Isuzu WW
▶
TRUCKS
▶
NPR
▶
51259 - NPR CNG-RHD
▶
0 - Engine, Emission, Engine Electrical
▶
0-61 - BATTERY AND ENGINE ELECTRICAL PARTS
▶
0-61 — BATTERY AND ENGINE ELECTRICAL PARTS
(#76731) — 15 parça
3
37
31
112
3
58
1
6
5
42
225
30
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
02.341 CABLE; BATTERY
L=280
8-98081-510-0
01
1
0907-
3
02.525 HARNESS; CABLE,BATTERY TO STARTE
(A)
8-98081-472-1
01
1
0907-1409
3
02.525 HARNESS; CABLE,BATTERY TO STARTE
(A)
8-98293-919-0
01
1
1410-
3
02.525 HARNESS; CABLE,BATTERY TO STARTE
(B)
8-98081-560-2
01
1
0907-
5
02.559 CLIP; BATTERY CABLE TO BODY
03.162 L=140
5-09707-031-1
01
1
0907-
6
02.343 GROMMET; BATTERY CABLE
03.162
8-98038-801-0
01
1
0907-
30
02.334 NUT; CABLE,STARTER TO BATTERY
M8
0-91110-508-0
01
1
0907-
31
02.334 WASHER; LK,CABLE,STARTER TO BATT
02.559 ID=8.2
0-91510-808-0
01
1
0907-
37
02.343 CAP; TERMINAL,BATTERY CABLE
8-98042-507-0
01
1
0907-
42
02.343 BOLT; BRKT,BATTERY CABLE
02.500 M6X16 FLANGE
8-97329-599-0
01
1
0907-
58
02.343 BOLT; CABLE,BATTERY
M8X25 W/LK&PL WASHER
8-97087-203-0
01
1
0907-1004
58
02.343 BOLT; CABLE,BATTERY
M8X24 W/PL WASHER
8-98141-256-1
01
1
1005-
112
02.343 TERMINAL; BATTERY
8-97365-770-0
01
1
0907-
225
02.343 BLOCK; TERMINAL
8-98029-689-0
01
1
0907-1409
225
02.343 BLOCK; TERMINAL
8-98294-524-0
01
1
1410-
