◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ EXY ▶ 10805 - EXY RHD ▶ 7 - Interior Trim, Emblems / Labels, Seats, Mirrors ▶ 7-01 - EMBLEM AND NAME PLATE ▶

7-01 — EMBLEM AND NAME PLATE (#6188) — 19 parça

70 4 75 137 245 174 211

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
4	EMBLEM; RAD GRILLE	1-76210-668-2	01	1	9905-0006
4	EMBLEM; RAD GRILLE AUSTRALIA EQUIPMENT(RR3) EXC. METER PANEL GRAIN OF WOOD<NAY>	1-76210-668-2	01	1	0007-0301
4	EMBLEM; RAD GRILLE EXC. AUSTRALIA EQUIPMENT(RR3)	1-76210-668-2	01	1	0007-0301
4	EMBLEM; RAD GRILLE EXC. METER PANEL GRAIN OF WOOD<NAY>	1-76210-668-3	01	1	0302-
4	EMBLEM; RAD GRILLE METER PANEL GRAIN OF WOOD<NAY> AUSTRALIA EQUIPMENT(RR3)	1-76210-669-2	01	1	0007-0301
4	EMBLEM; RAD GRILLE METER PANEL GRAIN OF WOOD<NAY>	1-76210-669-3	01	1	0302-
70	DECAL; INTERCOOLER	1-76218-114-0	01	1	9905-0104
70	DECAL; INTERCOOLER EXC. AUSTRALIA EQUIPMENT(RR3)	1-76218-114-0	01	1	0105-0301
75	DECAL; FRT CORNER METER PANEL GRAIN OF WOOD<NAY> AUSTRALIA EQUIPMENT(RR3)	1-76210-640-2	01	1	0007-0301
75	DECAL; FRT CORNER METER PANEL GRAIN OF WOOD<NAY>	1-76210-640-3	01	1	0302-
137	DECAL; DOOR BLACK	1-74998-049-3	01	1	9905-
137	DECAL; DOOR BLACK	1-74998-048-3	01	1	9905-
174	EMBLEM; FRT PANEL METER PANEL GRAIN OF WOOD<NAY> AUSTRALIA EQUIPMENT(RR3)	1-76210-641-1	01	1	0007-0301
174	EMBLEM; FRT PANEL METER PANEL GRAIN OF WOOD<NAY>	1-76210-641-2	01	1	0302-
211	DECAL; "GIGA" AUSTRALIA EQUIPMENT(RR3)	1-76230-424-0	03	1	0007-0301
211	DECAL; "GIGA"	1-76230-424-0	03	1	0302-
245	DECAL; MODEL	1-76217-152-0	01	1	9905-0104
245	DECAL; MODEL EXC. AUSTRALIA EQUIPMENT(RR3)	1-76217-152-0	01	1	0105-0301

202 202

	Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
	202	DECAL; METER CLUSTER METER PANEL GRAIN OF WOOD<NAY>	1-72418-016-1	01	1	9905-
