Sayfa 0-65 - Isuzu EPC

0-65 — STARTER (#73233) — 150 parça

31 51 2 85 85 28 7 73 54 27 27 9 10 9 23 21 43 22 19 17 17 16 20 50

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
2	02.085 CASE; PINION,STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-426-1	01	1	-
2	02.085 CASE; PINION,STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97142-908-0	01	1	-
2	02.085 CASE; PINION,STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97182-789-0	01	1	-
7	02.086 CLUTCH ASM; PINION,STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97182-787-0	01	1	-
9	02.083 BEARING; GEAR SHAFT STARTER (A) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97047-549-0	01	1	-
9	02.083 BEARING; GEAR SHAFT STARTER (B) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97047-550-0	01	1	-
10	02.086 SHAFT; GEAR STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97130-189-0	01	1	-
16	02.043 ARMATURE; STARTER ASM PART: A = 8-94384-314-1, 94384314	8-94377-253-0	01	1	-
16	02.043 ARMATURE; STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97112-555-0	01	1	-
16	02.043 ARMATURE; STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-869-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (A) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94228-436-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (B) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94228-437-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (A) ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94377-240-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (B) ASM PART: A = 8-94384-314-1, 94384314	8-94377-241-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (B) ASM PART: B = 8-97120-356-2, 97120356	8-97112-954-0	01	1	-
19	02.049 COIL; FIELD,STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505	8-97182-785-0	01	1	-
19	02.049 COIL; FIELD,STARTER ASM PART: E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97224-888-0	01	1	-
20	02.051 BRUSH; (+),STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97113-286-0	02	1	-
21	02.053 SPRING; BRUSH HOLDER STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94242-064-0	04	1	-
21	02.053 SPRING; BRUSH HOLDER STARTER ASM PART: A = 8-94384-314-1, 94384314	8-94377-244-0	04	1	-
21	02.053 SPRING; BRUSH HOLDER STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-880-0	04	1	-
22	02.051 HOLDER; BRUSH STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-424-0	01	1	-
22	02.051 HOLDER; BRUSH STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-873-0	01	1	-
22	02.051 HOLDER; BRUSH STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97142-597-0	01	1	-
23	02.067 COVER; RR COVER STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-423-0	01	1	-
23	02.067 COVER; RR COVER STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-875-0	01	1	-
23	02.067 COVER; RR COVER STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97130-193-0	01	1	-
27	02.077 BOLT; THROUGH,STARTER (A) ASM PART: A = 8-94384-314-1, 94384314	8-94377-243-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (B) ASM PART: A = 8-94384-314-1, 94384314	8-97041-422-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (C) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97112-565-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (A) ASM PART: B = 8-97120-356-2, 97120356	8-97112-881-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (B) ASM PART: B = 8-97120-356-2, 97120356	8-97112-957-0	02	1	-
28	02.108 LEVER; SHIFT,STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97130-186-0	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-425-0	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97142-907-1	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: C = 8-97146-338-3, 97146338	8-97182-788-0	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653	8-97210-564-0	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: F = 8-97323-437-0, 97323437	8-97353-957-0	01	1	-
43	02.086 RETAINER; PINION STARTER ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94377-246-0	01	1	-
43	02.086 RETAINER; PINION STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94435-570-0	01	1	-
50	02.051 BRUSH; (-),STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97113-286-0	02	1	-
51	02.104 COVER SET; DUST ENGAGE SW STARTE ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97130-185-0	01	1	-
54	02.086 CLUTCH; PINION,STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97047-548-0	01	1	-
54	02.086 CLUTCH; PINION,STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97078-002-0	01	1	-
54	02.086 CLUTCH; PINION,STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97148-687-0	01	1	-
73	02.063 STOPPER SET; PINION ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94228-450-0	01	1	-
85	02.102 BOLT; ENGAGE SW FIX,STARTER 02.041 ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	5-81129-294-0	02	1	-

