Isuzu WW
▶
TRUCKS
▶
FSR
▶
10700 - FSR32,33(RHD)
▶
3 - Brakes, Brake System
▶
3-08B - PARKING BRAKE
▶
3-08B — PARKING BRAKE
(#64258) — 13 parça
15
79
10
11
8
12
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
8
FLANGE; PARKING BRK
1-37245-095-0
01
1
9510-0004
8
FLANGE; PARKING BRK
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
1-37245-095-0
01
1
0005-
10
PLATE; LOCK
1-37249-021-0
01
1
9510-0004
10
PLATE; LOCK
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A)
1-37249-021-0
01
1
0005-
11
BOLT; FLANGE FIX
M14X44.5
1-09087-014-0
01
1
9510-0004
11
BOLT; FLANGE FIX
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A) M14X44.5
1-09087-014-0
01
1
0005-
12
BOLT; FIX
M6X14 W/LK WASHER
0-50040-614-0
01
1
9510-0004
12
BOLT; FIX
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A) M6X14 W/LK WASHER
0-50040-614-0
01
1
0005-0906
12
BOLT; FIX
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A) M6X14 W/LK WASHER
0-50540-614-0
01
1
0907-
15
BOLT; FLANGE
M14X46
9-46219-012-0
04
1
9510-0004
15
BOLT; FLANGE
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A) M14X46
9-46219-012-0
04
1
0005-
79
WASHER; FLANGE
ID=14.5 OD=56.426
1-09503-078-0
01
1
9510-0004
79
WASHER; FLANGE
REAR WHEEL PARKING BRAKE AIR CONTROL(B3A) ID=14.5 OD=56.426
1-09503-078-0
01
1
0005-
