1 |
00.886 DISC; CLUTCH
6VE1 ENG(LX5)
|
8-97941-529-0 |
01 |
1 |
1008- |
● |
|
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X4(TFS***)
4JJ1-TCS ENG(LFB)
COOLER WO/HEATER(C65),AIR CON
PREPARATORY PACK(C66)
EURO3 SPECIFICATION<NT3>
CHEVROLET EQUIPMENT(8JF)
|
8-97946-002-0 |
01 |
1 |
1008-1109 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X4(TFS***)
4JJ1-TCS ENG(LFB)
COOLER WO/HEATER(C65),AIR CON
PREPARATORY PACK(C66)
EURO3 SPECIFICATION<NT3>
CHEVROLET EQUIPMENT(8JF)
EXC. ELECTRONIC CONTROL<K20>
|
8-97946-002-0 |
01 |
1 |
1110- |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X4(TFS***)
4JJ1-TCS ENG(LFB)
EURO3 SPECIFICATION<NT3>
|
8-97946-002-0 |
01 |
1 |
0807-0809 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X4(TFS***)
4JJ1-TCS ENG(LFB)
COOLER WO/HEATER(C65),AIR CON
PREPARATORY PACK(C66)
EURO3 SPECIFICATION<NT3>
|
8-97946-002-0 |
01 |
1 |
0810-0810 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X4(TFS***)
4JJ1-TCS ENG(LFB)
COOLER WO/HEATER(C65),AIR CON
PREPARATORY PACK(C66)
EURO3 SPECIFICATION<NT3>
CHEVROLET EQUIPMENT(8JF)
|
8-97946-002-0 |
01 |
1 |
0810-1003 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X4(TFS***)
4JJ1-TCS ENG(LFB)
COOLER WO/HEATER(C65),AIR CON
PREPARATORY PACK(C66)
EURO3 SPECIFICATION<NT3>
EXC. CHEVROLET EQUIPMENT(8JF)
|
8-97947-166-0 |
01 |
1 |
0810-1003 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB)
COOLER WO/HEATER(C65),AIR CON
PREPARATORY PACK(C66)
EURO3 SPECIFICATION<NT3>
|
8-97947-166-0 |
01 |
1 |
1004-1007 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB)
COOLER WO/HEATER(C65),AIR CON
PREPARATORY PACK(C66)
EURO3 SPECIFICATION<NT3>
EXC. CHEVROLET EQUIPMENT(8JF)
|
8-97947-166-0 |
01 |
1 |
1008- |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
|
8-97941-521-0 |
01 |
1 |
0306-0609 |
|
|
● |
|
|
| |
1 |
00.886 DISC; CLUTCH
4JA1-T ENG(LP0)
|
8-97941-521-0 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JA1-T ENG(LP0)
|
8-97941-521-0 |
01 |
1 |
0610- |
● |
● |
● |
● |
|
| |
1 |
00.886 DISC; CLUTCH
C24SE ENG(LG1)
|
8-97941-527-0 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
1 |
00.886 DISC; CLUTCH
|
8-97941-527-0 |
01 |
1 |
0306-0609 |
|
|
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
C24SE ENG(LG1)
|
8-97941-527-0 |
01 |
1 |
0610-1003 |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
C24SE ENG(LG1)
|
8-97941-527-0 |
01 |
1 |
1004-1007 |
● |
|
|
|
|
| |
1 |
00.886 DISC; CLUTCH
C24SE ENG(LG1)
|
8-97941-527-0 |
01 |
1 |
1008- |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM)
|
8-97941-523-0 |
01 |
1 |
0306-0510 |
● |
|
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM)
|
8-97944-277-0 |
01 |
1 |
0511-0609 |
● |
|
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JH1-TC ENG(RDM)
|
8-97945-679-0 |
01 |
1 |
0610-0709 |
● |
|
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB)
|
8-97945-679-0 |
01 |
1 |
0610-0709 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB),4JH1-TC ENG(RDM)
|
8-97945-679-0 |
