Sayfa 1-01 - Isuzu EPC

1-01 — ACCELERATOR PEDAL AND CONTROL (#6812) — 296 parça

671 672 188 112 672 842 42 391 391

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
42	BOLT; BRKT,ENG CONT CABLE M8X16 FLANGE	0-28080-816-0	02	1	9806-9909	●
42	BOLT; BRKT,ENG CONT CABLE M8X20 FLANGE	0-28680-820-0	02	1	9910-9911	●
112	TUBE; RUBBER OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9> YELLOW SERVICED BY L=4000 OD=8	1-87410-074-0	01	1	9806-9911		●
188	HOSE; RUBBER OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9>	0-07532-300-1	01	1	9806-9911		●
391	BRACKET; ENG CONT (A)	8-94391-753-0	01	1	9806-9909	●
391	BRACKET; ENG CONT (A)	8-97600-891-0	01	1	9910-9911	●
391	BRACKET; ENG CONT (B)	8-94391-754-0	01	1	9806-9909	●
391	BRACKET; ENG CONT (B)	8-97600-892-0	01	1	9910-9910	●
391	BRACKET; ENG CONT (B)	8-97600-989-0	01	1	9911-9911	●
391	BRACKET; ENG CONT OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9> (C)	1-23249-021-0	01	1	9806-9911		●
391	BRACKET; ENG CONT (D)	1-23249-026-0	01	1	9912-			●
671	BOLT; EYE,FLEX HOSE OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9>	1-09675-227-0	01	1	9806-9911		●
672	GASKET; EYE BOLT OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9> T=3.0 OD=20	1-09630-110-0	01	1	9806-9911		●
672	GASKET; EYE BOLT OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9> ID=14.2	9-09851-004-0	01	1	9806-9911		●
842	GASKET; HOSE OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9> ID=11 OD=18	9-09572-510-0	01	1	9806-9911		●

8 67 500 499 497 68 138 14 31 138 164 16 637 29 538 172 35 199 39 15 534 65 140 418 430 92 8 8 535 411 391 199 199 45 45 111 111 508 508 545 579 545 579 508 508 822 822 12 709 12 709

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
8	LINK ASM; ENG CONT EXC. OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9>	1-23240-090-1	01	1	9806-9911	●	●
8	LINK ASM; ENG CONT OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9>	1-23240-089-1	01	1	9806-9911		●
8	LINK ASM; ENG CONT	1-23240-101-0	01	1	9912-			●
12	ROLLER; ENG CONT LEVER	1-09989-007-0	01	1	9806-9911	●	●
12	ROLLER; ENG CONT LEVER	1-09989-007-0	01	1	9912-			●
14	PAD; PEDAL,ACCEL	1-73907-563-0	01	1	9806-9911	●	●
14	PAD; PEDAL,ACCEL	1-73907-563-0	01	1	9912-			●
15	STAND; HEEL,ACCEL PEDAL	1-73907-266-2	01	1	9806-9911	●	●
15	STAND; HEEL,ACCEL PEDAL	1-73907-266-3	01	1	9912-			●
16	SCREW; HEEL STAND,ACCEL PEDAL M6X30 W/PL WASHER	1-09981-448-0	02	1	9806-9911	●	●
16	SCREW; HEEL STAND,ACCEL PEDAL M6X30 W/PL WASHER	1-09981-448-0	02	1	9912-			●
29	SHAFT; ACCEL PEDAL OD=8 L=74	1-09987-206-0	01	1	9806-9911	●	●
29	SHAFT; ACCEL PEDAL OD=8 L=74	1-09987-206-0	01	1	9912-			●
31	RING; SNAP,ACCEL PEDAL ID=6	9-09185-406-0	01	1	9806-9911	●	●
31	RING; SNAP,ACCEL PEDAL ID=6	9-09185-406-0	01	1	9912-0604			●
