Isuzu WW
▶
TRUCKS
▶
FXZ
▶
10754 - FXZ(INDONESIA)
▶
1 - Fuel Tank, Cooling, Air Intake, Exhaust System
▶
1-55 - EXHAUST BRAKE VALVE AND CONTROL CYLINDER
▶
1-55 — EXHAUST BRAKE VALVE AND CONTROL CYLINDER
(#64651) — 57 parça
◀
[155A] NO.2 (5 parça)
[155A] NO.1 (52 parça)
▶
42
83
47
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
42
HOSE; FLEX,EXH BRK
L=520
1-09363-589-1
01
1
9704-
47
BOLT; CLIP
M8X20 FLANGE
0-28080-820-0
01
1
9704-0512
47
BOLT; CLIP
M8X20 FLANGE
0-28050-820-0
01
1
0601-
83
CLIP; FLEX HOSE
ID=11 H=20 L=20
5-09700-351-0
01
1
9704-0707
83
CLIP; FLEX HOSE
ID=11 H=20 L=20
8-98033-780-0
01
1
0708-
74
24
111
6
6
6
23
21
20
40
18
17
15
16
7
26
107
6
106
13
35
35
161
133
132
14
35
32
35
25
158
134
37
34
34
133
162
163
10
9
104
105
107
160
30
154
30
159
153
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
6
VALVE; EXH BRAKE
(B)
1-22181-134-0
01
1
9704-0211
6
VALVE; EXH BRAKE
(A)
8-94395-246-2
01
1
9704-0211
6
VALVE; EXH BRAKE
(C)
8-97602-527-1
01
1
0212-
7
CYLINDER ASM; CONT
1-22190-632-0
01
1
9704-0211
9
COVER; CYL
1-22199-070-0
01
1
9704-0211
10
SEAL; DUST,CONT
1-22199-071-0
01
1
9704-0211
13
SPRING; CONT CYL
1-22199-157-0
01
1
9704-9807
13
SPRING; CONT CYL
1-09580-517-0
01
1
9808-0211
14
SHAFT; CONT CYL
1-22199-158-0
01
1
9704-0211
15
PLATE; CONT CYL
1-22199-156-0
01
1
9704-0211
16
RING; WEAR,CONT CYL
1-22189-161-0
01
1
9704-0211
17
GASKET; CONT CYL
1-22199-103-0
01
1
9704-0211
18
RETAINER; CONT CYL
9-88510-324-0
01
1
9704-0211
20
NUT; CONT CYL
9-83315-085-0
01
1
9704-0211
21
GASKET; COVER
1-22199-072-0
01
1
9704-0211
23
COVER; CONT CYL
1-22199-066-0
01
1
9704-0211
24
BOLT; COVER
1-22199-155-0
02
1
9704-0211
25
BOLT; CONT CYL
M10X60
9-01056-060-0
02
1
9704-9807
25
BOLT; CONT CYL
M10X60 FLANGE
0-28081-060-0
02
1
9808-0211
26
WASHER; LK,CONT CYL
ID=10.2
9-09150-510-0
02
1
9704-9807
30
ROD; LINK,CONT CYL
1-22199-124-0
02
1
9704-0211
32
WASHER; LK
ID=8.4 OD=18
9-09164-608-0
01
1
9704-9807
34
RING; SEAL
(A) ID=15
8-94397-184-0
02
1
9704-0211
34
RING; SEAL
(B) ID=13.7
9-22189-124-0
02
1
9704-0211
35
BOLT; PLATE FIX
(C) M8X16 W/LK WASHER
0-50040-816-0
05
1
9704-9807
35
BOLT; PLATE FIX
(C) M8X16 W/LK WASHER
0-50040-816-0
02
1
9808-0211
35
BOLT; PLATE FIX
(A) M10X20
9-02051-020-0
01
1
9704-9807
35
BOLT; PLATE FIX
(D)
1-22199-174-0
02
1
9808-0211
35
BOLT; PLATE FIX
(A) M10X20
0-28021-020-0
01
1
9808-0211
35
BOLT; PLATE FIX
(B)
1-22199-188-0
01
1
9808-0211
37
COVER; BODY
1-22189-274-0
01
1
9704-9807
37
COVER; BODY
1-22189-327-0
01
1
9808-0211
40
WASHER; LK,COVER
ID=8.2
9-09150-508-0
01
1
9704-0211
74
CONNECTOR; EXH BRK VLV
M12 & PT1/4 ELBOW
1-09650-430-0
01
1
0212-
104
RING; RET
9-88510-331-0
01
1
9704-0211
105
FILTER; CONT CYL
9-88510-330-0
01
1
9704-0211
106
BRACKET; CONT CYL
8-94395-578-0
01
1
9704-0211
107
NUT; CONT CYL
(B)
9-83315-080-0
02
1
9704-9807
107
NUT; CONT CYL
(B) M10 FLANGE
0-91150-110-0
02
1
9808-0211
107
NUT; CONT CYL
(A)
9-83315-085-0
01
1
9704-0211
111
ELBOW; CONT CYL
1-09650-358-1
01
1
9704-0211
132
LEVER; BRK VLV
1-22196-342-0
01
1
9704-0211
133
NUT; LK
M8 FLANGE
0-91150-108-0
03
1
9704-0211
134
BOLT; STOPPER
M8X30
1-09000-112-1
02
1
9704-0211
153
BOLT; CLEVIS,CONT CYL
1-33739-200-0
02
1
9704-0211
154
NUT; CLEVIS,CONT CYL
M8 FLANGE
0-91150-108-0
02
1
9704-0211
158
GASKET; COVER
1-22189-286-0
01
1
9704-0211
159
COLLAR; CONT CYL
1-22199-138-0
02
1
9704-0211
160
JOINT; CONT CYL
1-22199-137-0
01
1
9704-0211
161
PROTECTOR; CONT CYL
1-22199-146-0
01
1
9704-0211
162
GUIDE; CONT CYL
1-22199-147-0
01
1
9704-0211
163
WASHER; CONT CYL
1-22199-148-0
01
1
9704-0211
