7-10 — CAUTION PLATE AND LABEL (#68046) — 77 parça

9 35 35 160 140 49 140

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
9	PLATE; NAME,SPD RANGE 6HK1-TCS ENG(80L) TIRE 12R22.5-152/148K RIB(5K5) IRAN EQUIPMENT(D8T) SPEED LIMITER 90KM(NMJ) HEAVY DUTY PACKAGE TRUCK VAR3<Y48>	8-98175-389-0	01	1	1010-1106	●
9	PLATE; NAME,SPD RANGE 6HK1-TCS ENG(80L) TIRE 295/80R22.5-152/148M RIB EEC(55P) IRAN EQUIPMENT(D8T) SPEED LIMITER 90KM(NMJ) HEAVY DUTY PACKAGE TRUCK VAR3<Y48>	8-98175-388-0	01	1	1010-1106	●
35	PLATE; CAUTION,CAB AUTO CAB TILT<WV2> (B)	8-98017-667-1	01	1	1008-	●
35	PLATE; CAUTION,CAB CAUTIONS ARABIAN<WJ7> (A)	8-98070-107-0	01	1	0809-0907	●
35	PLATE; CAUTION,CAB CAUTIONS ARABIAN<WJ7> (A)	8-98070-107-0	01	1	0908-1007	●	●
35	PLATE; CAUTION,CAB CAUTIONS ARABIAN<WJ7> EXC. AUTO CAB TILT<WV2> (A)	8-98070-107-0	01	1	1008-	●
35	PLATE; CAUTION,CAB CAUTIONS ARABIAN<WJ7> (A)	8-98070-107-0	01	1	1008-		●
35	PLATE; CAUTION,CAB CAUTIONS FRENCH<WJ8> (A)	8-98070-108-0	01	1	0809-0907	●
35	PLATE; CAUTION,CAB CAUTIONS FRENCH<WJ8> (A)	8-98070-108-0	01	1	0908-1007	●	●
35	PLATE; CAUTION,CAB CAUTIONS FRENCH<WJ8> EXC. AUTO CAB TILT<WV2> (A)	8-98070-108-0	01	1	1008-	●
35	PLATE; CAUTION,CAB CAUTIONS FRENCH<WJ8> (A)	8-98070-108-0	01	1	1008-		●
35	PLATE; CAUTION,CAB CAUTIONS SPANISH<YN1> (A)	8-98070-109-0	01	1	0809-0907	●
35	PLATE; CAUTION,CAB CAUTIONS SPANISH<YN1> (A)	8-98070-109-0	01	1	0908-1007	●	●
35	PLATE; CAUTION,CAB CAUTIONS SPANISH<YN1> EXC. AUTO CAB TILT<WV2> (A)	8-98070-109-0	01	1	1008-	●
35	PLATE; CAUTION,CAB CAUTIONS SPANISH<YN1> (A)	8-98070-109-0	01	1	1008-		●
35	PLATE; CAUTION,CAB (A)	8-98065-363-0	01	1	0803-0808	●
35	PLATE; CAUTION,CAB EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, CAUTIONS SPANISH<YN1> (A)	8-98065-363-0	01	1	0809-0907	●
35	PLATE; CAUTION,CAB EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, CAUTIONS SPANISH<YN1> (A)	8-98065-363-0	01	1	0908-1007	●	●
35	PLATE; CAUTION,CAB EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, AUTO CAB TILT<WV2>,CAUTIONS SPANISH<YN1> (A)	8-98065-363-0	01	1	1008-	●
