7-70 — SEPARATER AND BED (#60382) — 49 parça

64 51 51 44 92 44 92

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
44	CURTAIN ASM; CABIN CENTER (A) BLUE	8-97407-947-1	01	1	0906-
44	CURTAIN ASM; CABIN CENTER (B) BLUE	8-97407-948-1	01	1	0906-
51	CURTAIN; BACK (A) BLUE	8-97407-758-1	01	1	0906-
51	CURTAIN; BACK (B) BLUE	8-97407-759-1	01	1	0906-
64	CURTAIN KIT	8-97415-695-0	01	1	0906-
92	CURTAIN ASM; ROUND (A) BLUE	8-97415-698-0	01	1	0906-
92	CURTAIN ASM; ROUND (B) BLUE	8-97415-701-0	01	1	0906-

48 42 84 41 85 45 42 50 42 84 41 50 47 47 85 41 45 47 50 42 41 45 47 58 59 130 73 73 84 50 47

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
41	HOOK; CURTAIN RAIL H=14.5 WHITE	1-73996-398-0	32	1	1006-
41	HOOK; CURTAIN RAIL H=14.5 WHITE	1-73996-398-0	56	1	0906-1005
41	HOOK; CURTAIN RAIL H=14.5 WHITE	1-73996-398-0	24	1	1006-
42	STOPPER; CURTAIN RAIL (A) LIGHT GRAY	8-97408-038-0	02	1	1006-
42	STOPPER; CURTAIN RAIL (A) LIGHT GRAY	8-97408-038-0	03	1	0906-1005
42	STOPPER; CURTAIN RAIL (A) LIGHT GRAY	8-97408-038-0	01	1	1006-
42	STOPPER; CURTAIN RAIL (B) DARK GRAY	8-97407-972-2	01	1	0906-
42	STOPPER; CURTAIN RAIL (B) DARK GRAY	8-97407-499-2	01	1	0906-
45	RAIL; CURTAIN,FRT (A) DARK GRAY	8-97407-488-1	01	1	0906-
45	RAIL; CURTAIN,FRT (B) LIGHT GRAY	8-97415-680-0	01	1	0906-
45	RAIL; CURTAIN,FRT (B) LIGHT GRAY	8-97415-679-0	01	1	0906-
47	SCREW; CURTAIN RAIL M5X20	5-09981-059-0	06	1	0906-1005
47	SCREW; CURTAIN RAIL M5X20	5-09981-059-0	06	1	1006-
47	SCREW; CURTAIN RAIL ROUND CURTAIN RAIL<EDH> M5X20	5-09981-059-0	06	1	1006-
47	SCREW; CURTAIN RAIL ROUND CURTAIN RAIL<EDH> M5X20	5-09981-059-0	14	1	0906-1005
47	SCREW; CURTAIN RAIL ROUND CURTAIN RAIL<EDH> M5X20	5-09981-059-0	08	1	1006-
48	RAIL; CURTAIN,BACK DARK GRAY	8-97407-490-2	01	1	0906-
50	GROMMET; SCREW,CURTAIN RAIL EXC. ROUND CURTAIN RAIL<EDH> D=8.6X7.7 L=7.5	8-94279-078-0	04	1	1406-
50	GROMMET; SCREW,CURTAIN RAIL D=8.6X7.7 L=7.5	8-94279-078-0	12	1	0906-1005
50	GROMMET; SCREW,CURTAIN RAIL D=8.6X7.7 L=7.5	8-94279-078-0	06	1	1006-1405
50	GROMMET; SCREW,CURTAIN RAIL D=8.6X7.7 L=7.5	8-94279-078-0	06	1	1006-1405
50	GROMMET; SCREW,CURTAIN RAIL ROUND CURTAIN RAIL<EDH> D=8.6X7.7 L=7.5	8-94279-078-0	06	1	1006-1405
50	GROMMET; SCREW,CURTAIN RAIL D=8.6X7.7 L=7.5	8-94279-078-0	06	1	1406-
50	GROMMET; SCREW,CURTAIN RAIL ROUND CURTAIN RAIL<EDH> D=8.6X7.7 L=7.5	8-94279-078-0	06	1	1406-
50	GROMMET; SCREW,CURTAIN RAIL ROUND CURTAIN RAIL<EDH> D=8.6X7.7 L=7.5	8-94279-078-0	14	1	0906-1005
50	GROMMET; SCREW,CURTAIN RAIL ROUND CURTAIN RAIL<EDH> D=8.6X7.7 L=7.5	8-94279-078-0	08	1	1006-1405
50	GROMMET; SCREW,CURTAIN RAIL ROUND CURTAIN RAIL<EDH> D=8.6X7.7 L=7.5	8-94279-078-0	14	1	1406-
58	BED; MAT MATTRESS SLEEPER CAB<E40> SEAT CLOTH<7FL> DARK GRAY	8-97407-384-2	01	1	1001-
58	BED; MAT MATTRESS SLEEPER CAB<E40> DARK GRAY	8-97409-894-1	01	1	0906-0912
58	BED; MAT VINYL SEAT<A83> MATTRESS SLEEPER CAB<E40> DARK GRAY	8-97409-894-1	01	1	1001-
59	COVER ASM; TRIM,BED MAT MATTRESS SLEEPER CAB<E40> SEAT CLOTH<7FL> DARK GRAY	8-97412-043-1	01	1	1001-
59	COVER ASM; TRIM,BED MAT MATTRESS SLEEPER CAB<E40> DARK GRAY	8-97414-135-0	01	1	0906-0912
59	COVER ASM; TRIM,BED MAT VINYL SEAT<A83> MATTRESS SLEEPER CAB<E40> DARK GRAY	8-97414-135-0	01	1	1001-
73	BOLT; GUARD PIPE MATTRESS SLEEPER CAB<E40> M8X20 FLANGE	0-28450-820-0	04	1	0906-
84	BRACKET; CURTAIN RAIL (A)	8-98028-326-1	02	1	0906-1405
84	BRACKET; CURTAIN RAIL ROUND CURTAIN RAIL<EDH> (A)	8-98028-326-1	02	1	1406-
84	BRACKET; CURTAIN RAIL (B)	8-98042-152-0	04	1	0906-
85	SCREW; BRKT EXC. ROUND CURTAIN RAIL<EDH> M5X20	5-09981-059-0	04	1	1406-
85	SCREW; BRKT EXC. HEADER CONSOLE DRIVER & PASSENGER<EDG> M6X12 FLANGE	8-97108-669-0	02	1	1102-
85	SCREW; BRKT M5X20	5-09981-059-0	06	1	0906-1405
85	SCREW; BRKT ROUND CURTAIN RAIL<EDH> M5X20	5-09981-059-0	06	1	1406-
130	PIPE; GUARD,BED MATTRESS SLEEPER CAB<E40>	8-98014-968-0	01	1	0906-
