STEERING<N51>	8-97146-519-0	01	1	1406-						●
208	01.540 PIPE; WATER,HTR NMR SGL CAB(NM**SN) HEATER & DEFROSTER(C41) HIGH ALTITUDE COMPENSATOR(EE2) SAUDI ARABIA EQUIPMENT(GH3) FAST GLOW SYSTEM<KM6> ANTI EROSION SPEC(7XK) EXC. MANUAL STEERING<N51>	8-97146-519-0	01	1	1406-						●
208	01.540 PIPE; WATER,HTR NMR SGL CAB(NM**SN) AIR CONDITIONER MANUAL CONT(C60) FAST GLOW SYSTEM<KM6> EXHAUST BRAKE<NF8> EXC. COLOMBIA EQUIPMENT(CB7), AZERBAIJAN EQUIPMENT(CX0),HIGH ALTITUDE COMPE NSATOR(EE2),PERU EQUIPMENT(E07), SAUDIARABIA EQUIPMENT(GH3),CHILE EQUIPMEN T(KE1)	8-97146-519-0	01	1	1406-						●
208	01.540 PIPE; WATER,HTR NMR SGL CAB(NM**SN) HEATER & DEFROSTER(C41) HIGH ALTITUDE COMPENSATOR(EE2) EXHAUST BRAKE<NF8> GLOW SYSTEM DELETE<7RK> EXC. COLOMBIA EQUIPMENT(CB7), AZERBAIJAN EQUIPMENT(CX0),PERU EQUIPMENT(E07) ,SAUDI ARABIA EQUIPMENT(GH3),CHILE EQUIPMENT(KE1)	8-97146-519-0	01	1	1406-						●
208	01.540 PIPE; WATER,HTR NMR SGL CAB(NM**SN) HEATER & DEFROSTER(C41) FAST GLOW SYSTEM<KM6> EXHAUST BRAKE<NF8> EXC. COLOMBIA EQUIPMENT(CB7), AZERBAIJAN EQUIPMENT(CX0),PERU EQUIPMENT(E07) ,SAUDI ARABIA EQUIPMENT(GH3),CHILE EQUIPMENT(KE1)	8-97146-519-0	01	1	1406-						●
208	01.540 PIPE; WATER,HTR NMR SGL CAB(NM**SN) HEATER & DEFROSTER(C41),AIR CONDITIONER MANUAL CONT(C60) EXHAUST BRAKE<NF8> GLOW SYSTEM DELETE<7RK> EXC. COLOMBIA EQUIPMENT(CB7), AZERBAIJAN EQUIPMENT(CX0),HIGH ALTITUDE COMPE NSATOR(EE2),PERU EQUIPMENT(E07), SAUDIARABIA EQUIPMENT(GH3),CHILE EQUIPMEN T(KE1)	8-97146-519-0	01	1	1406-						●
265	01.837 BODY; OIL FILTER	8-97096-677-4	01	1	1012-					●	●
272	01.844 GASKET; OIL FILTER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). ID=22.1	8-94399-399-0	02	1	1012-					●	●
272	01.844 GASKET; OIL FILTER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). 01.550	8-98087-965-0	01	1	1012-			●	●
273	01.840 BOLT; OIL FILTER 00.780 M10X30 FLANGE	0-28751-030-0	02	1	1012-					●	●
362	01.837 NUT; OIL FILTER 03.162 M10 FLANGE	0-91180-110-0	02	1	1012-					●	●
362	01.837 NUT; OIL FILTER 01.540 M8 FLANGE	0-91180-208-0	02	1	1012-	●	●
379	01.540 NUT; OIL COOLER 01.062 M8 FLANGE	0-91180-108-0	03	1	1012-					●	●
394	01.837 STUD; OIL FILTER M10X25 L=48.5	0-49241-025-0	02	1	1012-					●	●
444	01.550 GASKET; ELEMENT TO BODY	8-97384-130-0	02	1	1012-					●	●
469	01.550 GASKET; OIL COOLER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). (A)	8-94338-878-1	01	1	1012-					●	●
469	01.550 GASKET; OIL COOLER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). 01.844 (B) ID=9.8	8-94399-339-0	01	1	1012-					●	●
469	01.550 GASKET; OIL COOLER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). (C) OD=30.2 W/PLATE	8-98045-447-0	01	1	1012-					●	●
496	01.835 FILTER ASM; OIL	8-97148-268-4	01	1	1012-1509					●	●
496	01.835 FILTER ASM; OIL	8-98328-202-0	01	1	1510-					●	●
544	08.845 COVER; HEATER EXC. HEATER & DEFROSTER(C41),AIR CONDITIONER MANUAL CONT(C60)	8-97147-028-0	01	1	1012-1405					●	●