35	PLATE; CAUTION,CAB EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, CAUTIONS SPANISH<YN1> (A)	8-98065-363-0	01	1	1008-		●
49	PLATE; CAUTION,FUSE BOX CAUTIONS ARABIAN<WJ7>	8-98127-559-0	01	1	0809-0907	●
49	PLATE; CAUTION,FUSE BOX CAUTIONS ARABIAN<WJ7>	8-98127-559-0	01	1	0908-	●	●
49	PLATE; CAUTION,FUSE BOX CAUTIONS FRENCH<WJ8>	8-98127-560-0	01	1	0809-0907	●
49	PLATE; CAUTION,FUSE BOX CAUTIONS FRENCH<WJ8>	8-98127-560-0	01	1	0908-	●	●
49	PLATE; CAUTION,FUSE BOX CAUTIONS SPANISH<YN1>	8-98069-841-0	01	1	0809-0907	●
49	PLATE; CAUTION,FUSE BOX CAUTIONS SPANISH<YN1>	8-98069-841-0	01	1	0908-	●	●
49	PLATE; CAUTION,FUSE BOX	8-98111-970-0	01	1	0803-0805	●
49	PLATE; CAUTION,FUSE BOX	8-98122-354-0	01	1	0806-0808	●
49	PLATE; CAUTION,FUSE BOX EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, CAUTIONS SPANISH<YN1>	8-98122-354-0	01	1	0809-0907	●
49	PLATE; CAUTION,FUSE BOX EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, CAUTIONS SPANISH<YN1>	8-98122-354-0	01	1	0908-	●	●
140	PLATE; CAUTION,SRS AIR BAG DRIVER(AJ3),AIR BAG DRIVER & PASSENGER(AK5) CAUTIONS SPANISH<YN1> EXC. EURO4 SPECIFICATION<NT4> (B)	8-98224-287-0	01	1	1212-	●
140	PLATE; CAUTION,SRS AIR BAG DRIVER(AJ3) CAUTIONS SPANISH<YN1> (B)	8-98224-287-0	01	1	1212-		●
140	PLATE; CAUTION,SRS AIR BAG DRIVER & PASSENGER(AK5) (A)	8-98080-839-0	02	1	1008-	●
140	PLATE; CAUTION,SRS AIR BAG DRIVER & PASSENGER(AK5) EXC. EURO4 SPECIFICATION<NT4> (B)	8-98139-964-0	01	1	1008-1206	●
140	PLATE; CAUTION,SRS AIR BAG DRIVER(AJ3),AIR BAG DRIVER & PASSENGER(AK5) EXC. EURO4 SPECIFICATION<NT4> (B)	8-98139-964-0	01	1	1207-1211	●
140	PLATE; CAUTION,SRS AIR BAG DRIVER(AJ3),AIR BAG DRIVER & PASSENGER(AK5) EXC. EURO4 SPECIFICATION<NT4>,CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>,CAUTIONS SPANISH<YN1> (B)	8-98139-964-0	01	1	1212-	●
140	PLATE; CAUTION,SRS AIR BAG DRIVER(AJ3) EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, CAUTIONS SPANISH<YN1> (B)	8-98139-964-0	01	1	1212-		●
160	PLATE; CAUTION,TOWING ZF9S1110 M/T(Y5E)	1-85888-737-1	01	1	0803-	●
306	LABEL; BEAM & PASS	8-98070-239-0	01	1	0803-0907	●
306	LABEL; BEAM & PASS	8-98070-239-0	01	1	0908-	●	●