01 |
1 |
0710-0806 |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB)
EGYPT EQUIPMENT(B09)
|
8-97945-679-0 |
01 |
1 |
0710-0806 |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
4JH1-TC ENG(RDM)
|
8-97945-679-0 |
01 |
1 |
0807-0809 |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB)
EGYPT EQUIPMENT(B09)
|
8-97945-679-0 |
01 |
1 |
0807-0809 |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB)
EURO2 SPECIFICATION<NT2>
EXC. EGYPT EQUIPMENT(B09)
|
8-97945-679-0 |
01 |
1 |
0807-0809 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X2(TFB***)
4JJ1-TCS ENG(LFB)
EURO3 SPECIFICATION<NT3>
|
8-97945-679-0 |
01 |
1 |
0807-0809 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JH1-TC ENG(RDM)
|
8-97945-679-0 |
01 |
1 |
0810-1003 |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB)
EGYPT EQUIPMENT(B09)
|
8-97945-679-0 |
01 |
1 |
0810-1003 |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
4X2(TFB***)
4JJ1-TCS ENG(LFB)
EURO2 SPECIFICATION<NT2>,EURO3
SPECIFICATION<NT3>
|
8-97945-679-0 |
01 |
1 |
0810-1003 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X4(TFS***)
4JJ1-TCS ENG(LFB)
EURO2 SPECIFICATION<NT2>
|
8-97945-679-0 |
01 |
1 |
0810-1003 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JH1-TC ENG(RDM)
|
8-97945-679-0 |
01 |
1 |
1004-1007 |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB)
EURO2 SPECIFICATION<NT2>
|
8-97945-679-0 |
01 |
1 |
1004-1007 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JH1-TC ENG(RDM)
|
8-97945-679-0 |
01 |
1 |
1008-1402 |
● |
|
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JK1-TCX ENG(LR0)
|
8-97945-679-0 |
01 |
1 |
1008-1402 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X4(TFS***)
4JJ1-TCS ENG(LFB)
EURO2 SPECIFICATION<NT2>
|
8-97945-679-0 |
01 |
1 |
1008-1402 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X2(TFB***)
4JJ1-TCS ENG(LFB)
EURO2 SPECIFICATION<NT2>,EURO3
SPECIFICATION<NT3>
|
8-97945-679-0 |
01 |
1 |
1008-1402 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JH1-TC ENG(RDM)
|
8-97945-679-0 |
01 |
1 |
1403- |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
EGYPT EQUIPMENT(B09)
|
8-97945-679-0 |
01 |
1 |
1403- |
● |
● |
|
● |
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCS ENG(LFB)
EURO2 SPECIFICATION<NT2>
EXC. EGYPT EQUIPMENT(B09)
|
8-97945-679-0 |
01 |
1 |
1403- |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X2(TFB***)
4JJ1-TCS ENG(LFB)
EURO3 SPECIFICATION<NT3>
CHEVROLET EQUIPMENT(8JF)
EXC. EGYPT EQUIPMENT(B09)
|
8-97945-679-0 |
01 |
1 |
1403- |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JK1-TCX ENG(LR0)
EXC. IDENTIFICATION LABEL FOR
KD<6UT>
|
8-97945-679-0 |
01 |
1 |
1403- |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
6VE1 ENG(LX5)
|
8-97941-529-0 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCX ENG(LS0)
HEATER & DEFROSTER(C42),AIR
CONDITIONER MANUAL CONT(C60)
EURO3 SPECIFICATION<NT3>
|
8-97944-506-2 |
01 |
1 |
0610-0611 |
|
|
|
|
● |
| |
1 |
00.886 DISC; CLUTCH
