Isuzu WW
▶
TRUCKS
▶
FVZ
▶
11305 - FVZ AUST/NZ EURO5
▶
1 - Fuel Tank, Cooling, Air Intake, Exhaust System
▶
1-55 - EXHAUST BRAKE VALVE AND CONTROL CYLINDER
▶
1-55 — EXHAUST BRAKE VALVE AND CONTROL CYLINDER
(#69637) — 10 parça
174
42
74
6
42
42
6
146
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
6
VALVE; EXH BRAKE
(A)
8-98054-173-6
01
1
1010-1302
6
VALVE; EXH BRAKE
(A)
8-98233-801-0
01
1
1303-
6
VALVE; EXH BRAKE
(B)
8-98116-162-4
01
1
1010-
42
HOSE; FLEX,EXH BRK
WHEEL BASE 5000MM(50W),WHEEL BASE 7100MM(71W) (B) L=340
1-09363-617-0
01
1
1307-
42
HOSE; FLEX,EXH BRK
(A) L=370
1-09363-771-0
01
1
1010-1306
42
HOSE; FLEX,EXH BRK
(A) L=370
1-09363-771-0
01
1
1307-
42
HOSE; FLEX,EXH BRK
WHEEL BASE 5900MM(59W) (A) L=370
1-09363-771-0
01
1
1307-
74
CONNECTOR; EXH BRK VLV
M12 & PT1/4 ELBOW
1-09650-430-0
01
1
1010-
146
NUT; EXH BRK VLV
M10 FLANGE
0-91180-210-0
04
1
1010-
174
TUBE; NYLON
SERVICED BY L=2000 OD=12
1-87411-011-0
01
1
1307-
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