74 309 309 41 260 309 119

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> EURO2 SPECIFICATION<NT2>,EURO3 SPECIFICATION<NT3> CAUTIONS ARABIAN<WJ7>	8-98141-841-0	01	1	0907-0907	●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> EURO2 SPECIFICATION<NT2>,EURO3 SPECIFICATION<NT3> CAUTIONS ARABIAN<WJ7>	8-98141-841-0	01	1	0908-	●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> CAUTIONS ARABIAN<WJ7>	8-98141-841-0	01	1	0908-		●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> EURO2 SPECIFICATION<NT2>,EURO3 SPECIFICATION<NT3> CAUTIONS FRENCH<WJ8>	8-98141-839-0	01	1	0907-0907	●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> EURO2 SPECIFICATION<NT2>,EURO3 SPECIFICATION<NT3> CAUTIONS FRENCH<WJ8>	8-98141-839-0	01	1	0908-	●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> CAUTIONS FRENCH<WJ8>	8-98141-839-0	01	1	0908-		●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> EURO2 SPECIFICATION<NT2>,EURO3 SPECIFICATION<NT3> CAUTIONS SPANISH<YN1>	8-98141-840-0	01	1	0907-0907	●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> EURO2 SPECIFICATION<NT2>,EURO3 SPECIFICATION<NT3> CAUTIONS SPANISH<YN1>	8-98141-840-0	01	1	0908-	●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> CAUTIONS SPANISH<YN1>	8-98141-840-0	01	1	0908-		●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> EURO2 SPECIFICATION<NT2>,EURO3 SPECIFICATION<NT3> EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, CAUTIONS SPANISH<YN1>	8-98141-836-0	01	1	0907-0907	●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> EURO2 SPECIFICATION<NT2>,EURO3 SPECIFICATION<NT3> EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, CAUTIONS SPANISH<YN1>	8-98141-836-0	01	1	0908-	●
41	PLATE; CAUTION,HSA H.S.A SYSTEM<6EP> EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, CAUTIONS SPANISH<YN1>	8-98141-836-0	01	1	0908-		●
74	PLATE; CAUTION,CHANGE LEV ZF9S1110 M/T(Y5E) ASSISTOR SHIFT CONTROL<WX8>	1-85881-736-1	01	1	0803-0805	●
74	PLATE; CAUTION,CHANGE LEV ZF9S1110 M/T(Y5E) ASSISTOR SHIFT CONTROL<WX8>	8-98118-493-0	01	1	0806-	●
119	PLATE; CAUTION,HAND BRK LEVER REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)	1-85881-759-0	01	1	0803-0911	●
119	PLATE; CAUTION,HAND BRK LEVER REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)	1-85881-759-0	01	1	0912-	●
119	PLATE; CAUTION,HAND BRK LEVER	1-85881-759-0	01	1	0912-		●
260	PLATE; CAUTION,HEAD LAMP LEVELING	8-98008-779-0	01	1	0803-0907	●
260	PLATE; CAUTION,HEAD LAMP LEVELING	8-98008-779-0	01	1	0908-	●	●
306	LABEL; BEAM & PASS	8-98070-239-0	01	1	0803-0907	●
306	LABEL; BEAM & PASS	8-98070-239-0	01	1	0908-	●	●
309	LABEL; M/T SHIFT (A)	1-85881-598-0	01	1	0908-		●
309	LABEL; M/T SHIFT (B)	8-98098-606-0	01	1	0908-		●

6 228

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
6	PLATE; CAUTION,SPARE TIRE CAUTIONS ARABIAN<WJ7>	8-98082-441-0	01	1	0809-	●
6	PLATE; CAUTION,SPARE TIRE CAUTIONS FRENCH<WJ8>	8-98082-440-0	01	1	0809-	●
6	PLATE; CAUTION,SPARE TIRE CAUTIONS SPANISH<YN1>	8-98082-439-0	01	1	0809-	●
6	PLATE; CAUTION,SPARE TIRE SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE TIRE CARRIER LIFTING TYPE VAR1<SY8>	8-98082-437-0	01	1	0803-0808	●
6	PLATE; CAUTION,SPARE TIRE EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>, CAUTIONS SPANISH<YN1>	8-98082-437-0	01	1	0809-	●
228	PLATE; CAUTION,AIR DRYER AIR DRYER<PS7> CAUTIONS ARABIAN<WJ7>	1-85877-948-0	01	1	0809-0907	●
228	PLATE; CAUTION,AIR DRYER AIR DRYER<PS7> CAUTIONS ARABIAN<WJ7>	1-85877-948-0	01	1	0908-1001	●	●
228	PLATE; CAUTION,AIR DRYER AIR DRYER<PS7> CAUTIONS FRENCH<WJ8>	1-85887-936-0	01	1	0809-0907	●
228	PLATE; CAUTION,AIR DRYER AIR DRYER<PS7> CAUTIONS FRENCH<WJ8>	1-85887-936-0	01	1	0908-1001	●	●
228	PLATE; CAUTION,AIR DRYER	1-85887-935-0	01	1	0803-0808	●
228	PLATE; CAUTION,AIR DRYER AIR DRYER<PS7> EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>	1-85887-935-0	01	1	0809-0907	●
228	PLATE; CAUTION,AIR DRYER AIR DRYER<PS7> EXC. CAUTIONS ARABIAN<WJ7>,CAUTIONS FRENCH<WJ8>	1-85887-935-0	01	1	0908-1001	●	●
306	LABEL; BEAM & PASS	8-98070-239-0	01	1	0803-0907	●
306	LABEL; BEAM & PASS	8-98070-239-0	01	1	0908-	●	●
