◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ NP ▶ 51266 - NP/NQR(LHD)EU4 W/DOC ▶ 7 - Interior Trim, Emblems / Labels, Seats, Mirrors ▶ 7-10 - CAUTION PLATE AND LABEL ▶
7-10 — CAUTION PLATE AND LABEL (#77892) — 41 parça
çizim 186888
306 190 4 4 5 5 35
BalonParca AdiParca NoAdetTipApplied Date A B
4 00.004 LABEL; ENG MAINTENANCE
4JJ1-TCC ENG(RDU) CAUTION SPANISH<YN1> (B) 		8-98030-803-1 01 1 1209- ●
4 00.004 LABEL; ENG MAINTENANCE
4JJ1-TCC ENG(RDU) EXC. CAUTION SPANISH<YN1> (A) 		8-98030-757-0 01 1 1209- ●
4 00.004 LABEL; ENG MAINTENANCE
4HK1-TCN ENG(RDQ) CAUTION SPANISH<YN1> (B) 		8-98013-424-0 01 1 1010-1108 ● ●
4 00.004 LABEL; ENG MAINTENANCE
4HK1-TCN ENG(RDQ),4HK1-TCS ENG(RJS) CAUTION SPANISH<YN1> (B) 		8-98013-424-0 01 1 1109- ● ●
4 00.004 LABEL; ENG MAINTENANCE
4HK1-TCN ENG(RDQ) EXC. CAUTION SPANISH<YN1> (A) 		8-98013-423-0 01 1 1010-1108 ● ●
4 00.004 LABEL; ENG MAINTENANCE
4HK1-TCN ENG(RDQ),4HK1-TCS ENG(RJS) EXC. CAUTION SPANISH<YN1> (A) 		8-98013-423-0 01 1 1109- ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
FRT&RR 215/75R17.5 17.5X6.00-127 SILVER(CQU) CAUTION SPANISH<YN1> (A) 		8-97188-835-0 01 1 1010-1102 ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
FRT&RR 215/75R17.5 RIB&LUG 17.5X6.00-127B LACK(CQB),FRT&RR 215/75R17.5 RIB 17.5X6.00-127 BLACK(CQC),FRT&RR 215/75R17.5 17.5X 6.00-127 SILVER(CQU),F&R 215/75R17.5(MICHELIN)17.5X6.00-127 SILVER(CRV) CAUTION SPANISH<YN1> (A) 		8-97188-835-0 01 1 1103- ●
5 05.880 LABEL; TIRE AIR PRESSURE
FRT&RR 215/75R17.5 17.5X6.00-127 SILVER(CQU) CAUTION SPANISH<YN1> (A) 		8-97188-835-0 01 1 1103- ●
5 05.880 LABEL; TIRE AIR PRESSURE
FRT&RR 215/75R17.5 17.5X6.00-127 SILVER(CQU) EXC. CAUTION SPANISH<YN1> (B) 		8-97188-834-0 01 1 1010-1102 ● ●
5 05.880 LABEL; TIRE AIR PRESSURE
FRT&RR 215/75R17.5 RIB&LUG 17.5X6.00-127B LACK(CQB),FRT&RR 215/75R17.5 RIB 17.5X6.00-127 BLACK(CQC),FRT&RR 215/75R17.5 17.5X 6.00-127 SILVER(CQU),F&R 215/75R17.5(MICHELIN)17.5X6.00-127 SILVER(CRV) EXC. CAUTION SPANISH<YN1> (B) 		8-97188-834-0 01 1 1103- ●
5 05.880 LABEL; TIRE AIR PRESSURE
FRT&RR 215/75R17.5 17.5X6.00-127 SILVER(CQU) EXC. CAUTION SPANISH<YN1> (B) 		8-97188-834-0 01 1 1103- ●
35 08.808 PLATE; CAUTION,CAB
MANUAL TILT CAB<RWZ> CAUTION SPANISH<YN1> 		8-98070-512-0 01 1 1103-1108 ●
35 08.808 PLATE; CAUTION,CAB
MANUAL TILT CAB<RWZ> CAUTION SPANISH<YN1> 		8-98070-512-0 01 1 1109- ● ●
35 08.808 PLATE; CAUTION,CAB
MANUAL TILT CAB<RWZ> EXC. CAUTION SPANISH<YN1> 		8-98067-809-0 01 1 1103-1108 ●
35 08.808 PLATE; CAUTION,CAB
MANUAL TILT CAB<RWZ> EXC. CAUTION SPANISH<YN1> 		8-98067-809-0 01 1 1109- ● ●
190 08.808 PLATE; CAUTION,OIL CHANGE
4HK1-TCN ENG(RDQ),4HK1-TCS ENG(RJS) REAR AXLE HEAVY DUTY 320MM(6CP) FINAL GEAR RATIO 41/10(GT5) 4 WHEEL ANTI LOCK BRAKE<JE5> G.V.W. 7.5-8.0TON(RPY) LIMITED SLIP DIFF<6LV> HYDRO BRAKE BOOSTER(7QQ) EXC. DRIVE GEAR NOISE CONTROL<8KU> 		8-97200-740-0 01 1 1209- ●
