7-70 — SEPARATER AND BED (#59534) — 22 parça

44 44

	Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
	44	CURTAIN ASM; CABIN CENTER CURTAIN SLEEPER COMPARTMENT<E25>	1-73908-207-1	01	1	0411-
	44	CURTAIN ASM; CABIN CENTER CURTAIN SLEEPER COMPARTMENT<E25>	1-73908-208-1	01	1	0411-

84 85 86 86 50 84 85 42 50 84 48 42 85 86 47 50 41 45 101 42 50 42 47 47 50 42 47 45 101 42 40 42 40 47 58 59

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
40	RAIL; CURTAIN,SIDE	1-73996-380-1	01	1	0411-
40	RAIL; CURTAIN,SIDE	1-73996-379-0	01	1	0411-
41	HOOK; CURTAIN RAIL CURTAIN SLEEPER COMPARTMENT<E25> H=14.5 WHITE	1-73996-398-0	14	1	0411-
42	STOPPER; CURTAIN RAIL (C)	1-73907-657-0	02	1	0411-
42	STOPPER; CURTAIN RAIL (A)	1-73996-393-0	02	1	0411-
42	STOPPER; CURTAIN RAIL (B)	1-73996-399-0	01	1	0411-
45	RAIL; CURTAIN,FRT CURTAIN SLEEPER COMPARTMENT<E25> (A)	1-73908-374-2	01	1	0411-
45	RAIL; CURTAIN,FRT EXC. CURTAIN SLEEPER COMPARTMENT<E25> (B)	1-73908-373-1	01	1	0411-
47	SCREW; CURTAIN RAIL (B) M5X20	5-09981-059-0	17	1	0411-
47	SCREW; CURTAIN RAIL (A) M5X25	5-09981-093-0	07	1	0411-
48	RAIL; CURTAIN,BACK	1-73996-385-1	01	1	0411-
50	GROMMET; SCREW,CURTAIN RAIL (B) D=8X8 L=13 M5	1-09983-159-0	07	1	0411-
50	GROMMET; SCREW,CURTAIN RAIL (A) D=8.6X7.7 L=7.5	8-94279-078-0	17	1	0411-
58	BED; MAT MATTRESS SLEEPER CAB<E40>	1-75116-522-1	01	1	0411-
59	COVER ASM; TRIM,BED MAT MATTRESS SLEEPER CAB<E40>	1-75116-669-1	01	1	0411-
84	BRACKET; CURTAIN RAIL (A)	1-73998-986-2	02	1	0411-
84	BRACKET; CURTAIN RAIL (B)	1-73998-987-4	07	1	0411-
85	SCREW; BRKT M5X20	5-09981-059-0	09	1	0411-
86	GROMMET; SCREW,BRKT D=8.6X7.7 L=7.5	8-94279-078-0	09	1	0411-
101	SCREW; STOPPER	1-73907-400-0	02	1	0411-
