31 |
BOLT; CLIP
M6X35 FLANGE
|
0-28680-635-0 |
02 |
1 |
9912-0405 |
● |
|
|
| |
31 |
BOLT; CLIP
M6X35 FLANGE
|
0-28680-635-0 |
01 |
1 |
0406-0512 |
● |
|
|
| |
31 |
BOLT; CLIP
M6X35 FLANGE
|
0-28650-635-0 |
01 |
1 |
0601- |
● |
|
|
| |
33 |
BOLT; BRKT
M8X12 FLANGE
|
0-28080-812-0 |
02 |
1 |
9912-0512 |
● |
|
|
| |
33 |
BOLT; BRKT
M8X12 FLANGE
|
0-28050-812-0 |
02 |
1 |
0601- |
● |
|
|
| |
46 |
GASKET; WATER DUCT,TO OIL COOLER
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=48.5 OD=53.3
|
8-94396-680-2 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
46 |
GASKET; WATER DUCT,TO OIL COOLER
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=48.5 OD=53.3
|
8-94396-680-2 |
01 |
1 |
9912- |
● |
|
|
| |
47 |
BOLT; DUCT,TO OIL COOLER
M8X45 FLANGE
|
0-28080-845-0 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
47 |
BOLT; DUCT,TO OIL COOLER
M8X45 FLANGE
|
0-28080-845-0 |
03 |
1 |
9912-0512 |
● |
|
|
| |
47 |
BOLT; DUCT,TO OIL COOLER
M8X45 FLANGE
|
0-28050-845-0 |
03 |
1 |
0601- |
● |
|
|
| |
47 |
BOLT; DUCT,TO OIL COOLER
M8X25 FLANGE
|
0-28680-825-0 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
47 |
BOLT; DUCT,TO OIL COOLER
M8X25 FLANGE
|
0-28680-825-0 |
01 |
1 |
9912-0512 |
● |
|
|
| |
47 |
BOLT; DUCT,TO OIL COOLER
M8X25 FLANGE
|
0-28650-825-0 |
01 |
1 |
0601- |
● |
|
|
| |
63 |
BRACKET; WATER PIPE
|
8-97600-504-0 |
01 |
1 |
9912- |
● |
|
|
| |
76 |
BRACKET; WATER DUCT,PUMP
|
8-94394-784-0 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
76 |
BRACKET; WATER DUCT,PUMP
|
8-94394-784-0 |
01 |
1 |
9912- |
● |
|
|
| |
77 |
BOLT; BRKT,WATER DUCT
M8X50 FLANGE
|
0-28080-850-0 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
77 |
BOLT; BRKT,WATER DUCT
M8X50 FLANGE
|
0-28080-850-0 |
01 |
1 |
9912-0512 |
● |
|
|
| |
77 |
BOLT; BRKT,WATER DUCT
M8X50 FLANGE
|
0-28050-850-0 |
01 |
1 |
0601- |
● |
|
|
| |
89 |
PIPE; WATER,AIR CMPR,IN
|
8-94395-452-2 |
01 |
1 |
9806-9911 |
|
● |
|
| |
89 |
PIPE; WATER,AIR CMPR,IN
|
8-94395-452-2 |
01 |
1 |
9912- |
● |
|
|
| |
89 |
PIPE; WATER,AIR CMPR,IN
|
8-94395-178-1 |
01 |
1 |
9806-9911 |
|
|
● |
| |
90 |
BOLT; EYE,WATER PIPE,AIR CMPR
(A)
M14X27 EYE-BOLT
|
1-09675-193-0 |
03 |
1 |
9806-9911 |
|
● |
|
| |
90 |
BOLT; EYE,WATER PIPE,AIR CMPR
(A)
M14X27 EYE-BOLT
|
1-09675-193-0 |
04 |
1 |
9912- |
● |
|
|
| |
90 |
BOLT; EYE,WATER PIPE,AIR CMPR
(B)
M16X25
|
5-09675-028-2 |
01 |
1 |
9806-9911 |
|
● |
|
| |
90 |
BOLT; EYE,WATER PIPE,AIR CMPR
(A)
M14X27 EYE-BOLT
|
1-09675-193-0 |
04 |
1 |
9806-9809 |
|
|
● |
| |
90 |
BOLT; EYE,WATER PIPE,AIR CMPR
AIR CMPR HVY DUTY<E1Q>
(A)
M14X27 EYE-BOLT
|
1-09675-193-0 |
04 |
1 |
9810-9911 |
|
|
● |
| |
91 |
GASKET; WATER PIPE,AIR CMPR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
06 |
1 |
9806-9911 |
|
● |
|
| |
91 |
GASKET; WATER PIPE,AIR CMPR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
08 |
1 |
9912- |
● |
|
|
| |
91 |
GASKET; WATER PIPE,AIR CMPR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=16.2