306 08.808 LABEL; BEAM & PASS 8-98070-239-0 01 1 1010- ● ●
çizim 186889
49 234 310
BalonParca AdiParca NoAdetTipApplied Date A B
49 08.808 PLATE; CAUTION,FUSE BOX 8-98090-175-0 01 1 1010- ● ●
234 08.808 PLATE; CAUTION,ENG COVER
CAUTION SPANISH<YN1> 		8-98071-067-0 01 1 1010-1102 ● ●
234 08.808 PLATE; CAUTION,ENG COVER
CAUTION SPANISH<YN1> INSPECTION ENGINE COVER<8GA> 		8-98071-067-0 01 1 1103-1108 ●
234 08.808 PLATE; CAUTION,ENG COVER
CAUTION SPANISH<YN1> 		8-98071-067-0 01 1 1103-1108 ●
234 08.808 PLATE; CAUTION,ENG COVER
CAUTION SPANISH<YN1> INSPECTION ENGINE COVER<8GA> 		8-98071-067-0 01 1 1109- ● ●
234 08.808 PLATE; CAUTION,ENG COVER
EXC. CAUTION SPANISH<YN1> 		8-97994-545-0 01 1 1010-1102 ● ●
234 08.808 PLATE; CAUTION,ENG COVER
INSPECTION ENGINE COVER<8GA> EXC. CAUTION SPANISH<YN1> 		8-97994-545-0 01 1 1103-1108 ●
234 08.808 PLATE; CAUTION,ENG COVER
EXC. CAUTION SPANISH<YN1> 		8-97994-545-0 01 1 1103-1108 ●
234 08.808 PLATE; CAUTION,ENG COVER
INSPECTION ENGINE COVER<8GA> EXC. CAUTION SPANISH<YN1> 		8-97994-545-0 01 1 1109- ● ●
310 08.808 LABEL; WARNING,SRS
AIR BAG DRIVER<AJ3> CAUTION SPANISH<YN1> 		8-98224-287-0 01 1 1211- ● ●
310 08.808 LABEL; WARNING,SRS
AIR BAG DRIVER<AJ3> EXC. CAUTION SPANISH<YN1> 		8-98139-964-0 01 1 1211- ● ●
çizim 186918
48 9 84
BalonParca AdiParca NoAdetTipApplied Date A B
9 08.808 PLATE; NAME,SPD RANGE
4HK1-TCN ENG(RDQ) FRT&RR 215/75R17.5 RIB&LUG 17.5X6.00-127B LACK(CQB),FRT&RR 215/75R17.5 RIB 17.5X6.00-127 BLACK(CQC),FRT&RR 215/75R17.5 17.5X 6.00-127 SILVER(CQU),F&R 215/75R17.5(MICHELIN)17.5X6.00-127 SILVER(CRV) MOROCCO EQUIPMENT(CGA) SPEED LIMITER 90KM(NMJ) 		8-98315-801-0 01 1 1504- ●
9 08.808 PLATE; NAME,SPD RANGE
4JJ1-TCC ENG(RDU) FRT&RR TIRE 205/85R16 DISC 16-5.5J-116.5(CSB) MOROCCO EQUIPMENT(CGA) SPEED LIMITER 90KM(NMJ) 		8-98315-800-0 01 1 1504- ●
48 08.808 PLATE; CAUTION,PTO
CAUTION SPANISH<YN1> PTO MANUAL CONTROL(6WC) 		8-94313-054-0 01 1 1103-1108 ●
48 08.808 PLATE; CAUTION,PTO
CAUTION SPANISH<YN1> PTO MANUAL CONTROL(6WC) 		8-94313-054-0 01 1 1109- ● ●
48 08.808 PLATE; CAUTION,PTO
PTO MANUAL CONTROL(6WC) EXC. CAUTION SPANISH<YN1> 		8-94469-277-0 01 1 1103-1108 ●
48 08.808 PLATE; CAUTION,PTO
PTO MANUAL CONTROL(6WC) EXC. CAUTION SPANISH<YN1> 		8-94469-277-0 01 1 1109- ● ●
84 08.808 PLATE; CAUTION,BRAKE FLUID
RUSSIA EQUIPMENT(B12) 		8-98022-836-1 01 1 1103-1408 ●
84 08.808 PLATE; CAUTION,BRAKE FLUID
RUSSIA EQUIPMENT(B12),MOROCCO EQUIPMENT(CGA) 		8-98022-836-1 01 1 1409- ●
çizim 292164
96 2
BalonParca AdiParca NoAdetTipApplied Date A B
2 03.680 LABEL; FUEL CAUTION
4JJ1-TCC ENG(RDU) CAUTION SPANISH<YN1> 		8-98083-876-0 01 1 1209- ●
2 03.680 LABEL; FUEL CAUTION
4JJ1-TCC ENG(RDU) EXC. CAUTION SPANISH<YN1> 08.808 		8-98036-252-0 01 1 1209- ●
96 08.808 PLATE; CAUTION,ENGINE OIL
4JJ1-TCC ENG(RDU) CAUTION SPANISH<YN1> 		8-98036-733-0 01 1 1209- ●
96 08.808 PLATE; CAUTION,ENGINE OIL
4JJ1-TCC ENG(RDU) EXC. CAUTION SPANISH<YN1> 		8-98036-732-0 01 1 1209- ●
