Isuzu WW
▶
TRUCKS
▶
FSS
▶
11306 - FSS(AUST/NZ)EURO5
▶
4 - Propeller Shaft, Axles, Steering, Suspension
▶
4-11 - FRONT HUB AND DRUM OR ROTOR
▶
4-11 — FRONT HUB AND DRUM OR ROTOR
(#69851) — 35 parça
Tümü
A - FCS5MS
B - FCS5WS
5
10
6
13
17
30
19
28
21
23
22
35
27
15
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
5
BOLT; LK WASHER
M6X16 HEX SOCKET
8-98084-271-0
06
1
1011-1102
●
5
BOLT; LK WASHER
M6X16 HEX SOCKET
8-98084-271-0
06
1
1103-1201
●
●
5
BOLT; LK WASHER
M6X16 HEX SOCKET
8-98200-943-0
06
1
1202-
●
●
6
WASHER; LK,FRT HUB
ID=74.6
1-09533-008-0
02
1
1011-1102
●
6
WASHER; LK,FRT HUB
ID=74.6
1-09533-008-0
02
1
1103-
●
●
10
NUT; FRT HUB BRG
M74.6
9-09843-064-2
02
1
1011-1102
●
10
NUT; FRT HUB BRG
M74.6
9-09843-064-2
02
1
1103-
●
●
13
BEARING; HUB OUTER,FRT AXLE
NSK
1-09812-153-0
02
1
1011-1102
●
13
BEARING; HUB OUTER,FRT AXLE
NSK
1-09812-153-0
02
1
1103-
●
●
13
BEARING; HUB OUTER,FRT AXLE
JTEKT
1-09812-154-0
02
1
1011-1102
●
13
BEARING; HUB OUTER,FRT AXLE
JTEKT
1-09812-154-0
02
1
1103-
●
●
15
PIN; WHEEL,FRT AXLE
M24X37.5,M22X57.5 RH THREAD
1-42331-109-1
08
1
1011-1102
●
15
PIN; WHEEL,FRT AXLE
M24X37.5,M22X57.5 RH THREAD
1-42331-109-1
08
1
1103-
●
●
15
PIN; WHEEL,FRT AXLE
M24X37.5 LH THREAD,M22X57.5 RH THREAD
1-42332-109-1
08
1
1011-1102
●
15
PIN; WHEEL,FRT AXLE
M24X37.5 LH THREAD,M22X57.5 RH THREAD
1-42332-109-1
08
1
1103-
●
●
17
HUB; FRT AXLE
1-42312-143-1
02
1
1011-1102
●
17
HUB; FRT AXLE
1-42312-143-1
02
1
1103-1306
●
●
17
HUB; FRT AXLE
1-42312-144-1
02
1
1307-
●
●
19
BEARING; HUB INNER,FRT AXLE
NSK
1-09812-150-0
02
1
1011-1102
●
19
BEARING; HUB INNER,FRT AXLE
NSK
1-09812-150-0
02
1
1103-
●
●
19
BEARING; HUB INNER,FRT AXLE
NACHI
1-09812-151-0
02
1
1011-1102
●
19
BEARING; HUB INNER,FRT AXLE
NACHI
1-09812-151-0
02
1
1103-
●
●
21
RING; SNAP,HUB
OD=150
9-09950-147-0
02
1
1011-1102
●
21
RING; SNAP,HUB
OD=150
9-09950-147-0
02
1
1103-
●
●
22
COVER SET; FRT BRK DRUM
1-85576-014-1
02
1
1011-1102
●
22
COVER SET; FRT BRK DRUM
1-85576-014-1
02
1
1103-
●
●
23
DRUM; BRK,FRT
1-42315-362-1
02
1
1011-1102
●
23
DRUM; BRK,FRT
1-42315-362-1
02
1
1103-
●
●
27
NUT; WHEEL PIN,FRT AXLE
M22 FLANGE
1-09440-065-0
16
1
1011-1102
●
27
NUT; WHEEL PIN,FRT AXLE
M22 FLANGE
1-09440-065-0
16
1
1103-
●
●
28
SEAL; OIL,FRT HUB
TKK
9-09924-415-0
02
1
1011-1102
●
28
SEAL; OIL,FRT HUB
TKK
9-09924-415-0
02
1
1103-
●
●
30
RING; EXCITER,FRT HUB
1-42319-173-0
02
1
1307-
●
●
35
BOLT; DRUM COVER
M10X12
1-47159-187-0
12
1
1011-1102
●
35
BOLT; DRUM COVER
M10X12
1-47159-187-0
12
1
1103-
●
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
