1 |
CAP; HUB,FRT AXLE
|
8-94173-314-2 |
02 |
1 |
0503-0508 |
● |
|
| |
1 |
CAP; HUB,FRT AXLE
|
8-94173-314-2 |
02 |
1 |
0509-0606 |
● |
● |
| |
1 |
CAP; HUB,FRT AXLE
|
8-97944-565-0 |
02 |
1 |
0607- |
● |
● |
| |
3 |
BOLT; HUB CAP,FRT WHEEL
M10X20
|
9-02061-020-0 |
12 |
1 |
0503-0601 |
● |
|
| |
3 |
BOLT; HUB CAP,FRT WHEEL
M10X20
|
0-20951-020-0 |
12 |
1 |
0602- |
● |
|
| |
3 |
BOLT; HUB CAP,FRT WHEEL
M10X33
|
8-94176-987-1 |
12 |
1 |
0509-0802 |
|
● |
| |
3 |
BOLT; HUB CAP,FRT WHEEL
M10X33
|
8-98117-920-0 |
12 |
1 |
0803- |
|
● |
| |
6 |
WASHER; LK,FRT HUB
T=1.8 OD=65
|
8-94442-398-0 |
02 |
1 |
0503-0508 |
● |
|
| |
6 |
WASHER; LK,FRT HUB
T=1.8 OD=65
|
8-94442-398-0 |
02 |
1 |
0509- |
● |
● |
| |
8 |
NUT; ADJ,FRT HUB
ID=40 OD=65 T=8
|
8-94442-399-1 |
02 |
1 |
0503-0508 |
● |
|
| |
8 |
NUT; ADJ,FRT HUB
ID=40 OD=65 T=8
|
8-94442-399-1 |
02 |
1 |
0509- |
● |
● |
| |
9 |
SCREW; ADJ,NUT
M4X8 CK-HEAD
|
9-93090-408-0 |
06 |
1 |
0503-0508 |
● |
|
| |
9 |
SCREW; ADJ,NUT
M4X8 CK-HEAD
|
9-93090-408-0 |
06 |
1 |
0509-0606 |
● |
● |
| |
9 |
SCREW; ADJ,NUT
M4X8 CK-HEAD
|
8-98008-301-0 |
06 |
1 |
0607- |
● |
● |
| |
13 |
BEARING; HUB OUTER,FRT AXLE
NSK
|
8-94227-041-0 |
02 |
1 |
0503-0508 |
● |
|
| |
13 |
BEARING; HUB OUTER,FRT AXLE
NSK
|
8-94227-041-0 |
02 |
1 |
0509- |
● |
● |
| |
14 |
RING; SPR,FRT WHEEL
ID=25.9
|
9-09180-028-0 |
02 |
1 |
0509- |
|
● |
| |
15 |
PIN; WHEEL,FRT AXLE
M12X37.5
|
8-97213-871-0 |
12 |
1 |
0503-0508 |
● |
|
| |
15 |
PIN; WHEEL,FRT AXLE
M12X37.5
|
8-97213-871-0 |
12 |
1 |
0509-0606 |
● |
● |
| |
15 |
PIN; WHEEL,FRT AXLE
M12X37.5
|
8-97944-564-0 |
12 |
1 |
0607- |
● |
● |
| |
17 |
HUB; FRT AXLE
|
8-97238-419-0 |
02 |
1 |
0503-0508 |
● |
|
| |
17 |
HUB; FRT AXLE
|
8-97238-419-0 |
02 |
1 |
0509-0708 |
● |
● |
| |
17 |
HUB; FRT AXLE
|
8-98054-665-0 |
02 |
1 |
0709- |
● |
● |
| |
19 |
BEARING; HUB INNER,FRT AXLE
NSK
|
8-94258-819-0 |
02 |
1 |
0503-0508 |
● |
|
| |
19 |
BEARING; HUB INNER,FRT AXLE
NSK
|
8-94258-819-0 |
02 |
1 |
0509- |
● |
● |
| |
25 |
ROTOR; DISC BRK,FRT
|
8-97360-677-0 |
02 |
1 |
0503-0508 |
● |
|
| |
25 |
ROTOR; DISC BRK,FRT
|
8-97360-677-0 |
02 |
1 |
0509- |
● |
● |
| |
26 |
BOLT; BRK,DISC TO HUB
M12X31.5 FLANGE
|
8-97943-952-0 |
12 |
1 |
0503-0508 |
● |
|
| |
26 |
BOLT; BRK,DISC TO HUB
M12X31.5 FLANGE
|
8-97943-952-0 |
12 |
1 |
0509-0606 |
● |
● |
| |
26 |
BOLT; BRK,DISC TO HUB
M12X31.5 FLANGE
|
8-98006-065-0 |
12 |
1 |
0607- |
● |
● |
| |
28 |
SEAL; OIL,FRT HUB
|
8-94407-711-0 |
02 |
1 |
0503-0508 |
● |
|
| |
28 |
SEAL; OIL,FRT HUB
|
8-94407-711-0 |
02 |
1 |
0509-0604 |
● |
● |
| |
28 |
SEAL; OIL,FRT HUB
|
8-98036-594-0 |
02 |
1 |
0605- |
● |
● |
| |
31 |
COVER; DUST,FRT BRAKE
|
8-97327-612-0 |
01 |
1 |
0503-0508 |
● |
|
| |
31 |
COVER; DUST,FRT BRAKE
|
8-97327-612-0 |
01 |
1 |
0509- |
● |
● |
| |
31 |
COVER; DUST,FRT BRAKE
|
8-97327-611-0 |
01 |
1 |
0503-0508 |
● |
|
| |
31 |
COVER; DUST,FRT BRAKE
|
8-97327-611-0 |
01 |
1 |
0509- |
● |
● |
| |
32 |
BOLT; DUST COVER TO KNUCKLE
M8X10 W/LK WASHER
|
8-97943-023-0 |
06 |
1 |
0503-0508 |
● |
|
| |
32 |
BOLT; DUST COVER TO KNUCKLE
M8X10 W/LK WASHER
|
8-97943-023-0 |
06 |
1 |
0509-0606 |
● |
● |
| |
32 |
BOLT; DUST COVER TO KNUCKLE
M8X10 W/LK WASHER
|
8-98006-352-0 |
06 |
1 |
0607- |
● |
● |
| |
40 |
FLANGE; FRT WHEEL HUB
|
8-94173-313-0 |
02 |
1 |
0509-1207 |
|
● |
| |
40 |
FLANGE; FRT WHEEL HUB
|
8-98197-869-0 |
02 |
1 |
1208- |
|
● |
| |
67 |
ROTOR; SENSOR
|
8-97238-280-0 |
02 |
1 |
0503-0508 |
● |
|
| |
67 |
ROTOR; SENSOR
|
8-97238-280-0 |
02 |
1 |
0509- |
● |
● |
| |
91 |
SPACER; HUB BRG
T=0.20
|
8-94178-929-0 |
AR |
1 |
0509- |
|
● |
| |
91 |
SPACER; HUB BRG
T=0.30
|
8-94178-930-0 |
AR |
1 |
0509- |
|
● |
| |
91 |
SPACER; HUB BRG
T=0.50
|
8-94178-931-0 |
AR |
1 |
0509- |
|
● |
| |
91 |
SPACER; HUB BRG
T=1.00
|
8-94178-932-0 |
AR |
1 |
0509- |
|
● |
