4-12 — FRONT DRIVE SHAFT (#61258) — 50 parça

70 57 62 58 73 60 75 62 71 71 73 59 61 74 77 64 122 76 81 12 80 69 66 65 37 63 51 50 108 74 100 52 49 77 52 84 83 18 50 51 69 12 53 52 62 65 55 55 55 78 55 55 54 66 57 61 79 79 63 59 64 60 58 54 55 62 53 48

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
12	JOINT ASM LOCKING HUB FRT WHEEL DRIVE(W12)	1-43330-012-0	02	1	1112-
12	JOINT ASM EXC. LOCKING HUB FRT WHEEL DRIVE(W12)	1-43330-018-0	02	1	1112-
18	CASE; FRT AXLE	8-98200-146-0	01	1	1112-
37	BREATHER; FRT AXLE CASE	9-36122-015-1	01	1	1112-
48	PLUG; DRAIN,AXLE CASE M24X17 FLANGE	1-09604-023-0	01	1	1112-
49	GASKET; DRAIN PLUG ID=26.8	9-09920-605-0	01	1	1112-
50	SEAL; OIL,SHAFT,FRT AXLE	1-09625-192-0	02	1	1112-
51	GUIDE; OIL,FRT AXLE	9-43339-003-0	02	1	1112-
52	SEAL; OIL,KNUCKLE	1-09625-004-0	02	1	1112-
53	BOLT; OIL SEAL M8X12 FLANGE	0-28050-812-0	20	1	1112-
53	BOLT; OIL SEAL M8X16 FLANGE	0-28050-816-0	04	1	1112-
54	GASKET; OIL SEAL (A)	1-09625-241-0	02	1	1112-
54	GASKET; OIL SEAL (B)	1-09625-242-0	02	1	1112-
55	RING; OIL SEAL (A)	1-09625-243-0	04	1	1112-
55	RING; OIL SEAL (B)	1-09625-244-0	04	1	1112-
55	RING; OIL SEAL (C)	1-09625-245-0	04	1	1112-
57	COVER; FLANGE,FRT AXLE SHAFT EXC. LOCKING HUB FRT WHEEL DRIVE(W12)	9-42313-116-0	02	1	1112-
58	FLANGE; AXLE SHAFT,FRT EXC. LOCKING HUB FRT WHEEL DRIVE(W12)	1-42312-028-0	02	1	1112-
59	BOLT; FLANGE,FRT AXLE SHAFT EXC. LOCKING HUB FRT WHEEL DRIVE(W12) M12X45	9-09804-239-1	20	1	1112-
60	GASKET; FLANGE,FRT AXLE SHAFT EXC. LOCKING HUB FRT WHEEL DRIVE(W12)	1-42175-001-0	02	1	1112-
61	PLATE; LK,FLANGE EXC. LOCKING HUB FRT WHEEL DRIVE(W12)	1-43319-005-0	08	1	1112-
62	RING; SNAP,AXLE SHAFT ID=38.5 T=2.00	9-09952-253-0	02	1	1112-
63	SPINDLE; KNUCKLE,FRT AXLE SHAFT	1-43241-061-0	02	1	1112-
64	BOLT; SPINDLE M12X30 FLANGE	0-28061-230-0	08	1	1112-
64	BOLT; SPINDLE M12X45 FLANGE	0-28061-245-0	16	1	1112-
65	GASKET; KNUCKLE TO SPINDLE	9-43254-005-0	02	1	1112-
66	BUSHING; SPINDLE,FRT AXLE SHAFT	1-43321-011-0	02	1	1112-
69	SHAFT; AXLE,FRT INNER	1-43311-063-0	01	1	1112-
69	SHAFT; AXLE,FRT INNER	1-43311-064-0	01	1	1112-
70	ABSORBER ASM; SHOCK,SHIMMY	1-51630-207-0	01	1	1112-
71	BUSHING; RUB,LWR,FRT S/ABS	9-51631-037-0	02	1	1112-
73	WASHER; LWR,FRT S/ABS (A)	9-51679-010-0	01	1	1112-
73	WASHER; LWR,FRT S/ABS (B)	9-51679-011-0	01	1	1112-
74	NUT; S/ABS (A) M16	0-91110-516-0	01	1	1112-
74	NUT; S/ABS (B) M12	0-91116-512-0	01	1	1112-
75	PIN; SPLIT,S/ABS OD=2.8 L=20	0-81123-020-0	01	1	1112-
76	NUT; LWR,FRT S/ABS	9-51631-083-0	01	1	1112-
77	WASHER; LK,S/ABS (A) ID=12.2	0-91510-512-0	01	1	1112-
77	WASHER; LK,S/ABS (B) ID=16.2	0-91510-516-0	01	1	1112-
78	BRACKET; SHIMMY DAMPER	1-43219-017-0	01	1	1112-
79	BOLT; BRKT (A) M12X20 FLANGE	0-28051-220-0	02	1	1112-
79	BOLT; BRKT (B) M12X25 FLANGE	0-28051-225-0	02	1	1112-
80	NIPPLE; GREASE,BRKT PT1/8 ELBOW 67.5 DEGREES	0-90301-510-0	01	1	1112-
81	PIN; SHIMMY DAMPER	1-43219-018-0	01	1	1112-
83	PLUG; OIL FILLER M24X17 FLANGE	1-09604-022-0	01	1	1112-
84	GASKET; PLUG,OIL FILLER ID=26.8	9-09920-605-0	01	1	1112-
100	WASHER; LK,FRT FINAL DRIVE ID=12.2	0-91510-812-0	12	1	1112-
108	BOLT; FRT FINAL DRIVE M12X35	0-20951-235-0	08	1	1112-
108	BOLT; FRT FINAL DRIVE M12X45	9-92061-245-0	04	1	1112-
122	WASHER; S/ABS ID=17 OD=30	0-91610-516-0	01	1	1112-
