Isuzu WW
▶
BUSES
▶
LT
▶
10794 - LT(TAIWAN)
▶
7 - Interior Trim, Emblems / Labels, Seats, Mirrors
▶
7-10 - CAUTION PLATE AND LABEL
▶
7-10 — CAUTION PLATE AND LABEL
(#6892) — 24 parça
◀
[710A] NO.2 (10 parça)
[710A] NO.3 (4 parça)
[710A] NO.1 (10 parça)
▶
49
49
49
150
150
58
58
58
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
49
PLATE; CAUTION,FUSE BOX
CAUTIONS SPANISH<YN1> EXC. EMIS REGULATION W/CONV<TCA> (B)
1-85888-640-0
01
1
9806-9911
49
PLATE; CAUTION,FUSE BOX
EMIS REGULATION W/CONV<TCA> EXC. CAUTIONS FRENCH<WJ8>,CAUTIONS SPANISH<YN1> (A)
1-85877-611-0
01
1
9806-9911
49
PLATE; CAUTION,FUSE BOX
EMIS REGULATION W/CONV<TCA> CAUTIONS SPANISH<YN1> (B)
1-85878-081-0
01
1
9807-9911
49
PLATE; CAUTION,FUSE BOX
(C)
8-97531-038-0
01
1
9912-
49
PLATE; CAUTION,FUSE BOX
EXC. EMIS REGULATION W/CONV<TCA>,CAUTIONS FRENCH<WJ8>,CAUTIONS SPANISH<YN1> (A)
1-85888-542-0
01
1
9806-9911
58
PLATE; CAUTION,ENG START
CAUTIONS FRENCH<WJ8> EXC. ELEC SW BOX ENG ROOM<TEK> (C)
1-85887-535-0
01
1
9806-9911
58
PLATE; CAUTION,ENG START
CAUTIONS SPANISH<YN1> EXC. ELEC SW BOX ENG ROOM<TEK> (B)
9-83999-419-0
01
1
9806-9911
58
PLATE; CAUTION,ENG START
EXC. ELEC SW BOX ENG ROOM<TEK>,CAUTIONS FRENCH<WJ8> ,CAUTIONS SPANISH<YN1> (A)
1-85887-389-0
01
1
9806-9911
150
PLATE; CAUTION,INSTRUCTION
ELEC SW BOX ENG ROOM<TEK> EXC. CAUTIONS FRENCH<WJ8> (A)
1-85888-543-0
01
1
9806-9911
150
PLATE; CAUTION,INSTRUCTION
(B)
8-97530-785-0
01
1
9912-
228
228
181
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
181
PLATE; CAUTION,AIR CLEANER
8-97530-783-0
01
1
9912-
228
PLATE; CAUTION,AIR DRYER
AIR DRYER<PS7> CAUTIONS FRENCH<WJ8> (A)
1-48199-326-0
01
1
9806-9911
228
PLATE; CAUTION,AIR DRYER
(B)
8-97530-422-0
01
1
9912-
228
PLATE; CAUTION,AIR DRYER
AIR DRYER<PS7> EXC. CAUTIONS FRENCH<WJ8> (A)
1-48199-325-0
01
1
9806-9911
2
4
6
6
4
6
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
2
LABEL; FUEL CAUTION
1-85889-068-0
02
1
9806-
4
LABEL; ENG MAINTENANCE
6HH1-S ENG(65L) ENG OIL CLR HVY DUTY<E1E> INJ PUMP Q SET SPECIAL +5%Q(T1A) (A)
8-94391-228-0
01
1
9807-9911
4
LABEL; ENG MAINTENANCE
(B)
8-94391-524-0
01
1
9912-
4
LABEL; ENG MAINTENANCE
6HH1-S ENG(65L) INJ PUMP HIGH ALTITUDE ANEROID COMPENSATOR<YC4> EXC. INJ PUMP Q SET SPECIAL +5%Q(T1A) (A)
8-94395-936-0
01
1
9807-9911
4
LABEL; ENG MAINTENANCE
6HH1-S ENG(65L) INJ PUMP Q SET SPECIAL +5%Q(T1A) EXC. ENG OIL CLR HVY DUTY<E1E> (A)
8-94395-931-0
01
1
9807-9809
4
LABEL; ENG MAINTENANCE
6HH1-S ENG(65L) INJ PUMP Q SET SPECIAL +5%Q(T1A) EXC. ENG OIL CLR HVY DUTY<E1E> (A)
8-94395-931-0
01
1
9810-9911
4
LABEL; ENG MAINTENANCE
6HH1-S ENG(65L) EXC. INJ PUMP Q SET SPECIAL +5%Q(T1A),INJ PUMP HIGHALTITUDE ANEROID COMPENSATOR<YC4> (A)
8-94395-931-0
01
1
9810-9911
6
PLATE; CAUTION,SPARE TIRE
SPARE WHL CARRIER(SFB) CAUTIONS FRENCH<WJ8> (C)
1-85883-108-0
01
1
9806-9911
6
PLATE; CAUTION,SPARE TIRE
SPARE WHL CARRIER(SFB) EXC. CAUTIONS FRENCH<WJ8>,CAUTIONS SPANISH<YN1> (A)
1-53639-004-0
01
1
9806-9911
6
PLATE; CAUTION,SPARE TIRE
SPARE WHL CARRIER(SFB) CAUTIONS SPANISH<YN1> (B)
1-53639-005-0
01
1
9806-9911
