Sayfa 4-25 - Isuzu EPC

4-25 — REAR FINAL DRIVE (#7866) — 283 parça

69 70 1 85 71 20 21 22 85 24 25 17 88 21 20 88 89 56 70 84 17 17 69 55 66 61 61 65 64 63 41 40 40 39 100 126 62 50 49 43 48 45 4 37 60

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	DRIVE ASM; FINAL,RR 39/6	1-41000-380-0	01	1	0302-	●
1	DRIVE ASM; FINAL,RR 39/7	1-41001-133-0	01	1	9905-		●
1	DRIVE ASM; FINAL,RR 41/8	1-41001-682-0	01	1	9905-			●
4	GASKET; FLANGE,FINAL PINION ID=42	9-09921-116-0	01	1	0302-	●
4	GASKET; FLANGE,FINAL PINION ID=37.5 T=4	1-09623-582-0	01	1	9905-		●	●
17	BOLT; DIFF CAGE SETTING (A) M14X121 FLANGE	1-09044-006-0	08	1	0302-	●
17	BOLT; DIFF CAGE SETTING (A) M14X121 FLANGE	1-09044-006-0	04	1	9905-		●	●
17	BOLT; DIFF CAGE SETTING (B) M14X95 FLANGE	1-09044-007-0	04	1	9905-0301		●	●
17	BOLT; DIFF CAGE SETTING (B) M14X95 FLANGE	1-09044-007-0	04	1	0302-	●	●	●
20	WASHER; THRUST,SIDE GEAR T=2.80	1-41562-169-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=2.90	1-41562-170-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=3.00	1-41562-171-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=3.10	1-41562-172-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=3.20	1-41562-173-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=3.30	1-41562-174-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=3.40	1-41562-175-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=2.80	1-41562-061-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=3.00	1-41562-062-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=3.20	1-41562-063-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=3.40	1-41562-064-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=2.90	1-41562-080-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=3.10	1-41562-081-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=3.30	1-41562-082-0	AR	1	9905-		●	●
21	GEAR; SIDE,DIFF Z=16	1-41561-076-0	02	1	0302-0405	●
21	GEAR; SIDE,DIFF Z=16	1-41561-123-0	02	1	0406-	●
21	GEAR; SIDE,DIFF Z=16	1-41561-107-0	02	1	9905-0407		●	●
21	GEAR; SIDE,DIFF Z=16	1-41561-135-0	02	1	0408-		●	●
22	PIN; CROSS,DIFF PINION OD=32	1-41521-002-1	01	1	0302-	●
22	PIN; CROSS,DIFF PINION	1-41521-050-2	01	1	9905-		●	●
24	GEAR; PINION,DIFF Z=10	1-41551-022-0	04	1	0302-0405	●
24	GEAR; PINION,DIFF Z=10	1-41551-040-0	04	1	0406-	●
24	GEAR; PINION,DIFF Z=10	1-41551-032-0	04	1	9905-0407		●	●
24	GEAR; PINION,DIFF Z=10	1-41551-042-0	04	1	0408-		●	●
25	WASHER; THRUST,PINION T=1.6	1-41552-001-0	04	1	0302-	●
25	WASHER; THRUST,PINION ID=29 OD=60	1-41562-119-0	04	1	9905-		●	●
37	NUT; DRIVING PINION M39 FLANGE	1-09449-056-2	01	1	0302-	●
37	NUT; DRIVING PINION M36 FLANGE	1-09449-058-2	01	1	9905-		●	●
39	BEARING; FINAL PINION NSK	1-09812-086-0	01	1	0302-	●
39	BEARING; FINAL PINION NTN	9-00093-072-1	01	1	0302-	●
39	BEARING; FINAL PINION KOYO	9-00093-206-2	01	1	0302-	●
39	BEARING; FINAL PINION NSK	1-09812-026-0	01	1	9905-		●	●
