7-60 — SEAT BELT (#59280) — 18 parça

163 2 3

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
2	BELT; SEAT,TONGUE SIDE AIR BAG DRIVER(AJ3) GRAY	8-97407-771-5	01	1	0906-1209
2	BELT; SEAT,TONGUE SIDE AIR BAG DRIVER(AJ3) GRAY	8-97423-521-2	01	1	1210-1407
2	BELT; SEAT,TONGUE SIDE AIR BAG DRIVER(AJ3) GRAY	8-97428-394-0	01	1	1408-
2	BELT; SEAT,TONGUE SIDE EXC. AIR BAG DRIVER(AJ3) GRAY	8-97407-770-4	01	1	0906-1209
2	BELT; SEAT,TONGUE SIDE EXC. AIR BAG DRIVER(AJ3) GRAY	8-97423-516-1	01	1	1210-1407
2	BELT; SEAT,TONGUE SIDE EXC. AIR BAG DRIVER(AJ3) GRAY	8-97428-435-0	01	1	1408-
3	BELT; SEAT,BUCKLE SIDE GRAY	8-97407-374-2	01	1	0906-
163	COVER; ADJUSTER GRAY	8-97405-991-0	01	1	0906-

169 160 170 4 160 6 170 5

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
4	BELT; PASSENGER SEAT,BUCKLE SIDE CENTER SEAT DELETE<SP9> GRAY	8-97407-376-1	01	1	0906-1310
4	BELT; PASSENGER SEAT,BUCKLE SIDE EXC. SEAT ASM - WITH CENTER SEAT<7BC> GRAY	8-97407-376-1	01	1	1311-
5	BELT; CENTER SEAT,BUCKLE SIDE SEAT ASM - WITH CENTER SEAT<7BC> GRAY	8-97407-377-1	01	1	0906-
6	BELT; CENTER SEAT,TONGUE SIDE SEAT ASM - WITH CENTER SEAT<7BC> GRAY	8-97409-768-3	01	1	0906-1209
6	BELT; CENTER SEAT,TONGUE SIDE SEAT ASM - WITH CENTER SEAT<7BC> GRAY	8-97423-515-1	01	1	1210-
160	COVER; THROUGH ANCHOR GRAY	8-97405-991-0	01	1	0906-
169	SEAL CENTER SEAT DELETE<SP9> OD=25 BLACK	1-76798-019-0	01	1	0906-
170	BELT; PASSENGER SEAT,TONGUE SIDE GRAY	8-97407-770-4	01	1	0906-1209
170	BELT; PASSENGER SEAT,TONGUE SIDE GRAY	8-97423-516-1	01	1	1210-1407
170	BELT; PASSENGER SEAT,TONGUE SIDE GRAY	8-97428-435-0	01	1	1408-

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
