8-03 — LAMP; REAR AND REAR SIDE (#75897) — 25 parça

55 7 37 58 59 49 1 1 3 8 24 51 5 49 5 22 50 54 28 14 5 13 15

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	LAMP ASM; RR COMB	8-97065-809-0	01	1	0807-	●	●
1	LAMP ASM; RR COMB	8-97065-810-0	01	1	0807-	●	●
3	GASKET; RR COMB LAMP	8-97066-836-0	02	1	0807-	●	●
5	BULB; RR COMB LAMP (A) 12V 27W	1-82194-040-0	04	1	0807-	●	●
5	BULB; RR COMB LAMP (B) 12V 27/8W	8-94404-036-0	02	1	0807-	●	●
7	SCREW; RR COMB LAMP BOLT M6X20	8-94402-623-0	06	1	0807-	●	●
8	HARNESS; RR COMB LAMP	8-97066-998-0	02	1	0807-	●	●
13	LENS; TURN SIGNAL AMBER	8-97066-839-0	02	1	0807-	●	●
14	LENS; TAIL & STOP,RR COMB LAMP RED	8-97066-838-0	01	1	0807-	●	●
14	LENS; TAIL & STOP,RR COMB LAMP RED	8-97066-981-0	01	1	0807-	●	●
15	SCREW; RR COMB LAMP M4X20 TAPPING STAINLESS	0-71190-420-0	20	1	0807-	●	●
15	SCREW; RR COMB LAMP M4X12 TAPPING	9-07076-412-0	01	1	0807-	●	●
15	SCREW; RR COMB LAMP M4X14 TAPPING	9-07076-414-0	01	1	0807-	●	●
22	LENS; BACKUP,RR COMB LAMP CLEAR	8-94257-512-0	02	1	0807-	●	●
24	GASKET; BACK,LAMP	8-94257-506-0	02	1	0807-	●	●
28	GASKET; TURN,LAMP	8-97066-837-0	02	1	0807-	●	●
37	COVER; RR COMB LAMP	8-97066-250-0	01	1	0807-	●	●
37	COVER; RR COMB LAMP	8-97066-251-0	01	1	0807-	●	●
49	LAMP; LICENSE PLATE	8-94178-897-0	01	1	0807-	●	●
50	LENS; LICENSE PLATE LAMP	5-82125-004-0	01	1	0807-	●	●
51	BULB; LICENSE PLATE LAMP 12V 7.5W	9-82692-128-0	01	1	0807-	●	●
54	SCREW; LICENSE PLATE LAMP M4X8	8-94419-312-0	01	1	0807-	●	●
55	NUT; LICENSE PLATE LAMP M5 FLANGE	8-94153-039-0	02	1	0807-	●	●
58	COVER; LICENSE PLATE LAMP	8-97076-590-1	01	1	0807-	●	●
59	SCREW; TAP,LICENSE LAMP BODY M5X20	9-93490-520-0	02	1	0807-	●	●
