Isuzu WW
▶
TRUCKS
▶
FVZ
▶
11305 - FVZ AUST/NZ EURO5
▶
2 - Clutch, Transmission, Trans Axle
▶
2-37 - MANUAL TRANSMISSION CONT; MISSION SIDE
▶
2-37 — MANUAL TRANSMISSION CONT; MISSION SIDE
(#69651) — 12 parça
Tümü
A - FGY5MV
B - FGZ5MV
65
66
66
76
132
72
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
65
BRACKET; SHIFT TO SELECT,TRANS CONT
ZF9S1110 M/T(Y5E) EXC. ASSISTOR SHIFT CONTROL<WX8>
8-98060-386-0
01
1
1010-1306
●
●
65
BRACKET; SHIFT TO SELECT,TRANS CONT
ZF9S1110 M/T(Y5E) ASSISTOR SHIFT CONTROL<WX8>
8-98049-613-1
01
1
1010-
●
●
66
CLIP; SELECT BRKT
ZF9S1110 M/T(Y5E) ID=22.2
1-09701-209-1
02
1
1010-1203
●
●
66
CLIP; SELECT BRKT
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) ID=22.2
1-09701-209-1
02
1
1204-1306
●
●
66
CLIP; SELECT BRKT
ZF9S1110 M/T(Y5E) ID=22.2
1-09701-209-1
02
1
1307-
●
●
72
NUT; TRANS CONT,SELECT
ZF9S1110 M/T(Y5E) M8 FLANGE
1-09440-049-0
01
1
1010-1203
●
●
72
NUT; TRANS CONT,SELECT
TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) M8 FLANGE
1-09440-049-0
01
1
1204-1306
●
●
72
NUT; TRANS CONT,SELECT
ZF9S1110 M/T(Y5E) M8 FLANGE
1-09440-049-0
01
1
1307-
●
●
76
NUT; BALL JOINT,SELECT WIRE
ZF9S1110 M/T(Y5E) EXC. ASSISTOR SHIFT CONTROL<WX8> M10 FLANGE
1-09440-056-0
01
1
1010-1306
●
●
76
NUT; BALL JOINT,SELECT WIRE
ZF9S1110 M/T(Y5E) ASSISTOR SHIFT CONTROL<WX8> M8 FLANGE
1-09440-049-0
01
1
1010-1306
●
●
76
NUT; BALL JOINT,SELECT WIRE
ZF9S1110 M/T(Y5E) M8 FLANGE
1-09440-049-0
01
1
1307-
●
●
132
CONNECTOR; FLEX HOSE
ZF9S1110 M/T(Y5E) EXC. ASSISTOR SHIFT CONTROL<WX8> DIN8 & M12 STRAIGHT
1-09660-873-0
01
1
1010-1306
●
●