31	RING; SNAP,ACCEL PEDAL ID=6	0-91805-506-0	01	1	0605-			●
35	STOPPER; ACCEL PEDAL M8X130	1-09000-200-1	01	1	9806-9911	●
35	STOPPER; ACCEL PEDAL ISUZU M/T<X9A> M8X45	0-20800-845-0	01	1	9912-			●
35	STOPPER; ACCEL PEDAL M8X75	0-20800-875-0	01	1	9806-9911		●
39	NUT; ACCEL PEDAL STOPPER M8 FLANGE	0-91150-108-0	01	1	9806-9911	●	●
39	NUT; ACCEL PEDAL STOPPER ISUZU M/T<X9A> M8 FLANGE	0-91150-108-0	01	1	9912-0602			●
39	NUT; ACCEL PEDAL STOPPER ISUZU M/T<X9A> M8 FLANGE	0-91180-108-0	01	1	0603-			●
45	PIN; ACCEL CONT PEDAL	1-09987-081-0	01	1	9806-9911	●	●
65	BOLT M6X12 FLANGE	0-28080-612-0	01	1	9806-9911	●	●
67	CABLE ASM; IDLE CONT L=407	1-23230-072-0	01	1	9806-9911	●	●
68	KNOB; IDLE CONT	5-23210-008-1	01	1	9806-9911	●	●
92	WASHER; PL,IDLE CONT CABLE ID=5.3	9-09160-505-0	01	1	9806-9911	●	●
111	SPRING; RETURN	1-73997-824-0	01	1	9806-9911	●	●
138	BOLT; LINK ROD M6X16 FLANGE	0-28080-616-0	03	1	9806-9911	●	●
140	NUT; BALL JOINT (A) M6 FLANGE	0-91150-106-0	02	1	9806-9911	●	●
140	NUT; BALL JOINT (B) M6	9-09110-406-0	01	1	9806-9911	●	●
164	WASHER; PL ID=8.4	9-09160-508-0	01	1	9806-9911	●	●
172	BRACKET; IDLE CONT	1-73998-527-1	01	1	9806-9911	●	●
199	PIN; SNAP (A) L=27.7	1-09747-005-0	01	1	9806-9911	●	●
199	PIN; SNAP (B) L=27.7	8-94202-777-0	01	1	9806-9911	●	●
391	BRACKET; ENG CONT (A)	8-94391-753-0	01	1	9806-9909	●
391	BRACKET; ENG CONT (A)	8-97600-891-0	01	1	9910-9911	●
391	BRACKET; ENG CONT (B)	8-94391-754-0	01	1	9806-9909	●
391	BRACKET; ENG CONT (B)	8-97600-892-0	01	1	9910-9910	●
391	BRACKET; ENG CONT (B)	8-97600-989-0	01	1	9911-9911	●
391	BRACKET; ENG CONT OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9> (C)	1-23249-021-0	01	1	9806-9911		●
391	BRACKET; ENG CONT (D)	1-23249-026-0	01	1	9912-			●
411	WIRE; ENG CONT L=448	1-23240-088-0	01	1	9806-9911	●	●
418	JOINT; BALL,ENG CONT	1-09760-004-0	01	1	9806-9911	●	●
430	SPRING; RETURN,ACCEL CONT CABLE	1-09583-002-0	01	1	9806-9911	●	●
497	SCREW; SET,KNOB,IDLE CONT CABLE	5-09120-004-0	01	1	9806-9911	●	●
499	NUT; IDLE CONT CABLE M18 RING NUT	5-09409-004-1	01	1	9806-9911	●	●
500	WASHER; IDLE CONT CABLE ID=18.5	5-09550-005-0	01	1	9806-9911	●	●
508	BUSHING; LINK ROD	8-94206-569-0	02	1	9806-9911	●	●
534	PIN; JAW JOINT,IDLING CONT CABLE	1-09987-034-1	01	1	9806-9911	●	●
535	PIN; SNAP,IDLING CONT CABLE L=17.9	1-09747-002-0	01	1	9806-9911	●	●
538	BOLT; CLIP,IDLING CONT M5X14 W/LK WASHER	1-09980-023-0	01	1	9806-9911	●	●
545	WASHER; NYLON ID=10.5 OD=16	9-09855-178-0	01	1	9806-9911	●	●
579	LEVER; IDLING CONT	1-73997-781-2	01	1	9806-9911	●	●
637	GROMMET; ACCEL CABLE RUBBER	1-23249-009-0	01	1	9806-9911	●	●
637	GROMMET; ACCEL CABLE ISUZU M/T<X9A> RUBBER	1-23249-009-0	01	1	9912-			●
709	RING; SNAP ID=6	9-09185-406-0	01	1	9806-9911	●	●