40	SHIM; FINAL PINION T=3.50	1-41229-106-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.51	1-41229-107-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.52	1-41229-108-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.53	1-41229-109-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.54	1-41229-110-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.55	1-41229-111-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.56	1-41229-112-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.57	1-41229-113-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.58	1-41229-114-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.59	1-41229-115-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.60	1-41229-116-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=1.60	1-41229-179-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.61	1-41229-180-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.62	1-41229-181-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.63	1-41229-182-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.64	1-41229-183-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.65	1-41229-184-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.66	1-41229-185-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.67	1-41229-186-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.68	1-41229-187-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.69	1-41229-188-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.70	1-41229-189-0	AR	1	9905-		●	●
41	SPACER; FINAL DRIVE PINION BRG T=7.600	1-41229-101-0	AR	1	0302-	●
41	SPACER; FINAL DRIVE PINION BRG T=7.800	1-41229-102-0	AR	1	0302-	●
41	SPACER; FINAL DRIVE PINION BRG T=8.000	1-41229-103-0	AR	1	0302-	●
41	SPACER; FINAL DRIVE PINION BRG T=8.200	1-41229-104-0	AR	1	0302-	●
41	SPACER; FINAL DRIVE PINION BRG T=8.400	1-41229-105-0	AR	1	0302-	●
43	CAGE; FINAL PINION T=75	1-41151-005-0	01	1	0302-	●
43	CAGE; FINAL PINION	1-41151-027-0	01	1	9905-		●	●
45	BOLT; FINAL PINION CAGE M14X50	0-16806-450-0	08	1	0302-	●
45	BOLT; FINAL PINION CAGE M12X40	9-02361-240-0	06	1	9905-		●	●
48	WASHER; LK,FINAL PINION ID=14.2	9-09150-514-0	08	1	0302-0603	●
48	WASHER; LK,FINAL PINION ID=14.2	0-91510-514-0	08	1	0604-	●
48	WASHER; LK,FINAL PINION ID=12.2	9-09150-512-0	06	1	9905-0603		●	●
48	WASHER; LK,FINAL PINION ID=12.2	0-91510-512-0	06	1	0604-		●	●
49	SHIM; FINAL PINION CAGE T=1.000	1-41154-009-0	AR	1	0302-	●
49	SHIM; FINAL PINION CAGE T=0.500	1-41154-010-0	AR	1	0302-	●
49	SHIM; FINAL PINION CAGE T=0.300	1-41154-104-0	AR	1	0302-	●
49	SHIM; FINAL PINION CAGE T=0.400	1-41154-105-0	AR	1	0302-	●
49	SHIM; FINAL PINION CAGE T=0.50	1-41154-021-1	AR	1	9905-		●	●
49	SHIM; FINAL PINION CAGE T=0.30	1-41154-051-1	AR	1	9905-		●	●
49	SHIM; FINAL PINION CAGE T=0.40	1-41154-052-1	AR	1	9905-		●	●
49	SHIM; FINAL PINION CAGE T=1.00	1-41154-053-1	AR	1	9905-		●	●
50	BEARING; FINAL PINION KOYO	1-09812-042-1	01	1	0612-		●	●
50	BEARING; FINAL PINION NTN	1-09812-013-0	01	1	0302-	●
50	BEARING; FINAL PINION KOYO	1-09812-070-1	01	1	0302-	●
50	BEARING; FINAL PINION NSK	1-09812-041-2	01	1	9905-		●	●
55	CARRIER; DIFF	1-41110-120-1	01	1	0302-	●
55	CARRIER; DIFF	1-41110-048-1	01	1	9905-		●	●
56	BOLT; BRG CAP M20X112	1-09070-042-0	04	1	0302-	●