544	08.845 COVER; HEATER NLR SGL CAB(NM**SE) FAST GLOW SYSTEM<KM6>,GLOW SYSTEM DELETE<7RK> EXC. HEATER & DEFROSTER(C41),AIR CONDITIONER MANUAL CONT(C60),HIGH ALTITUD E COMPENSATOR(EE2),MANUAL STEERING<N51>	8-97147-028-0	01	1	1406-					●
544	08.845 COVER; HEATER NMR SGL CAB(NM**SN) SAUDI ARABIA EQUIPMENT(GH3) FAST GLOW SYSTEM<KM6>,GLOW SYSTEM DELETE<7RK> ANTI EROSION SPEC(7XK) EXC. HEATER & DEFROSTER(C41),AIR CONDITIONER MANUAL CONT(C60),MANUAL STEER ING<N51>	8-97147-028-0	01	1	1406-						●
544	08.845 COVER; HEATER NMR SGL CAB(NM**SN) EXHAUST BRAKE<NF8> FAST GLOW SYSTEM<KM6>,GLOW SYSTEM DELETE<7RK> EXC. COLOMBIA EQUIPMENT(CB7), AZERBAIJAN EQUIPMENT(CX0),HEATER & DEFROSTER(C41),AIR CONDITIONER MANUAL CONT(C60) ,PERU EQUIPMENT(E07),SAUDI ARABIA EQUIPMENT(GH3),CHILE EQUIPMENT(KE1)	8-97147-028-0	01	1	1406-						●

64 1 2 62 63 70 70 70 70 70 69 70 65 69 65 272 1 329

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D	E	F
1	01.540 FILTER & COOLER ASM; OIL	8-98003-929-9	01	1	1012-1208	●	●
1	01.540 FILTER & COOLER ASM; OIL	8-98196-739-0	01	1	1209-1504	●	●
1	01.540 FILTER & COOLER ASM; OIL	8-98270-496-0	01	1	1505-	●	●
1	01.540 FILTER & COOLER ASM; OIL	8-97224-298-2	01	1	1012-			●
1	01.540 FILTER & COOLER ASM; OIL	8-94327-272-1	01	1	1012-				●
2	01.836 ELEMENT; OIL FILTER	8-97148-270-1	01	1	1012-1509					●	●
2	01.836 ELEMENT; OIL FILTER	8-98328-207-0	01	1	1510-					●	●
2	01.836 ELEMENT; OIL FILTER	8-98018-858-0	01	1	1012-	●	●
2	01.836 ELEMENT; OIL FILTER	8-97329-911-0	01	1	1012-			●
2	01.836 ELEMENT; OIL FILTER	8-97049-708-0	01	1	1012-				●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-021-0	01	1	1012-			●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-118-0	01	1	1012-	●	●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-117-0	02	1	1012-1509					●	●
62	01.540 COOLER ASM; OIL	8-97226-391-0	01	1	1012-			●
62	01.540 COOLER ASM; OIL	8-94401-680-0	01	1	1012-				●
63	01.550 GASKET; COOLER TO BRKT	8-94383-720-0	01	1	1012-			●	●
64	01.540 BODY; OIL FILTER & OIL COOLER	8-97166-497-2	01	1	1012-			●
64	01.540 BODY; OIL FILTER & OIL COOLER	8-97081-756-0	01	1	1012-				●
65	01.540 VALVE; OIL COOLER	8-94450-772-0	01	1	1012-			●
65	01.540 VALVE; OIL COOLER 01.837	8-94167-882-0	01	1	1012-				●
69	01.837 PLUG; BODY,OIL FILTER	8-94167-883-0	01	1	1012-				●
70	01.844 GASKET; PLUG,OIL FILTER (D)	9-09921-193-0	01	1	1012-			●
70	01.844 GASKET; PLUG,OIL FILTER (A) ID=13.6	8-94167-884-0	01	1	1012-				●
70	01.844 GASKET; PLUG,OIL FILTER (B) ID=8.8	8-94167-885-0	01	1	1012-				●
70	01.844 GASKET; PLUG,OIL FILTER (C) ID=6.8	8-94167-886-0	01	1	1012-				●
272	01.844 GASKET; OIL FILTER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). ID=22.1	8-94399-399-0	02	1	1012-					●	●
272	01.844 GASKET; OIL FILTER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). 01.550	8-98087-965-0	01	1	1012-			●	●
