Sayfa 4-80 - Isuzu EPC

4-80 — ROAD WHEEL (#73315) — 114 parça

22 22 22 22 22 7 6 36 34 6 6 34 3 34 7 3 6 3 6

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 215/80R16 6JJX16 STEEL(AQV) (A) M12 H=40	8-97129-440-1	24	1	9712-9908	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 215/80R16 6JJX16 STEEL(AQV) (A) M12 H=40	8-97222-248-1	24	1	9909-0210	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI (ATQ),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF), FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(AUU),FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV) ,FRT&RR 245/70R16 7JJX16 STEEL(AVL) (B) M12 H=30.5	8-97176-091-0	24	1	9712-9905	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI (ATQ),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF), FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(AUU),FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV) ,FRT&RR 245/70R16 7JJX16 STEEL(AVL) (B) M12 H=30.5	8-97229-212-0	24	1	9906-9908	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF),FR T&RR 245/70R16 7JJX16 MESH ALUMI(AUV), FRT&RR 245/70R16 7JJX16 STEEL(AVL),FRT&RR 24 5/70R16 7JJX16 12 SPOKE ALUMI(BNT), FRT&RR245/70R16 7JJX16 12 SPOKE ALUMI(BNV) (B) M12 H=30.5	8-97229-212-0	24	1	9909-0001	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF),FR T&RR 245/70R16 7JJX16 MESH ALUMI(AUV), FRT&RR 245/70R16 7JJX16 STEEL(AVL),FRT&RR 24 5/70R16 7JJX16 12 SPOKE ALUMI(BNT), FRT&RR245/70R16 7JJX16 12 SPOKE ALUMI(BNV),FRT &RR 245/70R16 7JJX16 MESH ALUMI(BVD) (B) M12 H=30.5	8-97229-212-0	24	1	0002-0111	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF),FR T&RR 245/70R16 7JJX16 MESH ALUMI(AUV), FRT&RR 245/70R16 7JJX16 STEEL(AVL),FRT&RR 24 5/70R16 7JJX16 12 SPOKE ALUMI(BNT), FRT&RR245/70R16 7JJX16 12 SPOKE ALUMI(BNV) (B) M12 H=30.5	8-97229-212-0	24	1	0112-0204	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF),FR T&RR 245/70R16 7JJX16 MESH ALUMI(AUV), FRT&RR 245/70R16 7JJX16 STEEL(AVL),FRT&RR 24 5/70R16 7JJX16 12 SPOKE ALUMI(BNT), FRT&RR245/70R16 7JJX16 12 SPOKE ALUMI(BNV) (B) M12 H=30.5	8-97333-108-0	24	1	0205-0306	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 STEEL(AUF), FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV),FRT&R R 245/70R16 7JJX16 12 SPOKE ALUMI(BNT), FRT&RR 245/70R16 7JJX16 STEEL(CQY),FRT&RR 2 45/70R16 7JJX16 MESH ALUMI(CQZ),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(CRA),FRT&RR 245/70R16 7JJX16 12 SPOKE ALUMI(CRB) (B) M12 H=30.5	8-97333-108-0	24	1	0307-	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 7.00-16-6PR 5.5FX16 STEEL(9MY) (C) M12 H=16	8-94200-216-0	24	1	9712-9809	●	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> (C) REAR	8-97807-457-0	02	1	9712-9908	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. THAILAND EQUIPMENT(PM9) (C) REAR	8-97807-457-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2) (C) FRONT	8-97090-653-0	02	1	9712-9908	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2),THAILAND EQUIPMENT(PM9) (C) FRONT	8-97090-653-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2) (C) FRONT	8-97090-653-1	02	1	9909-	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> (C) FRONT	8-97090-653-1	02	1	9909-	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2),THAILAND EQUIPMENT(PM9) (C) FRONT	8-97090-653-1	02	1	9909-		●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. THAILAND EQUIPMENT(PM9) (C) FRONT	8-97090-653-1	02	1	9909-		●