6VE1 ENG(LX5)
|
8-97941-529-0 |
01 |
1 |
0710-1003 |
● |
|
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4X4(TFS***)
4JJ1-TCS ENG(LFB)
EGYPT EQUIPMENT(B09)
EURO3 SPECIFICATION<NT3>
|
8-97946-002-0 |
01 |
1 |
0612-0612 |
|
● |
|
|
|
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCX ENG(LS0)
COOLER WO/HEATER(C65),AIR CON
PREPARATORY PACK(C66)
|
8-97945-774-0 |
01 |
1 |
0610-0809 |
|
|
|
|
● |
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCX ENG(LS0)
EURO3 SPECIFICATION<NT3>
|
8-97945-774-0 |
01 |
1 |
0810- |
|
|
|
|
● |
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCX ENG(LS0)
HEATER & DEFROSTER(C42),AIR
CONDITIONER MANUAL CONT(C60)
EURO4 SPECIFICATION<NT4>
|
8-97945-775-0 |
01 |
1 |
0610-0611 |
|
|
|
|
● |
| |
1 |
00.886 DISC; CLUTCH
4JJ1-TCX ENG(LS0)
HEATER & DEFROSTER(C42),AIR
CONDITIONER MANUAL CONT(C60)
EURO4 SPECIFICATION<NT4>
|
8-97946-171-0 |
01 |
1 |
0612- |
|
|
|
|
● |
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
6VE1 ENG(LX5)
|
8-97941-528-0 |
01 |
1 |
1008- |
● |
|
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
|
8-97943-331-0 |
01 |
1 |
0306-0609 |
|
|
● |
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
4JA1-T ENG(LP0)
|
8-97943-331-0 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
4JA1-T ENG(LP0)
|
8-97943-331-0 |
01 |
1 |
0610- |
● |
● |
● |
● |
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
C24SE ENG(LG1)
|
8-97941-526-1 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
|
8-97941-526-1 |
01 |
1 |
0306-0609 |
|
|
|
● |
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
C24SE ENG(LG1)
|
8-97941-526-1 |
01 |
1 |
0610-1003 |
● |
● |
|
● |
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
C24SE ENG(LG1)
|
8-97941-526-1 |
01 |
1 |
1004-1007 |
● |
|
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
C24SE ENG(LG1)
|
8-97941-526-1 |
01 |
1 |
1008- |
● |
● |
|
● |
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM)
|
8-97941-522-0 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
4JH1-TC ENG(RDM)
|
8-97941-522-0 |
01 |
1 |
0610-1007 |
● |
|
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
4JJ1-TCS ENG(LFB)
|
8-97941-522-0 |
01 |
1 |
0610-1007 |
|
● |
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
4JH1-TC ENG(RDM)
|
8-97941-522-0 |
01 |
1 |
1008-1401 |
● |
|
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
|
8-97941-522-0 |
01 |
1 |
1008-1401 |
|
● |
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
4JJ1-TCS ENG(LFB),4JH1-TC ENG(RDM)
|
8-97941-522-0 |
01 |
1 |
1402- |
● |
● |
|
● |
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
4JK1-TCX ENG(LR0)
EXC. IDENTIFICATION LABEL FOR
KD<6UT>
|
8-97941-522-0 |
01 |
1 |
1402- |
|
● |
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
6VE1 ENG(LX5)
|
8-97941-528-0 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
4JJ1-TCX ENG(LS0)
|
8-97944-507-2 |
01 |
1 |
0610- |
|
|
|
|
● |
| |
2 |
00.859 PLATE ASM; PRESSURE,CLU
6VE1 ENG(LX5)
|
8-97941-528-0 |
01 |
1 |
0710-1003 |
