Isuzu WW
▶
TRUCKS
▶
NLR
▶
51146 - NLR/NMR(SOUTHAFRICA)
▶
2 - Clutch, Transmission, Trans Axle
▶
2-03 - CLUTCH PEDAL AND CONTROL
▶
2-03 — CLUTCH PEDAL AND CONTROL
(#75316) — 30 parça
Tümü
A - NMR5SE
B - NMR5SN
C - NMR5WN
242
7
31
242
9
30
61
10
31
14
27
10
11
6
6
11
32
30
13
32
6
6
4
1
49
85
84
85
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
1
PEDAL; CLU
POWER ASSIST CLUTCH(S2T)
8-98002-484-0
01
1
0804-
●
●
●
1
PEDAL; CLU
EXC. POWER ASSIST CLUTCH(S2T)
8-98034-752-0
01
1
0804-
●
●
●
4
STOPPER; CLU PEDAL
SOU
8-97853-534-1
02
1
0804-
●
●
●
6
BUSHING; CLU PEDAL
(C) SOU
8-94238-596-0
02
1
0804-
●
●
●
6
BUSHING; CLU PEDAL
EXC. POWER ASSIST CLUTCH(S2T) (A) SOU
8-97853-619-0
02
1
0804-
●
●
●
6
BUSHING; CLU PEDAL
EXC. POWER ASSIST CLUTCH(S2T) (B) SOU
8-97853-620-0
01
1
0804-
●
●
●
7
BRACKET; CLU PEDAL
8-98029-186-4
01
1
0804-
●
●
●
9
PIN; CLU PEDAL
SOU
8-97866-667-0
01
1
0804-
●
●
●
10
PIN; CLU PEDAL
8-97387-230-0
01
1
0804-1007
●
●
●
10
PIN; CLU PEDAL
8-98147-657-0
01
1
1008-
●
●
●
11
PIN; SNAP,PUSH ROD TO PEDAL
8-98007-161-0
01
1
0804-
●
●
●
13
SPRING; ASSIST,CLU PEDAL
POWER ASSIST CLUTCH(S2T)
8-98023-621-1
01
1
0804-
●
●
●
13
SPRING; ASSIST,CLU PEDAL
EXC. POWER ASSIST CLUTCH(S2T)
8-98034-014-0
01
1
0804-
●
●
●
14
BRACKET ASM; CLU PEDAL MTG
POWER ASSIST CLUTCH(S2T)
8-98002-482-4
01
1
0804-
●
●
●
14
BRACKET ASM; CLU PEDAL MTG
EXC. POWER ASSIST CLUTCH(S2T)
8-98034-750-0
01
1
0804-
●
●
●
27
NUT; FULCRUM PIN
M10 LOCK NUT FLANGE
0-91380-010-0
01
1
0804-
●
●
●
30
BOLT; CLU MTG BRKT
(A) M10X25 FLANGE
0-28661-025-0
01
1
0804-
●
●
●
30
BOLT; CLU MTG BRKT
(B) M10X22 W/PL WASHER
8-98033-926-0
01
1
0804-0903
●
●
●
30
BOLT; CLU MTG BRKT
(B) M10X22 W/PL WASHER SOU
8-97313-188-0
01
1
0904-
●
●
●
31
NUT; MTG BRKT TO BODY
M8 W/LK WASHER SOU
8-94279-050-0
02
1
0804-
●
●
●
32
NUT; BRKT TO CLU M/CYL
M8 W/LK WASHER SOU
8-94279-050-0
02
1
0804-
●
●
●
49
RUBBER; PAD,CLU PEDAL
SOU
8-97853-413-2
01
1
0804-
●
●
●
61
NUT; BOOSTER TO BRKT
POWER ASSIST CLUTCH(S2T) M8 W/LK WASHER SOU
8-94279-050-0
04
1
0804-
●
●
●
84
HOSE; RUBBER,CLU LINE
POWER ASSIST CLUTCH(S2T)
8-98023-510-4
01
1
0804-1208
●
●
●
84
HOSE; RUBBER,CLU LINE
POWER ASSIST CLUTCH(S2T)
8-98218-205-1
01
1
1209-
●
●
●
84
HOSE; RUBBER,CLU LINE
EXC. POWER ASSIST CLUTCH(S2T)
8-98025-422-1
01
1
0804-1208
●
●
●
84
HOSE; RUBBER,CLU LINE
EXC. POWER ASSIST CLUTCH(S2T)
8-98218-207-1
01
1
1209-
●
●
●
85
CLIP; HOSE TO M/CYL
8-98031-178-0
02
1
0804-1208
●
●
●
85
CLIP; HOSE TO M/CYL
8-98168-080-0
02
1
1209-
●
●
●
242
BOLT; BRKT,CLUTCH
M8X16 FLANGE
0-28450-816-0
02
1
0804-
●
●
●