56	BOLT; BRG CAP M16X100	9-91661-600-0	04	1	9905-0104		●	●
56	BOLT; BRG CAP M16X100 FLANGE	1-09070-047-0	04	1	0105-		●	●
60	GEAR SET; FINAL DRIVE,RR 39/6	1-41210-371-2	01	1	0302-	●
60	GEAR SET; FINAL DRIVE,RR 39/7	1-41210-391-2	01	1	9905-		●
60	GEAR SET; FINAL DRIVE,RR 41/8	1-41210-453-0	01	1	9905-			●
61	RETAINER; PILOT BRG,PINION T=3.2	1-41227-015-0	02	1	0302-	●
61	RETAINER; PILOT BRG,PINION T=2.3	1-41227-006-0	02	1	9905-		●	●
62	BOLT; RET M8X38 W/PIN HOLE	1-09042-036-0	02	1	0302-	●
62	BOLT; RET M8X35 W/PIN HOLE	1-09042-034-0	02	1	9905-		●	●
63	BEARING; PINION PILOT KOYO	1-09810-229-2	01	1	0302-	●
63	BEARING; PINION PILOT NSK	1-09810-230-1	01	1	0302-	●
63	BEARING; PINION PILOT NSK	1-09810-073-2	01	1	9905-		●	●
63	BEARING; PINION PILOT KOYO	1-09810-074-1	01	1	9905-		●	●
64	NUT; RET M8 SLOTTED	9-09117-508-0	02	1	9905-0301		●	●
64	NUT; RET M8 SLOTTED	9-09117-508-0	02	1	0302-0512	●	●	●
64	NUT; RET M8 SLOTTED	0-91117-508-0	02	1	0601-	●	●	●
65	PIN; SPLIT,RET	9-08112-012-0	02	1	9905-0301		●	●
65	PIN; SPLIT,RET	9-08112-012-0	02	1	0302-	●	●	●
66	RING; SNAP,PILOT BRG OD=42	9-09950-179-0	01	1	0302-	●
66	RING; SNAP,PILOT BRG OD=34.2	1-09588-066-1	01	1	9905-		●	●
69	NUT; ADJ,DIFF CAGE	1-41121-001-0	01	1	0302-	●
69	NUT; ADJ,DIFF CAGE	1-41121-002-0	01	1	0302-	●
69	NUT; ADJ,DIFF CAGE M128 H=22	1-41121-013-0	01	1	9905-		●	●
69	NUT; ADJ,DIFF CAGE M128 H=30	1-41121-015-0	01	1	9905-		●	●
70	BEARING; DIFF CAGE KOYO ID=92 OD=152 T=40	1-09812-225-0	02	1	0302-	●
70	BEARING; DIFF CAGE NSK ID=70 OD=125 T=26.3	1-09812-058-1	01	1	9905-		●	●
70	BEARING; DIFF CAGE NSK ID=70 OD=125 T=33.3	1-09812-056-1	01	1	9905-		●	●
70	BEARING; DIFF CAGE KOYO ID=70 OD=125 T=33.3	1-09812-062-2	01	1	9911-		●	●
70	BEARING; DIFF CAGE KOYO ID=70 OD=125 T=26.3	1-09812-063-1	01	1	9911-		●	●
71	CAGE ASM; DIFF,FINAL DRIVE	1-41510-270-0	01	1	0302-	●
71	CAGE ASM; DIFF,FINAL DRIVE	1-41510-112-0	01	1	9905-		●	●
84	BOLT; FINAL DRIVE GEAR M16X37.5 FLANGE	1-09020-167-0	16	1	0302-	●
84	BOLT; FINAL DRIVE GEAR M16X34.5 FLANGE	9-09802-575-1	16	1	9905-		●	●
85	NUT; DIFF CAGE SETTING M14	1-09400-077-1	12	1	0302-	●
85	NUT; DIFF CAGE SETTING M14	1-09400-077-1	08	1	9905-		●	●
88	PLATE; LK,ADJ NUT (C) T=3.2	1-41124-006-0	02	1	0302-	●
88	PLATE; LK,ADJ NUT (A) T=1.0	9-41124-005-0	02	1	9905-0301		●	●
88	PLATE; LK,ADJ NUT (A) T=1.0	9-41124-005-0	02	1	0302-	●	●	●
88	PLATE; LK,ADJ NUT (B) T=2.3	9-41124-015-0	02	1	9905-		●	●
89	BOLT; LK PLATE M8X16	0-20800-816-0	04	1	9905-0301		●	●
89	BOLT; LK PLATE M8X16	0-20800-816-0	04	1	0302-0512	●	●	●
89	BOLT; LK PLATE M8X16	0-20850-816-0	04	1	0601-	●	●	●
100	SEAL; OIL,FINAL PINION NOK	1-09625-017-0	01	1	0302-	●
100	SEAL; OIL,FINAL PINION TKK	1-09625-432-0	01	1	9905-9908		●	●
100	SEAL; OIL,FINAL PINION TKK	1-09625-637-0	01	1	9909-		●	●
100	SEAL; OIL,FINAL PINION NOK	1-09625-484-1	01	1	9905-		●	●
126	COUPLING; DRIVING PINION	1-37245-403-0	01	1	0302-	●
126	COUPLING; DRIVING PINION	1-37245-069-6	01	1	9905-		●	●

1 4 45 37 48 126 40 40 100 39 49 49 49 164 43 50 62 61 64 55 63 61 66 56 65 134 69 60 70 88 88 85 89 20 25 24 24 25 21 20 21 24 85 17 25 22 24 25 70 71 84 69 17

