Isuzu WW
▶
TRUCKS
▶
EXZ
▶
10806 - EXZ RHD FUEL TANK 400L
▶
2 - Clutch, Transmission, Trans Axle
▶
2-25A - SPEEDOMETER DRIVEN GEAR
▶
2-25A — SPEEDOMETER DRIVEN GEAR
(#6285) — 14 parça
10
2
3
1
13
32
33
57
19
35
18
33
57
34
32
32
33
57
19
35
27
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
GEAR; DRIVEN,SPD
Z=15
1-33372-147-4
01
1
9906-
2
BUSHING; DRIVEN GEAR,SPEEDOMETER
1-33373-077-0
01
1
9906-
3
GASKET; BUSHING
ALSO INCLUDED IN GASKET SET(M/T).
1-09623-246-0
01
1
9906-
10
SEAL; OIL,DRIVE GEAR
ALSO INCLUDED IN GASKET SET(M/T). NOK
1-09625-510-0
01
1
9906-
13
SCREW; BUSHING,DRIVEN GEAR
M6X12.5 FLANGE
1-09044-063-0
01
1
9906-
18
BOLT; CLU HSG TO TRANS
M16X50 W/LK&PL WASHER
0-50151-650-0
06
1
9906-
19
WASHER; PL,CLU HSG TO TRANS
ID=17
9-09160-516-0
02
1
9906-
27
NUT; CLU HSG TO TRANS
M16
9-99110-516-0
02
1
9906-
32
BOLT; CLU HSG TO FLYWHEEL HSG
(A) M12X60
0-28181-260-0
08
1
9906-
32
BOLT; CLU HSG TO FLYWHEEL HSG
(B) M10X16,M12X67 L=91
1-09029-043-1
04
1
9906-
33
WASHER; LK,CLU HSG
ID=12.2
9-09150-612-0
04
1
9906-
34
STUD; CLU HSG
M16X45 L=69
9-04411-645-0
02
1
9906-
35
WASHER; LK,CLU HSG TO TRANS
ID=16.2
9-09150-516-0
02
1
9906-
57
WASHER; PL,CLU HSG
ID=12.5
9-09164-512-0
04
1
9906-