6	05.858 CAP; WHEEL HUB CAP STEEL WHEEL<PA5> EXC. MANUAL LOCKING HUB(ED2) (B) REAR	8-94359-268-1	04	1	9712-	●	●
6	05.858 CAP; WHEEL HUB CAP STEEL WHEEL<6ZT> EXC. MANUAL LOCKING HUB(ED2) (A) FRONT & REAR	8-94499-940-0	04	1	9712-9908	●	●
6	05.858 CAP; WHEEL HUB CAP STEEL WHEEL<6ZT> EXC. MANUAL LOCKING HUB(ED2) (A) FRONT & REAR	8-97222-167-0	04	1	9909-0210	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP ALUMI WHEEL<6ZR> (G) FRONT W/HOLE	8-97807-456-0	02	1	9712-	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<PA5> (B) FRONT W/HOLE	8-94359-267-1	02	1	9712-	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<PA5> (B) REAR	8-94359-268-1	02	1	9712-	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<6ZT> (A) FRONT W/HOLE	8-94499-939-0	02	1	9712-9908	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<6ZT> (G) FRONT W/HOLE W/HOLE	8-97222-166-0	02	1	9909-0210	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<6ZT> (A) REAR	8-94499-940-0	02	1	9712-9908	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<6ZT> (A) REAR	8-97222-167-0	02	1	9909-0210	●	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<7LK> EXC. MANUAL LOCKING HUB(ED2) (D) FRONT & REAR WO/HOLE	8-97127-048-0	04	1	9712-9908		●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP ALUMI WHEEL<7LK> (E) FRONT W/HOLE W/HOLE	8-94485-732-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP ALUMI WHEEL<7LK> (D) REAR WO/HOLE	8-97127-048-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6UY> (E) FRONT & REAR	8-97184-676-2	04	1	9909-0210	●	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6UY> (E) FRONT & REAR	8-97353-407-0	04	1	0211-	●	●
6	05.858 CAP; WHEEL THAILAND EQUIPMENT(PM9) HUB CAP ALUMI WHEEL<6ZR> (F) REAR	8-97127-046-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL THAILAND EQUIPMENT(PM9) HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2) (F) FRONT	8-97127-044-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL THAILAND EQUIPMENT(PM9) HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2) (F) FRONT	8-97127-044-1	02	1	9909-		●
6	05.858 CAP; WHEEL THAILAND EQUIPMENT(PM9) HUB CAP ALUMI WHEEL<6ZR> (F) FRONT	8-97127-044-1	02	1	9909-		●
7	05.812 SCREW; HUB CAP HUB CAP ALUMI WHEEL<7LK> 09.786 M6X20	9-03910-620-0	12	1	9712-9908		●
7	05.812 SCREW; HUB CAP HUB CAP ALUMI WHEEL<6UY> 06.500 M6X25	8-94279-204-0	12	1	9909-	●	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 MESH ALUMI(BVD) (B) FRONT,REAR AND SPARE	8-97211-044-0	05	1	0002-0111	●	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX), FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV) (B) FRONT,REAR AND SPARE	8-97149-118-1	05	1	9712-0011	●	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV) (B) FRONT,REAR AND SPARE	8-97149-118-1	05	1	0012-0306	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX), FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV) (B) FRONT,REAR AND SPARE	8-97149-118-1	05	1	0012-0306		●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV) (B) FRONT,REAR AND SPARE	8-97149-118-1	05	1	0307-	