Isuzu WW
▶
SUV
▶
UCR
▶
51027 - UCR/UCS(THAILAND)
▶
3 - Brakes, Brake System
▶
3-60 - BRAKE PIPING; VACUUM
▶
3-60 — BRAKE PIPING; VACUUM
(#73795) — 26 parça
Tümü
A - UCB5VF
B - UCS5VF
◀
[360A] '06/7- (13 parça)
[360A] -'06/6 (13 parça)
▶
66
116
169
66
66
98
22
116
66
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
22
CLIP; HOSE,VAC TANK
THA
8-97089-536-0
01
1
0411-0606
●
●
22
CLIP; HOSE,VAC TANK
AIR CONDITIONER ROOF MOUNTED<C69> ID=12 & 16.5 IMA
8-94400-865-0
01
1
0607-
●
●
66
CLIP; VAC HOSE,M/VAC
(A) ID=15.5 IMA
8-94367-944-0
01
1
0411-0604
●
●
66
CLIP; VAC HOSE,M/VAC
(A) ID=15.5 THA
8-98035-872-0
01
1
0605-0606
●
●
66
CLIP; VAC HOSE,M/VAC
(A) ID=15.5 THA
8-98035-872-0
03
1
0607-
●
●
66
CLIP; VAC HOSE,M/VAC
(B) ID=16 THA
8-97173-222-0
01
1
0411-0606
●
●
66
CLIP; VAC HOSE,M/VAC
(C) ID=16 THA
8-98036-539-0
01
1
0607-
●
●
98
BOLT; VAC PIPE FIX
M6X20 FLANGE THA
0-28650-620-0
01
1
0411-0606
●
●
98
BOLT; VAC PIPE FIX
M6X16 FLANGE THA
0-28650-616-0
02
1
0607-
●
●
116
HOSE; VAC,M/VAC
(A) THA
8-97368-829-0
01
1
0411-0606
●
●
116
HOSE; VAC,M/VAC
(C) THA
8-97944-840-1
01
1
0607-
●
●
116
HOSE; VAC,M/VAC
(B) THA
8-97944-841-0
01
1
0607-
●
●
169
PIPE; VAC,BOOSTER SIDE
THA
8-97944-847-1
01
1
0607-
●
●
66
98
22
116
23
66
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
22
CLIP; HOSE,VAC TANK
THA
8-97089-536-0
01
1
0411-0606
●
●
22
CLIP; HOSE,VAC TANK
AIR CONDITIONER ROOF MOUNTED<C69> ID=12 & 16.5 IMA
8-94400-865-0
01
1
0607-
●
●
23
BRACKET; VAC PIPE
THA
8-97368-824-0
01
1
0411-0606
●
●
66
CLIP; VAC HOSE,M/VAC
(A) ID=15.5 IMA
8-94367-944-0
01
1
0411-0604
●
●
66
CLIP; VAC HOSE,M/VAC
(A) ID=15.5 THA
8-98035-872-0
01
1
0605-0606
●
●
66
CLIP; VAC HOSE,M/VAC
(A) ID=15.5 THA
8-98035-872-0
03
1
0607-
●
●
66
CLIP; VAC HOSE,M/VAC
(B) ID=16 THA
8-97173-222-0
01
1
0411-0606
●
●
66
CLIP; VAC HOSE,M/VAC
(C) ID=16 THA
8-98036-539-0
01
1
0607-
●
●
98
BOLT; VAC PIPE FIX
M6X20 FLANGE THA
0-28650-620-0
01
1
0411-0606
●
●
98
BOLT; VAC PIPE FIX
M6X16 FLANGE THA
0-28650-616-0
02
1
0607-
●
●
116
HOSE; VAC,M/VAC
(A) THA
8-97368-829-0
01
1
0411-0606
●
●
116
HOSE; VAC,M/VAC
(C) THA
8-97944-840-1
01
1
0607-
●
●
116
HOSE; VAC,M/VAC
(B) THA
8-97944-841-0
01
1
0607-
●
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