822	LEVER ASM; ENG CONT EXC. OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9>	1-23249-024-1	01	1	9806-9911	●	●
822	LEVER ASM; ENG CONT OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9>	1-23249-023-1	01	1	9806-9911		●

403 646 6 141 646 403 269 269 351 140 424 335 272 119 2 423 140 417 273 613 566 161 271 415 60 415 404 539 539 60 539 60 404 404 539 444 389 396 637 60 389 539 60 74 62 57 63 64 63 72 54 60 323 404 681

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
2	LEVER; ENG CONT	1-23311-296-1	01	1	9806-9911	●	●
2	LEVER; ENG CONT	1-23249-027-0	01	1	9912-			●
6	RING; SNAP,LINK TO LINK (C) ID=9	9-09185-409-0	01	1	9806-9911	●	●
6	RING; SNAP,LINK TO LINK (B) ID=6	9-09185-406-0	01	1	9912-0604			●
6	RING; SNAP,LINK TO LINK (B) ID=6	0-91805-506-0	01	1	0605-			●
6	RING; SNAP,LINK TO LINK (A) ID=4	9-09185-404-0	02	1	9912-0604			●
6	RING; SNAP,LINK TO LINK (A) ID=4	0-91805-504-0	02	1	0605-			●
54	CABLE; ENG CONT L=4107.5	1-23230-200-1	01	1	9806-9908	●
54	CABLE; ENG CONT EXC. CTR SPLIT FRAME<TLW> L=4107.5	1-23230-344-0	01	1	9909-9911	●
54	CABLE; ENG CONT CTR SPLIT FRAME<TLW> L=8760.5	1-23230-345-0	01	1	9909-9911	●
54	CABLE; ENG CONT CTR SPLIT FRAME<TLW> L=8833	1-23230-213-0	01	1	9806-9908		●
54	CABLE; ENG CONT CTR SPLIT FRAME<TLW> L=8833	1-23230-343-0	01	1	9909-9911		●
54	CABLE; ENG CONT EXC. CTR SPLIT FRAME<TLW> L=4180	1-23230-131-0	01	1	9806-9908		●
54	CABLE; ENG CONT EXC. CTR SPLIT FRAME<TLW> L=4180	1-23230-341-0	01	1	9909-9911		●
57	WASHER; ENG CONT CABLE ID=8.4	9-09160-508-0	01	1	9806-9911	●	●
60	BOLT; CABLE (A) M6X20 FLANGE	0-28680-620-0	02	1	9806-9911	●	●
60	BOLT; CABLE (C) M6X25 FLANGE	0-28680-625-0	02	1	9806-9911	●	●
60	BOLT; CABLE EXC. CTR SPLIT FRAME<TLW> (B) M8X30 FLANGE	0-28680-830-0	06	1	9806-9911	●	●
60	BOLT; CABLE CTR SPLIT FRAME<TLW> (B) M8X30 FLANGE	0-28680-830-0	18	1	9806-9911		●
62	CLIP; ENG CONT CABLE	1-09701-227-1	01	1	9806-9908	●
62	CLIP; ENG CONT CABLE	1-09701-227-1	01	1	9909-9911	●	●
62	CLIP; ENG CONT CABLE	1-09700-326-0	01	1	9806-9908		●
63	NUT; LOCK,BRKT M8	9-09111-408-0	02	1	9806-9911	●	●
64	BRACKET; ENG CONT CABLE	1-23219-144-0	01	1	9806-9908	●
64	BRACKET; ENG CONT CABLE	1-23219-144-0	01	1	9909-9911	●	●
64	BRACKET; ENG CONT CABLE	1-09768-018-1	01	1	9806-9908		●
72	PIN; JAW JOINT,CABLE END OD=8 L=17	9-08223-817-0	01	1	9806-9911	●	●
74	PIN; SNAP,CABLE END L=27.7	1-09747-005-0	01	1	9806-9911	●	●
119	BUSHING; CONT LEVER	1-09330-072-0	01	1	9806-9911	●	●
140	NUT; BALL JOINT (A) M6 FLANGE	0-91150-106-0	02	1	9806-9911	●	●
140	NUT; BALL JOINT (B) M6	9-09110-406-0	01	1	9806-9911	●	●
141	JOINT ASM; BALL	1-09760-004-0	01	1	9806-9911	●	●
161	ROD; LINK EXC. CTR SPLIT FRAME<TLW> 1ST ROD L=2850	1-09765-265-1	01	1	9806-9911	●	●
161	ROD; LINK CTR SPLIT FRAME<TLW> 1ST ROD L=1350	1-09765-284-0	01	1	9806-9911		●