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	DRIVE ASM; FINAL,RR 39/6	1-41000-380-0	01	1	0302-	●
1	DRIVE ASM; FINAL,RR 39/7	1-41001-133-0	01	1	9905-		●
1	DRIVE ASM; FINAL,RR 41/8	1-41001-682-0	01	1	9905-			●
4	GASKET; FLANGE,FINAL PINION ID=42	9-09921-116-0	01	1	0302-	●
4	GASKET; FLANGE,FINAL PINION ID=37.5 T=4	1-09623-582-0	01	1	9905-		●	●
17	BOLT; DIFF CAGE SETTING (A) M14X121 FLANGE	1-09044-006-0	08	1	0302-	●
17	BOLT; DIFF CAGE SETTING (A) M14X121 FLANGE	1-09044-006-0	04	1	9905-		●	●
17	BOLT; DIFF CAGE SETTING (B) M14X95 FLANGE	1-09044-007-0	04	1	9905-0301		●	●
17	BOLT; DIFF CAGE SETTING (B) M14X95 FLANGE	1-09044-007-0	04	1	0302-	●	●	●
20	WASHER; THRUST,SIDE GEAR T=2.80	1-41562-169-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=2.90	1-41562-170-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=3.00	1-41562-171-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=3.10	1-41562-172-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=3.20	1-41562-173-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=3.30	1-41562-174-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=3.40	1-41562-175-0	AR	1	0302-	●
20	WASHER; THRUST,SIDE GEAR T=2.80	1-41562-061-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=3.00	1-41562-062-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=3.20	1-41562-063-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=3.40	1-41562-064-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=2.90	1-41562-080-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=3.10	1-41562-081-0	AR	1	9905-		●	●
20	WASHER; THRUST,SIDE GEAR T=3.30	1-41562-082-0	AR	1	9905-		●	●
21	GEAR; SIDE,DIFF Z=16	1-41561-076-0	02	1	0302-0405	●
21	GEAR; SIDE,DIFF Z=16	1-41561-123-0	02	1	0406-	●
21	GEAR; SIDE,DIFF Z=16	1-41561-107-0	02	1	9905-0407		●	●
21	GEAR; SIDE,DIFF Z=16	1-41561-135-0	02	1	0408-		●	●
22	PIN; CROSS,DIFF PINION OD=32	1-41521-002-1	01	1	0302-	●
22	PIN; CROSS,DIFF PINION	1-41521-050-2	01	1	9905-		●	●
24	GEAR; PINION,DIFF Z=10	1-41551-022-0	04	1	0302-0405	●
24	GEAR; PINION,DIFF Z=10	1-41551-040-0	04	1	0406-	●
24	GEAR; PINION,DIFF Z=10	1-41551-032-0	04	1	9905-0407		●	●
24	GEAR; PINION,DIFF Z=10	1-41551-042-0	04	1	0408-		●	●
25	WASHER; THRUST,PINION T=1.6	1-41552-001-0	04	1	0302-	●
25	WASHER; THRUST,PINION ID=29 OD=60	1-41562-119-0	04	1	9905-		●	●
37	NUT; DRIVING PINION M39 FLANGE	1-09449-056-2	01	1	0302-	●
37	NUT; DRIVING PINION M36 FLANGE	1-09449-058-2	01	1	9905-		●	●
39	BEARING; FINAL PINION NSK	1-09812-086-0	01	1	0302-	●
39	BEARING; FINAL PINION NTN	9-00093-072-1	01	1	0302-	●
39	BEARING; FINAL PINION KOYO	9-00093-206-2	01	1	0302-	●
39	BEARING; FINAL PINION NSK	1-09812-026-0	01	1	9905-		●	●
