◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ GXZ ▶ 11462 - GXZ CNG(THAI)EURO3 ▶ 7 - Interior Trim, Emblems / Labels, Seats, Mirrors ▶ 7-10 - CAUTION PLATE AND LABEL ▶
7-10 — CAUTION PLATE AND LABEL (#73171) — 27 parça
çizim 132779
2 2
BalonParca AdiParca NoAdetTipApplied Date A B
2 LABEL; FUEL CAUTION
(A) THA 		8-97924-883-1 01 1 1204-1208 ●
2 LABEL; FUEL CAUTION
(A) THA 		8-97924-883-1 01 1 1209- ● ●
2 LABEL; FUEL CAUTION
(B) THA 		8-97924-884-1 08 1 1204-1208 ●
2 LABEL; FUEL CAUTION
(B) THA 		8-97924-884-1 08 1 1209- ● ●
çizim 133095
51 181 6
BalonParca AdiParca NoAdetTipApplied Date A B
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME SIDE<P13> THA 		8-97918-788-0 01 1 1204-1208 ●
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME SIDE<P13> THA 		8-97918-788-0 01 1 1209- ●
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10> THA 		8-97918-788-0 01 1 1209- ●
51 PLATE; CAUTION,WARNING
THA 		8-97924-894-1 01 1 1204-1208 ●
51 PLATE; CAUTION,WARNING
THA 		8-97924-894-1 01 1 1209- ● ●
181 PLATE; CAUTION,AIR CLEANER
THA 		8-97923-977-1 01 1 1204-1208 ●
181 PLATE; CAUTION,AIR CLEANER
THA 		8-97923-977-1 01 1 1209- ● ●
çizim 194253
119 49 35 60 291 160 306
BalonParca AdiParca NoAdetTipApplied Date A B
35 PLATE; CAUTION,CAB
THA 		8-97923-976-1 01 1 1204-1208 ●
35 PLATE; CAUTION,CAB
THA 		8-97923-976-1 01 1 1209- ● ●
49 PLATE; CAUTION,FUSE BOX
EXC. ANTILOCK BRAKE SYSTEM<BFA> THA 		8-97923-962-1 01 1 1204-1208 ●
49 PLATE; CAUTION,FUSE BOX
EXC. ANTILOCK BRAKE SYSTEM<BFA> THA 		8-97923-962-1 01 1 1209- ●
49 PLATE; CAUTION,FUSE BOX
THA 		8-97923-962-1 01 1 1209- ●
49 PLATE; CAUTION,FUSE BOX
ANTILOCK BRAKE SYSTEM<BFA> THA 		8-97924-890-0 01 1 1204- ●
60 PLATE; CAUTION,CAB TILT 8-98017-667-1 01 1 1204-1208 ●
60 PLATE; CAUTION,CAB TILT 8-98017-667-1 01 1 1209- ● ●
119 PLATE; CAUTION,HAND BRK LEVER
THA 		8-97924-257-1 01 1 1204-1208 ●
119 PLATE; CAUTION,HAND BRK LEVER
THA 		8-97924-257-1 01 1 1209- ● ●
160 PLATE; CAUTION,TOWING
THA 		8-97918-791-1 01 1 1204-1208 ●
160 PLATE; CAUTION,TOWING
THA 		8-97918-791-1 01 1 1209- ● ●
291 PLATE; CAUTION,TIRE AIR PRESS
THA 		8-97924-660-1 01 1 1204-1208 ●
291 PLATE; CAUTION,TIRE AIR PRESS
THA 		8-97924-660-1 01 1 1209- ● ●
306 LABEL; BEAM & PASS 8-98070-239-0 01 1 1204-1208 ●
306 LABEL; BEAM & PASS 8-98070-239-0 01 1 1209- ● ●
