Isuzu WW
▶
TRUCKS
▶
FVZ
▶
11305 - FVZ AUST/NZ EURO5
▶
2 - Clutch, Transmission, Trans Axle
▶
2-42 - AUTO TRANS OIL PAN AND OIL CONTROL
▶
2-42 — AUTO TRANS OIL PAN AND OIL CONTROL
(#69655) — 21 parça
6
5
61
61
103
105
105
103
61
61
6
60
61
61
103
103
61
61
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
5
PLUG; OIL PAN
1-34139-039-0
01
1
1010-1501
5
PLUG; OIL PAN
EXC. VIN MODEL YEAR 2015<VZF>
1-34139-039-0
01
1
1502-1503
5
PLUG; OIL PAN
1-34139-039-0
01
1
1504-
6
GASKET; OIL PAN TO PLUG
ID=16.4
1-34139-040-0
01
1
1010-1501
6
GASKET; OIL PAN TO PLUG
EXC. VIN MODEL YEAR 2015<VZF> ID=16.4
1-34139-040-0
01
1
1502-1503
6
GASKET; OIL PAN TO PLUG
ID=16.4
1-34139-040-0
01
1
1504-
60
REPAIR KIT; OIL FILTER,A/T
1-34139-041-0
01
1
1010-1501
60
REPAIR KIT; OIL FILTER,A/T
EXC. VIN MODEL YEAR 2015<VZF>
1-34139-041-0
01
1
1502-1503
60
REPAIR KIT; OIL FILTER,A/T
1-34139-041-0
01
1
1504-
61
SEAL; OIL FILTER
(A) ID=75.9
1-34139-042-0
02
1
1010-1501
61
SEAL; OIL FILTER
EXC. VIN MODEL YEAR 2015<VZF> (A) ID=75.9
1-34139-042-0
02
1
1502-1503
61
SEAL; OIL FILTER
(A) ID=75.9
1-34139-042-0
02
1
1504-
61
SEAL; OIL FILTER
(B)
1-34139-043-0
02
1
1010-1501
61
SEAL; OIL FILTER
EXC. VIN MODEL YEAR 2015<VZF> (B)
1-34139-043-0
02
1
1502-1503
61
SEAL; OIL FILTER
(B)
1-34139-043-0
02
1
1504-
103
GASKET; COVER
1-34139-044-0
02
1
1010-1501
103
GASKET; COVER
EXC. VIN MODEL YEAR 2015<VZF>
1-34139-044-0
02
1
1502-1503
103
GASKET; COVER
1-34139-044-0
02
1
1504-
105
BOLT; COVER
1-34139-045-0
12
1
1010-1501
105
BOLT; COVER
EXC. VIN MODEL YEAR 2015<VZF>
1-34139-045-0
12
1
1502-1503
105
BOLT; COVER
1-34139-045-0
12
1
1504-