40	SHIM; FINAL PINION T=3.50	1-41229-106-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.51	1-41229-107-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.52	1-41229-108-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.53	1-41229-109-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.54	1-41229-110-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.55	1-41229-111-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.56	1-41229-112-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.57	1-41229-113-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.58	1-41229-114-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.59	1-41229-115-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=3.60	1-41229-116-0	AR	1	0302-	●
40	SHIM; FINAL PINION T=1.60	1-41229-179-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.61	1-41229-180-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.62	1-41229-181-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.63	1-41229-182-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.64	1-41229-183-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.65	1-41229-184-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.66	1-41229-185-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.67	1-41229-186-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.68	1-41229-187-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.69	1-41229-188-0	AR	1	9905-		●	●
40	SHIM; FINAL PINION T=1.70	1-41229-189-0	AR	1	9905-		●	●
43	CAGE; FINAL PINION T=75	1-41151-005-0	01	1	0302-	●
43	CAGE; FINAL PINION	1-41151-027-0	01	1	9905-		●	●
45	BOLT; FINAL PINION CAGE M14X50	0-16806-450-0	08	1	0302-	●
45	BOLT; FINAL PINION CAGE M12X40	9-02361-240-0	06	1	9905-		●	●
48	WASHER; LK,FINAL PINION ID=14.2	9-09150-514-0	08	1	0302-0603	●
48	WASHER; LK,FINAL PINION ID=14.2	0-91510-514-0	08	1	0604-	●
48	WASHER; LK,FINAL PINION ID=12.2	9-09150-512-0	06	1	9905-0603		●	●
48	WASHER; LK,FINAL PINION ID=12.2	0-91510-512-0	06	1	0604-		●	●
49	SHIM; FINAL PINION CAGE T=1.000	1-41154-009-0	AR	1	0302-	●
49	SHIM; FINAL PINION CAGE T=0.500	1-41154-010-0	AR	1	0302-	●
49	SHIM; FINAL PINION CAGE T=0.300	1-41154-104-0	AR	1	0302-	●
49	SHIM; FINAL PINION CAGE T=0.400	1-41154-105-0	AR	1	0302-	●
49	SHIM; FINAL PINION CAGE T=0.50	1-41154-021-1	AR	1	9905-		●	●
49	SHIM; FINAL PINION CAGE T=0.30	1-41154-051-1	AR	1	9905-		●	●
49	SHIM; FINAL PINION CAGE T=0.40	1-41154-052-1	AR	1	9905-		●	●
49	SHIM; FINAL PINION CAGE T=1.00	1-41154-053-1	AR	1	9905-		●	●
50	BEARING; FINAL PINION KOYO	1-09812-042-1	01	1	0612-		●	●
50	BEARING; FINAL PINION NTN	1-09812-013-0	01	1	0302-	●
50	BEARING; FINAL PINION KOYO	1-09812-070-1	01	1	0302-	●
50	BEARING; FINAL PINION NSK	1-09812-041-2	01	1	9905-		●	●
55	CARRIER; DIFF	1-41110-120-1	01	1	0302-	●
55	CARRIER; DIFF	1-41110-048-1	01	1	9905-		●	●
56	BOLT; BRG CAP M20X112	1-09070-042-0	04	1	0302-	●
56	BOLT; BRG CAP M16X100	9-91661-600-0	04	1	9905-0104		●	●
56	BOLT; BRG CAP M16X100 FLANGE	1-09070-047-0	04	1	0105-		●	●
60	GEAR SET; FINAL DRIVE,RR 39/6	1-41210-371-2	01	1	0302-	●
60	GEAR SET; FINAL DRIVE,RR 39/7	1-41210-391-2	01	1	9905-		●
60	GEAR SET; FINAL DRIVE,RR 41/8	1-41210-453-0	01	1	9905-			●
61	RETAINER; PILOT BRG,PINION T=3.2	1-41227-015-0	02	1	0302-	●
61	RETAINER; PILOT BRG,PINION T=2.3	1-41227-006-0	02	1	9905-		●	●
62	BOLT; RET M8X38 W/PIN HOLE	1-09042-036-0	02	1	0302-	●
62	BOLT; RET M8X35 W/PIN HOLE	1-09042-034-0	02	1	9905-		●	●