● |
|
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
|
8-94167-751-0 |
01 |
1 |
0306- |
|
|
● |
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
C24SE ENG(LG1)
|
8-94457-209-1 |
01 |
1 |
0306-1003 |
● |
|
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
|
8-94457-209-1 |
01 |
1 |
0306-1003 |
|
|
|
● |
|
| |
57 |
00.795 FORK; SHIFT,CLU
C24SE ENG(LG1)
|
8-94457-209-1 |
01 |
1 |
1004-1007 |
● |
|
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
C24SE ENG(LG1)
|
8-94457-209-1 |
01 |
1 |
1008- |
● |
|
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
|
8-94457-209-1 |
01 |
1 |
1008- |
|
|
|
● |
|
| |
57 |
00.795 FORK; SHIFT,CLU
4JA1-T ENG(LP0),4JA1-TC ENG(L4Z),
4JH1-TC ENG(RDM)
|
8-97365-654-0 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
4JA1-T ENG(LP0),4JH1-TC ENG(RDM)
|
8-97365-654-0 |
01 |
1 |
0610-1007 |
● |
|
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
4JJ1-TCS ENG(LFB)
|
8-97365-654-0 |
01 |
1 |
0610-1007 |
|
● |
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
4JJ1-TCS ENG(LFB),4JA1-T ENG(LP0),
4JK1-TCX ENG(LR0),4JH1-TC ENG(RDM)
|
8-97365-654-0 |
01 |
1 |
1008- |
● |
● |
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
6VE1 ENG(LX5)
|
8-94370-379-3 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
4JJ1-TCX ENG(LS0)
|
8-94370-379-3 |
01 |
1 |
0610-0708 |
|
|
|
|
● |
| |
57 |
00.795 FORK; SHIFT,CLU
4JJ1-TCX ENG(LS0)
|
8-98086-423-0 |
01 |
1 |
0709-0709 |
|
|
|
|
● |
| |
57 |
00.795 FORK; SHIFT,CLU
6VE1 ENG(LX5)
|
8-98086-423-0 |
01 |
1 |
0710-1003 |
● |
|
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
4JJ1-TCX ENG(LS0)
|
8-98086-423-0 |
01 |
1 |
0710-1003 |
|
|
|
|
● |
| |
57 |
00.795 FORK; SHIFT,CLU
4JJ1-TCX ENG(LS0)
|
8-98086-423-0 |
01 |
1 |
1004-1007 |
|
|
|
|
● |
| |
57 |
00.795 FORK; SHIFT,CLU
6VE1 ENG(LX5)
|
8-98086-423-0 |
01 |
1 |
1008- |
● |
|
|
|
|
| |
57 |
00.795 FORK; SHIFT,CLU
4JJ1-TCX ENG(LS0)
|
8-98086-423-0 |
01 |
1 |
1008- |
|
|
|
|
● |
| |
60 |
00.780 NUT; SLAVE CYL
02.042
M12 FLANGE
|
0-91180-112-0 |
01 |
1 |
0306-0609 |
|
|
● |
|
|
| |
60 |
00.780 NUT; SLAVE CYL
4JA1-T ENG(LP0),4JA1-TC ENG(L4Z),
4JH1-TC ENG(RDM)
02.042
M12 FLANGE
|
0-91180-112-0 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
60 |
00.780 NUT; SLAVE CYL
02.042
M12 FLANGE
|
0-91180-112-0 |
01 |
1 |
0610-1003 |
|
|
● |
|
|
| |
60 |
00.780 NUT; SLAVE CYL
4JJ1-TCS ENG(LFB),4JA1-T ENG(LP0),
4JH1-TC ENG(RDM)
02.042
M12 FLANGE
|
0-91180-112-0 |
01 |
1 |
0610-1003 |
● |
● |
|
● |
|
| |
60 |
00.780 NUT; SLAVE CYL
4JJ1-TCS ENG(LFB),4JA1-T ENG(LP0),
4JH1-TC ENG(RDM)
02.042
M12 FLANGE
|
0-91180-112-0 |
01 |
1 |
1004-1007 |
● |
● |
● |
|
|
| |
60 |
00.780 NUT; SLAVE CYL
4JJ1-TCS ENG(LFB),4JA1-T ENG(LP0),
4JK1-TCX ENG(LR0),4JH1-TC ENG(RDM)
02.042
M12 FLANGE
|
0-91180-112-0 |
01 |
1 |
1008- |
● |
● |
● |
|
|
| |
118 |
00.799 BEARING; CLU RELEASE
NSK ID=56 OD=71.7
|
8-97209-197-0 |
01 |
1 |
0306- |
|
|
● |
|
|
| |
118 |
00.799 BEARING; CLU RELEASE
C24SE ENG(LG1),4JA1-TC ENG(L4Z),