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV), FRT&RR 245/70R16 7JJX16 MESH ALUMI(CQZ) (B) FRONT,REAR AND SPARE	8-97149-118-1	05	1	0307-		●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL) (D) SPARE	8-97168-995-0	01	1	9712-9908	●	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN) (D) FRONT,REAR AND SPARE	8-97168-995-0	05	1	9909-0011	●	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL) (D) FRONT,REAR AND SPARE	8-97168-995-1	05	1	0012-0306	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN) (D) FRONT,REAR AND SPARE	8-97168-995-1	05	1	0012-0306		●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL) (D) FRONT,REAR AND SPARE	8-97168-995-1	05	1	0307-	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(CRA) (D) FRONT,REAR AND SPARE	8-97168-995-1	05	1	0307-		●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATQ) (D) FRONT,REAR	8-97168-995-0	04	1	9712-9908	●	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN) (D) FRONT,REAR AND SPARE	8-97168-995-0	05	1	9712-9908	●	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(AUU) (A) FRONT,REAR AND SPARE	8-97172-065-0	05	1	9712-9908	●	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 SPIDER ALUMI(AUK) (C) FRONT,REAR AND SPARE	8-97102-276-2	05	1	9712-9908		●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 12 SPOKE ALUMI(BNT),FRT&RR 245/70R16 7JJX16 12 SPOKE ALUMI(BNV) (E) FRONT,REAR AND SPARE	8-97219-484-0	05	1	9909-0011	●	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 12 SPOKE ALUMI(BNT) (E) FRONT,REAR AND SPARE	8-97219-484-1	05	1	0012-0306	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 12 SPOKE ALUMI(BNT),FRT&RR 245/70R16 7JJX16 12 SPOKE ALUMI(BNV) (E) FRONT,REAR AND SPARE	8-97219-484-1	05	1	0012-0306		●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 12 SPOKE ALUMI(BNT) (E) FRONT,REAR AND SPARE	8-97219-484-1	05	1	0307-	●
22	05.809 WHEEL; DISC,AL FRT&RR 245/70R16 7JJX16 12 SPOKE ALUMI(BNT),FRT&RR 245/70R16 7JJX16 12 SPOKE ALUMI(CRB) (E) FRONT,REAR AND SPARE	8-97219-484-1	05	1	0307-		●
34	05.871 BOLT; HUB CAP HUB CAP ALUMI WHEEL<6ZR> M6X16 W/FLANGE	8-97807-546-0	12	1	9712-9802	●	●
34	05.871 BOLT; HUB CAP HUB CAP ALUMI WHEEL<6ZR> M6X16 W/PL WASHER	8-97201-913-0	12	1	9803-9902	●	●
34	05.871 BOLT; HUB CAP HUB CAP ALUMI WHEEL<6ZR> M6X16	8-97227-442-0	12	1	9903-9906	●	●
34	05.871 BOLT; HUB CAP HUB CAP ALUMI WHEEL<6ZR> M6X16 FLANGE	8-97230-790-0	12	1	9907-0112	●	●
34	05.871 BOLT; HUB CAP HUB CAP ALUMI WHEEL<6ZR> M6X18 FLANGE	8-97324-856-0	12	1	0201-	●	●
36	05.871 WASHER; PL,HUB CAP HUB CAP ALUMI WHEEL<6ZR>	8-97227-438-0	12	1	9903-9906	●	●

2 6 3 2 31 3 2 3 6

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
2	05.803 WHEEL; DISC FRT&RR 215/80R16 6JJX16 STEEL(AQV) (A) FRONT,REAR AND SPARE OFF SET=30	8-97032-008-1	05	1	9712-0210	●	●
2	05.803 WHEEL; DISC FRT&RR 245/70R16 7JJX16 STEEL(AUF) (B) FRONT,REAR OFFSET=38	8-97170-821-0	04	1	9712-9908	●	●
2	05.803 WHEEL; DISC FRT&RR 245/70R16 7JJX16 STEEL(AVL) (B) FRONT,REAR AND SPARE OFFSET=38	8-97170-821-0	05	1	9712-9908	●	●
2	05.803 WHEEL; DISC FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATQ),FRT&RR 245/70R16 7JJX16 STEEL(AUF) (B) SPARE OFFSET=38	8-97170-821-0	01	1	9712-9908	●	●
