◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ FVZ ▶ 10707 - FVZ-RHD ▶ 7 - Interior Trim, Emblems / Labels, Seats, Mirrors ▶ 7-10 - CAUTION PLATE AND LABEL ▶
7-10 — CAUTION PLATE AND LABEL (#65184) — 56 parça
çizim 132861
4 4 228 119 1 69 2 6 6 260
BalonParca AdiParca NoAdetTipApplied Date
1 PLATE; CAUTION,SHIFT PATTERN
(A) 		1-85881-639-0 01 1 9601-9702
1 PLATE; CAUTION,SHIFT PATTERN
FULLER RT7608LL M/T(X8P) (A) 		1-85881-639-0 01 1 9703-
1 PLATE; CAUTION,SHIFT PATTERN
(B) 		1-85881-640-0 01 1 9601-9702
1 PLATE; CAUTION,SHIFT PATTERN
FULLER RT7608LL M/T(X8P) (B) 		1-85881-640-0 01 1 9703-
2 LABEL; FUEL CAUTION
FUEL TANK 200L FMCSR(PK6) 		8-94414-353-0 01 1 9601-9604
2 LABEL; FUEL CAUTION
FUEL TANK 200L+200L(NF7) AUSTRALIA EQUIPMENT(RR3) 		8-94414-353-0 01 1 9601-9604
2 LABEL; FUEL CAUTION
FUEL TANK 200L FMCSR(PK6),FUEL TANK 200L+200L FMCSR(TGS) 		8-94414-353-0 01 1 9605-9804
2 LABEL; FUEL CAUTION
FUEL TANK 200L+200L FMCSR(TGS) 		8-94414-353-0 01 1 9605-9804
2 LABEL; FUEL CAUTION
FUEL TANK 200L FMCSR(PK6),FUEL TANK 200L+200L FMCSR(TGS) 		8-97135-605-0 01 1 9805-0004
2 LABEL; FUEL CAUTION
FUEL TANK 200L+200L FMCSR(TGS) 		8-97135-605-0 01 1 9805-0004
4 LABEL; ENG MAINTENANCE
(A) 		1-85889-081-0 01 1 0605-
4 LABEL; ENG MAINTENANCE
(B) 		8-94391-524-0 01 1 0605-
4 LABEL; ENG MAINTENANCE
(A) 		1-85886-788-0 01 1 9601-9705
4 LABEL; ENG MAINTENANCE
EXC. NEW ZEALAND EQUIPMENT(PK5) (A) 		1-85886-788-0 01 1 9706-9810
4 LABEL; ENG MAINTENANCE
6SD1 TCN ENG(31L) EXC. NEW ZEALAND EQUIPMENT(PK5) (A) 		1-85886-788-0 01 1 9811-
4 LABEL; ENG MAINTENANCE
NEW ZEALAND EQUIPMENT(PK5) (A) 		1-85886-864-0 01 1 9706-9810
4 LABEL; ENG MAINTENANCE
6SD1 TCN ENG(31L) NEW ZEALAND EQUIPMENT(PK5) (A) 		1-85886-864-0 01 1 9811-0604
4 LABEL; ENG MAINTENANCE
6SD1 TCN ENG(31L) NEW ZEALAND EQUIPMENT(PK5) EXC. EURO3 SPECIFICATION<NJX> (A) 		1-85886-864-0 01 1 0605-
4 LABEL; ENG MAINTENANCE
6SD1 STD ENG(37L) (A) 		1-85886-789-0 01 1 9811-
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE WHEEL CARRIER FRAME SIDE<P13>,SPARE TIRE CARRIER LIFTING TYPE VAR1<SY8> (A) 		1-53639-004-0 01 1 9601-0004
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE WHEEL CARRIER FRAME SIDE<P13> (A) 		1-53639-004-0 01 1 0005-0708
6 PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE WHEEL CARRIER FRAME SIDE<P13> (B) 		8-98082-437-0 01 1 0709-
69 PLATE; CAUTION,STARTER SW
NEW ZEALAND EQUIPMENT(PK5),AUSTRALIA EQUIPMENT(RR3) 		1-85887-389-0 01 1 9601-0004
69 PLATE; CAUTION,STARTER SW
NEW ZEALAND EQUIPMENT(PK5) 		1-85887-389-0 01 1 0005-0302
69 PLATE; CAUTION,STARTER SW