4JH1-TC ENG(RDM)
NSK
|
8-97316-591-0 |
01 |
1 |
0306-0609 |
● |
|
|
|
|
| |
118 |
00.799 BEARING; CLU RELEASE
NSK
|
8-97316-591-0 |
01 |
1 |
0306-0609 |
|
|
|
● |
|
| |
118 |
00.799 BEARING; CLU RELEASE
C24SE ENG(LG1),4JH1-TC ENG(RDM)
NSK
|
8-97316-591-0 |
01 |
1 |
0610-0809 |
● |
|
|
|
|
| |
118 |
00.799 BEARING; CLU RELEASE
NSK
|
8-97316-591-0 |
01 |
1 |
0610-0809 |
|
|
|
● |
|
| |
118 |
00.799 BEARING; CLU RELEASE
4JJ1-TCS ENG(LFB)
NSK
|
8-97316-591-0 |
01 |
1 |
0610-0809 |
|
● |
|
|
|
| |
118 |
00.799 BEARING; CLU RELEASE
4JJ1-TCS ENG(LFB),C24SE ENG(LG1),
4JH1-TC ENG(RDM)
NSK
|
8-97316-591-0 |
01 |
1 |
0810-1003 |
● |
● |
|
● |
|
| |
118 |
00.799 BEARING; CLU RELEASE
4JJ1-TCS ENG(LFB),C24SE ENG(LG1),
4JH1-TC ENG(RDM)
NSK
|
8-97316-591-0 |
01 |
1 |
1004-1007 |
● |
● |
|
|
|
| |
118 |
00.799 BEARING; CLU RELEASE
4JJ1-TCS ENG(LFB),C24SE ENG(LG1),
4JK1-TCX ENG(LR0),4JH1-TC ENG(RDM)
NSK
|
8-97316-591-0 |
01 |
1 |
1008- |
● |
● |
|
● |
|
| |
118 |
00.799 BEARING; CLU RELEASE
4JA1-T ENG(LP0)
NSK ID=56 OD=71.7
|
8-97333-487-0 |
01 |
1 |
0306- |
● |
|
|
|
|
| |
137 |
00.862 BOLT; CLU COVER
02.343
M8X16 FLANGE
|
0-28050-816-0 |
06 |
1 |
0306-0609 |
|
|
● |
● |
|
| |
137 |
00.862 BOLT; CLU COVER
C24SE ENG(LG1),4JA1-T ENG(LP0),
4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
06 |
1 |
0306-0609 |
● |
|
|
|
|
| |
137 |
00.862 BOLT; CLU COVER
4JJ1-TCX ENG(LS0)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
09 |
1 |
0610-0709 |
|
|
|
|
● |
| |
137 |
00.862 BOLT; CLU COVER
6VE1 ENG(LX5)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
09 |
1 |
0710-1003 |
● |
|
|
|
|
| |
137 |
00.862 BOLT; CLU COVER
4JJ1-TCX ENG(LS0)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
09 |
1 |
0710-1003 |
|
|
|
|
● |
| |
137 |
00.862 BOLT; CLU COVER
4JJ1-TCS ENG(LFB),C24SE ENG(LG1),
4JA1-T ENG(LP0),4JH1-TC ENG(RDM)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
06 |
1 |
1004-1007 |
● |
● |
● |
|
|
| |
137 |
00.862 BOLT; CLU COVER
4JJ1-TCS ENG(LFB),C24SE ENG(LG1),
4JA1-T ENG(LP0),4JH1-TC ENG(RDM)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
06 |
1 |
1008-1401 |
● |
● |
● |
● |
|
| |
137 |
00.862 BOLT; CLU COVER
4JJ1-TCS ENG(LFB),C24SE ENG(LG1),
4JA1-T ENG(LP0),4JH1-TC ENG(RDM)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
06 |
1 |
1402- |
● |
● |
● |
● |
|
| |
137 |
00.862 BOLT; CLU COVER
4JK1-TCX ENG(LR0)
EXC. IDENTIFICATION LABEL FOR
KD<6UT>
02.343
M8X16 FLANGE
|
0-28050-816-0 |
06 |
1 |
1402- |
|
● |
|
|
|
| |
137 |
00.862 BOLT; CLU COVER
6VE1 ENG(LX5)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
09 |
1 |
0306-0609 |
● |
|
|
|
|
| |
137 |
00.862 BOLT; CLU COVER
4JJ1-TCS ENG(LFB),C24SE ENG(LG1),
4JA1-T ENG(LP0),4JH1-TC ENG(RDM)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
06 |
1 |
0610-1003 |
● |
● |
● |
● |
|
| |
137 |
00.862 BOLT; CLU COVER
4JJ1-TCX ENG(LS0)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
09 |
1 |
1004-1007 |
|
|
|
|
● |
| |
137 |
00.862 BOLT; CLU COVER