2	05.803 WHEEL; DISC FRT&RR 245/70R16 7JJX16 STEEL(AUF), FRT&RR245/70R16 7JJX16 STEEL(AVL) (B) FRONT,REAR AND SPARE OFFSET=38	8-97170-821-0	05	1	9909-0011	●	●
2	05.803 WHEEL; DISC FRT&RR 245/70R16 7JJX16 STEEL(AUF) (B) FRONT,REAR AND SPARE OFFSET=38	8-97170-821-0	05	1	0012-0306	●
2	05.803 WHEEL; DISC FRT&RR 245/70R16 7JJX16 STEEL(AUF), FRT&RR245/70R16 7JJX16 STEEL(AVL) (B) FRONT,REAR AND SPARE OFFSET=38	8-97170-821-0	05	1	0012-0306		●
2	05.803 WHEEL; DISC FRT&RR 245/70R16 7JJX16 STEEL(AUF) (B) FRONT,REAR AND SPARE OFFSET=38	8-97170-821-0	05	1	0307-	●
2	05.803 WHEEL; DISC FRT&RR 245/70R16 7JJX16 STEEL(AUF), FRT&RR245/70R16 7JJX16 STEEL(CQY) (B) FRONT,REAR AND SPARE OFFSET=38	8-97170-821-0	05	1	0307-		●
2	05.803 WHEEL; DISC FRT&RR 7.00-16-6PR 5.5FX16 STEEL(9MY) (C) FRONT,REAR AND SPARE OFFSET=20	8-97018-904-1	05	1	9712-9809	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 215/80R16 6JJX16 STEEL(AQV) (A) M12 H=40	8-97129-440-1	24	1	9712-9908	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 215/80R16 6JJX16 STEEL(AQV) (A) M12 H=40	8-97222-248-1	24	1	9909-0210	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI (ATQ),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF), FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(AUU),FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV) ,FRT&RR 245/70R16 7JJX16 STEEL(AVL) (B) M12 H=30.5	8-97176-091-0	24	1	9712-9905	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI (ATQ),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF), FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(AUU),FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV) ,FRT&RR 245/70R16 7JJX16 STEEL(AVL) (B) M12 H=30.5	8-97229-212-0	24	1	9906-9908	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF),FR T&RR 245/70R16 7JJX16 MESH ALUMI(AUV), FRT&RR 245/70R16 7JJX16 STEEL(AVL),FRT&RR 24 5/70R16 7JJX16 12 SPOKE ALUMI(BNT), FRT&RR245/70R16 7JJX16 12 SPOKE ALUMI(BNV) (B) M12 H=30.5	8-97229-212-0	24	1	9909-0001	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF),FR T&RR 245/70R16 7JJX16 MESH ALUMI(AUV), FRT&RR 245/70R16 7JJX16 STEEL(AVL),FRT&RR 24 5/70R16 7JJX16 12 SPOKE ALUMI(BNT), FRT&RR245/70R16 7JJX16 12 SPOKE ALUMI(BNV),FRT &RR 245/70R16 7JJX16 MESH ALUMI(BVD) (B) M12 H=30.5	8-97229-212-0	24	1	0002-0111	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF),FR T&RR 245/70R16 7JJX16 MESH ALUMI(AUV), FRT&RR 245/70R16 7JJX16 STEEL(AVL),FRT&RR 24 5/70R16 7JJX16 12 SPOKE ALUMI(BNT), FRT&RR245/70R16 7JJX16 12 SPOKE ALUMI(BNV) (B) M12 H=30.5	8-97229-212-0	24	1	0112-0204	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATN),FRT&RR 245/70R16 7JJX16 MESHE ALUMI(ATX),FRT&RR 245/70R16 7JJX16 STEEL(AUF),FR T&RR 245/70R16 7JJX16 MESH ALUMI(AUV), FRT&RR 245/70R16 7JJX16 STEEL(AVL),FRT&RR 24 5/70R16 7JJX16 12 SPOKE ALUMI(BNT), FRT&RR245/70R16 7JJX16 12 SPOKE ALUMI(BNV) (B) M12 H=30.5	8-97333-108-0	24	1	0205-0306	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(ATL),FRT&RR 245/70R16 7JJX16 STEEL(AUF), FRT&RR 245/70R16 7JJX16 MESH ALUMI(AUV),FRT&R R 245/70R16 7JJX16 12 SPOKE ALUMI(BNT), FRT&RR 245/70R16 7JJX16 STEEL(CQY),FRT&RR 2 45/70R16 7JJX16 MESH ALUMI(CQZ),FRT&RR 245/70R16 7JJX16 5 SPOKE ALUMI(CRA),FRT&RR 245/70R16 7JJX16 12 SPOKE ALUMI(CRB) (B) M12 H=30.5	8-97333-108-0	24	1	0307-	●	●