23 41 14 22 21 13 14 27 16 17 58 32 17 114 46 44 43 114 31 47 48 54 96 27 2

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
2	02.085 CASE; PINION,STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-426-1	01	1	-
2	02.085 CASE; PINION,STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97142-908-0	01	1	-
2	02.085 CASE; PINION,STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97182-789-0	01	1	-
13	02.049 YOKE; STARTER ASM PART: A = 8-94384-314-1, 94384314	8-94377-254-0	01	1	-
13	02.049 YOKE; STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97135-497-0	01	1	-
14	02.087 GASKET; YOKE,STARTER 02.049 ASM PART: A = 8-94384-314-1, 94384314	8-94170-214-0	02	1	-
16	02.043 ARMATURE; STARTER ASM PART: A = 8-94384-314-1, 94384314	8-94377-253-0	01	1	-
16	02.043 ARMATURE; STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97112-555-0	01	1	-
16	02.043 ARMATURE; STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-869-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (A) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94228-436-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (B) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94228-437-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (A) ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94377-240-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (B) ASM PART: A = 8-94384-314-1, 94384314	8-94377-241-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (B) ASM PART: B = 8-97120-356-2, 97120356	8-97112-954-0	01	1	-
21	02.053 SPRING; BRUSH HOLDER STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94242-064-0	04	1	-
21	02.053 SPRING; BRUSH HOLDER STARTER ASM PART: A = 8-94384-314-1, 94384314	8-94377-244-0	04	1	-
21	02.053 SPRING; BRUSH HOLDER STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-880-0	04	1	-
22	02.051 HOLDER; BRUSH STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-424-0	01	1	-
22	02.051 HOLDER; BRUSH STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-873-0	01	1	-
22	02.051 HOLDER; BRUSH STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97142-597-0	01	1	-
23	02.067 COVER; RR COVER STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-423-0	01	1	-
23	02.067 COVER; RR COVER STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-875-0	01	1	-
23	02.067 COVER; RR COVER STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97130-193-0	01	1	-
27	02.077 BOLT; THROUGH,STARTER (A) ASM PART: A = 8-94384-314-1, 94384314	8-94377-243-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (B) ASM PART: A = 8-94384-314-1, 94384314	8-97041-422-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (C) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97112-565-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (A) ASM PART: B = 8-97120-356-2, 97120356	8-97112-881-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (B) ASM PART: B = 8-97120-356-2, 97120356	8-97112-957-0	02	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-425-0	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97142-907-1	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: C = 8-97146-338-3, 97146338	8-97182-788-0	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653	8-97210-564-0	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: F = 8-97323-437-0, 97323437	8-97353-957-0	01	1	-
32	02.115 COVER; RUBBER,STARTER ASM PART: B = 8-97120-356-2, 97120356	5-81119-029-0	01	1	-
32	02.115 COVER; RUBBER,STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-420-0	01	1	-
41	02.067 SCREW; RR COVER,STARTER ASM PART: A = 8-94384-314-1, 94384314	8-94170-216-0	02	1	-
41	02.067 SCREW; RR COVER,STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97142-903-0	02	1	-
43	02.086 RETAINER; PINION STARTER ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94377-246-0	01	1	-
43	02.086 RETAINER; PINION STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94435-570-0	01	1	-
44	02.086 ROLLER; PINION STARTER ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	5-81129-099-0	05	1	-
46	02.086 GEAR; CLU STARTER (C) ASM PART: A = 8-94384-314-1, 94384314	8-94377-247-0	01	1	-
46	02.086 GEAR; CLU STARTER (A) ASM PART: B = 8-97120-356-2, 97120356	8-97078-649-0	01	1	-
46	02.086 GEAR; CLU STARTER (B) ASM PART: B = 8-97120-356-2, 97120356	8-97142-904-0	01	1	-
47	02.086 SPRING; PINION STARTER ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94377-245-0	01	1	-
48	02.108 BALL; PINION,STARTER ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	5-81129-092-0	01	1	-
54	02.086 CLUTCH; PINION,STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97047-548-0	01	1	-
54	02.086 CLUTCH; PINION,STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97078-002-0	01	1	-
54	02.086 CLUTCH; PINION,STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97148-687-0	01	1	-
58	03.330 PIPE; DRAIN RR COVER STARTER 02.067 ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-97041-421-0	01	1	-
96	02.104 GASKET; FRT CASE ASM PART: A = 8-94384-314-1, 94384314	8-97078-001-0	01	1	-
114	02.055 NUT; TERMINAL 02.102, (A) ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94109-763-0	01	1	-
114	02.055 NUT; TERMINAL (B) ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94377-238-0	01	1	-