4JJ1-TCX ENG(LS0),6VE1 ENG(LX5)
02.343
M8X16 FLANGE
|
0-28050-816-0 |
09 |
1 |
1008- |
● |
|
|
|
● |
| |
140 |
00.862 PIN; STRAIGHT
OD=6 L=24
|
9-09878-532-0 |
03 |
1 |
0306-0609 |
|
|
● |
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JA1-T ENG(LP0),6VE1 ENG(LX5)
OD=6 L=24
|
9-09878-532-0 |
03 |
1 |
0306-0609 |
● |
|
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
OD=6 L=24
|
9-09878-532-0 |
03 |
1 |
0610-0709 |
|
|
● |
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JA1-T ENG(LP0)
OD=6 L=24
|
9-09878-532-0 |
03 |
1 |
0610-0709 |
● |
|
|
● |
|
| |
140 |
00.862 PIN; STRAIGHT
OD=6 L=24
|
9-09878-532-0 |
03 |
1 |
0710-1003 |
|
|
● |
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JA1-T ENG(LP0),6VE1 ENG(LX5)
OD=6 L=24
|
9-09878-532-0 |
03 |
1 |
0710-1003 |
● |
|
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
OD=6 L=24
|
9-09878-532-0 |
03 |
1 |
1004-1007 |
|
|
● |
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JA1-T ENG(LP0)
OD=6 L=24
|
9-09878-532-0 |
03 |
1 |
1004-1007 |
● |
|
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
OD=6 L=24
|
9-09878-532-0 |
03 |
1 |
1008- |
|
|
● |
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JA1-T ENG(LP0),6VE1 ENG(LX5)
OD=6 L=24
|
9-09878-532-0 |
03 |
1 |
1008- |
● |
|
|
● |
|
| |
140 |
00.862 PIN; STRAIGHT
4JA1-TC ENG(L4Z)
TURKEY EQUIPMENT(B11)
OD=6 L=24
|
8-97920-965-0 |
02 |
1 |
0403-0609 |
● |
|
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JJ1-TCX ENG(LS0)
OD=6 L=27
|
8-97945-592-0 |
03 |
1 |
0610-1007 |
|
|
|
|
● |
| |
140 |
00.862 PIN; STRAIGHT
4JJ1-TCS ENG(LFB),4JK1-TCX ENG(LR0)
EXC. EGYPT EQUIPMENT(B09)
OD=6 L=27
|
8-97945-592-0 |
02 |
1 |
1008- |
|
● |
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
0306-0402 |
● |
|
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM)
EXC. TURKEY EQUIPMENT(B11)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
0403-0508 |
● |
|
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM)
EXC. TURKEY EQUIPMENT(B11)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
0509-0609 |
● |
|
|
● |
|
| |
140 |
00.862 PIN; STRAIGHT
4JH1-TC ENG(RDM)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
0610-0701 |
● |
|
|
● |
|
| |
140 |
00.862 PIN; STRAIGHT
4JH1-TC ENG(RDM)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
0702-0809 |
● |
|
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JJ1-TCS ENG(LFB)
EGYPT EQUIPMENT(B09)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
0702-0809 |
|
● |
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JJ1-TCS ENG(LFB),4JH1-TC ENG(RDM)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
0810-0905 |
● |
● |
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JH1-TC ENG(RDM)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
0906-1003 |
● |
|
|
● |
|
| |
140 |
00.862 PIN; STRAIGHT
4JJ1-TCS ENG(LFB)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
0906-1003 |
|
● |
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JH1-TC ENG(RDM)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