3	05.813 NUT; WHEEL,FRT AXLE FRT&RR 7.00-16-6PR 5.5FX16 STEEL(9MY) (C) M12 H=16	8-94200-216-0	24	1	9712-9809	●	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> (C) REAR	8-97807-457-0	02	1	9712-9908	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. THAILAND EQUIPMENT(PM9) (C) REAR	8-97807-457-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2) (C) FRONT	8-97090-653-0	02	1	9712-9908	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2),THAILAND EQUIPMENT(PM9) (C) FRONT	8-97090-653-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2) (C) FRONT	8-97090-653-1	02	1	9909-	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> (C) FRONT	8-97090-653-1	02	1	9909-	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2),THAILAND EQUIPMENT(PM9) (C) FRONT	8-97090-653-1	02	1	9909-		●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6ZR> EXC. THAILAND EQUIPMENT(PM9) (C) FRONT	8-97090-653-1	02	1	9909-		●
6	05.858 CAP; WHEEL HUB CAP STEEL WHEEL<PA5> EXC. MANUAL LOCKING HUB(ED2) (B) REAR	8-94359-268-1	04	1	9712-	●	●
6	05.858 CAP; WHEEL HUB CAP STEEL WHEEL<6ZT> EXC. MANUAL LOCKING HUB(ED2) (A) FRONT & REAR	8-94499-940-0	04	1	9712-9908	●	●
6	05.858 CAP; WHEEL HUB CAP STEEL WHEEL<6ZT> EXC. MANUAL LOCKING HUB(ED2) (A) FRONT & REAR	8-97222-167-0	04	1	9909-0210	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP ALUMI WHEEL<6ZR> (G) FRONT W/HOLE	8-97807-456-0	02	1	9712-	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<PA5> (B) FRONT W/HOLE	8-94359-267-1	02	1	9712-	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<PA5> (B) REAR	8-94359-268-1	02	1	9712-	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<6ZT> (A) FRONT W/HOLE	8-94499-939-0	02	1	9712-9908	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<6ZT> (G) FRONT W/HOLE W/HOLE	8-97222-166-0	02	1	9909-0210	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<6ZT> (A) REAR	8-94499-940-0	02	1	9712-9908	●	●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP STEEL WHEEL<6ZT> (A) REAR	8-97222-167-0	02	1	9909-0210	●	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<7LK> EXC. MANUAL LOCKING HUB(ED2) (D) FRONT & REAR WO/HOLE	8-97127-048-0	04	1	9712-9908		●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP ALUMI WHEEL<7LK> (E) FRONT W/HOLE W/HOLE	8-94485-732-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL MANUAL LOCKING HUB(ED2) HUB CAP ALUMI WHEEL<7LK> (D) REAR WO/HOLE	8-97127-048-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6UY> (E) FRONT & REAR	8-97184-676-2	04	1	9909-0210	●	●
6	05.858 CAP; WHEEL HUB CAP ALUMI WHEEL<6UY> (E) FRONT & REAR	8-97353-407-0	04	1	0211-	●	●
6	05.858 CAP; WHEEL THAILAND EQUIPMENT(PM9) HUB CAP ALUMI WHEEL<6ZR> (F) REAR	8-97127-046-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL THAILAND EQUIPMENT(PM9) HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2) (F) FRONT	8-97127-044-0	02	1	9712-9908		●
6	05.858 CAP; WHEEL THAILAND EQUIPMENT(PM9) HUB CAP ALUMI WHEEL<6ZR> EXC. MANUAL LOCKING HUB(ED2) (F) FRONT	8-97127-044-1	02	1	9909-		●
6	05.858 CAP; WHEEL THAILAND EQUIPMENT(PM9) HUB CAP ALUMI WHEEL<6ZR> (F) FRONT	8-97127-044-1	02	1	9909-		●
31	05.839 RING; SIDE,DISC WHEEL FRT&RR 7.00-16-6PR 5.5FX16 STEEL(9MY)	8-97019-013-0	05	1	9712-9809	●	●