23 38 13 41 17 58 16 32 21 22 38 114 17 46 46 44 43 27 31 47 48 114 54 27 2

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
2	02.085 CASE; PINION,STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-426-1	01	1	-
2	02.085 CASE; PINION,STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97142-908-0	01	1	-
2	02.085 CASE; PINION,STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97182-789-0	01	1	-
13	02.049 YOKE; STARTER ASM PART: A = 8-94384-314-1, 94384314	8-94377-254-0	01	1	-
13	02.049 YOKE; STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97135-497-0	01	1	-
16	02.043 ARMATURE; STARTER ASM PART: A = 8-94384-314-1, 94384314	8-94377-253-0	01	1	-
16	02.043 ARMATURE; STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97112-555-0	01	1	-
16	02.043 ARMATURE; STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-869-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (A) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94228-436-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (B) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94228-437-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (A) ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94377-240-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (B) ASM PART: A = 8-94384-314-1, 94384314	8-94377-241-0	01	1	-
17	02.083 BEARING; ARMATURE,STARTER (B) ASM PART: B = 8-97120-356-2, 97120356	8-97112-954-0	01	1	-
21	02.053 SPRING; BRUSH HOLDER STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94242-064-0	04	1	-
21	02.053 SPRING; BRUSH HOLDER STARTER ASM PART: A = 8-94384-314-1, 94384314	8-94377-244-0	04	1	-
21	02.053 SPRING; BRUSH HOLDER STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-880-0	04	1	-
22	02.051 HOLDER; BRUSH STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-424-0	01	1	-
22	02.051 HOLDER; BRUSH STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-873-0	01	1	-
22	02.051 HOLDER; BRUSH STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97142-597-0	01	1	-
23	02.067 COVER; RR COVER STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-423-0	01	1	-
23	02.067 COVER; RR COVER STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97112-875-0	01	1	-
23	02.067 COVER; RR COVER STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97130-193-0	01	1	-
27	02.077 BOLT; THROUGH,STARTER (A) ASM PART: A = 8-94384-314-1, 94384314	8-94377-243-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (B) ASM PART: A = 8-94384-314-1, 94384314	8-97041-422-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (C) ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97112-565-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (A) ASM PART: B = 8-97120-356-2, 97120356	8-97112-881-0	02	1	-
27	02.077 BOLT; THROUGH,STARTER (B) ASM PART: B = 8-97120-356-2, 97120356	8-97112-957-0	02	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-425-0	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97142-907-1	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: C = 8-97146-338-3, 97146338	8-97182-788-0	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653	8-97210-564-0	01	1	-
31	02.100 SWITCH; ENGAGE STARTER ASM PART: F = 8-97323-437-0, 97323437	8-97353-957-0	01	1	-
32	02.115 COVER; RUBBER,STARTER ASM PART: B = 8-97120-356-2, 97120356	5-81119-029-0	01	1	-
32	02.115 COVER; RUBBER,STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97041-420-0	01	1	-
38	02.070 GASKET; RR COVER,STARTER 02.049 ASM PART: B = 8-97120-356-2, 97120356	8-94170-214-0	02	1	-
41	02.067 SCREW; RR COVER,STARTER ASM PART: A = 8-94384-314-1, 94384314	8-94170-216-0	02	1	-
41	02.067 SCREW; RR COVER,STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97142-903-0	02	1	-
43	02.086 RETAINER; PINION STARTER ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94377-246-0	01	1	-
43	02.086 RETAINER; PINION STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-94435-570-0	01	1	-
44	02.086 ROLLER; PINION STARTER ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	5-81129-099-0	05	1	-
46	02.086 GEAR; CLU STARTER (C) ASM PART: A = 8-94384-314-1, 94384314	8-94377-247-0	01	1	-
46	02.086 GEAR; CLU STARTER (A) ASM PART: B = 8-97120-356-2, 97120356	8-97078-649-0	01	1	-
46	02.086 GEAR; CLU STARTER (B) ASM PART: B = 8-97120-356-2, 97120356	8-97142-904-0	01	1	-
47	02.086 SPRING; PINION STARTER ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94377-245-0	01	1	-
48	02.108 BALL; PINION,STARTER ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	5-81129-092-0	01	1	-
54	02.086 CLUTCH; PINION,STARTER ASM PART: C = 8-97146-338-3, 97146338, D = 8-97210-505-0, 97210505, E = 8-97223-653-0, 97223653, F = 8-97323-437-0, 97323437	8-97047-548-0	01	1	-
54	02.086 CLUTCH; PINION,STARTER ASM PART: A = 8-94384-314-1, 94384314	8-97078-002-0	01	1	-
54	02.086 CLUTCH; PINION,STARTER ASM PART: B = 8-97120-356-2, 97120356	8-97148-687-0	01	1	-
58	03.330 PIPE; DRAIN RR COVER STARTER 02.067 ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-97041-421-0	01	1	-
114	02.055 NUT; TERMINAL 02.102, (A) ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94109-763-0	01	1	-
114	02.055 NUT; TERMINAL (B) ASM PART: A = 8-94384-314-1, 94384314, B = 8-97120-356-2, 97120356	8-94377-238-0	01	1	-