NEW ZEALAND EQUIPMENT(PK5) EXC. STARTER SWITCH DELETION<E5D> 		1-85887-389-0 01 1 0303-
119 PLATE; CAUTION,HAND BRK LEVER 1-85881-726-0 01 1 9601-9606
119 PLATE; CAUTION,HAND BRK LEVER 1-85881-759-0 01 1 9607-
228 PLATE; CAUTION,AIR DRYER
AIR DRYER<PS7> 		1-48199-325-0 01 1 9805-0004
228 PLATE; CAUTION,AIR DRYER
AIR DRYER<PS7> 		1-85887-935-0 01 1 0005-1001
260 PLATE; CAUTION,HEAD LAMP LEVELING
LIGHTING SYSTEM-JAPANESE STANDARDS<JBZ> 		1-85878-501-1 01 1 0605-
çizim 132949
51 49 51 1 60 109 160
BalonParca AdiParca NoAdetTipApplied Date
1 PLATE; CAUTION,SHIFT PATTERN
(A) 		1-85881-639-0 01 1 9601-9702
1 PLATE; CAUTION,SHIFT PATTERN
FULLER RT7608LL M/T(X8P) (A) 		1-85881-639-0 01 1 9703-
1 PLATE; CAUTION,SHIFT PATTERN
(B) 		1-85881-640-0 01 1 9601-9702
1 PLATE; CAUTION,SHIFT PATTERN
FULLER RT7608LL M/T(X8P) (B) 		1-85881-640-0 01 1 9703-
49 PLATE; CAUTION,FUSE BOX 1-85888-554-2 01 1 9601-9804
49 PLATE; CAUTION,FUSE BOX
A/T<X9D> 		1-85877-557-0 01 1 9805-9806
49 PLATE; CAUTION,FUSE BOX
A/T<X9D> EXC. ELEC OUTLET 12V<TAW> 		1-85877-557-0 01 1 9807-0004
49 PLATE; CAUTION,FUSE BOX
ELEC OUTLET 12V<TAW> 		1-85878-077-0 01 1 9807-0004
49 PLATE; CAUTION,FUSE BOX 1-85878-278-0 01 1 0005-
49 PLATE; CAUTION,FUSE BOX
FULLER M/T<X9B>,ZF M/T<X9E> 		1-85877-623-0 01 1 9805-9806
49 PLATE; CAUTION,FUSE BOX
FULLER M/T<X9B>,ZF M/T<X9E> EXC. ELEC OUTLET 12V<TAW> 		1-85877-623-0 01 1 9807-0004
51 PLATE; CAUTION,WARNING
EURO3 SPECIFICATION<NJX> (B) 		1-85878-472-0 01 1 0605-
51 PLATE; CAUTION,WARNING
(A) 		1-85880-707-1 01 1 9601-
51 PLATE; CAUTION,WARNING
(B) 		1-85888-559-2 01 1 9601-9804
51 PLATE; CAUTION,WARNING
A/T<X9D> (B) 		1-85877-550-0 01 1 9805-0004
51 PLATE; CAUTION,WARNING
(B) 		1-85888-559-2 01 1 0005-0604
51 PLATE; CAUTION,WARNING
EXC. EURO3 SPECIFICATION<NJX> (B) 		1-85888-559-2 01 1 0605-
51 PLATE; CAUTION,WARNING
FULLER M/T<X9B>,ZF M/T<X9E> (B) 		1-85888-559-2 01 1 9805-0004
60 PLATE; CAUTION,CAB TILT 1-85883-169-0 01 1 9601-
109 PLATE; CAUTION,TIRE PLACARD
AUSTRALIA EQUIPMENT(RR3) 		1-85881-744-0 01 1 9601-9603
109 PLATE; CAUTION,TIRE PLACARD
AUSTRALIA EQUIPMENT(RR3) 		1-85881-743-0 01 1 9604-9804
109 PLATE; CAUTION,TIRE PLACARD
AUSTRALIA EQUIPMENT(RR3) 		1-85881-744-1 01 1 9805-0004
160 PLATE; CAUTION,TOWING
ZF 9S109 OD M/T(Y2L) 		1-85888-737-1 01 1 9805-9903
160 PLATE; CAUTION,TOWING
ZF 9S109 OD M/T(Y2L),ZF 9S109 OD M/T SOUTH AFRICA(Y3Y) 		1-85888-737-1 01 1 9904-0004
160 PLATE; CAUTION,TOWING
ZF 9S109 OD M/T(Y2L) 		1-85888-737-1 01 1 0005-1102
160 PLATE; CAUTION,TOWING
ZF 9S109 OD M/T(Y2L),ZF9S1110 M/T(Y5E) 		1-85888-737-1 01 1 1103-
İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