1004-1007 |
● |
|
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JH1-TC ENG(RDM)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
1008- |
● |
|
|
● |
|
| |
140 |
00.862 PIN; STRAIGHT
4JJ1-TCS ENG(LFB)
EGYPT EQUIPMENT(B09)
OD=6 L=24
|
9-09878-532-0 |
02 |
1 |
1008- |
|
● |
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JJ1-TCS ENG(LFB)
OD=6 L=27
|
8-97945-592-0 |
02 |
1 |
0610-0809 |
|
● |
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JJ1-TCS ENG(LFB)
EXC. EGYPT EQUIPMENT(B09)
OD=6 L=27
|
8-97945-592-0 |
02 |
1 |
0810-1003 |
|
● |
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JJ1-TCS ENG(LFB)
OD=6 L=27
|
8-97945-592-0 |
02 |
1 |
1004-1007 |
|
● |
|
|
|
| |
140 |
00.862 PIN; STRAIGHT
4JJ1-TCX ENG(LS0)
OD=6 L=27
|
8-97945-592-0 |
03 |
1 |
1008- |
|
|
|
|
● |
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
6VE1 ENG(LX5)
M10X30 FLANGE
|
0-28751-030-0 |
03 |
1 |
1008- |
● |
|
|
|
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
M12X90 FLANGE
|
0-28051-290-0 |
02 |
1 |
0306-0609 |
|
|
● |
|
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
4JA1-T ENG(LP0),4JA1-TC ENG(L4Z),
4JH1-TC ENG(RDM)
M12X90 FLANGE
|
0-28051-290-0 |
02 |
1 |
0306-0609 |
● |
|
|
|
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
M12X90 FLANGE
|
0-28051-290-0 |
02 |
1 |
0610-1003 |
|
|
● |
|
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
4JJ1-TCS ENG(LFB),4JA1-T ENG(LP0),
4JH1-TC ENG(RDM)
M12X90 FLANGE
|
0-28051-290-0 |
02 |
1 |
0610-1003 |
● |
● |
|
● |
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
4JJ1-TCS ENG(LFB),4JA1-T ENG(LP0),
4JH1-TC ENG(RDM)
M12X90 FLANGE
|
0-28051-290-0 |
02 |
1 |
1004-1007 |
● |
● |
● |
|
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
4JJ1-TCS ENG(LFB),4JA1-T ENG(LP0),
4JK1-TCX ENG(LR0),4JH1-TC ENG(RDM)
M12X90 FLANGE
|
0-28051-290-0 |
02 |
1 |
1008- |
● |
● |
● |
|
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
C24SE ENG(LG1)
00.029
M10X40 FLANGE
|
0-28751-040-0 |
02 |
1 |
0306-0609 |
● |
|
|
|
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
00.029
M10X40 FLANGE
|
0-28751-040-0 |
02 |
1 |
0306-0609 |
|
|
|
● |
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
C24SE ENG(LG1)
00.029
M10X40 FLANGE
|
0-28751-040-0 |
02 |
1 |
0610-1003 |
● |
● |
|
● |
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
C24SE ENG(LG1)
00.029
M10X40 FLANGE
|
0-28751-040-0 |
02 |
1 |
1004-1007 |
● |
|
|
|
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
C24SE ENG(LG1)
00.029
M10X40 FLANGE
|
0-28751-040-0 |
02 |
1 |
1008- |
● |
● |
|
● |
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
6VE1 ENG(LX5)
M10X30 FLANGE
|
0-28751-030-0 |
02 |
1 |
0306-0609 |
● |
|
|
|
|
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
00.683
M10X60 FLANGE
|
0-28151-060-0 |
02 |
1 |
0610- |
|
|
|
|
● |
| |
146 |
00.780 BOLT; SLAVE CYL TO TRANS CASE
6VE1 ENG(LX5)
M10X30 FLANGE
|
0-28751-030-0 |
03 |
1 |
0710-1003 |
● |
|
|
|
|
