Isuzu WW
▶
TRUCKS
▶
NLR
▶
51275 - NLR/NMR(85) AUST/NZ EURO5
▶
8 - Chassis Electrical, Heating / Air Conditioning, Wipers, Radio
▶
8-26 - ELECTRICAL CONTROL AND OTHER PARTS
▶
8-26 — ELECTRICAL CONTROL AND OTHER PARTS
(#78216) — 42 parça
Tümü
A - NMR5SE
B - NMR5SN
◀
[826A] NO.1 (18 parça)
[826A] NO.2 (9 parça)
[826A] NO.3 (15 parça)
▶
68
67
446
67
67
305
305
69
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
67
03.887 BRACKET; CONT UNIT
CAN INTERFACE FMS STD(8PG) (C)
8-98203-991-0
01
1
1112-1208
●
●
67
03.887 BRACKET; CONT UNIT
CAN INTERFACE FMS STD(8PG) (E)
8-98222-208-0
01
1
1209-
●
●
67
03.887 BRACKET; CONT UNIT
(A)
8-98022-170-1
01
1
1009-
●
●
67
03.887 BRACKET; CONT UNIT
(B)
8-98022-206-2
01
1
1009-1111
●
●
67
03.887 BRACKET; CONT UNIT
(D)
8-98203-057-0
01
1
1112-1207
●
●
67
03.887 BRACKET; CONT UNIT
(D)
8-98217-377-0
01
1
1208-1212
●
●
67
03.887 BRACKET; CONT UNIT
(D)
8-98237-555-0
01
1
1301-1404
●
●
67
03.887 BRACKET; CONT UNIT
(D)
8-98217-377-0
01
1
1405-
●
●
68
02.500 BOLT; BRKT
CAN INTERFACE FMS STD(8PG) 16.100 (B) M5X20 HEXALOBULAR SOCKET
8-98177-743-0
04
1
1112-1212
●
●
68
02.500 BOLT; BRKT
CAN INTERFACE FMS STD(8PG) 09.647 (B) M5X20 TAPPING HEXALOBULAR
0-72180-520-0
04
1
1301-
●
●
68
02.500 BOLT; BRKT
00.206 (A) M6X12 FLANGE
0-28450-612-0
01
1
1009-
●
●
69
02.458 NUT; BRKT
01.062 M6 FLANGE
0-91180-106-0
02
1
1009-
●
●
305
08.915 NUT; CONT UNIT
H.S.A SYSTEM<6EP> 01.062 (B) M6 FLANGE
0-91180-106-0
02
1
1009-
●
305
08.915 NUT; CONT UNIT
01.062 (B) M6 FLANGE
0-91180-106-0
02
1
1009-
●
305
08.915 NUT; CONT UNIT
TRANSMISSION CONTROL-SMOOTHER(8GF) 00.777 (A) M8 W/LK WASHER
8-94279-050-0
02
1
1009-
●
305
08.915 NUT; CONT UNIT
01.062 (B) M6 FLANGE
0-91180-106-0
01
1
1009-
●
●
446
02.510 CONTROL UNIT; HSA
H.S.A SYSTEM<6EP>
8-98046-563-1
01
1
1009-
●
446
02.510 CONTROL UNIT; HSA
8-98046-563-1
01
1
1009-
●
448
744
737
305
1
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
09.709 LIGHTER; CIGAR
8-98142-962-0
01
1
1009-
●
●
305
08.915 NUT; CONT UNIT
H.S.A SYSTEM<6EP> 01.062 (B) M6 FLANGE
0-91180-106-0
02
1
1009-
●
305
08.915 NUT; CONT UNIT
01.062 (B) M6 FLANGE
0-91180-106-0
02
1
1009-
●
305
08.915 NUT; CONT UNIT
TRANSMISSION CONTROL-SMOOTHER(8GF) 00.777 (A) M8 W/LK WASHER
8-94279-050-0
02
1
1009-
●
305
08.915 NUT; CONT UNIT
01.062 (B) M6 FLANGE
0-91180-106-0
01
1
1009-
●
●
448
02.500 BOLT; SENSOR
AIR BAG DRIVER & PASSENGER<AK5> 06.870 M6X18 W/PL WASHER
8-97105-796-1
02
1
1009-
●
●
737
04.115 CONTROL UNIT; TRANSMISSION
TRANSMISSION CONTROL-SMOOTHER(8GF)
8-98106-133-9
01
1
1009-1211
●
737
04.115 CONTROL UNIT; TRANSMISSION
TRANSMISSION CONTROL-SMOOTHER(8GF)
8-98223-000-2
01
1
1212-
●
744
03.682 SENSOR; AIR BAG
AIR BAG DRIVER & PASSENGER<AK5>
8-97386-841-2
01
1
1009-
●
●
700
21
68
68
67
67
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
21
09.744 COVER; HOLE
16.081
8-98025-954-1
01
1
1009-
●
●
21
09.744 COVER; HOLE
16.081
8-98025-954-1
02
1
1009-
●
●
67
03.887 BRACKET; CONT UNIT
CAN INTERFACE FMS STD(8PG) (C)
8-98203-991-0
01
1
1112-1208
●
●
67
03.887 BRACKET; CONT UNIT
CAN INTERFACE FMS STD(8PG) (E)
8-98222-208-0
01
1
1209-
●
●
67
03.887 BRACKET; CONT UNIT
(A)
8-98022-170-1
01
1
1009-
●
●
67
03.887 BRACKET; CONT UNIT
(B)
8-98022-206-2
01
1
1009-1111
●
●
67
03.887 BRACKET; CONT UNIT
(D)
8-98203-057-0
01
1
1112-1207
●
●
67
03.887 BRACKET; CONT UNIT
(D)
8-98217-377-0
01
1
1208-1212
●
●
67
03.887 BRACKET; CONT UNIT
(D)
8-98237-555-0
01
1
1301-1404
●
●
67
03.887 BRACKET; CONT UNIT
(D)
8-98217-377-0
01
1
1405-
●
●
68
02.500 BOLT; BRKT
CAN INTERFACE FMS STD(8PG) 16.100 (B) M5X20 HEXALOBULAR SOCKET
8-98177-743-0
04
1
1112-1212
●
●
68
02.500 BOLT; BRKT
CAN INTERFACE FMS STD(8PG) 09.647 (B) M5X20 TAPPING HEXALOBULAR
0-72180-520-0
04
1
1301-
●
●
68
02.500 BOLT; BRKT
00.206 (A) M6X12 FLANGE
0-28450-612-0
01
1
1009-
●
●
700
02.510 CONTROL UNIT; CAN CONVERTER
CAN INTERFACE FMS STD(8PG)
8-98188-383-0
01
1
1112-1204
●
●
700
02.510 CONTROL UNIT; CAN CONVERTER
CAN INTERFACE FMS STD(8PG)
8-98219-812-1
01
1
1205-
●
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