63	BEARING; PINION PILOT KOYO	1-09810-229-2	01	1	0302-	●
63	BEARING; PINION PILOT NSK	1-09810-230-1	01	1	0302-	●
63	BEARING; PINION PILOT NSK	1-09810-073-2	01	1	9905-		●	●
63	BEARING; PINION PILOT KOYO	1-09810-074-1	01	1	9905-		●	●
64	NUT; RET M8 SLOTTED	9-09117-508-0	02	1	9905-0301		●	●
64	NUT; RET M8 SLOTTED	9-09117-508-0	02	1	0302-0512	●	●	●
64	NUT; RET M8 SLOTTED	0-91117-508-0	02	1	0601-	●	●	●
65	PIN; SPLIT,RET	9-08112-012-0	02	1	9905-0301		●	●
65	PIN; SPLIT,RET	9-08112-012-0	02	1	0302-	●	●	●
66	RING; SNAP,PILOT BRG OD=42	9-09950-179-0	01	1	0302-	●
66	RING; SNAP,PILOT BRG OD=34.2	1-09588-066-1	01	1	9905-		●	●
69	NUT; ADJ,DIFF CAGE	1-41121-001-0	01	1	0302-	●
69	NUT; ADJ,DIFF CAGE	1-41121-002-0	01	1	0302-	●
69	NUT; ADJ,DIFF CAGE M128 H=22	1-41121-013-0	01	1	9905-		●	●
69	NUT; ADJ,DIFF CAGE M128 H=30	1-41121-015-0	01	1	9905-		●	●
70	BEARING; DIFF CAGE KOYO ID=92 OD=152 T=40	1-09812-225-0	02	1	0302-	●
70	BEARING; DIFF CAGE NSK ID=70 OD=125 T=26.3	1-09812-058-1	01	1	9905-		●	●
70	BEARING; DIFF CAGE NSK ID=70 OD=125 T=33.3	1-09812-056-1	01	1	9905-		●	●
70	BEARING; DIFF CAGE KOYO ID=70 OD=125 T=33.3	1-09812-062-2	01	1	9911-		●	●
70	BEARING; DIFF CAGE KOYO ID=70 OD=125 T=26.3	1-09812-063-1	01	1	9911-		●	●
71	CAGE ASM; DIFF,FINAL DRIVE	1-41510-270-0	01	1	0302-	●
71	CAGE ASM; DIFF,FINAL DRIVE	1-41510-112-0	01	1	9905-		●	●
84	BOLT; FINAL DRIVE GEAR M16X37.5 FLANGE	1-09020-167-0	16	1	0302-	●
84	BOLT; FINAL DRIVE GEAR M16X34.5 FLANGE	9-09802-575-1	16	1	9905-		●	●
85	NUT; DIFF CAGE SETTING M14	1-09400-077-1	12	1	0302-	●
85	NUT; DIFF CAGE SETTING M14	1-09400-077-1	08	1	9905-		●	●
88	PLATE; LK,ADJ NUT (C) T=3.2	1-41124-006-0	02	1	0302-	●
88	PLATE; LK,ADJ NUT (A) T=1.0	9-41124-005-0	02	1	9905-0301		●	●
88	PLATE; LK,ADJ NUT (A) T=1.0	9-41124-005-0	02	1	0302-	●	●	●
88	PLATE; LK,ADJ NUT (B) T=2.3	9-41124-015-0	02	1	9905-		●	●
89	BOLT; LK PLATE M8X16	0-20800-816-0	04	1	9905-0301		●	●
89	BOLT; LK PLATE M8X16	0-20800-816-0	04	1	0302-0512	●	●	●
89	BOLT; LK PLATE M8X16	0-20850-816-0	04	1	0601-	●	●	●
100	SEAL; OIL,FINAL PINION NOK	1-09625-017-0	01	1	0302-	●
100	SEAL; OIL,FINAL PINION TKK	1-09625-432-0	01	1	9905-9908		●	●
100	SEAL; OIL,FINAL PINION TKK	1-09625-637-0	01	1	9909-		●	●
100	SEAL; OIL,FINAL PINION NOK	1-09625-484-1	01	1	9905-		●	●
126	COUPLING; DRIVING PINION	1-37245-403-0	01	1	0302-	●
126	COUPLING; DRIVING PINION	1-37245-069-6	01	1	9905-		●	●
134	WASHER; LK,BRG CAP ID=16.2	9-09150-516-0	04	1	9905-0104		●	●
164	COLLAR; DIST,PINION T=10.7	1-36355-031-0	01	1	9905-		●	●
164	COLLAR; DIST,PINION T=10.90	1-36355-033-0	01	1	9905-		●	●
164	COLLAR; DIST,PINION T=11.10	1-36355-035-0	01	1	9905-		●	●
164	COLLAR; DIST,PINION T=11.30	1-36355-037-0	01	1	9905-		●	●
164	COLLAR; DIST,PINION T=11.50	1-36355-039-0	01	1	9905-		●	●
164	COLLAR; DIST,PINION T=11.70	1-36355-041-0	01	1	9905-		●	●
164	COLLAR; DIST,PINION T=11.9	1-36355-043-0	01	1	9905-		●	●
164	COLLAR; DIST,PINION T=12.10	1-36355-045-0	01	1	9905-		●	●
164	COLLAR; DIST,PINION T=12.30	1-36355-047-0	01	1	9905-		●	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