269	BRACKET; RELAY LEVER	1-23335-453-0	02	1	9806-9911	●	●
271	SHAFT; ENG CONT	1-23331-125-1	01	1	9806-9911	●	●
271	SHAFT; ENG CONT OD=8.0 L=74	1-71907-212-1	01	1	9912-			●
272	BOLT; LEVER M6X35 W/LK&PL WASHER	0-50140-635-0	01	1	9806-9911	●	●
273	NUT; LEVER M6	9-09110-406-0	01	1	9806-9911	●	●
323	BOLT; CLIP M10X25 FLANGE	0-28681-025-0	01	1	9806-9911	●	●
335	SUPPORT; ACCEL CONT ROD WB 5000MM(50W)	1-23319-020-0	08	1	9806-9911	●	●
335	SUPPORT; ACCEL CONT ROD WB 5700MM(57W),WB 6300MM(63W) EXC. CTR SPLIT FRAME<TLW>	1-23319-020-0	10	1	9806-9911	●	●
335	SUPPORT; ACCEL CONT ROD CTR SPLIT FRAME<TLW>	1-23319-020-0	02	1	9806-9911		●
351	KEY; SHAFT,ENG CONT	9-08030-410-0	01	1	9806-9911	●	●
389	NUT; ACCEL CONT CABLE FIX M6 FLANGE	0-91150-106-0	02	1	9806-9911	●	●
396	BRACKET; CLIP CTR SPLIT FRAME<TLW> L=105 B=25	1-47476-161-0	02	1	9806-9911		●
403	BOLT; BRKT,ACCEL PEDAL M10X25 FLANGE	0-28681-025-0	04	1	9806-9911	●	●
404	CLIP; CABLE (A)	1-09700-412-0	02	1	9806-9911	●	●
404	CLIP; CABLE (E) ID=11 H=20 L=20	5-09700-351-0	01	1	9806-9911	●	●
404	CLIP; CABLE (C) ID=11 L=40	8-94123-171-1	01	1	9806-9911	●	●
404	CLIP; CABLE EXC. CTR SPLIT FRAME<TLW> (C) ID=11 L=40	8-94123-171-1	01	1	9806-9911	●	●
404	CLIP; CABLE (B) ID=9 L=28	9-09524-855-0	01	1	9806-9911	●	●
404	CLIP; CABLE (B) ID=9 L=50	9-09524-885-0	01	1	9806-9911	●	●
404	CLIP; CABLE CTR SPLIT FRAME<TLW> (E) ID=11 H=20 L=20	5-09700-351-0	02	1	9806-9911		●
404	CLIP; CABLE CTR SPLIT FRAME<TLW> (C) ID=11 L=40	8-94123-171-1	04	1	9806-9911		●
404	CLIP; CABLE CTR SPLIT FRAME<TLW> (B) ID=9 L=20	9-09524-835-0	07	1	9806-9911		●
415	NUT; LK,TURN BUCKLE (B) M6 FLANGE	0-91150-106-0	01	1	9806-9911	●	●
415	NUT; LK,TURN BUCKLE EXC. CTR SPLIT FRAME<TLW> (B) M6 FLANGE	0-91150-106-0	01	1	9806-9911	●	●
415	NUT; LK,TURN BUCKLE EXC. CTR SPLIT FRAME<TLW> (B) M6 FLANGE	0-91150-106-0	01	1	9806-9911	●	●
415	NUT; LK,TURN BUCKLE (A) M6	8-94438-375-0	01	1	9806-9911	●	●
415	NUT; LK,TURN BUCKLE EXC. CTR SPLIT FRAME<TLW> (A) M6	8-94438-375-0	01	1	9806-9911	●	●
415	NUT; LK,TURN BUCKLE EXC. CTR SPLIT FRAME<TLW> (A) M6	8-94438-375-0	01	1	9806-9911	●	●
417	BUCKLE; TURN,ENG CONT	8-94148-967-0	01	1	9806-9911	●	●
417	BUCKLE; TURN,ENG CONT EXC. CTR SPLIT FRAME<TLW>	8-94148-967-0	01	1	9806-9911	●	●
417	BUCKLE; TURN,ENG CONT EXC. CTR SPLIT FRAME<TLW>	8-94148-967-0	01	1	9806-9911	●	●
423	BOLT; SUPPORT WB 5000MM(50W) M6X30 FLANGE	0-28680-630-0	08	1	9806-9911	●	●
423	BOLT; SUPPORT WB 5700MM(57W),WB 6300MM(63W) EXC. CTR SPLIT FRAME<TLW> M6X30 FLANGE	0-28680-630-0	10	1	9806-9911	●	●
423	BOLT; SUPPORT CTR SPLIT FRAME<TLW> M6X30 FLANGE	0-28680-630-0	02	1	9806-9911		●
424	NUT; SUPPORT WB 5000MM(50W) M6 FLANGE	0-91150-106-0	08	1	9806-9911	●	●
424	NUT; SUPPORT WB 5700MM(57W),WB 6300MM(63W) EXC. CTR SPLIT FRAME<TLW> M6 FLANGE	0-91150-106-0	10	1	9806-9911	●	●