|
1-09630-086-0 |
02 |
1 |
9806-9911 |
|
● |
|
| |
91 |
GASKET; WATER PIPE,AIR CMPR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=19.2
|
1-09630-085-0 |
08 |
1 |
9806-9809 |
|
|
● |
| |
91 |
GASKET; WATER PIPE,AIR CMPR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
AIR CMPR HVY DUTY<E1Q>
ID=14.2 OD=19.2
|
1-09630-085-0 |
08 |
1 |
9810-9911 |
|
|
● |
| |
92 |
PIPE; WATER,AIR CMPR,OUT
|
8-94391-659-0 |
01 |
1 |
9806-9911 |
|
● |
|
| |
92 |
PIPE; WATER,AIR CMPR,OUT
|
8-97600-301-0 |
01 |
1 |
9912- |
● |
|
|
| |
92 |
PIPE; WATER,AIR CMPR,OUT
|
8-94395-742-1 |
01 |
1 |
9806-9809 |
|
|
● |
| |
92 |
PIPE; WATER,AIR CMPR,OUT
AIR CMPR HVY DUTY<E1Q>
|
8-94395-742-1 |
01 |
1 |
9810-9911 |
|
|
● |
| |
94 |
CLIP; WATER PIPE
|
8-94396-860-0 |
02 |
1 |
9912- |
● |
|
|
| |
129 |
BOLT; WATER PIPE TO BRKT
M8X12 FLANGE
|
0-28080-812-0 |
02 |
1 |
9806-9911 |
|
● |
|
| |
130 |
NUT; WATER PIPE TO BRKT
M6 FLANGE
|
0-91150-106-0 |
01 |
1 |
0406-0602 |
● |
|
|
| |
130 |
NUT; WATER PIPE TO BRKT
M6 FLANGE
|
0-91180-106-0 |
01 |
1 |
0603- |
● |
|
|
| |
177 |
BOLT; WATER DUCT
(C)
M8X80 FLANGE
|
0-28080-880-0 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
177 |
BOLT; WATER DUCT
(C)
M8X80 FLANGE
|
0-28080-880-0 |
01 |
1 |
9912-0512 |
● |
|
|
| |
177 |
BOLT; WATER DUCT
(C)
M8X80 FLANGE
|
0-28050-880-0 |
01 |
1 |
0601- |
● |
|
|
| |
177 |
BOLT; WATER DUCT
(B)
M8X25 FLANGE
|
0-28680-825-0 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
177 |
BOLT; WATER DUCT
(B)
M8X25 FLANGE
|
0-28680-825-0 |
01 |
1 |
9912-0512 |
● |
|
|
| |
177 |
BOLT; WATER DUCT
(B)
M8X25 FLANGE
|
0-28650-825-0 |
01 |
1 |
0601- |
● |
|
|
| |
177 |
BOLT; WATER DUCT
(A)
M8X65 FLANGE
|
1-09044-072-1 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
177 |
BOLT; WATER DUCT
(A)
M8X65 FLANGE
|
1-09044-072-1 |
01 |
1 |
9912- |
● |
|
|
| |
177 |
BOLT; WATER DUCT
(D)
M16X75 FLANGE
|
8-94397-360-1 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
177 |
BOLT; WATER DUCT
(D)
M16X75 FLANGE
|
8-94397-360-1 |
01 |
1 |
9912- |
● |
|
|
| |
178 |
DUCT; WATER,BYPASS
(B)
|
8-94390-644-0 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
178 |
DUCT; WATER,BYPASS
(B)
|
8-94390-644-0 |
01 |
1 |
9912- |
● |
|
|
| |
178 |
DUCT; WATER,BYPASS
(A)
|
8-94396-627-2 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
178 |
DUCT; WATER,BYPASS
(A)
|
8-94396-627-3 |
01 |
1 |
9912- |
● |
|
|
| |
179 |
GASKET; WATER DUCT
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=31.2
|
8-94396-679-0 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
179 |
GASKET; WATER DUCT
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=31.2
|
8-94396-679-0 |
01 |
1 |
9912- |
● |
|
|
| |
180 |
GASKET; WATER DUCT
ALSO INCLUDED IN GASKET SET(ENGINE).
|
8-94396-720-1 |
01 |
1 |
9806-9911 |
|
● |
● |
| |
180 |
GASKET; WATER DUCT
ALSO INCLUDED IN GASKET SET(ENGINE).
|
8-94396-720-1 |
01 |
1 |
9912- |
● |
|
|
