Isuzu WW
▶
TRUCKS
▶
FTS
▶
11307 - FTS AUST/NZ EURO5
▶
3 - Brakes, Brake System
▶
3-08B - PARKING BRAKE
▶
3-08B — PARKING BRAKE
(#71076) — 20 parça
Tümü
A - LCT2000 A/T ALLISON
B - LCT2500 A/T ALLISON
8
11
9
8
15
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
8
FLANGE; PARKING BRK
(B)
1-37243-426-0
01
1
1204-1306
●
8
FLANGE; PARKING BRK
(B)
1-37243-426-0
01
1
1307-1501
●
8
FLANGE; PARKING BRK
EXC. VIN MODEL YEAR 2015<VZF> (B)
1-37243-426-0
01
1
1502-1503
●
8
FLANGE; PARKING BRK
(B)
1-37243-426-0
01
1
1504-
●
8
FLANGE; PARKING BRK
(A)
1-37249-199-0
01
1
1204-1306
●
8
FLANGE; PARKING BRK
(A)
1-37249-199-0
01
1
1307-1501
●
8
FLANGE; PARKING BRK
EXC. VIN MODEL YEAR 2015<VZF> (A)
1-37249-199-0
01
1
1502-1503
●
8
FLANGE; PARKING BRK
(A)
1-37249-199-0
01
1
1504-
●
9
WASHER; FLANGE FIX
1-37249-200-0
01
1
1204-1306
●
9
WASHER; FLANGE FIX
1-37249-200-0
01
1
1307-1501
●
9
WASHER; FLANGE FIX
EXC. VIN MODEL YEAR 2015<VZF>
1-37249-200-0
01
1
1502-1503
●
9
WASHER; FLANGE FIX
1-37249-200-0
01
1
1504-
●
11
BOLT; FLANGE FIX
1-09087-048-0
01
1
1204-1306
●
11
BOLT; FLANGE FIX
1-09087-048-0
01
1
1307-1501
●
11
BOLT; FLANGE FIX
EXC. VIN MODEL YEAR 2015<VZF>
1-09087-048-0
01
1
1502-1503
●
11
BOLT; FLANGE FIX
1-09087-048-0
01
1
1504-
●
15
BOLT; FLANGE
M14X46
9-46219-012-0
04
1
1204-1306
●
15
BOLT; FLANGE
M14X46
9-46219-012-0
04
1
1307-1501
●
15
BOLT; FLANGE
EXC. VIN MODEL YEAR 2015<VZF> M14X46
9-46219-012-0
04
1
1502-1503
●
15
BOLT; FLANGE
M14X46
9-46219-012-0
04
1
1504-
●