424	NUT; SUPPORT CTR SPLIT FRAME<TLW> M6 FLANGE	0-91150-106-0	02	1	9806-9911		●
444	BOLT; CABLE CLIP CTR SPLIT FRAME<TLW> M8X30 FLANGE	0-28680-830-0	02	1	9806-9911		●
539	NUT; CLIP M8	9-09110-508-0	05	1	9806-9911	●	●
539	NUT; CLIP EXC. CTR SPLIT FRAME<TLW> M8 FLANGE	0-91150-108-0	05	1	9806-9911	●	●
539	NUT; CLIP CTR SPLIT FRAME<TLW> M8 FLANGE	0-91150-108-0	17	1	9806-9911		●
566	NUT; LK,JOINT M6 FLANGE	0-91150-106-0	01	1	9806-9911	●	●
613	WASHER; PL,SPACER ID=6.4	9-09160-506-0	01	1	9806-9911	●	●
637	GROMMET; ACCEL CABLE RUBBER	1-23249-009-0	01	1	9806-9911	●	●
637	GROMMET; ACCEL CABLE ISUZU M/T<X9A> RUBBER	1-23249-009-0	01	1	9912-			●
646	NUT; BRKT,LEVER M10 FLANGE	0-91150-210-0	04	1	9806-9911	●	●
681	CLIP; ENG CONT CABLE ID=9 L=28	1-09700-468-1	01	1	9806-9911	●	●

403 646 6 141 646 403 269 269 351 140 424 335 272 119 2 423 140 417 273 613 566 161 271 415 60 415 404 539 539 60 424 561 335 423 539 60 404 404 417 539 415 637 415 389 389 60 74 62 57 60 63 64 63 72 54 60 323 404 681

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
2	LEVER; ENG CONT	1-23311-296-1	01	1	9806-9911	●	●
2	LEVER; ENG CONT	1-23249-027-0	01	1	9912-			●
6	RING; SNAP,LINK TO LINK (C) ID=9	9-09185-409-0	01	1	9806-9911	●	●
6	RING; SNAP,LINK TO LINK (B) ID=6	9-09185-406-0	01	1	9912-0604			●
6	RING; SNAP,LINK TO LINK (B) ID=6	0-91805-506-0	01	1	0605-			●
6	RING; SNAP,LINK TO LINK (A) ID=4	9-09185-404-0	02	1	9912-0604			●
6	RING; SNAP,LINK TO LINK (A) ID=4	0-91805-504-0	02	1	0605-			●
54	CABLE; ENG CONT L=4107.5	1-23230-200-1	01	1	9806-9908	●
54	CABLE; ENG CONT EXC. CTR SPLIT FRAME<TLW> L=4107.5	1-23230-344-0	01	1	9909-9911	●
54	CABLE; ENG CONT CTR SPLIT FRAME<TLW> L=8760.5	1-23230-345-0	01	1	9909-9911	●
54	CABLE; ENG CONT CTR SPLIT FRAME<TLW> L=8833	1-23230-213-0	01	1	9806-9908		●
54	CABLE; ENG CONT CTR SPLIT FRAME<TLW> L=8833	1-23230-343-0	01	1	9909-9911		●
54	CABLE; ENG CONT EXC. CTR SPLIT FRAME<TLW> L=4180	1-23230-131-0	01	1	9806-9908		●
54	CABLE; ENG CONT EXC. CTR SPLIT FRAME<TLW> L=4180	1-23230-341-0	01	1	9909-9911		●
57	WASHER; ENG CONT CABLE ID=8.4	9-09160-508-0	01	1	9806-9911	●	●
60	BOLT; CABLE (A) M6X20 FLANGE	0-28680-620-0	02	1	9806-9911	●	●
60	BOLT; CABLE (C) M6X25 FLANGE	0-28680-625-0	02	1	9806-9911	●	●
60	BOLT; CABLE EXC. CTR SPLIT FRAME<TLW> (B) M8X30 FLANGE	0-28680-830-0	06	1	9806-9911	●	●
60	BOLT; CABLE CTR SPLIT FRAME<TLW> (B) M8X30 FLANGE	0-28680-830-0	18	1	9806-9911		●
62	CLIP; ENG CONT CABLE	1-09701-227-1	01	1	9806-9908	●
62	CLIP; ENG CONT CABLE	1-09701-227-1	01	1	9909-9911	●	●
62	CLIP; ENG CONT CABLE	1-09700-326-0	01	1	9806-9908		●
63	NUT; LOCK,BRKT M8	9-09111-408-0	02	1	9806-9911	●	●
64	BRACKET; ENG CONT CABLE	1-23219-144-0	01	1	9806-9908	●
64	BRACKET; ENG CONT CABLE	1-23219-144-0	01	1	9909-9911	●	●
