8-45 — HEATER PIPING (#73516) — 41 parça

13 25 27 13 13 13 13 25 13 13 18 27 13 13

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0) (C) ID=45X22 L=46	9-09917-380-0	01	1	0610-0612	●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0),4JJ1-TCX ENG(LS0) (C) ID=45X22 L=46	9-09917-380-0	01	1	0610-0612			●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0) (C)	8-98063-683-0	01	1	0701-	●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0),4JJ1-TCX ENG(LS0) (C)	8-98063-683-0	01	1	0701-			●	●
13	08.846 CLIP; HTR HOSE (B) ID=22	8-94382-401-0	01	1	0307-0508	●	●	●	●
13	08.846 CLIP; HTR HOSE (B) ID=22	8-94382-401-0	01	1	0307-0508	●	●	●	●
13	08.846 CLIP; HTR HOSE 4JA1-TC ENG(L4Z) (B) ID=22	8-94382-401-0	01	1	0509-0609	●	●
13	08.846 CLIP; HTR HOSE 4JA1-TC ENG(L4Z) (B) ID=22	8-94382-401-0	01	1	0509-0609	●	●
13	08.846 CLIP; HTR HOSE 4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM) (B) ID=22	8-94382-401-0	01	1	0509-0609			●	●
13	08.846 CLIP; HTR HOSE 4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM) (B) ID=22	8-94382-401-0	01	1	0509-0609			●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0) (B) ID=22	8-94382-401-0	01	1	0610-1004	●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0) (B) ID=22	8-94382-401-0	01	1	0610-1004	●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0),4JJ1-TCX ENG(LS0) (B) ID=22	8-94382-401-0	01	1	0610-1004			●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0),4JJ1-TCX ENG(LS0) (B) ID=22	8-94382-401-0	01	1	0610-1004			●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0) 03.278 (B) ID=22	8-97359-141-0	01	1	1005-	●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0) 03.278 (B) ID=22	8-97359-141-0	01	1	1005-	●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0),4JJ1-TCX ENG(LS0) 03.278 (B) ID=22	8-97359-141-0	01	1	1005-			●	●
13	08.846 CLIP; HTR HOSE 4JK1-TCX ENG(LR0),4JJ1-TCX ENG(LS0) 03.278 (B) ID=22	8-97359-141-0	01	1	1005-			●	●
13	08.846 CLIP; HTR HOSE (A) ID=21.7	8-97203-074-0	02	1	0307-0508	●	●	●	●
13	08.846 CLIP; HTR HOSE 4JA1-TC ENG(L4Z) (A) ID=21.7	8-97203-074-0	02	1	0509-0609	●	●
13	08.846 CLIP; HTR HOSE 4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM) (A) ID=21.7	8-97203-074-0	02	1	0509-0609			●	●
13	08.846 CLIP; HTR HOSE (A) ID=21.7	8-97203-074-0	02	1	0610-	●	●	●	●
18	08.866 BOLT; WATER HOSE 4JK1-TCX ENG(LR0) 02.343 M8X12 FLANGE	0-28050-812-0	01	1	0610-	●	●
18	08.866 BOLT; WATER HOSE 4JK1-TCX ENG(LR0),4JJ1-TCX ENG(LS0) 02.343 M8X12 FLANGE	0-28050-812-0	01	1	0610-			●	●
25	08.846 HOSE; WATER,ENG TO HTR UNIT	8-97236-494-1	01	1	0307-0412	●	●	●	●
25	08.846 HOSE; WATER,ENG TO HTR UNIT	8-98002-547-0	01	1	0501-0508	●	●	●	●
25	08.846 HOSE; WATER,ENG TO HTR UNIT 4JA1-TC ENG(L4Z)	8-98002-547-0	01	1	0509-0609	●	●
25	08.846 HOSE; WATER,ENG TO HTR UNIT 4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM)	8-98002-547-0	01	1	0509-0609			●	●
25	08.846 HOSE; WATER,ENG TO HTR UNIT 4JK1-TCX ENG(LR0)	8-98007-112-2	01	1	0610-	●	●
25	08.846 HOSE; WATER,ENG TO HTR UNIT 4JK1-TCX ENG(LR0),4JJ1-TCX ENG(LS0)	8-98007-112-2	01	1	0610-			●	●
27	08.846 HOSE; WATER,HTR UNIT TO WATER PI	8-97236-490-1	01	1	0307-0412	●	●	●	●
27	08.846 HOSE; WATER,HTR UNIT TO WATER PI	8-98002-541-0	01	1	0501-0508	●	●	●	●
27	08.846 HOSE; WATER,HTR UNIT TO WATER PI 4JA1-TC ENG(L4Z)	8-98002-541-0	01	1	0509-0609	●	●
27	08.846 HOSE; WATER,HTR UNIT TO WATER PI 4JA1-TC ENG(L4Z),4JH1-TC ENG(RDM)	8-98002-541-0	01	1	0509-0609			●	●
27	08.846 HOSE; WATER,HTR UNIT TO WATER PI 4JK1-TCX ENG(LR0)	8-98007-110-2	01	1	0610-	●	●
27	08.846 HOSE; WATER,HTR UNIT TO WATER PI 4JK1-TCX ENG(LR0),4JJ1-TCX ENG(LS0)	8-98007-110-2	01	1	0610-			●	●

9 48 48 73 73 26 73 17 73

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D
9	08.846 PIPE; HTR	8-98011-513-1	01	1	0610-	●	●	●	●
17	08.846 HOSE; WATER,BYPASS 03.163	8-98031-860-0	01	1	0610-	●	●	●	●
26	08.846 HOSE; HTR	8-98011-630-0	01	1	0610-	●	●	●	●
48	09.262 BOLT; CLIP FIX 02.343 M8X12 FLANGE	0-28050-812-0	02	1	0610-	●	●	●	●
73	08.846 CLIP; HTR HOSE ID=20.8	8-97944-127-0	04	1	0610-	●	●	●	●