329	01.840 BOLT; OIL FILTER 04.686 (B) M8X60 FLANGE	0-28050-860-0	02	1	1012-			●
329	01.840 BOLT; OIL FILTER 00.004 (A) M8X32 FLANGE	0-28080-832-0	02	1	1012-			●
329	01.840 BOLT; OIL FILTER 03.275 (C) M8X25 FLANGE	0-28050-825-0	04	1	1012-				●

362 374 1 9 76 9 97 374 76 76 76 76 362 1 68 67 3 495 2 10 11 365 76 9 8 7 5

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D	E	F
1	01.540 FILTER & COOLER ASM; OIL	8-98003-929-9	01	1	1012-1208	●	●
1	01.540 FILTER & COOLER ASM; OIL	8-98196-739-0	01	1	1209-1504	●	●
1	01.540 FILTER & COOLER ASM; OIL	8-98270-496-0	01	1	1505-	●	●
1	01.540 FILTER & COOLER ASM; OIL	8-97224-298-2	01	1	1012-			●
1	01.540 FILTER & COOLER ASM; OIL	8-94327-272-1	01	1	1012-				●
2	01.836 ELEMENT; OIL FILTER	8-97148-270-1	01	1	1012-1509					●	●
2	01.836 ELEMENT; OIL FILTER	8-98328-207-0	01	1	1510-					●	●
2	01.836 ELEMENT; OIL FILTER	8-98018-858-0	01	1	1012-	●	●
2	01.836 ELEMENT; OIL FILTER	8-97329-911-0	01	1	1012-			●
2	01.836 ELEMENT; OIL FILTER	8-97049-708-0	01	1	1012-				●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-021-0	01	1	1012-			●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-118-0	01	1	1012-	●	●
2	01.836 ELEMENT; OIL FILTER BEST VALUE PARTS	5-87610-117-0	02	1	1012-1509					●	●
3	01.540 GASKET	8-98024-708-0	01	1	1012-	●	●
5	01.837 CASE; OIL FILTER	8-98018-862-0	01	1	1012-	●	●
7	01.840 PLUG; CENTER BOLT	8-98018-846-0	01	1	1012-	●	●
8	01.840 GASKET; PLUG 03.417 ID=9.8	1-09623-055-0	01	1	1012-	●	●
9	01.840 GASKET; CENTER BOLT ALSO INCLUDED IN GASKET SET(ENGINE). (A)	1-09623-500-0	01	1	1012-	●	●
9	01.840 GASKET; CENTER BOLT ALSO INCLUDED IN GASKET SET(ENGINE). 01.550 (B) ID=26.2	9-09566-226-0	02	1	1012-	●	●
9	01.840 GASKET; CENTER BOLT ALSO INCLUDED IN GASKET SET(ENGINE). (C)	8-97047-000-0	01	1	1012-			●
10	01.840 SPRING; ELEMENT	8-98018-850-0	01	1	1012-	●	●
11	01.840 BOLT; CENTER	8-98018-847-0	01	1	1012-	●	●
11	01.840 BOLT; CENTER	8-97144-713-0	01	1	1012-			●
67	01.550 GASKET; VLV	9-09562-215-0	01	1	1012-	●	●
67	01.550 GASKET; VLV 01.837	9-09920-975-0	01	1	1012-			●
68	01.837 PLUG; VLV 01.540	9-13263-010-0	01	1	1012-	●	●
76	01.840 BOLT; OIL FILTER 00.206 (A) M8X70 FLANGE	0-28050-870-0	04	1	1012-	●	●
76	01.840 BOLT; OIL FILTER 02.100 (C) M8X90 FLANGE	0-28050-890-0	02	1	1012-	●	●
76	01.840 BOLT; OIL FILTER 01.060 (B) M8X35 FLANGE	0-28650-835-0	11	1	1012-	●	●
76	01.840 BOLT; OIL FILTER (D)	8-98041-912-0	02	1	1012-	●	●
97	01.540 STUD; OIL COOLER BRKT M6X13,M8X35 L=53	8-98045-481-0	01	1	1012-	●	●
362	01.837 NUT; OIL FILTER 03.162 M10 FLANGE	0-91180-110-0	02	1	1012-					●	●
362	01.837 NUT; OIL FILTER 01.540 M8 FLANGE	0-91180-208-0	02	1	1012-	●	●
365	01.840 PROTECTOR; OIL FILTER	8-98018-857-0	01	1	1012-	●	●
374	01.840 STUD; OIL FILTER 02.510 M8X20 L=32	0-41010-820-0	02	1	1012-	●	●
495	03.680 PLATE; OIL FILTER	8-98018-853-0	01	1	1012-	●	●