64	BRACKET; ENG CONT CABLE	1-09768-018-1	01	1	9806-9908		●
72	PIN; JAW JOINT,CABLE END OD=8 L=17	9-08223-817-0	01	1	9806-9911	●	●
74	PIN; SNAP,CABLE END L=27.7	1-09747-005-0	01	1	9806-9911	●	●
119	BUSHING; CONT LEVER	1-09330-072-0	01	1	9806-9911	●	●
140	NUT; BALL JOINT (A) M6 FLANGE	0-91150-106-0	02	1	9806-9911	●	●
140	NUT; BALL JOINT (B) M6	9-09110-406-0	01	1	9806-9911	●	●
141	JOINT ASM; BALL	1-09760-004-0	01	1	9806-9911	●	●
161	ROD; LINK EXC. CTR SPLIT FRAME<TLW> 1ST ROD L=2850	1-09765-265-1	01	1	9806-9911	●	●
161	ROD; LINK CTR SPLIT FRAME<TLW> 1ST ROD L=1350	1-09765-284-0	01	1	9806-9911		●
269	BRACKET; RELAY LEVER	1-23335-453-0	02	1	9806-9911	●	●
271	SHAFT; ENG CONT	1-23331-125-1	01	1	9806-9911	●	●
271	SHAFT; ENG CONT OD=8.0 L=74	1-71907-212-1	01	1	9912-			●
272	BOLT; LEVER M6X35 W/LK&PL WASHER	0-50140-635-0	01	1	9806-9911	●	●
273	NUT; LEVER M6	9-09110-406-0	01	1	9806-9911	●	●
323	BOLT; CLIP M10X25 FLANGE	0-28681-025-0	01	1	9806-9911	●	●
335	SUPPORT; ACCEL CONT ROD WB 5000MM(50W)	1-23319-020-0	08	1	9806-9911	●	●
335	SUPPORT; ACCEL CONT ROD WB 5700MM(57W),WB 6300MM(63W) EXC. CTR SPLIT FRAME<TLW>	1-23319-020-0	10	1	9806-9911	●	●
335	SUPPORT; ACCEL CONT ROD CTR SPLIT FRAME<TLW>	1-23319-020-0	02	1	9806-9911		●
351	KEY; SHAFT,ENG CONT	9-08030-410-0	01	1	9806-9911	●	●
389	NUT; ACCEL CONT CABLE FIX M6 FLANGE	0-91150-106-0	02	1	9806-9911	●	●
403	BOLT; BRKT,ACCEL PEDAL M10X25 FLANGE	0-28681-025-0	04	1	9806-9911	●	●
404	CLIP; CABLE (A)	1-09700-412-0	02	1	9806-9911	●	●
404	CLIP; CABLE (E) ID=11 H=20 L=20	5-09700-351-0	01	1	9806-9911	●	●
404	CLIP; CABLE (C) ID=11 L=40	8-94123-171-1	01	1	9806-9911	●	●
404	CLIP; CABLE EXC. CTR SPLIT FRAME<TLW> (C) ID=11 L=40	8-94123-171-1	01	1	9806-9911	●	●
404	CLIP; CABLE (B) ID=9 L=28	9-09524-855-0	01	1	9806-9911	●	●
404	CLIP; CABLE (B) ID=9 L=50	9-09524-885-0	01	1	9806-9911	●	●
404	CLIP; CABLE CTR SPLIT FRAME<TLW> (E) ID=11 H=20 L=20	5-09700-351-0	02	1	9806-9911		●
404	CLIP; CABLE CTR SPLIT FRAME<TLW> (C) ID=11 L=40	8-94123-171-1	04	1	9806-9911		●
404	CLIP; CABLE CTR SPLIT FRAME<TLW> (B) ID=9 L=20	9-09524-835-0	07	1	9806-9911		●
415	NUT; LK,TURN BUCKLE (B) M6 FLANGE	0-91150-106-0	01	1	9806-9911	●	●
415	NUT; LK,TURN BUCKLE EXC. CTR SPLIT FRAME<TLW> (B) M6 FLANGE	0-91150-106-0	01	1	9806-9911	●	●
415	NUT; LK,TURN BUCKLE EXC. CTR SPLIT FRAME<TLW> (B) M6 FLANGE	0-91150-106-0	01	1	9806-9911	●	●
415	NUT; LK,TURN BUCKLE (A) M6	8-94438-375-0	01	1	9806-9911	●	●
415	NUT; LK,TURN BUCKLE EXC. CTR SPLIT FRAME<TLW> (A) M6	8-94438-375-0	01	1	9806-9911	●	●
415	NUT; LK,TURN BUCKLE EXC. CTR SPLIT FRAME<TLW> (A) M6	8-94438-375-0	01	1	9806-9911	●	●
417	BUCKLE; TURN,ENG CONT	8-94148-967-0	01	1	9806-9911	●	●
417	BUCKLE; TURN,ENG CONT EXC. CTR SPLIT FRAME<TLW>	8-94148-967-0	01	1	9806-9911	●	●
