Isuzu WW
▶
BUSES
▶
MT
▶
10969 - MT133/FTR(FRAME BUS) RHD
▶
3 - Brakes, Brake System
▶
3-52 - BRAKE PIPING; OIL,FRONT
▶
3-52 — BRAKE PIPING; OIL,FRONT
(#65909) — 49 parça
Tümü
A - MTR5FB
B - FTR5VF
◀
[352A] LEAF SUSPENSION (24 parça)
[352A] BUS CHASSIS (25 parça)
▶
18
24
19
71
6
7
4
3
1
8
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
HOSE; FLEX,FRT BRK
L=610
0-05312-610-0
02
1
0504-0907
●
1
HOSE; FLEX,FRT BRK
L=610
0-05212-610-0
02
1
0908-1411
●
1
HOSE; FLEX,FRT BRK
L=610
0-05212-610-0
02
1
1412-
●
●
3
BOLT; BRKT,FLEX HOSE,FRT BRK
M8X25 FLANGE
0-28680-825-0
04
1
0504-0512
●
3
BOLT; BRKT,FLEX HOSE,FRT BRK
M8X25 FLANGE
0-28650-825-0
04
1
0601-1411
●
3
BOLT; BRKT,FLEX HOSE,FRT BRK
M8X25 FLANGE
0-28650-825-0
04
1
1412-
●
●
4
NUT; FLEX HOSE BRKT,FRT BRK
M8
0-91110-508-0
04
1
0602-
●
6
NUT; FLEX HOSE,FRT BRK
M12
9-09840-280-0
02
1
0504-1411
●
6
NUT; FLEX HOSE,FRT BRK
M12
9-09840-280-0
02
1
1412-
●
●
7
WASHER; LK,FLEX HOSE,FRT BRK
ID=12.2
9-09150-512-0
02
1
0504-0603
●
7
WASHER; LK,FLEX HOSE,FRT BRK
ID=12.2
0-91510-512-0
02
1
0604-1411
●
7
WASHER; LK,FLEX HOSE,FRT BRK
ID=12.2
0-91510-512-0
02
1
1412-
●
●
8
GASKET; FLEX HOSE,FRT BRK
ID=9 OD=17
9-09920-472-0
02
1
0504-1411
●
8
GASKET; FLEX HOSE,FRT BRK
ID=9 OD=17
9-09920-472-0
02
1
1412-
●
●
18
PIPE; OIL,UNION TO FRT FLEX HOSE
(B) L=2712 SERVICED BY L=2900
1-47426-364-0
01
1
1412-
●
18
PIPE; OIL,UNION TO FRT FLEX HOSE
(A) L=1911 SERVICED BY L=2000
1-47428-739-0
01
1
0504-1411
●
18
PIPE; OIL,UNION TO FRT FLEX HOSE
(A) L=1911 SERVICED BY L=2000
1-47428-739-0
01
1
1412-
●
●
19
UNION; OIL PIPE
M12 3WAY
9-09228-906-1
01
1
0504-0607
●
19
UNION; OIL PIPE
M12 3WAY
0-92138-906-0
01
1
0608-1411
●
19
UNION; OIL PIPE
M12 3WAY
0-92138-906-0
01
1
1412-
●
●
24
NUT; UNION,OIL PIPE
M12
9-09840-280-0
01
1
0504-1411
●
24
NUT; UNION,OIL PIPE
M12
9-09840-280-0
01
1
1412-
●
●
71
GROMMET; OIL PIPE
ID=24 OD=30 T=17
9-09956-092-1
02
1
0504-1411
●
71
GROMMET; OIL PIPE
ID=24 OD=30 T=17
9-09956-092-1
02
1
1412-
●
●
18
18
2
3
6
7
1
8
71
24
19
32
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
HOSE; FLEX,FRT BRK
L=610
0-05312-610-0
02
1
0504-0907
●
1
HOSE; FLEX,FRT BRK
L=610
0-05212-610-0
02
1
0908-1411
●
1
HOSE; FLEX,FRT BRK
L=610
0-05212-610-0
02
1
1412-
●
●
2
BRACKET; FLEX HOSE,FRT BRK
1-47476-817-0
02
1
1412-
●
3
BOLT; BRKT,FLEX HOSE,FRT BRK
M8X25 FLANGE
0-28680-825-0
04
1
0504-0512
●
3
BOLT; BRKT,FLEX HOSE,FRT BRK
M8X25 FLANGE
0-28650-825-0
04
1
0601-1411
●
3
BOLT; BRKT,FLEX HOSE,FRT BRK
M8X25 FLANGE
0-28650-825-0
04
1
1412-
●
●
6
NUT; FLEX HOSE,FRT BRK
M12
9-09840-280-0
02
1
0504-1411
●
6
NUT; FLEX HOSE,FRT BRK
M12
9-09840-280-0
02
1
1412-
●
●
7
WASHER; LK,FLEX HOSE,FRT BRK
ID=12.2
9-09150-512-0
02
1
0504-0603
●
7
WASHER; LK,FLEX HOSE,FRT BRK
ID=12.2
0-91510-512-0
02
1
0604-1411
●
7
WASHER; LK,FLEX HOSE,FRT BRK
ID=12.2
0-91510-512-0
02
1
1412-
●
●
8
GASKET; FLEX HOSE,FRT BRK
ID=9 OD=17
9-09920-472-0
02
1
0504-1411
●
8
GASKET; FLEX HOSE,FRT BRK
ID=9 OD=17
9-09920-472-0
02
1
1412-
●
●
18
PIPE; OIL,UNION TO FRT FLEX HOSE
(B) L=2712 SERVICED BY L=2900
1-47426-364-0
01
1
1412-
●
18
PIPE; OIL,UNION TO FRT FLEX HOSE
(A) L=1911 SERVICED BY L=2000
1-47428-739-0
01
1
0504-1411
●
18
PIPE; OIL,UNION TO FRT FLEX HOSE
(A) L=1911 SERVICED BY L=2000
1-47428-739-0
01
1
1412-
●
●
19
UNION; OIL PIPE
M12 3WAY
9-09228-906-1
01
1
0504-0607
●
19
UNION; OIL PIPE
M12 3WAY
0-92138-906-0
01
1
0608-1411
●
19
UNION; OIL PIPE
M12 3WAY
0-92138-906-0
01
1
1412-
●
●
24
NUT; UNION,OIL PIPE
M12
9-09840-280-0
01
1
0504-1411
●
24
NUT; UNION,OIL PIPE
M12
9-09840-280-0
01
1
1412-
●
●
32
PIPE; OIL,AIR MASTER TO UNION
L=1218 SERVICED BY L=1200
1-47426-352-0
01
1
1412-
●
71
GROMMET; OIL PIPE
ID=24 OD=30 T=17
9-09956-092-1
02
1
0504-1411
●
71
GROMMET; OIL PIPE
ID=24 OD=30 T=17
9-09956-092-1
02
1
1412-
●
●