417	BUCKLE; TURN,ENG CONT EXC. CTR SPLIT FRAME<TLW>	8-94148-967-0	01	1	9806-9911	●	●
423	BOLT; SUPPORT WB 5000MM(50W) M6X30 FLANGE	0-28680-630-0	08	1	9806-9911	●	●
423	BOLT; SUPPORT WB 5700MM(57W),WB 6300MM(63W) EXC. CTR SPLIT FRAME<TLW> M6X30 FLANGE	0-28680-630-0	10	1	9806-9911	●	●
423	BOLT; SUPPORT CTR SPLIT FRAME<TLW> M6X30 FLANGE	0-28680-630-0	02	1	9806-9911		●
424	NUT; SUPPORT WB 5000MM(50W) M6 FLANGE	0-91150-106-0	08	1	9806-9911	●	●
424	NUT; SUPPORT WB 5700MM(57W),WB 6300MM(63W) EXC. CTR SPLIT FRAME<TLW> M6 FLANGE	0-91150-106-0	10	1	9806-9911	●	●
424	NUT; SUPPORT CTR SPLIT FRAME<TLW> M6 FLANGE	0-91150-106-0	02	1	9806-9911		●
539	NUT; CLIP M8	9-09110-508-0	05	1	9806-9911	●	●
539	NUT; CLIP EXC. CTR SPLIT FRAME<TLW> M8 FLANGE	0-91150-108-0	05	1	9806-9911	●	●
539	NUT; CLIP CTR SPLIT FRAME<TLW> M8 FLANGE	0-91150-108-0	17	1	9806-9911		●
561	ROD; LINK WB 5000MM(50W) L=2150	1-09765-264-1	01	1	9806-9911	●	●
561	ROD; LINK WB 5700MM(57W) EXC. CTR SPLIT FRAME<TLW> L=2850	1-09765-265-1	01	1	9806-9911	●	●
561	ROD; LINK WB 6300MM(63W) L=3450	1-09765-266-1	01	1	9806-9911		●
566	NUT; LK,JOINT M6 FLANGE	0-91150-106-0	01	1	9806-9911	●	●
613	WASHER; PL,SPACER ID=6.4	9-09160-506-0	01	1	9806-9911	●	●
637	GROMMET; ACCEL CABLE RUBBER	1-23249-009-0	01	1	9806-9911	●	●
637	GROMMET; ACCEL CABLE ISUZU M/T<X9A> RUBBER	1-23249-009-0	01	1	9912-			●
646	NUT; BRKT,LEVER M10 FLANGE	0-91150-210-0	04	1	9806-9911	●	●
681	CLIP; ENG CONT CABLE ID=9 L=28	1-09700-468-1	01	1	9806-9911	●	●

644 8 8 82 527 391 14 526 31 29 730 16 843 271 15 637 35 39 104 6 86 82 87 24 332 86 12 24 6 2 332 81 6 82

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
2	LEVER; ENG CONT	1-23311-296-1	01	1	9806-9911	●	●
2	LEVER; ENG CONT	1-23249-027-0	01	1	9912-			●
6	RING; SNAP,LINK TO LINK (C) ID=9	9-09185-409-0	01	1	9806-9911	●	●
6	RING; SNAP,LINK TO LINK (B) ID=6	9-09185-406-0	01	1	9912-0604			●
6	RING; SNAP,LINK TO LINK (B) ID=6	0-91805-506-0	01	1	0605-			●
6	RING; SNAP,LINK TO LINK (A) ID=4	9-09185-404-0	02	1	9912-0604			●
6	RING; SNAP,LINK TO LINK (A) ID=4	0-91805-504-0	02	1	0605-			●
8	LINK ASM; ENG CONT EXC. OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9>	1-23240-090-1	01	1	9806-9911	●	●
8	LINK ASM; ENG CONT OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9>	1-23240-089-1	01	1	9806-9911		●
8	LINK ASM; ENG CONT	1-23240-101-0	01	1	9912-			●
12	ROLLER; ENG CONT LEVER	1-09989-007-0	01	1	9806-9911	●	●
12	ROLLER; ENG CONT LEVER	1-09989-007-0	01	1	9912-			●
14	PAD; PEDAL,ACCEL	1-73907-563-0	01	1	9806-9911	●	●
14	PAD; PEDAL,ACCEL	1-73907-563-0	01	1	9912-			●
15	STAND; HEEL,ACCEL PEDAL	1-73907-266-2	01	1	9806-9911	●	●
15	STAND; HEEL,ACCEL PEDAL	1-73907-266-3	01	1	9912-			●
16	SCREW; HEEL STAND,ACCEL PEDAL M6X30 W/PL WASHER	1-09981-448-0	02	1	9806-9911	●	●
16	SCREW; HEEL STAND,ACCEL PEDAL M6X30 W/PL WASHER	1-09981-448-0	02	1	9912-			●
24	BOLT; BRKT M8X20 FLANGE	0-28680-820-0	02	1	9912-0512			●
24	BOLT; BRKT M8X20 FLANGE	0-28650-820-0	02	1	0601-			●
29	SHAFT; ACCEL PEDAL OD=8 L=74	1-09987-206-0	01	1	9806-9911	●	●
29	SHAFT; ACCEL PEDAL OD=8 L=74	1-09987-206-0	01	1	9912-			●
31	RING; SNAP,ACCEL PEDAL ID=6	9-09185-406-0	01	1	9806-9911	●	●
31	RING; SNAP,ACCEL PEDAL ID=6	9-09185-406-0	01	1	9912-0604			●
31	RING; SNAP,ACCEL PEDAL ID=6	0-91805-506-0	01	1	0605-			●
35	STOPPER; ACCEL PEDAL M8X130	1-09000-200-1	01	1	9806-9911	●
35	STOPPER; ACCEL PEDAL ISUZU M/T<X9A> M8X45	0-20800-845-0	01	1	9912-			●
35	STOPPER; ACCEL PEDAL M8X75	0-20800-875-0	01	1	9806-9911		●
39	NUT; ACCEL PEDAL STOPPER M8 FLANGE	0-91150-108-0	01	1	9806-9911	●	●
39	NUT; ACCEL PEDAL STOPPER ISUZU M/T<X9A> M8 FLANGE	0-91150-108-0	01	1	9912-0602			●
39	NUT; ACCEL PEDAL STOPPER ISUZU M/T<X9A> M8 FLANGE	0-91180-108-0	01	1	0603-			●
81	SPRING; RETURN,ENG CONT LEVER	8-97853-205-1	01	1	9912-			●
82	BUSHING; ENG CONT LVR (B) L=31.5	1-53459-627-0	01	1	9912-			●
82	BUSHING; ENG CONT LVR (A)	1-71907-244-1	02	1	9912-			●
86	WASHER; PL,ENG CONT LEVER ID=6.4	9-09160-506-0	02	1	9912-			●
87	LINK; ENG CONT	8-97865-545-0	01	1	9912-			●
104	NUT; ENG CONT D=17.5	8-94368-617-0	01	1	9912-			●
271	SHAFT; ENG CONT	1-23331-125-1	01	1	9806-9911	●	●
271	SHAFT; ENG CONT OD=8.0 L=74	1-71907-212-1	01	1	9912-			●
332	BRACKET; ACCEL PEDAL STOPPER A/T<X9D> (B)	1-23335-518-1	01	1	9912-			●
332	BRACKET; ACCEL PEDAL STOPPER ISUZU M/T<X9A> (A)	1-23335-521-0	01	1	9912-			●
391	BRACKET; ENG CONT (A)	8-94391-753-0	01	1	9806-9909	●
391	BRACKET; ENG CONT (A)	8-97600-891-0	01	1	9910-9911	●
391	BRACKET; ENG CONT (B)	8-94391-754-0	01	1	9806-9909	●
391	BRACKET; ENG CONT (B)	8-97600-892-0	01	1	9910-9910	●
391	BRACKET; ENG CONT (B)	8-97600-989-0	01	1	9911-9911	●
391	BRACKET; ENG CONT OVERHEAD COOLING SYSTEM W/O SUB ENG<YS9> (C)	1-23249-021-0	01	1	9806-9911		●
391	BRACKET; ENG CONT (D)	1-23249-026-0	01	1	9912-			●
526	SENSOR; ACCEL	8-94390-280-0	01	1	9912-			●
527	BOLT; ACCEL SENSOR M6X25 FLANGE	0-28680-625-0	02	1	9912-0512			●
527	BOLT; ACCEL SENSOR M6X25 FLANGE	0-28650-625-0	02	1	0601-			●
637	GROMMET; ACCEL CABLE RUBBER	1-23249-009-0	01	1	9806-9911	●	●
637	GROMMET; ACCEL CABLE ISUZU M/T<X9A> RUBBER	1-23249-009-0	01	1	9912-			●
644	NUT; LINK,ENG CONT M8 FLANGE	0-91150-108-0	02	1	9912-0602			●
644	NUT; LINK,ENG CONT M8 FLANGE	0-91180-108-0	02	1	0603-			●
730	CLIP ID=11 L=20	9-09525-032-0	01	1	9912-0606			●
730	CLIP ID=11 L=20	0-95235-032-0	01	1	0607-			●
843	NUT M6 FLANGE	0-91150-106-0	02	1	9912-0602			●
843	NUT M6 FLANGE	0-91180-106-0	02	1	0603-			●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
